Lopi Radiant Plus Large™ Gas Fireplace Insert User manual

Lopi
Brand
Lopi
Model
Radiant Plus Large™ Gas Fireplace Insert
Type
User manual

This manual is also suitable for

Radiant Plus
Face (Large, Medium or Small)
See SKUs Below
Page 1 of 1 17601902 - Printed 3/13/18 © Travis Industries, Inc.
SKUs
Large Radiant Plus
SKU
Height
Width
Universal w Door – Large Radiant Plus
95200527
30-1/2”
40”
Times Square w Door – Large Radiant Plus*
95200528
27-3/4”
35-1/2”
Designer w Door – Large Radiant Plus
95200529
25-5/8”
35-7/8” **
Medium Radiant Plus
SKU
Height
Width
Universal w Door – Medium Radiant Plus
95200267
25”
37”
Times Square w Door – Medium Radiant Plus*
95200268
23-5/8”
31-7/8”
Designer w Door – Medium Radiant Plus
95200269
21-5/8”
32” **
Small Radiant Plus
SKU
Height
Width
Universal w Door – Small Radiant Plus
95200172
22-3/8”
34-1/2”
Times Square w Door – Small Radiant Plus*
95200173
20-9/16”
29-5/16”
Designer w Door – Small Radiant Plus
95200174
19-1/8”
29-1/8” **
* The Times Square face, when installed, is 9/16” above the base of the insert.
** The Designer face is ½” wider than this dimension at the top.
Installation
1. The insert should be in position with gas line and flue/intake attached. If using a surround panel, it should
be attached as well.
2. Attach the face to the insert as shown below.
