SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
A-series POE Camera Basic Instruction
Version 20191016
Directory
1. Overview......................................................................................................................................................................................................... 2
1.1 Video tutorials..................................................................................................................................................................................... 2
2. Installation of POE Camera......................................................................................................................................................................... 3
2.1 Camera Interface Introduction..........................................................................................................................................................3
2.2 Work with Poe injector or Poe switch..............................................................................................................................................3
2.3 Work with 12v adapter.......................................................................................................................................................................3
2.4 Installation of Multiple PoE Cameras System ...............................................................................................................................4
FULUVA Recommended combination :................................................................................................................................................ 4
FULUVA 8ch 4K NVR......................................................................................................................................................................4
3. Search & Modify IP Address of Camera....................................................................................................................................................5
3.1 Download Software and install.........................................................................................................................................................5
http://www.fuluva.cn/a-support.html....................................................................................................................................................... 5
3.2 Search Camera and Modify IP......................................................................................................................................................... 5
3.3 Preview camera video in “AjDevTool”.............................................................................................................................................6
4. Configure in the Web browser.....................................................................................................................................................................7
4.1 Log in camera website.......................................................................................................................................................................7
4.2 Configure Camera parameters.........................................................................................................................................................9
4.2.1 P2P (Remote Monitor Service)............................................................................................................................................ 9
4.2.2 Video Encode (Resolution and H.265 or H.264).............................................................................................................10
5. APP user guide............................................................................................................................................................................................11
5.1 Download APP and Install.............................................................................................................................................................. 11
Scan the QR code to download the APP................................................................................................................................... 11
5.2 Add Camera into APP..................................................................................................................................................................... 12
6. LMS user guide............................................................................................................................................................................................13
7. Integration with 3rd software..................................................................................................................................................................... 16
7.1 RTSP.................................................................................................................................................................................................. 16
x.x.x.x is camera ip address......................................................................................................................................................... 16
7.2 Blue Iris.............................................................................................................................................................................................. 16
7.3 ZoneMinder....................................................................................................................................................................................... 17
7.4 Security Eye...................................................................................................................................................................................... 19
7.5 ISPY................................................................................................................................................................................................... 22
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
7.6 Ivideon................................................................................................................................................................................................23
8. Work with ONVIF NVR............................................................................................................................................................................... 27
9. Q&A............................................................................................................................................................................................................... 27
A: There are three scenarios.................................................................................................................................................................28
1. Overview.
FULUVA A-series POE Camera is the professional HD security surveillance camera series launched by the
FULUVA security team in 2018. Simple, durable, cost-effective is the product purpose of A-series cameras. We
hope every customer can become our long-term partner.
Every customer of A-series Camera recevices FULUVA lifetime technical support service.
Support Email : support@fuluva.cn
Support Skype : support@fuluva.cn
Office Website : www.fuluva.cn
When you receive the product, please send an email to us, so that we can update the new version of
firmware and user guide for you.
Please feel free to contact us with any questions and we will reply to you as soon as possible.
1.1 Video tutorials.
Video tutorial 1 - Download Tools and Configure Camera.
YOUTUBE Play : https://youtu.be/i-zc-ss8JIg
Video tutorial 2 - How to Install PoE Camera.
YOUTUBE Play : https://youtu.be/dKrtKTY5Aj0
Video tutorial 3 - APP User Guide.
YOUTUBE Play : https://youtu.be/jgg7xQLSwEg
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
2. Installation of POE Camera.
2.1 Camera Interface Introduction.
RJ45 Network Interface : Support IEEE 802.3af/at PoE Standard.
DC 12V Interface : If you do not use POE power, you can use a 12V2A DC power adapter to power the camera.
Light sensor & IR LED : Auto identify day and night, turn on IR LED at night and turn off IR LED at day.
2.2 Work with Poe injector or Poe switch.
2.3 Work with 12v adapter.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
2.4 Installation of Multiple PoE Cameras System .
FULUVA Recommended combination :
FULUVA 8ch 4K NVR
Amazon Sale Link :
www.amazon.com/dp/B07XG9ZBKG
Amazon Sale Price :
$60.00
FULUVA Gigabit 11 Port PoE Switch | 8 port Poe + 2 Gigabit Uplink +
1 SFP | 120W | 250m
Amazon Sale Link :
www.amazon.com/dp/B07XGB1G3Y
Amazon Sale Price :
$45.00
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
3. Search & Modify IP Address of Camera.
3.1 Download Software and install.
3.1.1 FULUVA A-series Camera software download website:
http://www.fuluva.cn/a-support.html
3.1.2 Download and Install “AjDevTools”.
About AjDevTools :
Network Search, Batch configuration & Upgrade tool For FULUVA A-series Camera .
3.2 Search Camera and Modify IP.
“Start Search” -> You will find cameras (You've installed it) in the list.
Select camera -> IP Batch Setting.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
IP Batch Setting -> IP Batch Manual Setting (recommended) or DHCP .
Tips :
For long-service security camera , we recommend that the camera use fixed IP (Manual IP) because DHCP
changes the IP address as the router reassign the IP. Frequent IP changes can affect your user experience, so we
recommend that you use a manually fixed IP and make sure that the IP does not conflict.
Input your camera network info -> Check.
Good network info will show “IP address Check OK”
-> OK. You will save the setting of ip address .
3.3 Preview camera video in “AjDevTool”.
Right Click -> One-click play -> Preview Sub Stream (default) of Camera.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
Right Click -> Stream -> Main Stream -> Preview Main Stream
Tips :
The camera provide main stream and sub stream at same time. Main stream is high resolution and sub
stream is anther resolution. Of course, these resolution and encode type are configurable.We'll talk about that in
4.2.2 .
4. Configure in the Web browser.
4.1 Log in camera website.
Enter your camera ip adress into the browser address bar.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
For example :
my camera ip is 192.168.31.160.
Select Web Language .
Default Username is admin
Defualt Password is 123456
--> Login
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
4.2 Configure Camera parameters.
Click Configuration ->
4.2.1 P2P (Remote Monitor Service).
P2P is remote monitoring technology. We need to Enable P2P . Configuration->Network -> P2P.
Cloud Type : Danale
Login Status :
Online or Offline. For remote Internet access, we
need to ensure that this status is Online.
QR Code :
This QR code will be used when we add
cameras to the APP.We'll talk about that in 5.2 .
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
4.2.2 Video Encode (Resolution and H.265 or H.264).
Camera -> Video
Encode Mode : Support H265 and H264.
We recommend H265, an advanced encoding type that saves network bandwidth and storage space.
However, if your decoder device or software does not support H265, you will need to set it to H264 here.
Resolution :
All FULUVA A-series cameras support multiple resolution Settings, and the default factory resolution maybe
is not the highest one in the list of supported resolutions. Please understand this.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
5. APP user guide.
5.1 Download APP and Install.
Scan the QR code to download the APP
APP Name is DANALE .
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
5.2 Add Camera into APP.
Add devices - > Click “Qr code to add” (Please See 4.2.1 P2P configuration)
Camera QR Code is Here. Configuration-> Network-> P2P (Enable P2P and Login status is online).
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
View Camera Video in Danale.
6. LMS user guide.
About LMS:
FULUVA Windows Client With Camera Configuration, Camera Manager , Live view,
Recording, Alarm, Playback function For FULUVA A-series Camera .
Download website:
http://www.fuluva.cn/a-support.html
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
Default Username of LMS is admin
Default Password of LMS is 123456
Add a camera into LMS.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
Auto Search -> Select Camera in the search list -> Add.
Open a liveView Window. You will view a camera you added.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
7. Integration with 3
rd
software.
Please complete “3. Search and modify ip address of camera” before doing the following step. You need to
know your camera's configured ip address.
7.1 RTSP.
MainStream:
rtsp://admin:123456@x.x.x.x:554/stream0
SubStream:
rtsp://admin:123456@x.x.x.x:554/stream1
x.x.x.x is camera ip address.
admin is default camera username.
123456 is default camera password.
For example:
My camera ip is 192.168.31.160.
My camera main stream rtsp url : rtsp://admin:123456@192.168.31.160:554/stream0
About the setting of mainstream and substream please see 4.2.2 encode configuration of camera.
7.2 Blue Iris.
Open Blue Iris
Add Camera to Blue Iris. Enter RTSP url into “Address”.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
View Camera Video in Blue Iris.
7.3 ZoneMinder.
Open ZoneMinder Console Web.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
Add Camera into ZoneMinder List. Enter RTSP url into Source Path in ZoneMiner.
Note : Please refer to the camera actual configuration for Zoneminder's stream-related configuration .Please see
4.2.1 Encode configuration of Camera.
View Camera Video in ZoneMinder .
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
7.4 Security Eye.
Open Security Eye.
Add camera to Security Eye.
Security EYE could not search the camera, we need to add it to the list manually.
SHENZHEN EASTVISION ELECTRONICS CO.,LTD
http://www.fuluva.cn
Head office: ShaJin Town,BaoAn ,Shenzhen City
Select Onvif Brand , Enter IP address and port 554.
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
-
1
-
2
-
3
-
4
-
5
-
6
-
7
-
8
-
9
-
10
-
11
-
12
-
13
-
14
-
15
-
16
-
17
-
18
-
19
-
20
-
21
-
22
-
23
-
24
-
25
-
26
-
27
-
28
Ask a question and I''ll find the answer in the document
Finding information in a document is now easier with AI
Other documents
-
NexTrend 3216560508 User manual
-
Q-See QT8516-4Z7-1 Installation guide
-
PROLINK PIC1006WN-HD User manual
-
REOLINK PoE Security Camera System User guide
-
JCO Electronic Technology 1080P HD Panoramic Indoor camera User manual
-
Panoeagle PoE Security Camera System User manual
-
Selve Home_integration of IP cameras Operating instructions
-
APPRO TECHNOLOGY LC-6865 Quick Installation Manual
-
GPI LPR CAM User guide
-
Hikvision 2MP POE Security Camera System User guide
