Introduction 2
Introduction
BeoLab Transmitter 1 is a stand-alone box, that enables existing music systems and TVs to connect wirelessly - within one room - to any Bang &
Olufsen wireless speaker and BeoLab Receiver 1.
BeoLab Transmitter 1 works in the wireless 5 GHz U-NII band frequency spectrum. It is compliant with and will only work with all new Bang &
Olufsen WiSA approved speakers and speakers connected to the BeoLab Receiver 1.
The WiSA technology offers multi-channel wireless sound performance for full surround sound setup. The benets for the Bang & Olufsen
customer are:
- Eliminates cable clutter.
- Offers complete exibility when decorating your room.
- Is an easy add-on to an existing wired setup.
- Delivers high-quality wireless surround sound.
- Offers easy 3rd party integration: mix and match your favourite audio and video components.
The BeoLab Transmitter 1 has four RJ45 inputs with Power Link / Line-in connection which have both a left and right sound channel. This means
you can connect as much as 8 sound channels as input of which one can be a subwoofer in the room. In addition there is an optical stereo
TOSLINK TM input (S/P-DIF) and two RCA (Line-in) for connection stereo sound channels of an audio system.
Despite this the wireless technology used makes it possible to congure up to 11 wireless speakers to the sound channels as desired. One scenario
may be a 7.4 setup.
One switch is used to shift between a Bang & Olufsen Power Link signal in and a line-in signal from a 3rd party product (B&O INPUT YES/NO).
Another switch is used for providing either a pure stereo output in two sound channels only (SUB 2.1 set to OFF) or providing the two stereo sound
channels plus a third sound channel provided by the built in bass management function for the conguration of a wireless subwoofer (SUB 2.1 set
to ON).
Active sources are prioritised in the following order: 1) POWER LINK; 2) TOSLINK; 3) Line-in (via RCA connectors or RJ45 connector).
With the BeoLab Transmitter 1 comes a cable cover for optimised cable management. The BeoLab Transmitter 1 is clicked onto the cable cover and
can be mounted on the wall with the cables directed either up/down or sideways in any direction that is convenient for an elegant installation. The
cable cover becomes an inherent part of the BeoLab Transmitter 1 and lets the solution stand out as one entity.
In a stereo setup, the speakers and the subwoofer must be connected wirelessly.
In a surround sound setup, you can combine wired and wireless speakers as you like.
When the BeoLab 19 has wireless connection the LP FILTER switch is set to OFF. This ensures that the BeoLab 19 emits the frequency pattern sent
to the speaker and also makes the noise pattern audible when conguring the speaker setup.
How to use this installation guide 3
How to use this installation guide
This installation guide gives step by step instructions on how to:
- Mount the product,
- Understand placement rules,
- Connecting and setting up BeoLab Transmitter 1 with products and speakers,
- Use push buttons and understand LED indications,
- Use the ServiceTool and make SW update,
- Understand channel patterns and use worldwide.
Warning
Installation and replacement of parts must be made by Bang & Olufsen
certied installers only.
Navigation in this guide
When the guide is opened, it automatically opens in Full Screen Mode (can be
left as desired - see below). This is primarily done to optimise the usability of
screen reading. There are several ways to navigate when using the guide, see
the survey of keys, shortcuts and hot keys below:
/ (arrow keys on the keyboard) navigates to the next page
/ (arrow keys on the keyboard) navigates to the previous page
Esc (Esc button ) exits Full Screen Mode (press Ctrl + L to return to
Full Screen Mode).
Another feature to optimise the navigation is the navigation icons at the
bottom of the screen (see below for explanation).
Navigates you to the previous view
Navigates you directly to the start page
Navigates directly to the table of contents (these are active links
- click the link to be directed directly to the associated section)
Prints the document - the print dialogue box opens (Ctrl + P also
brings up this feature)
Navigation TIP
The right side of this page and the Table of Contents, page 30, acts as an active table of contents. Simply click the subject you want and you are
transferred to the section in question.
Introduction
Connecting source system to BeoLab Transmitter 1
Placement of BeoLab Transmitter 1
LED indications
Site survey (Wi-Spy)
Use of USB memory stick
IR-eye - 3rd party product remote control
Always On
Line-in settings and log les
Use of ServiceTool
How to use this installation guide
Setting up and connecting BeoLab Transmitter 1
Push button functions
Combination of Channel pattern and product type No.
Distance between 5 GHz transmitters
Connection specications
BeoLab Transmitter 1 front
BeoLab Transmitter 1 connection panel (rear side)
Demount from wall mounting
Mounting
BeoLab Transmitter 1 front - connection panel 4
BeoLab Transmitter 1 front
The Product Status LED is placed in the front, middle of the BeoLab Transmitter 1; see page 18.
BeoLab Transmitter 1 connection panel (rear side)
The WIRELESS LED is placed in the rear side above the push buttons of the BeoLab Transmitter 1; see LED indications page 18.
The Power Link connectors are used to connect to the source signals.
Above each Power Link input connector two LEDs are placed to give indications regarding the sound channels established to the wireless speakers.
The white LED gives indications regarding the left (L) channel and the red LED gives indications regarding the right (R) channel; see LED indications
page 18.
The Wireless Power Link antennas are placed in the lid (top) of the BeoLab Transmitter 1, and due to the PCBs placed below this, the signal
strength is somewhat attenuated on the backside of the BeoLab Transmitter 1.
It is recommended to place the BeoLab Transmitter 1, so it is not hidden, and it must never be placed behind the TV as the metal parts will prevent
the wireless signals to reach the speakers.
The push buttons can be activated as follows; see also description of push button functions page 17:
- short press ≤1.5 s
- long press ≥ 1.5 s and ≤10 s (often conrmed when the LED turns solid)
- very long press ≥ 10 s
100 - 240V 50/60Hz
Mounting 5
Mounting
The BeoLab Transmitter 1 can be mounted in various ways:
- On a shelf or similar horizontal surface.
- Wall mounted.
Note: Product Status LED on front of BeoLab Transmitter 1, and WIRELESS LED on the rear side.
Wall mounting
The BeoLab Transmitter 1 can be mounted on a wall by using the cable cover as wall bracket.
Two screws are placed with a distance of 260 mm/ 10.6”.
See also the setting-up guide enclosed in the packaging for the BeoLab Transmitter 1.
The BeoLab Transmitter 1 can be placed vertically or horizontally. The cable cover is naturally used for organizing the cables.
See example in the below illustrations. (The holes for mounting shown are placed on the back side of the BeoLab Transmitter 1).
Demount from wall mounting
The BeoLab Transmitter 1 is demounted from the cable cover by releasing the two snap-locks , followed by moving the transmitter away from
the cable cover .
Placement of the Beolab Transmitter 1 6
Placement of BeoLab Transmitter 1
The BeoLab Transmitter 1 has an
omnidirectional transmission
characteristic, although this can not
be an ideal sphere.
The transmitter and the receivers of
the loudspeakers must have line-of-
sight.
The transmitter and the speakers are
placed inside an area that is
recommended to have the maximum
measurements of 9 × 9m / 30 ×
30ft.
The distance between the BeoLab
Transmitter 1 and any receiver must
not exceed 12 m / 40 ft.
Ideally there must be placed no
objects between the BeoLab
Transmitter 1 and the speakers -
especially not objects consisting of
material that will block or totally
reect the wireless signals.
Setting listening distance to speakers
In most TVs the listening distance to
each speaker can be set to obtain
true-time listening from all speakers.
If the speaker setup consists of a
mixture of wired and wireless
connected speakers, the distance to
the wireless speakers must be added
6 ms (milliseconds) matching 2 m /
6.7 ft to the actual distance between
the listening position and each
speaker connected wirelessly due to the sound delay handling.
Alternatively the time or distance can be subtracted from the wired speaker setup.
9 m / 30 ft
9 m / 30 ft
maximum 12 m / 40 ft
Connecting source systems to BeoLab Transmitter 1 7
Connecting source system to BeoLab Transmitter 1
Bang & Olufsen product - Power Link
Connect Bang & Olufsen products to the BeoLab Transmitter 1 using Power Link cables. See more examples page 14.
B&O INPUT
Remember to set the B&O INPUT switch to YES.
SUB 2.1
With Bang & Olufsen video sources set the SUB 2.1 switch to OFF.
With a stereo only signal as input and a wireless subwoofer available,
set the SUB 2.1 switch to ON. The bass management function of the
BeoLab Transmitter 1 provides the subwoofer signal to a wireless subwoofer
indicated as the third sound channel (PL 2 L).
The cut-off frequency for the Bass management is 120Hz.
See the guide for BeoLab Transmitter 1 for variety in connections depending on type of BeoVision and setting the SUB 2.1 switch with the various
speaker combinations.
100 - 240V 50/60Hz
PL 1PL 2PL 3
PL 4 PL 5
Video or
Audio product
Connecting source systems to BeoLab Transmitter 1 8
3rd party product using Power Link as Line-in
A wireless 7.1 setup is shown as example in the above illustration.
Connect 3rd party products to the BeoLab Transmitter 1 using Power Link cables.
The volume of the signal must be adjusted from the source system.
B&O INPUT
Remember to set the B&O INPUT switch to NO.
SUB 2.1
With a multiple sounc channel as input set the SUB 2.1 switch to OFF.
With a stereo only signal as input and a wireless subwoofer available,
set the SUB 2.1 switch to ON. The bass management function of the
BeoLab Transmitter 1 provides the subwoofer signal to a wireless subwoofer
indicated as the third sound channel (PL 2 L).
The cut-off frequency for the Bass management is 120Hz.
See the guide for BeoLab Transmitter 1 for variety in speaker combinations.
100 - 240V 50/60Hz
Surround Sound Decoder
FL FR RL RR CS SWCL CR
Connecting source systems to BeoLab Transmitter 1 9
3rd party product using TOSLINK (S/P-DIF)
Connect 3rd party products to the BeoLab Transmitter 1 using a TOSLINK cable. The volume of the signal must be adjusted from the audio system.
B&O INPUT
Remember to set the B&O INPUT switch to NO.
In case a Bang & Olufsen product is connected
additional to the 3rd party product the switch is
set to YES.
SUB 2.1
With a stereo only signal as input and a wireless subwoofer available,
set the SUB 2.1 switch to ON. The bass management function of the
BeoLab Transmitter 1 provides the subwoofer signal to a wireless subwoofer
indicated as the third sound channel (PL 2 L).
The cut-off frequency for the Bass management is 120Hz.
See the guide for BeoLab Transmitter 1 for variety in speaker combinations.
100 - 240V 50/60Hz
TOSLINK
Out
Audio
product
Connecting source systems to BeoLab Transmitter 1 10
3rd party product using audio input (RCA)
Connect 3rd party products to the BeoLab Transmitter 1 using Line-in (RCA) cables. The volume of the signal must be adjusted from the audio
system.
B&O INPUT
Remember to set the B&O INPUT switch to NO.
In case a Bang & Olufsen product is connected
additional to the 3rd party product the switch is set
to YES.
SUB 2.1
With a stereo only signal as input and a wireless subwoofer available,
set the SUB 2.1 switch to ON. The bass management function of the
BeoLab Transmitter 1 provides the subwoofer signal to a wireless subwoofer
indicated as the third sound channel (PL 2 L).
The cut-off frequency for the Bass management is 120Hz.
See the guide for BeoLab Transmitter 1 for variety in speaker combinations.
100 - 240V 50/60Hz
Output
R L
Audio
product
Connecting source systems to BeoLab Transmitter 1 11
Audio input using Power Link - up to 11 speakers
This function is made available with the SW ver. 1.1 and newer.
Connect Bang & Olufsen audio or TV product using a Power Link cable to the PL1 socket (stereo only signal) or Power Link cables to the PL1 to
PL4 sockets (multi-channel) and set the B&O INPUT switch to YES.
Alternatively connect a 3rd party audio product using Power Link socket as Line-in and set the B&O INPUT switch to NO.
Up to 11 speakers may be arbitrarily congured to be connected to the available source channels: Examples of source input are:
- Stereo input, no bass management. SUB 2.1 set to OFF. This provides a left and a right stereo sound channel.
- Stereo input, with bass management. SUB 2.1 set to ON. This provides a left and a right stereo sound channel plus a subwoofer sound channel.
- Multi-channel input, up to 8 channels, see page 7 and page 8. SUB 2.1 set to OFF. This provides sound channels according to the
Power Link input.
Note: Observe that the distance between the BeoLab Transmitter 1 and any speaker must not exceed 12 m / 40 ft.
> continues
100 - 240V 50/60Hz
BeoMaster 5
BS 5
L L
RR
L L
RR
SUB SUB SUB
Connecting source systems to BeoLab Transmitter 1 12
Associating wireless speakers to the BeoLab Transmitter 1
- Connect the source output channels to the input sockets of the BeoLab Transmitter 1.
- Connect the BeoLab Transmitter 1 and all wireless speakers to the mains.
If the BeoLab Transmitter 1 and any speaker have previously been congured then do the following to ensure such is completely cleared:
- Long press on SELECT and STORE simultaneously by which cleared state is obtained.
The WIRELESS LED will become solid white and then start ashing white.
The LED on the speakers will turn solid red for a few seconds and then start ashing green, indicating ready for being scanned.
Scanning
- Short press on SELECT by which BeoLab Transmitter 1 starts scanning for wireless speakers.
The WIRELESS LED is fast ashing green during the scanning mode.
The white and red LEDs above the POWER LINK sockets turns solid for each speaker found. When more than 8 speakers are found only the 8 LEDs
are lit.
The LED on the speakers will rst turn solid red for a few seconds and then when found it will turn to solid green, indicating ready for being
congured.
Conguring speaker position with sound channel
In the following description the conguration of the left stereo channel and of the right stereo channel is the same procedure to be used for
conguration of the left and right sound channel for each of the PL socket in a multi-channel setup.
Manual conguration
- Long press SELECT to start manual conguration.
The WIRELESS LED turns solid green to indicate manual conguration mode. When the SELECT button is released the WIRELESS LED continues fast
ashing green.
The white LED for the left (L) sound channel starts ashing. LEDs for the other sound channels are Off.
Noise is emitted from one of the speakers.
Left stereo channel
- Short press once or repeatedly on SELECT until the noise is emitted from a speaker that shall be congured with the left sound channel.
- If more speakers shall be congured for the left sound channel (else go to next bullet), make a long press on STORE, and the WIRELESS LED on the
BeoLab Transmitter 1 turns solid green, to conrm that the speaker conguration is stored for the left sound channel. When the STORE button is
released the WIRELESS LED continues fast ashing green.
Noise will now be emitted from another speaker and the LED for the left sound channel is ashing. Continue at the step above.
- If all speakers are congured for the left sound channel, make a short press on STORE, and the WIRELESS LED on the BeoLab Transmitter 1 turns
solid green, to conrm that the speaker conguration is stored for the left sound channel.
The white LED for the left sound channel becomes solid, and the red LED for the right sound channel starts ashing. LEDs for the other sound
channels are Off.
Noise will now be emitted from another speaker.
Connecting source systems to BeoLab Transmitter 1 13
Right stereo channel
- Short press once or repeatedly on SELECT until the noise is emitted from a speaker that shall be congured with the right sound channel.
- If more speakers shall be congured for the right sound channel (else go to next bullet), make a long press on STORE, and the WIRELESS LED on
the BeoLab Transmitter 1 turns solid green, to conrm that the speaker conguration is stored for the right sound channel. When the STORE
button is released the WIRELESS LED continues fast ashing green.
Noise will now be emitted from another speaker and the LED for the right sound channel is ashing. Continue at the step above.
- If all speakers are congured for the right sound channel, make a short press on STORE, and the WIRELESS LED on the BeoLab Transmitter 1 turns
solid green, to conrm that the speaker conguration is stored for the right sound channel.
The red LED for the right sound channel becomes solid.
- If speakers are to be congured with other sound channels or the subwoofer sound channel (else go to next bullet) the white LED for the sound
channel above the PL2 socket starts ashing. LEDs for the other sound channels are Off.
Noise will now be emitted from another speaker.
Either continue by repeating the above procedures for the left stereo channel or continue at conguring the subwoofer sound channel below.
- If subwoofers are not to be congured, all speakers found during the search are congured and the white LED for the left sound channel and the
red LED for the right sound channel switches Off after approx. 10 s.
Subwoofer sound channel
The white LED (L) above the PL2 socket is indicating the subwoofer sound channel.
- Short press once or repeatedly on SELECT until the noise is emitted from a speaker that shall be congured with the subwoofer sound channel.
- If more speakers shall be congured for the subwoofer sound channel (else go to next bullet), make a long press on STORE, and the WIRELESS
LED on the BeoLab Transmitter 1 turns solid green, to conrm that the speaker conguration is stored for the subwoofer sound channel. When the
STORE button is released the WIRELESS LED continues fast ashing green.
Noise will now be emitted from another speaker and the LED for the subwoofer sound channel is ashing. Continue at the step above.
- If all speakers are congured for the subwoofer sound channel, make a short press on STORE, and the WIRELESS LED on the BeoLab Transmitter 1
turns solid green, indicating that the speaker conguration is stored for the subwoofer sound channel.
The white LED for the subwoofer sound channel becomes solid and switches Off after approx. 10 s.
Speaker setup in TV products
When the sound source is a Bang & Olufsen TV, the speakers must be set up via the menus of the TV, see page 12 ff.
Finish/interrupt manual conguration
Whenever desired the manual conguration can be nished or interrupted by long press SELECT. The already congured speakers will be kept
stored, and the speakers not congured will not be playing.
When all speakers are congured, the speakers make a short boot, the LED on the speakers turn solid red and then turns Off. The LEDs above the
PL sockets turns solid for at few seconds and then fade out.
Setting up and connecting BeoLab Transmitter 1 14
Setting up and connecting BeoLab Transmitter 1
An interactive video on setting up connections to BeoLab Transmitter
1 is found on www.bang-olufsen.com/interactive-guide/
Setting up the BeoLab Transmitter 1
TV product as the source
- Ensure the speakers are set to WIRELESS.
- Ensure all speakers and the BeoLab Transmitter 1 are disconnected
from mains.
- Connect the BeoLab Transmitter 1 to the source product (TV or audio
master) using appropriate Power Link cables, TOSLINK or RCA cables.
- Cables in both BeoLab Transmitter 1 and Bang & Olufsen source
product must be in numerically increasing order; i.e. PL 1 to PL 1, Start
with the PL 1 socket and ll in the PL sockets from left to right.
Predened Power Link sockets are likewise connected to the PL 1, PL 2
sockets etc. It is recommended to place cable with the subwoofer
source signal in the rightmost Power Link socket of the sockets used.
TOSLINK or RCA cables are connected to their matching connectors.
Advice: Keep a record of cables and Power Link sockets.
- Set B&O INPUT switch to YES. When the source is not a Bang &
Olufsen product the B&O INPUT switch must be set to NO.
When set to YES the BeoLab Transmitter 1 reacts to the PL signal
Speaker On/Off. When set to NO the BeoLab Transmitter 1 reacts to
the signal level in the speaker channels (sound/noise).
- When source input comes to more Power Link sockets, the SUB 2.1
switch is set to OFF.
Audio product as the source (see next page)
- Set the SUB 2.1 switch to ON when the input is a stereo signal and the bass
management function of the BeoLab Transmitter 1 is providing the signal to a wireless
subwoofer in the third sound channel PL2 L.
- Connect mains to all speakers and the BeoLab Transmitter 1. The WIRELESS LED will
start ashing white during the conguration process.
PL 5 PL 4
MONITOR
CONTROL
PUC 2
A+B
PUC 1
A+B EXT. IR
PL 3 PL 2 PL1 PUC 3 A+B
CTRL 3 CTRL 2 CTRL 1
BeoLab Transmitter 1 BeoVision 11
CTRL 1
PUC2 A+B
CTRL 3
PUC1 A+B
CTRL 2
PL1 PL2 PL3
BeoLab Transmitter 1 BeoPlay V1
BeoLab Transmitter 1 BeoVision 10
POWER LINK
CENTRE 1 1(SUB)2 34
56
BeoLab Transmitter 1 BeoVision 7-40 MKIII to MKIV and TV
REAR FRONT
SUBWOOFER
REAR
SURROUND SOUND SPEAKERS
FRONT
CINEMA
CENTRE
BeoLab Transmitter 1
BeoVision 7-40 to MKII
Setting up and connecting BeoLab Transmitter 1 15
The Product Status LED on the front will be solid red, indicating it turns On and
becomes ready for operation and turns Off after 10 s time-out.
- The Wireless indicator on the speaker starts ashing green, indicating it is not yet
associated to the BeoLab Transmitter 1. When associated the LED stops ashing green.
(In case the speaker behaves differently, please refer to the guide included with the
speaker).
Associating wireless speakers to the BeoLab Transmitter 1
The speakers must now be associated with the Power Link channels in the order from left to right until all are associated with. Execute the below
instructions for each speaker. Next to each Power Link connector, the white LED to the left gives indications regarding the left sound channel (L)
and the red LED gives indications regarding the right sound channel (R).
Scanning
- On the BeoLab Transmitter 1 make a short press on the SELECT button. By this the BeoLab Transmitter 1 starts scanning for wireless speakers. The
WIRELESS LED will start ashing green, indicating that searching for wireless speakers is ongoing.
When the BeoLab Transmitter 1 has nished scanning the number of Power Link LEDs that are lit matches the number of speakers that are found.
When more than 8 speakers are found only the 8 LEDs are lit.
Likewise the WIRELESS LED indicator on the speakers will turn into solid green and then be turned Off after 10 s time-out.
The speakers are now connected to the BeoLab Transmitter 1, although the speaker role is not matched with the correct sound channel.
Conguring speaker position with power link output
To congure the speakers correctly with the Power Link sound channels, the matching hereof is done, using the following instructions.
BeoVision 11 / BeoPlay V1 / BeoSystem 4 using the remote control
- If the product is a BeoVision 11/BeoPlay V1 or BeoSystem 4, it is possible to press the STORE button when the scan is completed. All conguration
of the speakers can then be handled via the SPEAKER TYPE menu.
- Press Menu > SETUP > SOUND > SPEAKER TYPE and select each of the Power Link speakers, connected wired or wirelessly and select the
speaker type.
- Press Menu > SETUP > SOUND > SPEAKER GROUPS > SPEAKER GROUP SETUP > SPEAKER ROLES and assign each of the Power Link sockets
to the desired speaker position.
Manual conguration of Bang & Olufsen TVs, Audio Products and 3rd party products
- Make a long press ≥ 1.5 s (and ≤ 10 s) on the SELECT button, by which the BeoLab Transmitter 1 goes into manual conguration mode.
The Power Link LEDs will start ashing one-by-one starting from left to right, indicating the Power Link sound channel is ready to be congured
with at speaker. The LED will be ashing until conguration for the speaker is stored by then it turns to be solid lit. The LEDs to the right of the one
being congured are turned Off.
POWER LINK
BeoLab Transmitter 1 Bang & Olufsen
Audio product
Setting up and connecting BeoLab Transmitter 1 16
(Power Link channels are dedicated according to the output from the source).
- Noise is generated by the BeoLab Transmitter 1 and the noise is emitted from a (random) speaker that may not be the correct one matching the
Power Link (sound) channel indicated by the ashing LED. Make a short press ≤ 1.5 s on the SELECT button once or repeatedly until the noise is
emitted from the speaker position desired.
- Make a short press ≤ 1.5 s on the STORE button, by which the Power Link (sound) channel and the speaker are matched and stored in the
conguration table (speaker mapping table). The LED with that Power Link (sound) channel will stop ashing. If not all speakers are congured the
LED of the next Power Link channel will start ashing. Now repeat the instruction step just above. Se also page 12 ff when moren than 11
speakers are to be congured.
The below example illustrates the Power Link LED indications when speaker for the 3rd sound channel is being congured.
Speaker setup in TV menu
BeoVision 7-40
- Press Menu > OPTIONS > SOUND > SPEAKER TYPES and move the cursor to the rst line.
Sound will be emitted from one of the speakers.
First line is predened as CENTRE.
Go to rst line after SPEAKERS and the rst two are predened as subwoofers.
Step through the list and for each speaker emitting a sound assign the speaker type of the speaker; e.g. BeoLab 17.
- Press Menu > OPTIONS > SOUND > SPEAKER ROLES and move the cursor through the list, one speaker at a time. A sound is heard from a
speaker. Choose a speaker role that matches the position of the speaker.
BeoVision 10
- Press Menu > OPTIONS > SOUND > SPEAKER TYPE and move the cursor to the rst line.
Step through the list and for each speaker position assign the type of the speaker; e.g. BeoLab 17.
Sound can now be emitted through each speaker.
To optimise the sound experience, congure the levels and listening distances in the appropriate setup menus.
Push button functions 17
Push button functions
State SELECT STORE Time Comment
Scan X (short) - ≤1.5 s In non-conguration mode: Scans for wireless speakers
In conguration mode: Lit Power Link LEDs to show the number of speakers found
Store default - X (short) ≤1.5 s Scanning completed: store default. Note: when SUB 2.1 is set to On, manual conguration is forced
Show Power Link channel - X (long) ≥ 1.5 s and ≤10 s Show status on Power Link LEDs (turns Off after 10 s time-out)
Manual conguration mode X (long) - ≥ 1.5 s and ≤10 s Conguration mode: Mode for manually conguring the match between the sound channel and a
speaker
Shift noise to next speaker X (short) - ≤1.5 s Conguration mode: Move emitted noise to another speaker
Finish manual conguration * X (long) ≥ 1.5 s and ≤10 s Conguration mode: Finish manual conguration whenever desired
Store - X (short) ≤1.5 s Conguration mode: Stores the conguration of the match between the sound channel and a
speaker and continue with next channel
Store * - X (long) ≥ 1.5 s and ≤10 s Conguration mode: Stores the conguration of the match between the sound channel and a
speaker and remain on same channel to be matched with another speaker
Below: Press buttons simultaneously!
Cancel X (short) X (short) ≤1.5 s Conguration mode: Move emitted noise one step back to previous sound channel to recongure an
inadvertently stored conguration
Reset association X (long) X (long) ≥ 1.5 s and ≤10 s Erase speaker mapping.
Bang & Olufsen speakers will then ash green. If not press (long) the RESET button on the speaker(s)
Factory reset X (very long) X (very long) ≥ 10 s Erase speaker mapping, and resets the settings to factory default
Bang & Olufsen speakers will then ash green. If not press (long) the RESET button on the speaker(s)
* Functions available with the SW ver. 1.1 and newer.
Note: The cancel function me be used whenever a conguration of a speaker with at sound channel is to be regretted
If the product is a BeoVision 11/BeoPlay V1 or BeoSystem 4, it is possible to press the STORE button when the scan is completed. All conguration
of the speakers can then be handled via the SPEAKER CONNECTIONS menu.
LED indications 18
LED indications
Power Link LED indications
White ~ left speaker Red ~ right speaker Comment
Off Sound channel is inactive after power up
Not congured yet i.e. during manual conguration
Normal operation
On Solid light after scanning and storing; turns Off after 10 s time-out
Also shown when checking for connected speakers: long press on STORE
Flashing During manual conguration or if a speaker is not congured
WIRELESS LED indications
State Signal Time Comment
Congured wirelessly - - Product is congured wirelessly
Standby Off - Product is in standby mode
Normal operation White (solid) Off after 10 s time-out After pressing STORE: Speaker connections behave normally
Normal operation White (slow ashing) 200 ms/200 ms No speakers are connected
Connecting Green (fast ashing) 100 ms/100 ms In setup (scanning) mode and open for connecting speakers
Network strength is low Orange (solid) - Connection quality in network is low
Network failure Orange (fast ashing) 100 ms/100 ms Network error or some malfunctioning e.g. subwoofer not found in a SUB 2.1 setup
Product Status LED indications
State Signal Time Comment
Power Link Transmitter 1 is Off - - Product is switched Off
Standby Off - Product is in standby mode
Normal operation Off - Product behaves normally
Mains On and
Restart after Reset
Red (solid) Off after 10 s time-out * Lit when power is applied to the BeoLab Transmitter 1, to indicate that it is switched On and becomes
ready for operation
Also lit when reset either by the user (external) or by the BeoLab Transmitter 1 (internal)
Turning Off (go to Standby) Red (solid) Off after 10 s time-out * Lit when switching Off either via Power Link from the source product or when the signal is no longer
present (i.e. silence in 15 minutes)
Turning On Green (solid) Off after 10 s time-out * The BeoLab Transmitter 1 is switched On and has sensed an input
Software Update Green (slow ashing) 200 ms/100 ms
Off when done
Indicate that the power must not be disconnected during the update process
Product failure Orange (fast ashing) 100 ms/100 ms Hardware error - product will not revert to normal operation or if revert automatically to normal
operation : see ERROR LOG in ServiceTool
Product Status LED and WIRELESS LED indications simultaneously
State Signal Time Comment
Network strength low /
poor wireless range
Orange (solid) - System connection quality is low. Distance to speaker(s) too long
Network failure Orange (fast ashing) 100 ms/100 ms Network error or other malfunctioning
* The WIRELESS LED indicator will not go Off within time out or automatic standby mode, during the setup process.
(See page 4 and page 16)
(See page 4)
(See page 4)
Use of ServiceTool - SW update - BeoLab Transmitter 1 19
Use of ServiceTool
The ServiceTool is used for SW update during installation - apart from that the ServiceTool is primarily used with service and repair situations.
Follow the instructions with the mode and actions chosen.
SW update - BeoLab Transmitter 1
Note: A standard USB A to USB Mini-B cable is used for connection between the PC hosting the ServiceTool and the BeoLab Transmitter 1 (Part
No.: 6270848) and also a the CDC/ACM driver must be installed. (In ServiceTool, see Connections > USB Driver).
In the Launch view (activate the LAUNCH PAD in the quick launch tray of the ServiceTool), activate the Connections tool, and under USB driver
activate the Execute CDC/ACM driver installer. Usually the PC must be restarted for the driver to work.
- Connect the BeoLab Transmitter 1 to the mains.
- Connect the USB Mini-B connector (Service) of the BeoLab Transmitter 1 to a USB A connector of the PC hosting the ServiceTool.
- Identify the Com port used on the PC by entering e.g. Start > Control Panel > Hardware and Sound > Device Manager, and under
Ports(COM&LPT) it shows ATI COM port (COM n) where n is the number of the chosen Com port.
- In the lower left corner of the ServiceTool, remember to select the Com port used to connect to the BeoLab Transmitter 1.
- Select the BeoLab Transmitter 1 in the product list and open the entries Software > Automatic Software Update.
Follow the instructions in the ServiceTool, that are:
- Press the Read button to see the present Software in the Product.
- Under Select Software Build, and in the Version drop-down list select the desired SW build and press Update.
The Product Status LED will be slowly ashing green during the update process.
In the Logging eld, the progress of the SW update will be shown, ending by indicating the nal status.
Use or USB memory stick - SW update 20
Use of USB memory stick
This function is made awailable with the SW ver. 1.1 and newer.
SW update - BeoLab Transmitter 1 and wireless speakers
Additionally to updating the SW for the BeoLab Transmitter 1 it is also possible (with SW ver. 1.1 and newer) to push SW updates to the wireless
speakers and BeoLab Receiver 1 via the BeoLab Transmitter 1.
Note: It is recommended that the USB memory stick is emptied for les and folders to avoid loss of data.
Use a computer to download the desired SW build to the root of the USB memory stick from www.bang-olufsen.com.
Tick off the terms and conditions at the bottom of the page.
Select DOWNLOAD SOFTWARE
Extract the contents of the *.zip-le and read instructions.
[File formats supported are: FAT 16, FAT32 and lenames only consisting of 8.3 characters].
- Make sure that all speakers are mains supplied, and that the role switch is set to wireless.
- Disconnect the BeoLab Transmitter 1 from the mains for at least 60 s.
- Insert the USB memory stick into the USB A connector.
- Connect the BeoLab Transmitter 1 to the mains.
The BeoLab Transmitter 1 may restart (LED is solid red) and will continue to search for any SW builds and if a newer is found the SW for the
BeoLab Transmitter 1 will be updated automatically.
The Product Status LED will be slowly ashing green during the update process.
Sometimes two updates are initiated and the LED will be slowly ashing green during the second update process
- LEDs over the Power Link connectors will turn solid according to the number of wireless speakers connected.
The LED for the rst speaker will start to blink
The green LED on the speaker will be slowly ashing green during the update process.
If the update is successful the Power Link LED turns off and the above mentioned procedure will continue for the other speakers in sequence.
If the update is not successful the LED over the Power Link connector for the actual speaker will be quickly ashing green, and likewise the
white or red LED for the sound channel will be ashing while update for the next speaker will continue.
- Regarding the speakers not successfully updated, the mains power must be switched Off both for the BeoLab Transmitter 1 and the speaker.
When mains power is On again the SW update for the speaker will be redone.
- When all updates are completed, the BeoLab Transmitter 1 restarts automatically, LED is solid red and then switches off.
- Disconnect the BeoLab Transmitter 1 from the mains for at least 60 s before removing the USB memory stick, and then reconnect to the mains.
Note: A SW update usually consist of all three updates.
A SW update will usually take from 5 to 15 minutes for each speaker, depending on environment and number of updates. Playback is not possible
during a SW update.
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30

Bang & Olufsen Beolab Transmitter 1 Installation guide

Bang & Olufsen
Brand
Bang & Olufsen
Model
Beolab Transmitter 1
Category
Soundbar speakers
Type
Installation guide
This manual is also suitable for
Download PDF
report

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI

Related papers

Other documents
