ENGLISH
TOCe
-- 3 5 --
1 DIRECTIVE 36........................................................
2SAFETY 36...........................................................
3 INTRODUCTION 37...................................................
3.1 TECHNICAL DATA: LKB 265 37...............................................
3.2 TECHNICAL DATA: LKB 320 38...............................................
4 INSTALLATION 39....................................................
4.1 Mains supply 39..............................................................
4.2 Assembly of components 40...................................................
4.3 Electrical installation 40.......................................................
4.4 TECHNICAL DESCRIPTION 41................................................
5 MAINTENANCE 42....................................................
6 ORDERING OF SPARE PARTS 42......................................
7 ACCESSORIES 42....................................................
DIAGRAM 99.........................................................
SPARE PARTS LIST 103................................................
-- 3 6 --
bc14d12e
1 DIRECTIVE
DECLARATION OF CONFORMITY
Esab Welding Equipment AB, 695 81 Laxå, Sweden, gives its unreserved guarantee
that welding power source LKB 265/320 from serial number 523/521 complies with
standard EN 60974--1, in accordance with the requirements of directive (73/23/ EEA)
and addendum (93/68/EEA).
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --------
Paul Karlsson
Managing Director
Esab Welding Equipment AB
695 81 LAXÅ
SWEDEN Tel: + 46 584 81000 Fax: + 46 584 12336
Laxå 95--11--10
2SAFETY
WARNING
READ AND UNDERSTAND THE INSTRUCTION MANUAL BEFORE INSTALLING OR OPERATING.
ARC WELDING AND CUTTING CAN BE INJURIOUS TO YOURSELF AND OTHERS. TAKE PRECAU-
TIONS WHEN WELDING. ASK FOR YOUR EMPLOYER’S SAFETY PRACTICES WHICH SHOULD BE
BASED ON MANUFACTURERS’ HAZARD DATA.
ELECTRIC SHOCK -- Can kill
S Install and earth the welding unit in accordance with applicable standards.
S Do not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.
S Insulate yourself from earth and the workpiece.
S Ensure your working stance is safe.
FUMES AND GASES -- Can be dangerous to health
S Keep your head out of the fumes.
S Use ventilation, extraction at the arc, or both, to keep fumes and gases from your breathing zone and
the general area.
ARC RAYS -- Can injure eyes and burn skin.
S Protect your eyes and body. Use the correct welding screen and filter lens and wear protective
clothing.
S Protect bystanders with suitable screens or curtains.
FIRE HAZARD
S Sparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.
NOISE -- Excessive noise can damage hearing
S Protect your ears. Use ear defenders or other hearing protection.
S Warn bystanders of the risk.
MALFUNCTION -- Call for expert assistance in the event of malfunction.
PROTECT YOURSELF AND OTHERS!
GB
-- 3 7 --bc14d12e
3 INTRODUCTION
LKB 265 and LKB 320 are step controlled power sources in a compact design, in -
tended for welding with solid steel, stainless steel or aluminium wire a s well as tubu -
lar wire with or without shielding gas.
The possibility of welding with homogeneous wire/shielding gas and welding with
gasless tubular wire is obtained by switching the + and -- connections on the switch-
ing terminal above the wire feed unit.
3.1 TECHNICAL DATA: LKB 265
Standard delivery:
Power source equipped with spot welding function and adjustable burnback time.
Integrated wire feed mechanism with feed roller for solid wire, diameter 0.8, and 1.0.
Welding torch PSF 250 4.5 m.
Return cable 4.5 m with return clamp.
Mains cable 3 m and gas hose.
Includes: Handle, (fitted with 2 screws,) gas cylinder shelf (fitted with 2 screws).
Voltage 400--415 V, 3 50 Hz
230/400--415/500V350Hz
230/440--460V, 360Hz
Permissible load at
100% duty cycle 150 A/22 V 150 A/22 V
60 % duty cycle 190 A/24 V 190 A/24 V
30 % duty cycle 265 A/27 V 265 A/27 V
Setting range (DC) 30A/15V--265A/27V 30A/15V--265A/27V
Open circuit voltage 15--38 V 15--38 V
Open circuit power 50 W 50 W
Efficiency 0.69 0.69
Power factor 0.97 0.97
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Dimensions lxwxh 770x520x620 770x520x620
Weight 92 kg 92 kg
Enclosure class IP 23 IP 23
Application classification
LKB 265 comply with the requirements of IEC 974--1.
GB
-- 3 8 --
bc14d12e
3.2 TECHNICAL DATA: LKB 320
Standard delivery:
Power source equipped with switch for 2/4 step trigger action with gas pre--flow and
gas post--flow in the 4 step mode and adjustable burnback time.
Integrated wire feed mechanism with feed roller for solid wire, diameter 1.0, and 1.2.
Welding torch PSF 315 4.5 m.
Return cable 4.5 m with return clamps.
Mains cable 5 m and gas hose.
Includes: Handle, (fitted with 2 screws,) gas cylinder shelf (fitted with 2 screws).
Voltage 400--415 V, 3 50 Hz
230/400--415/500V350Hz
230/440--460V, 360Hz
Permissible load at
100% duty cycle 195 A/24 V 195 A/24 V
60 % duty cycle 250 A/27 V 250 A/27 V
30 % duty cycle 320 A/30 V 320 A/30 V
Setting range (DC) 40A/16(14)V--320A/30V 40A/16(14)V--320A/30V
Open circuit voltage 16--40 V 16--40 V
Open circuit power 52 W 52 W
Efficiency 0.71 0.71
Power factor 0.97 0.97
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Dimensions lxwxh 770x520x620 770x520x620
Weight 112 kg 112 kg
Enclosure class IP 23 IP 23
Application classification
LKB 320 comply with the requirements of IEC 974--1.
The IP code indicates the enclosure class, i.e. the degree of protection against pene-
tration by solid objects and water.
Equipment marked IP 23 is designed for in-- and outdoor use.
The symbol indicates that the power source is designed for use in areas where
there is an increased electrical hazard.
GB
-- 3 9 --bc14d12e
4 INSTALLATION
WARNING
This product is intended for industrial use. In a domestic environment this prod-
uct may cause radio interfer ence. It is the users responsibility to take adequate
precautions.
Installation must be carried out by a qualified electrician.
Connect the power supply lead using the appropriate fuse in conformance with local
regulations.
Cable areas acc. to Swedish regulations.
Make sure the welding rectifier is not covered or positioned so that cooling is ob -
structed.
4.1 Mains supply
LKB 265 3 50 Hz 3 50 Hz 3 50 Hz 3 60 Hz 3 60 Hz
Voltage V 230 400/415 500 230 450
Current A 100% 13 7 5 11 7
60% 18 9 8 18 9
30% 27 16 13 27 16
Mains lead rating mm
Ο
4x2.5 4x1.5 4x1.5 4x2.5 4x1.5
Fuse slow A 20 16 16 20 16
LKB 320 3 50 Hz 3 50 Hz 3 50 Hz 3 60 Hz 3 60 Hz
Voltage V 230 400/415 500 230 450
Current A 100% 16 9 7 16 8
60% 24 14 11 23 12
30% 35 20 17 34 18
Mains lead rating mm
Ο
4x4 4x2.5 4x2.5 4x4 4x2.5
Fuse slow A 20 16 16 20 16
IMPORTANT!
To prevent the r eel sliding off the hub: Lock the reel in place
by turning the red knob as shown on the warning label atta-
ched next to the hub.
GB
-- 4 0 --
bc14d12e
4.2 Assembly of components
ba14s0
03
ba14s0
0
8
4.3 Electrical installation
ba14s
006
ba14s0
07
230V 50/60 Hz
LKB265 2,5 m m @
LKB320 4 mm @
400--415V 3~50 Hz
ba14s
002
ba14s0
01
230V
440--460V
500V
TC1
XT2
Solid wire
Tube wire
GB
-- 4 1 --bc14d12e
4.4 TECHNICAL DESCRIPTION
The power sources can be equipped with instrument to display the current and volt-
age.
The instruments have a hold function and can be calibrated.
A thermal cut--out prevents overheating.Resetting takes place automatically when
the power source has cooled.
S A -- Space for digital meters (optional)
S B -- Voltage selector, 10--step
S C -- Voltage selector , 4--step
S D -- Main switch, on/off
S E -- Mains indicator lamp
S F -- Thermal overload warning lamp, lights up in case of overheating
S G -- Welding torch connection
S H -- Potentiometer ( wire feed)
S J -- Inductance connection
S K -- Potentiometer (spot welding)
ba14s005
GB
-- 4 2 --
bc14d12e
5 MAINTENANCE
Regularly maintenance is important for reliable and safe operations.
S Blow down the power source with dry, compressed air at a low pressure.
S Cleaning and replacement of the wire feed mechanism’s wear parts should take
place periodically to ensure trouble free wire feed.
Note that an excessive pressure setting can result in abnormal wear on the pres-
sure roller, feed roller and wire liner.
S Blow clean the wire liner regularly and clean the gas nozzle.
WARNING!
Rotating parts can cause injury, take
great care.
6 ORDERING OF SPARE PARTS
A service manual and list of spare parts can be ordered through your nearest ESAB
representative, see the last page of this booklet.
When ordering spare parts please specify the machine model, serial number and the
designation and order numbers of parts as shown in the list of spare parts. This sim-
plifies dispatch and ensures correct delivery.
7 ACCESSORIES
1 Meter glass 455 172--001
2 Meter kit 456 008--880
3 Transformer kit 456 010--880
ba14s0
04
1
2
3
GB
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10

ESAB LKB 265 User manual

Category
Welding System
Type
User manual
This manual is also suitable for

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI
