ADB L-852B User manual

Type
User manual
www.adb-air.com
Airfield Lighting
Product Solutions Catalog
User ManualUser Manual
L-852A-D, J & K ITCF, F-
Range, ICAO LED Taxiway
Centerline Light
FAA and ICAO Taxiway Centerline Lights
96A0460, Rev. C, 6/15/16
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
DISCLAIMER / WARRANTY
© ADB Airfield Solutions All Rights Reservedii
A.0 Disclaimer /
Standard Warranty
A.1 CE certification The equipment listed as CE certified means that the product complies with the essential requirements
concerning safety and hygiene. The directives that have been taken into consideration in the design are
available on written request to ADB.
A.2 ETL certification The equipment listed as ETL certified means that the product complies with the essential requirements
concerning safety and FAA Airfield regulations. The directives that have been taken into consideration in
the design are available on written request to ADB.
A.3 LED Product
Guarantee
Where applicable, per FAA EB67(applicable edition), ADB L858(L) Airfield Guidance Signs are warranted
against electrical defects in design or manufacture of the LED or LED specific circuitry for a period of 4
years. ADB LED light fixtures (with the exception of obstruction lighting) are warranted against
mechanical and physical defects in design or manufacture for a period of 12 months from date of
installation; and are warranted against electrical defects in design or manufacture of the LED or LED
specific circuitry for a period of 4 years per FAA EB67 (applicable edition).
NOTE: See your sales order contract for a complete warranty description. In some specific cases,
deviations are (to be) accepted in the contract, which will supersede the standard warranty.
A.4 Standard Product
Guarantee
Products of ADB manufacture are guaranteed against mechanical, electrical, and physical defects
(excluding lamps) which may occur during proper and normal use for a period of one year from the date
of installation or 2 years from date of shipment and are guaranteed to be merchantable and fit for the
ordinary purposes for which such products are made. ADB L858 Airfield Guidance Signs are warranted
against mechanical and physical defects in design or manufacture for a period of 2 years from date of
installation per FAA AC 150/5345-44 (applicable edition).
NOTE: See your sales order contract for a complete warranty description.
A.5 All Products LED Products of ADB, manufactured and sold by ADB or its licensed representatives, meets the
corresponding requirements of FAA, ICAO and IEC.
ADB will correct by repair or replacement per the applicable guarantee above, at its option, equipment or
parts which fail because of mechanical, electrical or physical defects, provided that the goods have been
properly handled and stored prior to installation, properly installed and properly operated after installation,
and provided further that Buyer gives ADB Airfield Solutions written notice of such defects after delivery of
the goods to Buyer. Refer to the Safety section for more information on Material Handling Precautions
and Storage precautions that must be followed.
ADB reserves the right to examine goods upon which a claim is made. Said goods must be presented in
the same condition as when the defect therein was discovered. ADB Airfield Solutions furthers reserves
the right to require the return of such goods to establish any claim.
ADB’s obligation under this guarantee is limited to making repair or replacement within a reasonable time
after receipt of such written notice and does not include any other costs such as the cost of removal of
defective part, installation of repaired product, labor or consequential damages of any kind, the exclusive
remedy being to require such new parts to be furnished.
ADB’s liability under no circumstances will exceed the contract price of goods claimed to be defective.
Any returns under this guarantee are to be on a transportation charges prepaid basis. For products not
manufactured by, but sold by ADB Airfield Solutions, warranty is limited to that extended by the original
manufacturer.
This is ADB’s sole guarantee and warranty with respect to the goods; there are no express warranties or
warranties of fitness for any particular purpose or any implied warranties of fitness for any particular
purpose or any implied warranties other than those made expressly herein. All such warranties being
expressly disclaimed.
© ADB Airfield Solutions All Rights Reserved iii
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
DISCLAIMER / WARRANTY
A.6
Liability
ADB cannot be held responsible for injuries or damages resulting from non-standard, unintended uses of
its equipment. The equipment is designed and intended only for the purpose described in the manual.
Uses not described in the manual are considered unintended uses and may result in serious personal
injury, death or property damage.
Unintended uses includes the following actions:
Making changes to equipment that have not been recommended or described in this manual or
using parts that are not genuine ADB replacement parts or accessories.
Failing to make sure that auxiliary equipment complies with approval agency requirements, local
codes, and all applicable safety standards if not in contradiction with the general rules.
Using materials or auxiliary equipment that are inappropriate or incompatible with your ADB
equipment.
Allowing unskilled personnel to perform any task on or with the equipment.
WARNING
Use of the equipment in ways other than described in the catalogue leaflet and the manual may result in personal
injury, death, or property and equipment damage. Use this equipment only as described in the manual.
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
DISCLAIMER / WARRANTY
© ADB Airfield Solutions All Rights Reservediv
A.7 © ADB BVBA This manual or parts thereof may not be reproduced, stored in a retrieval system, or transmitted, in any
form or by any means, electronic, mechanical, photocopying, recording, nor otherwise, without ADB
BVBA’s prior written consent.
This manual could contain technical inaccuracies or typographical errors. ADB BVBA reserves the right to
revise this manual from time to time in the contents thereof without obligation of ADB BVBA to notify any
person of such revision or change. Details and values given in this manual are average values and have
been compiled with care. They are not binding, however, and ADB BVBA disclaims any liability for
damages or detriments suffered as a result of reliance on the information given herein or the use of
products, processes or equipment to which this manual refers. No warranty is made that the use of the
information or of the products, processes or equipment to which this manual refers will not infringe any
third party’s patents or rights. The information given does not release the buyer from making their own
experiments and tests.
© ADB Airfield Solutions All Rights Reserved v
TABLE OF CONTENTS
A.0 Disclaimer / Standard Warranty.............................................................................................................................II
A.1 CE certification ..................................................................................................................... ii
A.2 ETL certification ................................................................................................................... ii
A.3 LED Product Guarantee ........................................................................................................... ii
A.4 Standard Product Guarantee ..................................................................................................... ii
A.5 All Products ......................................................................................................................... ii
A.6 Liability ..............................................................................................................................iii
A.7 © ADB BVBA ......................................................................................................................... iv
1.0 Safety .......................................................................................................................................................................1
1.1 HAZARD Icons used in the manual ............................................................................................... 1
1.1.1 Qualified Personnel ......................................................................................................... 1
1.2 To use this equipment safely: .................................................................................................... 2
1.2.1 Additional Reference Materials: .......................................................................................... 2
1.2.2 Intended Use ................................................................................................................. 2
1.2.3 Fasteners ..................................................................................................................... 2
1.2.4 Operation ..................................................................................................................... 3
1.2.5 Storage ........................................................................................................................ 3
1.2.6 Material Handling Precautions .............................................................................................3
1.2.7 Action in the Event of a System or Component Malfunction .......................................................... 4
1.2.8 Maintenance .................................................................................................................. 4
1.2.9 Maintenance and Repair ....................................................................................................4
2.0 ITCF LED Light ......................................................................................................................................................... 5
2.1 About this manual .................................................................................................................. 5
2.1.1 How to work with the manual ............................................................................................. 5
2.1.2 Record of changes ........................................................................................................... 5
2.2 Introduction ......................................................................................................................... 6
2.2.1 L852A-D, J & K ITCF ......................................................................................................... 6
2.2.1.1 Compliance with Standards .......................................................................................... 6
2.2.1.2 Uses...................................................................................................................... 6
2.2.1.3 Operating Conditions ................................................................................................. 6
2.2.1.4 Packaging ............................................................................................................... 6
2.2.1.5 Electrical Supply ...................................................................................................... 7
2.2.1.6 The ITCF Light Fixture ................................................................................................ 7
2.2.2 Typical Configuration ....................................................................................................... 7
2.2.2.1 Inner Pan Subassembly ............................................................................................... 8
2.2.2.2 Optical Unit L852A, B, C, J and ICAO Straight .................................................................... 8
2.2.2.3 Optical Unit L852D & K ............................................................................................... 8
2.3 Installation .......................................................................................................................... 9
2.3.1 Mechanical Requirements .................................................................................................. 9
2.3.2 Electrical Requirements ...................................................................................................11
2.3.3 Installing the Fixture ....................................................................................................... 12
2.3.3.1 Overview of Sequence of Work.................................................................................... 12
2.3.3.2 Safety Considerations............................................................................................... 13
2.3.3.3 Unpack the Unit ..................................................................................................... 13
2.3.3.4 Coding ................................................................................................................. 13
2.3.3.5 Verify Input Requirements and Equipment Needed ............................................................ 13
2.3.4 Snow Plow Ring Assembly ................................................................................................. 14
2.3.4.1 Installation on L-868 Base.......................................................................................... 16
2.3.5 Torquing and Installation Guidance for In-pavement Fixtures ...................................................... 17
2.3.5.1 Installation on a Shallow Base ..................................................................................... 17
2.4 Maintenance ....................................................................................................................... 18
2.4.1 L852 A-D ITCF Maintenance ............................................................................................... 18
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
TOC
© ADB Airfield Solutions All Rights Reservedvi
2.4.1.1 Cleaning the Light Channel and Prism ............................................................................ 18
2.4.1.2 Retorquing Mounting Bolts .......................................................................................... 18
2.4.1.3 Lifting Optical Unit Out of Base.................................................................................... 18
2.4.2 Repair Procedures .......................................................................................................... 19
2.4.2.1 Opening the Optical Unit ........................................................................................... 19
2.4.2.2 Replacing the Prism.................................................................................................. 20
2.4.2.3 Replacing a Prism on an L-852 LED Light Assembly ............................................................. 21
2.4.2.4 Testing an LED assembly ............................................................................................ 22
2.4.2.5 Replacing an LED Assembly ......................................................................................... 23
2.4.2.6 Replacing the Cord Set ............................................................................................. 24
2.4.2.7 Installing Power Supplies, Heaters, and Thermostats .......................................................... 25
2.4.2.8 Installing a New Optical Unit ....................................................................................... 28
2.4.2.9 Closing Optical Unit.................................................................................................. 29
2.4.3 Testing for Leaks ........................................................................................................... 30
2.5 Troubleshooting ................................................................................................................... 31
2.5.1 Troubleshooting Tips ......................................................................................................31
3.0 Appendix A.............................................................................................................................................................33
3.1 Installation Guidance for In-pavement Fixtures ............................................................................. 33
3.1.1 Reference Documents ..................................................................................................... 33
3.1.2 Mounting Systems ..........................................................................................................33
3.2 L-868 base can installation (load bearing) .................................................................................... 34
3.2.1 Use of Ceramic Bolts ......................................................................................................38
3.3 L-867 base can installation (non-load bearing) ..............................................................................39
3.4 Checking Bolt Torque ............................................................................................................ 42
4.0 Parts .......................................................................................................................................................................43
4.1 Part Diagrams and Part Numbers ............................................................................................... 44
4.1.1 ITCF Spare Parts ........................................................................................................... 50
© ADB Airfield Solutions All Rights Reserved 1
1.0 Safety This section contains general safety instructions for installing and using ADB Airfield
Solutions equipment. Some safety instructions may not apply to the equipment in this
manual. Task- and equipment-specific warnings are included in other sections of this manual
where appropriate.
1.1 HAZARD Icons
used in the manual
For all HAZARD symbols in use, see the Safety section. All symbols must comply with ISO
and ANSI standards.
Carefully read and observe all safety instructions in this manual, which alert you to safety
hazards and conditions that may result in personal injury, death or property and equipment
damage and are accompanied by the symbol shown below.
1.1.1 Qualified Personnel
WARNING
Failure to observe a warning may result in personal injury, death or equipment damage.
DANGER - RISK OF ELECTRICAL SHOCK OR ARC FLASH
Disconnect equipment from line voltage. Failure to observe this warning may result in
personal injury, death, or equipment damage. ARC Flash may cause blindness, severe
burns or death.
WARNING - WEAR PERSONAL PROTECTIVE EQUIPMENT
Failure to observe may result in serious injury.
WARNING - DO NOT TOUCH
Failure to observe this warning may result in personal injury, death, or equipment
damage.
CAUTION
Failure to observe a caution may result in equipment damage.
IMPORTANT INFORMATION
The term qualified personnel is defined here as individuals who thoroughly understand the equipment and its safe
operation, maintenance and repair. Qualified personnel are physically capable of performing the required tasks,
familiar with all relevant safety rules and regulations and have been trained to safely install, operate, maintain and
repair the equipment. It is the responsibility of the company operating this equipment to ensure that its personnel meet
these requirements.
Always use required personal protective equipment (PPE) and follow safe electrical work practices.
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
To use this equipment safely:
© ADB Airfield Solutions All Rights Reserved2
1.2 To use this
equipment safely:
1.2.1 Additional Reference
Materials:
1.2.2 Intended Use
1.2.3 Fasteners
WARNING
Read installation instructions in their entirety before starting installation.
Become familiar with the general safety instructions in this section of the manual before installing, operating,
maintaining or repairing this equipment.
Read and carefully follow the instructions throughout this manual for performing specific tasks and working with
specific equipment.
Make this manual available to personnel installing, operating, maintaining or repairing this equipment.
Follow all applicable safety procedures required by your company, industry standards and government or other
regulatory agencies.
Install all electrical connections to local code.
Use only electrical wire of sufficient gauge and insulation to handle the rated current demand. All wiring must meet
local codes.
Route electrical wiring along a protected path. Make sure they will not be damaged by moving equipment.
Protect components from damage, wear, and harsh environment conditions.
Allow ample room for maintenance, panel accessibility, and cover removal.
Protect equipment with safety devices as specified by applicable safety regulations.
If safety devices must be removed for installation, install them immediately after the work is completed and check
them for proper functioning prior to returning power to the circuit.
Failure to follow these warnings may result in serious injury or equipment damage.
IMPORTANT INFORMATION
IEC - International Standards and Conformity Assessment for all electrical, electronic and related technologies
IEC 60364 - Electrical Installations in Buildings
FAA Advisory: AC 150_5340_26 (current edition) Maintenance of Airport Visual Aid Facilities
ANSI/NFPA 79, Electrical Standards for Metalworking Machine Tools.
National and local electrical codes and standards.
WARNING
IMPROPER USE
Using this equipment in ways other than described in this manual may result in personal injury, death or property and
equipment damage. Use this equipment only as described in this manual.
THESE WARNINGS MAY RESULT IN SERIOUS INJURY OR EQUIPMENT DAMAGE.
WARNING
FOREIGN OBJECT DAMAGE - FOD
Only use fasteners of the same type as the one originally supplied with the equipment.
Always tighten the fasteners to the recommended torque. Use a calibrated torque wrench and apply the
recommended adhesive type.
Obey the instructions of the adhesives necessary for the fasteners.
Failure to follow these warnings may cause the fasteners to loosen, damage the
equipment, potentially to loosen the equipment. This can lead to a highly dangerous
situation of FOD, with potential lethal consequences.
© ADB Airfield Solutions All Rights Reserved 3
1.2.4 Operation
1.2.5 Storage
1.2.6 Material Handling
Precautions
CAUTION
IMPROPER OPERATION
Only qualified personnel, physically capable of operating the equipment and with no impairments in their judgment
or reaction times, should operate this equipment.
Read all system component manuals before operating this equipment. A thorough understanding of system
components and their operation will help you operate the system safely and efficiently.
Before starting this equipment, check all safety interlocks, fire-detection systems, and protective devices such as
panels and covers. Make sure all devices are fully functional. Do not operate the system if these devices are not
working properly. Do not deactivate or bypass automatic safety interlocks or locked-out electrical disconnects or
pneumatic valves.
Protect equipment with safety devices as specified by applicable safety regulations.
If safety devices must be removed for installation, install them immediately after the work is completed and check
them for proper functioning.
Route electrical wiring along a protected path. Make sure they will not be damaged by moving equipment.
Never operate equipment with a known malfunction.
Do not attempt to operate or service electrical equipment if standing water is present.
Use this equipment only in the environments for which it is rated. Do not operate this equipment in humid,
flammable, or explosive environments unless it has been rated for safe operation in these environments.
Never touch exposed electrical connections on equipment while the power is ON.
Failure to follow this instruction can result in equipment damage.
CAUTION
IMPROPER STORAGE
If equipment is to be stored prior to installation, it must be protected from the weather and kept free of condensation
and dust.
Failure to follow this instruction can result in equipment damage.
CAUTION
ELECTROSTATIC SENSITIVE DEVICES
This equipment may contain electrostatic sensitive devices.
Protect from electrostatic discharge.
Electronic modules and components should be touched only when this is unavoidable e.g. soldering, replacement.
Before touching any component of the cabinet you should bring your body to the same potential as the cabinet by
touching a conductive earthed part of the cabinet.
Electronic modules or components must not be brought in contact with highly insulating materials such as plastic
sheets, synthetic fiber clothing. They must be laid down on conductive surfaces.
The tip of the soldering iron must be grounded.
Electronic modules and components must be stored and transported in conductive packing.
Failure to follow this instruction can result in equipment damage.
WARNING
UNSTABLE LOAD
Use extreme care when moving heavy equipment.
Verify that the moving equipment is rated to handle the weight.
When removing equipment from a shipping pallet, carefully balance and secure it using a safety strap.
Failure to follow these instructions can result in death, serious injury, or equipment
damage.
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
To use this equipment safely:
© ADB Airfield Solutions All Rights Reserved4
1.2.7 Action in the Event
of a System or Component
Malfunction
1.2.8 Maintenance
1.2.9 Maintenance and
Repair
DANGER
ARC FLASH AND ELECTRIC SHOCK HAZARD
Do not operate a system that contains malfunctioning components. If a component malfunctions, turn the system
OFF immediately.
An open airfield current circuit is capable of generating >5000 Vac and may appear OFF to a meter.
Never unplug a device from a constant current circuit while it is operating. Arc flash may result.
Disconnect and lock out electrical power.
Allow only qualified personnel to make repairs. Repair or replace the malfunctioning component according to
instructions provided in its manual.
Failure to follow these warnings will result in death or equipment damage.
WARNING
ELECTRIC SHOCK HAZARD
Do not operate a system that contains malfunctioning components. If a component malfunctions, turn the system
OFF immediately.
Disconnect and lock out electrical power.
Allow only qualified personnel to make repairs. Repair or replace the malfunctioning component according to
instructions provided in its manual.
Failure to follow these warnings will result in death or equipment damage.
DANGER
ARC FLASH AND ELECTRIC SHOCK HAZARD
Allow only qualified personnel to perform maintenance, troubleshooting, and repair tasks.
Only persons who are properly trained and familiar with ADB Airfield Solutions equipment are permitted to service
this equipment.
An open airfield current circuit is capable of generating >5000 Vac and may appear OFF to a meter.
Never unplug a device from a constant current circuit while it is operating. Arc flash may result.
Disconnect and lock out electrical power.
Always use safety devices when working on this equipment.
Follow the recommended maintenance procedures in the product manuals.
Do not service or adjust any equipment unless another person trained in first aid and CPR is present.
Connect all disconnected equipment ground cables and wires after servicing equipment. Ground all conductive
equipment.
Use only approved ADB Airfield Solutions replacement parts. Using unapproved parts or making unapproved
modifications to equipment may void agency approvals and create safety hazards.
Check the interlock systems periodically to ensure their effectiveness.
Do not attempt to service electrical equipment if standing water is present. Use caution when servicing electrical
equipment in a high-humidity environment.
Use tools with insulated handles when working with airfield electrical equipment.
Failure to follow these warnings will result in death or equipment damage.
© ADB Airfield Solutions All Rights Reserved 5
2.0 ITCF LED Light ITCF-L LED Taxiway Centerline Light. The ITCF-L operates on both 3-step and 5-step CCRs
and can be powered with any CCR architecture type. When quartz-incandescent fixtures are
replaced with LED fixtures, airport staff can add more lights without increasing CCR size.
2.1 About this manual The manual shows the information necessary to:
Install and maintain the L-852A-D, J & K ITCF, F-Range, LED Taxiway Centerline Light.
2.1.1 How to work with the
manual
1. Become familiar with the structure and content.
2. Carry out the actions completely and in the given sequence.
2.1.2 Record of changes
PAGE REV DESCRIPTION CHECKED APPROVED DATE
All A Released new manual GM DM 12/20/13
All B Updated manual RW JC 8/15/15
All C update manual, parts, torque RW JC 6/16/16
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Introduction
© ADB Airfield Solutions All Rights Reserved6
2.2 Introduction
2.2.1 L852A-D, J & K ITCF
2.2.1.1 Compliance with
Standards
FAA: L-852(L) Series AC 150/5345-46 (Current Edition) and the FAA Engineering Brief No.
67. ETL Certified.
ICAO Taxiway Centerline Straight fixture designed according to ICAO Annex 14 Appendix 2.
Fig. A2-13
2.2.1.2 Uses
2.2.1.3 Operating Conditions
Temperature:
-40°C to +55°C (-40°F to +131°F)
Altitude: Sea level to 10,000 feet (3000 m)
Relative Humidity: Up to 100%
2.2.1.4 Packaging
In cardboard box: 7 x 13 x 13 in (17.8 x 33 x 33 cm)
Weight with packing: 15.3 lb (6.94 kg)
Weight without packing: 12.3 lb (5.58 kg)
WARNING
Read installation instructions in their entirety before starting installation.
Become familiar with the general safety instructions in this section of the
manual before installing, operating, maintaining or repairing this
equipment.
Read and carefully follow the instructions throughout this manual for
performing specific tasks and working with specific equipment.
Failure to follow these warnings may result in serious injury or
equipment damage.
FAA L-852A(L)
Taxiway centerline on straight sections and clearance bar in category I and
II applications, >
1,200 ft RVR
FAA L-852B(L)
Taxiway centerline on curved sections in category I and II applications,
>1,200 ft RVR
FAA L-852C(L)
Taxiway centerline on straight section and clearance bar in category III
applications,
FAA L-852D(L)
Taxiway centerline on curved sections in category III applications, <1,200
ft RVR
White/white or white/yellow used on MIRL runway edge for intersections
where runway edge spacing >400 ft (122 m)
FAA L-852J(L)
Taxiway centerline on curved sections in category I and II applications,
>
1,200 ft RVR
FAA L-852K(L)
Taxiway centerline on curved sections in category III applications, <1,200
ft RVR
NOTE: Use of two LED modules allows the option of separate control of each module in
bi-directional applications.
© ADB Airfield Solutions All Rights Reserved 7
2.2.1.5 Electrical Supply ITCF LED F-Range fixture is designed to work with any IEC or
FAA-compliant transformer up
to 100 W without affecting the performance or lifetime of the light fixture or transformer. See
data sheet 3033 for more details on recommended isolation transformers specified below.
1
One cord set
2
One cord set per side (2 total)
3
Fixture load does not include isolation transformer load
2.2.1.6 The ITCF Light Fixture
2.2.2 Typical Configuration F-Range in-pavement light fixtures are available in unidirectional, standard bidirectional and
switchable bidirectional, and are designed to provide visual guidance along the taxiway
centerlines. (see Figure 1).
The light fixtures are manufactured in accordance with FAA specification AC 150/5345-46
(current edition), Style 3: 1/4 in. (6.35mm) height above grade.
The ICAO straight and curved fixture is designed to be in compliance with ICAO Annex 14.
ITCF Fixture Fixture Load3 Isolation Transformer
L-852D(L), L-852K(L)
Unidirectional w/out heater 21 VA 20/25 W
Bidirectional w/out heater
1
27 VA 30/45 W
Bidirectional w/out heater
2
25 VA per side
(50 VA total)
20/25 W per side
Unidirectional with heater 56 VA 65 W
Bidirectional with heater
1
58 VA 65 W
Bidirectional with heater
2
45 VA
(90 VA total)
30/45 W per side
L-852C(L), L-852J(L)
Unidirectional w/out heater 14 VA 10/15 W
Bidirectional w/out heater
1
17 VA 20/25 W
Bidirectional w/out heater
2
14 VA per side
(28 VA total)
10/15 W per side
Unidirectional with heater 46 VA 30/45 W
Bidirectional with heater
1
56 VA 65 W
Bidirectional with heater
2
34 VA
(68 VA total)
30/45 W per side
L-852A(L), L-852B(L)
Unidirectional w/out heater 12 VA 10/15 W
Bidirectional w/out heater
1
16 VA 10/15 W
Unidirectional with heater 42 VA 30/45 W
Bidirectional with heater
1
46 VA 30/45 W
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Introduction
© ADB Airfield Solutions All Rights Reserved8
Figure 1: View of LED In-Pavement ITCF Light Fixture (Typical Configuration)
2.2.2.1 Inner Pan Subassembly The inner cover assembly includes the inner cover, L-823 cord sets, and the power supply, as
shown in Figure 1.
2.2.2.2 Optical Unit L852A, B,
C, J and ICAO Straight
Figure 2: Optical Unit 48A0444-XXX-XXX for L852A, B, C, J and ICAO Straight
2.2.2.3 Optical Unit L852D & K Figure 3: Optical Unit 48A0443-XXX-XXX for L852D and K
48A0444/ X X X
G R N = Green
Y L W = Amber
W H T = WHITE
R E D = RED
48A0443/ X X X
G R N = Green
Y L W = Yellow
© ADB Airfield Solutions All Rights Reserved 9
2.3 Installation
In-pavement fixtures must be installed according to the plans and specifications; the
applicable regulatory guidance; and the manufacturer’s instruction manual. For FAA
applications, installation guidance is provided in AC 150/5340-30 (current edition).
Following are a number of items to be aware of:
2.3.1 Mechanical
Requirements
1. Correct dimensional placement of the lights is of prime importance. To achieve this,
careful attention to detail is required. Survey instruments may be used to accurately
position all fixtures for their precise location, elevation, and azimuth. The tolerances
required in FAA AC 150/5340-30, and the plans, must not be exceeded. The light beam
must be aligned as described in FAA AC 150/5340-30 with a horizontal tolerance of ±1
degree. The light fixture must be level, and the top outside edge of the fixture must be
between +0 inch and -1/16 inch (1.5875 mm) with respect to the surrounding pavement.
See FAA AC 150/5340-30, Chapter 11, Fixture Mounting Bases, for additional guidance
on installing Light Bases. Incorrect installation may cause the light output to appear to be
too dim or too bright. Incorrect installation may also increase the risk for fixture
mechanical failures.
2. Insure all base can mounting surfaces are free of dust, dirt or debris.
3. Per FAA AC 150/5340-30, Chapter 10, and FAA Engineering Brief No 83, the fixture must
be mounted using properly installed anti-vibration lock washers under the mounting bolts.
An anti-vibration lock washer is composed of a pair of unique washers with radial teeth
that grip and seat the mating surfaces. The rise of the cams between the face of washers
is greater than the pitch of the bolt. This creates tension that positively locks the bolt. Use
extreme care when placing the two halves of the lock washer together. The cams (or
steps) of each half of the lock washer must face each other.
4. Per FAA AC 150/5340-30, Chapter 10, and FAA Engineering Brief No 83, it is extremely
important that other types of washers, such as split washers, must not
be used. Failure to
use properly installed anti-vibration lock washers will cause mounting bolts to become
loose. Loose bolts increase the risk for fixture mechanical failures. Loose bolts can also
increase fixture slippage which increases the shear load on the bolts. This can cause
individual bolt failure, resulting in increased load on the remaining bolts. Finally, this can
result in an increased risk that bolts come out or shear-off, causing the bolt and fixture to
become FOD on the Runway or Taxiway.
5. Consider the use of ceramic bolts, especially if stainless steel Light Bases are being used.
Guidance on the application of ceramic bolts is given in FAA Engineering Brief No 83.
6. The fixture hold down bolts must be torqued properly and must not be over torqued.
Recommended torque values are given in “Installation on L-868 Base” on page 16. If the
torque limit is exceeded (typically due to the use of impact wrenches), the bolt is
WARNING
Read installation instructions in their entirety before starting installation.
Become familiar with the general safety instructions in this section of the
manual before installing, operating, maintaining or repairing this
equipment.
Read and carefully follow the instructions throughout this manual for
performing specific tasks and working with specific equipment.
Failure to follow these warnings may result in serious injury or
equipment damage.
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Installation
© ADB Airfield Solutions All Rights Reserved10
overstressed and is on its way to failure. After corrosion occurs, removal can cause the
head to snap off. The head can then become FOD.
© ADB Airfield Solutions All Rights Reserved 11
2.3.2 Electrical
Requirements
1. One of the most common causes of water leakage within in-pavement fixtures is a
pinched cord-set. It is commonly caused by trapping the fixture wires when the fixture is
installed on the base can. Use caution when mounting the fixture on the base can to
prevent the incoming wires from becoming pinched.
2. If the wire conductor jacket is compromised, the entire cord-set must be replaced.
3. Never use electrical tape to repair the cord-set, since taping will not adequately seal the
wire conductor jacket adequately to prevent water leakage.
4. Never pick the fixture up using the electrical connection leads. Picking the fixture up by
the leads can cause a break in the wire conductor jacket. If the wire conductor jacket is
cut, water is drawn in during the On and Off periods due to thermal cycling of the fixture.
5. Insure that the primary isolation transformer connection splicing methods as shown in
FAA AC 150/5340-30 are followed. It is also recommended that heat shrink be used on
each primary isolation transformer connection to minimize the risk of overall series circuit
insulation resistance degradation.
6. Verify the correct current levels are coming into the fixture. Measure the fixture input
current on a sample of fixtures using a True RMS ammeter. If current is not correct at
each CCR step:
a. Verify the primary isolation transformer current is correct at all steps. If the primary
current is incorrect, the CCR may need to be calibrated or repaired.
b. Incorrect primary isolation transformer current may also be caused by low overall
series circuit insulation resistance. Meg the series circuit and repair if necessary.
7. Verify each isolation transformer wattage matches the wattage indicated in the “Electrical
Supply ” on page 7.
8. Verify each isolation transformer ratio is correct. For a 6.6A CCR, the isolation
transformer must have a ratio of 6.6A/6.6A. For a 20A CCR, the isolation transformer
must have a ratio of 20A/6.6A.
Where to obtain the documents mentioned in this Installation Guidance document:
FAA AC 150/5340-30, Design and Installation Details for Airport Visual Aids, may be
downloaded at http://www.faa.gov/airports/resources/advisory_circulars/
ADB Instruction Manuals may be downloaded at:
http://www.adb-airfield.com/product_center/products.aspx
. Then click on the “In-pavement
Lighting” tab and then click on the link for your particular fixture. The manuals are in the
“Literature Downloads” tab.
FAA Engineering Brief 83,
In-Pavement Light Fixture Bolts, may be downloaded at:
http://www.faa.gov/airports/engineering/engineering_briefs/
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Installation
© ADB Airfield Solutions All Rights Reserved12
2.3.3 Installing the Fixture This section provides installation instructions for the L852C-D and ICAO ITCF fixtures.
NOTE: Also see the following:
“Installing a New Optical Unit” on page 28.
NOTE: Light Detail:
2.3.3.1 Overview of Sequence
of Work
1. Electrical contractor locates new light bases and interconnecting conduit trench, and
excavates for light base bottom section by saw cutting or core drilling. Electrical contractor
prepares subgrade and stone subbase, sets bottom section with rebar, rigid steel conduit
stubs and drain, and pours high early strength concrete-encasement excavation.
Electrical contractor shall record can locations and elevations of mud plate after concrete-
encasement.
Electrical contractor excavates conduit trench, installs rigid steel and fittings, backfills
conduit trench with high early strength concrete.
2. General contractor prepares and installs concrete pavement. Electrical contractor makes
a pilot core to find mud plate center point indent before final core-drilling.
3. Electrical contractor core-drills concrete pavement. Electrical contractor installs top
section, y-flange ring, space and lighting fixture, and pours epoxy joint sealer. Provide
space for adjustment with spacers, maximum number of spacers shall be 3.
4. Se specific details as shown in FAA AC 150/5340-30 (current edition).
1. Light bases shall be installed with care to assure vertical & azimuth alignment of
fixture.
2. Provide 2'-3' cable slack within light base to allow transformer servicing.
3. Bolts and washers used during installation of base, cable and transformers shall
be replaced with new, for final installation. The minimum thread engagement into
top flange of base is 0.5".
4. As required to maintain +0/ through -1/16" below grade FAA installation
tolerance, a maximum of three spacer rings may be stacked together.
© ADB Airfield Solutions All Rights Reserved 13
2.3.3.2 Safety Considerations Read the installation section of all system component manuals before installing this
equipment. A thorough understanding of system components and their requirements will
promote safe and efficient installation. See FAA AC 150/5340-30, Design and Installation
Details for Airport Visual Aids, and site plans and specifications for field installation of taxiway
in-pavement lights.
2.3.3.3 Unpack the Unit To reduce the possibility of damaging the light assembly, unpack the F-Range components at
the installation site. The F-Range fixtures may be packed in individual boxes; for larger
quantities, up to 36 fixtures may be packed in one box.
To unpack the F-Range fixture, open the box flaps and carefully remove the top packing
material.
If damage to any equipment is noted, file a claim form with the carrier immediately.
2.3.3.4 Coding Review the coding details for the appropriate type of F-Range fixture before installation.
If applicable, verify you have the correct kit for the light fixture you are upgrading.
L-852A, B, C, D, J, K and ICAO Coding are identified in “Parts” on page 43.
NOTE: The triangular arrowhead on the top of the fixture shows the location of the index pin
in the lower cover. The arrowhead pointer does NOT indicate any geographical orientation or
placement.
2.3.3.5 Verify Input
Requirements and Equipment
Needed
The F-Range light fixture is designed for connection to a 6.6A or 20A series lighting circuit via
an L-830 (60 Hz) or L-831 (50 Hz) isolation transformer.
Make sure you have the necessary tools and materials ready for installation (not supplied).
Also consider other tools that might be needed based on site-specific conditions.
Table 1: Suggested Tools and Materials for Installation and Repair
WARNING
Allow only qualified personnel to install ADB Airfield Solutions and auxiliary
equipment. Use only approved equipment. Using unapproved equipment in
an approved system may void FAA approvals. Observe and follow the
safety instructions in this document and all other related documentation.
Make sure all equipment is rated and approved for the environment where
it is being used.
Failure to follow these warnings may result in serious injury or
equipment damage.
Qty. Description Qty. Description
1 Torque wrench
1
Set of screwdrivers, one with 3/8" (9.525mm)
minimum blade width
1 Alignment jig
1 Diamond-faced core drill
As
needed
Silicone grease
1
Diamond-faced saw, 3/8" (9.525mm)
thick
As
needed
Joint sealing filler
1 Crimping tool 1 Pressure test fitting assembly
1 Small water suction pump
As
needed
Dow Corning Molykote
®
3452 or equal
(ADB P/N 67A0095) - used on top cover
prism seal
2
Eyebolts, 3/8 inch (9.525mm)
diameter
1 Lifting rod, 16 inches (406mm) long
As
needed
Novagard
®
Silicone Versilube
®
G322L
(ADB P/N 67A0009) - used on O-ring
between top cover and inner pan assembly;
also may be applied to four nipples of inner
pan assembly to install optical assembly
1 or 2 L-830 / L-831 isolation transformer
1 Set of fiber brushes
1
Set of socket wrenches, 1/2"
(12.7mm) drive
L-852A-D, J & K ITCF, F-Range, ICAO LED Taxiway Centerline Light
96A0460 Rev. C
Installation
© ADB Airfield Solutions All Rights Reserved14
2.3.4 Snow Plow Ring
Assembly
Figure 4: Snow Plow Ring
SEE NOTE 1 OF PAGE 5
44A6760-X3X0
TOP CVR ASSEM., BI-DIR., L-852B
44A7335-XXXXX
BOTTOM PAN ASSEMBLY, NO MONITOR, STYLE 6
60A3202
THREADED DOWEL PIN
62A2193
2-PIECE ITCF SNOW PLOW RING
64A0176-20
HBOLT 0.3750-16x1.25x1.25-N
ACC0375
CEC LOCKWASHER PAIRS S.S 3/8" 2 EA
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58

ADB L-852B User manual

Type
User manual

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI
