DAZE MANUAL

507K Series

Table Of Contents

Basic Features

Adding Files and Connecting

Buttons

Turning On the Player

Charging

Main Menu

Music

Video

Record

FM Radio


Set-up

E-book

Video Conversion

Troubleshooting

TABLE OF CONTENTS

Thank you for purchasing the Daze. Please read

through this user manual in order to understand the

functions of your new player.

BASIC FEATURES

• Jpeg Picture Viewer

• Various Audio Format Playback

• Video Playback

• FM Radio w/Record

• Voice Recording

• Various Playback Modes

ADDING FILES AND CONNECTING

When connected to a PC, the player acts as a

standard USB-Disk drive, supporting Windows 98

(driver needed), Windows 2000 and above systems

(no driver needed), Mac OS 10.3, Linux Redhat 8.0

or above.

Once your player is detected, you simply drag and

droporcutandpastethelesthatyouwishtosave

to the player’s internal memory.

BUTTONS

The player functions are done by simply pressing

or holding down the buttons on the players. The

effects of holding or pressing on the buttons vary

per function. Pressing the MENU button will allow

you to enter sub menus or select options. Holding

down on the menu button will let you return to the

main menu.

Ι◄◄►►Ι:pressingthesebuttonswillletyou

scroll through music selection, options, volume set-

tings, and radio stations.

VOL:pressingthebuttoninthevideo,andaudio

menus will allow you to change the volume.

CENTERBUTTON:pressingthebuttonwillstartand

stop music or videos. Holding down this button will

shutdown the player and turn it back on.

TURNING ON THE PLAYER

To turn on the player, simply switch the player to

the “ON” position. The on/off switch is located on

the top left of the player. If your player is already

switched on, hold down on the play button.

CHARGING

Your player can be charged through either a wall

charger or by being directly connected to the com-

puter. Please note that charging times vary between

these to methods, wall charger being the quicker

method.NOTE:Tochargetheplayer,makesurethat

your player is on the “ON” position in order for charg-

ing to take place.

MAIN MENU

Below are the sub menu’s that can be found on your

player’s main menu. Please note some features may

be changed at anytime without prior notice.

• Music:musicplayback

• Movie:videoplayback

• Record:Wheretovoicerecord

• Voice:Playsyourrecordings

• FMRadio:Listentotheradiohere

• Photo:Displaysyourpictures

• Setup:Wheretochangesettings

• E-Book:Readtextleshere

To select an option from the main menu, scroll to

the option that you want and press the MENU but-

ton. To enter the sub menus, you will need to press

the menu button after selecting an option from the

main menu.

MUSIC

CHANGINGFOLDER:

While music playback is stopped, press the MENU

button once, this will take you to the folder select

option, the MENU button is used to select any folder

and or song you wish to playback.

PLAYBACKFUNCTIONS:

While music is playing, pressing the MENU button

will take you to the playback options menu, for such

options as changing repeat options, and equalizer

settings, again from this menu the MENU button

must be used to select any option.

VIDEO

NOTE:Inordertoviewyourvideoles,youmust

rstconverttheleandmoviesize.Pleaseseethe

section titled “Video Conversion” for more informa-

tion. To Enter the Movie Sub Menu, press the MENU

button once, to select any options while in the Music

Sub Menu, also press the MENU button.

SUBMENU:

Youcanselectwhichfoldertoplayordeleteles

from the sub menu by pressing MENU once while

music is not playing.

RECORD

Press the MENU button to enter the Record sub

menu. Hold to return to the main menu. Press MENU

inasubmenutoconrmanoption.PressMENU

after recording to save your recording.

Ι◄◄►►Ι:submenuonly.Scrollthroughoptions.

CENTERBUTTON:willstartandpauserecording.

From this sub menu, you can select where you would

likethelestobesavedandtherecordtype.

RECORDTYPES:

FineRecording:WAVFormat-Highsoundquality

Longrecording:ACTFormat-Consistentquality

FineVOR:WAVFormat-Soundcontrol

LongVOR:ACTFormat-Soundcontrol

(VOR mode is a sound activated recording)

FM RADIO

NOTE:Headphonesactastheantennaforthe

player. Press the MENU button to enter the FM

Radio sub menu. Hold to return to the main menu.

Pressinasubmenutoconrmanoptionyouhave

highlighted.

Ι◄◄►►Ι:scrollthroughradiostations.Hold

down to auto search.

VOL:allowsyoutoenterthevolumemenu.

CENTERBUTTON:willscrollthroughyoursaved

stations.

Press the MENU button to enter the sub menu,

you can auto search for stations, save up to 20

stations as presets, delete your presets, and enter

the recording menu so that you can record from the

radio station.


Press the MENU button to enter the sub menu. Hold

to return to the main menu. Press the MENU button

inasubmenutoconrmanoption.

Ι◄◄►►Ι:scrollthroughthepictures.

CENTERBUTTON:viewthecurrentselectedpicture.

Press the MENU button to enter the photo sub

menu. From here you can select a different folder

toview,deleteles,andstarttheslideshowoption

through Play Set.

SET-UP

Below are brief descriptions of the settings that can

be changed from the Set Up menu.

• Date&Time:setthetimeanddate

• LCDSet:changethebrightnessandthetime(in

seconds) before the player screen to turns dark

when idle.

• Language:changethelanguageoftheplayer

• PowerSaving:changethetime(inseconds)

before the player will turn off when idle.

• ReplayMode:choosebetweenmanualandauto

replay

• MemoryInfo:viewhowmuchmemoryremains.

• FirmwareVersion:viewthermwareversion.

E-BOOK

Press the MENU button to enter the E-book sub

menu.Whenthedesiredtextlehasbeenhigh-

lighted press the MENU button to view it.

NOTE:Onlytextles,or*.txtleswillworkwiththe

E-BOOK feature.

Ι◄◄►►Ι:scrollthroughthetext.

CENTERBUTTON:readthecurrenttextle

VIDEO CONVERSION

Inordertobeabletoplayvideoles,youwillneedto

use the program that is on the CD supplied, if your

playerdidnotcomewithaCD,allthelesnecessary

for the program are pre-loaded to your player. Simply

runtheSETUPletoinstalltheprogram.

1. Once the setup is complete, locate the newly

installed MP3 Player Utilities and click on AMV

convert tool.

2. Clickonthe“Inputle”icontondthelethat

you are looking to covert and click on “Output

le”iconandsavetheletoyour.

3. Now click on the icon with two arrows (tooltip

will show “Begin” if you put your cursor on

the arrows) to start the conversion. Once the

conversion is done the program will play with

theAMVplayer.Note:pleaseclickonhelpfor

further information; it is the square box next to

the two arrows.

4. TotransfertheconvertedAMVleontoyour

player,rstconnecttheVisualLandplayerto

yourcomputerandcopyandpastetheAMVle

onto the player folder.

5. ToaccesstheAMVlefromyourVisualLand

player, go onto the “Movie” menu of the player,

theleshouldshowup.Press“Play”toview

yourle.

TROUBLESHOOTING

Cannot t more than 99 les onto the player.

Toxthisproblem,createanewfolderonyour

playerandinsertyourlesinthere.Pleasedonot

insert subfolders within a subfolder, as it may cause

problems with your player.

Short battery life

The screen can drain the battery life of your player.

To increase the battery life, we suggest that you

decrease the brightness, and the time it takes for

the player screen to turn off when idle.

Firmware Upgrade

We strongly recommend that you only download

VisualLandapprovedrmwarefromourwebsite.

Downloadinganyotherrmwaremayharmyour

player.

FCCPart15:ThisdevicecomplieswithPart15oftheFCCRules.

Operationofthisproductissubjecttothefollowingtwoconditions:

(1) this device may not cause harmful interference, and (2) this

device must accept any interference received, including interference

that may cause undesired operation.

FCCWarning:Changesormodicationsnotexpresslyapprovedby

the party responsible to compliance with the FCC Rules could void

the user’s authority to operate this equipment.

DISCLAIMER

1. Without the company’s written permission, any form of repro-

duction, transmission, distribution and storage of any of the

contents of this manual is prohibited.

2. In the course of the preparation of this manual the contents are

accurate and complete, but we do not guarantee this manual is

without any errors or omissions.

3. The company is not responsible for errors or omissions.

4. We reserve the right to make changes to this manual without

prior notice.

5. In any case, we are not responsible for any losses or damages

caused by this manual.

NOTES

This manual is intended to inform users of the proper use of player

to ensure that the player’s in good condition, please read carefully

and follow.

• Do not severely impact (by dropping, hitting, etc.) the player.

• Do not clean player with benzene, thinner and other chemicals.

• Pleasedonotputtheplayerclosetoastrongmagneticeldor

electriceld.

• Please avoid direct light or heating appliances.

• Do not attempt to repair or modify the player.

• Do not attempt to replace the battery.

• Do not listen to the player using headphones at a high volume,

so as to avoid adverse effects on hearing.

• Please dispose of packaging waste, batteries, old electronic

productsaccordingtoitsclassication.

If you have a problem with your player please visit

our website and view our support pages.

http://www.visual-land.com
