OPER ATOR'S MANUAL

REAR BLADES

MAN0160

(Rev. 2/22/2006)

Tested. Proven. Unbeatable.

RB750-4

RB850-4

2 Introduction

Gen’l (Rev. 6/6/2005)

TO THE DEALER:

Assembly and proper installation of this product is the responsibility of the Woods

dealer. Read manual instructions

and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists in the Operator’s Manual

are completed before releasing equipment to the owner.

The dealer must complete the Product Registration included with the Operator’s Manual. The customer must sign the

registration which certifies that all Dealer Check List items have been completed. The dealer is to return the prepaid

postage portion to Woods, give one copy to the customer, and retain one copy. Failure to complete and return this

card does not diminish customer’s warranty rights.

TO THE OWNER:

Read this manual before operating your Woods equipment. The information presented will prepare you to do a better and

safer job. Keep this manual handy for ready reference. Require all operators to read this manual carefully and become

acquainted with all adjustment and operating procedures before attempting to operate. Replacement manuals can be

obtained from your dealer. To locate your nearest dealer, check the Dealer Locator at www.WoodsEquipment.com, or in

the United States and Canada call 1-800-319-6637.

The equipment you have purchased has been carefully engineered and manufactured to provide dependable and

satisfactory use. Like all mechanical products, it will require cleaning and upkeep. Lubricate the unit as specified.

Observe all safety information in this manual and safety decals on the equipment.

For service, your authorized Woods dealer has trained mechanics, genuine Woods service parts, and the necessary

tools and equipment to handle all your needs.

Use only genuine Woods service parts. Substitute parts will void the warranty and may not meet standards required for

safe and satisfactory operation. Record the model number and serial number of your equipment in the spaces

provided:

Model: _______________________________ Date of Purchase: _____________________

Serial Number: (see Safety Decal section for location) ____________________________________

Provide this information to your dealer to obtain correct repair parts.

Throughout this manual, the term IMPORTANT is used to indicate that failure to observe can cause damage to

equipment. The terms CAUTION, WARNING, and DANGER are used in conjunction with the Safety-Alert Symbol (a

triangle with an exclamation mark) to indicate the degree of hazard for items of personal safety.

CAUTION

IMPORTANT

WARNING

DANGER

NOTE

This Safety-Alert Symbol indicates a hazard and means ATTENTION!

BECOME ALERT! YOUR SAFETY IS INVOLVED!

Indicates an imminently hazardous situation that, if not avoided, will

result in death or serious injury.

Indicates a potentially hazardous situation that, if not avoided, could

result in death or serious injury, and includes hazards that are exposed

when guards are removed.

Indicates a potentially hazardous situation that, if not avoided, may

result in minor or moderate injury.

Indicates that failure to observe can cause damage to equipment.

Indicates helpful information.

Introduction 3

MAN0160 (Rev. 8/19/2005)

TABLE OF CONTENTS

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

SAFETY RULES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

SAFETY DECALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

OWNER SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

BOLT TORQUE CHART . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

BOLT SIZE CHART & ABBREVIATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . 48

PRODUCT WARRANTY . . . . . . . . . . . . . . . . . . . . . . . INSIDE BACK COVER

REPLACEMENT PARTS WARRANTY . . . . . . . . . . . . . . . . . . BACK COVER

GENERAL INFORMATION

The purpose of this manual is to assist you in oper-

ating and maintaining your Rear Blade. Read it

carefully. It furnishes information and instructions

that will help you achieve years of dependable per-

formance. These instructions have been compiled

from extensive field experience and engineering

data. Some information may be general in nature,

due to unknown and varying operating conditions.

However, through experience and these instruc-

tions, you should be able to develop procedures

suitable to your particular situation.

The illustrations and data used in this manual were

current at the time of printing. However, due to pos-

sible inline production changes, your machine may

vary slightly in detail. We reserve the right to rede-

sign and change the machines as may be neces-

sary without notification.

Throughout this manual, references are made to

right and left directions. These are determined by

standing behind the tractor facing the direction of

forward travel.

Si no lee Ingles, pida ayuda a

alguien que si lo lea para que le

traduzca las medidas de seguridad.

LEA EL INSTRUCTIVO!

4 Introduction

MAN0160 (Rev. 8/19/2005)

RB750-4 & RB850-4 SPECIFICATIONS

MODEL RB750-4 RB850-4

Blade Width 7 ft. (2133 mm) 8 ft. (2438 mm)

Tractor HP Requirement 100 HP Maximum 100 HP Maximum

(75 kW) (75 kW)

Weight:

M = Manual 811 lbs. (368 kg) 856 lbs. (388 kg)

H = Hydraulic 1010 lbs. (458 kg) 1050 lbs. (478 kg)

Model Codes:

M = All Manual: Angle, Tilt & Swing

MA = Manual Swing & Tilt; Hydraulic Angle for tractors with at least one hydraulic port

MT = Manual Swing & Angle; Hydraulic Tilt for tractors with at least one hydraulic port

SA = Manual Tilt; Hydraulic Swing & Angle for tractors with at least two hydraulic ports

TA = Manual Swing; Hydraulic Tilt & Angle for tractors with at least two ports

H = All Hydraulic; Angle, Tilt & Swing for tractors with three hydraulic ports

Blade Position - Mechanical . . . . . . Straight, forward or reverse;

Angle 15, 30, 45 & 60 degrees, right or left in forward;

15 & 30 degrees in reverse;

Tilt 15 or 30 degrees up or down;

Offset 12" or 24" (305 mm or 610 mm) left or right of

tractor center line;

Pitch adjustment in top link of tractor 3-point hitch

Blade Positions - Hydraulic . . . . . . . Straight, forward or reverse;

Angle 45 degrees right or left forward and reverse;

Tilt 22 degrees up or down;

Offset 24" (610 mm) right or left of tractor center line;

Pitch adjustment in top link of tractor 3-point hitch

Cutting Edge . . . . . . . . . . . . . . . . . . 1/2 x 6" (12.7 mm x 152 mm) High carbon steel, reversible

3-Point Hitch Category . . . . . . . . . . Category 2

Category 2 Quick attaching coupler, with bushing kit #18295

Category 3, with bushing kit #18295

Structural Strength:

A-Frame . . . . . . . . . . . . . . . . . . . . . 8 x 4 (203 mm x 102 mm) Formed channel

Boom. . . . . . . . . . . . . . . . . . . . . . . . All-welded box section

King Pin. . . . . . . . . . . . . . . . . . . . . . 6-5/8" (168 mm) Tubing

Moldboard . . . . . . . . . . . . . . . . . . . . Formed moldboard and all welded box section

Pivot Assembly . . . . . . . . . . . . . . . . All-welded steel box section

Safety 5

RB750/850-4 SR (Rev. 2/22/2006)

TRAINING

 Safety instructions are important! Read all

attachment and power unit manuals; follow all

safety rules and safety decal information. (Replace-

ment manuals and safety decals are available from

your dealer. To locate your nearest dealer, check

the Dealer Locator at www.WoodsEquipment.com,

or in the United States and Canada call 1-800-319-

6637.) Failure to follow instructions or safety rules

can result in serious injury or death.

 If you do not understand any part of this manual

and need assistance, see your dealer.

 Know your controls and how to stop engine and

attachment quickly in an emergency.

 Operators must be instructed in and be capable

of the safe operation of the equipment, its attach-

ments, and all controls. Do not allow anyone to

operate this equipment without proper instruc-

tions.

 Keep hands and body away from pressurized

lines. Use paper or cardboard, not hands or other

body parts to check for leaks. Wear safety goggles.

Hydraulic fluid under pressure can easily penetrate

skin and will cause serious injury or death.

 Make sure that all operating and service person-

nel know that if hydraulic fluid penetrates skin, it

must be surgically removed as soon as possible by

a doctor familiar with this form of injury or gan-

grene, serious injury, or death will result. CON-

TACT A PHYSICIAN IMMEDIATELY IF FLUID

ENTERS SKIN OR EYES. DO NOT DELAY.

 Never allow children or untrained persons to

operate equipment.

PREPARATION

 Check that all hardware is properly installed.

Always tighten to torque chart specifications

unless instructed otherwise in this manual.

 Do not connect a low-pressure hydraulic hose

into a high-pressure system—it will burst the hose.

Do not use a high-pressure hose in place of a low-

pressure hose—it is possible to rupture the valve.

 Always wear relatively tight and belted clothing

to avoid entanglement in moving parts. Wear

sturdy, rough-soled work shoes and protective

equipment for eyes, hair, hands, hearing, and head.

 Make sure attachment is properly secured,

adjusted, and in good operating condition.

 Power unit must be equipped with ROPS or

ROPS cab and seat belt. Keep seat belt securely

fastened. Falling off power unit can result in death

from being run over or crushed. Keep foldable

ROPS systems in “locked up” position at all times.

 A minimum 20% of tractor and equipment

weight must be on the tractor front wheels when

attachments are in transport position. Without this

weight, tractor could tip over, causing personal

injury or death. The weight may be attained with a

loader, front wheel weights, ballast in tires or front

tractor weights. Weigh the tractor and equipment.

Do not estimate.

 Make sure all safety decals are installed.

Replace if damaged. (See Safety Decals section for

location.)

 Make sure circuit selector lever does not hit

tractor cab, etc. throughout operating range of 3-

point hitch of tractor. Bend lever, if necessary, to

clear cab, but it should still be convenient to oper-

ate from the tractor seat.

OPERATION

 Do not allow bystanders in the area when oper-

ating, attaching, removing, assembling, or servic-

ing equipment.

 Do not operate equipment while under the influ-

ence of alcohol or drugs.

 Operate only in daylight or good artificial light.

 Keep hands, feet, hair, and clothing away from

equipment while engine is running. Stay clear of all

moving parts.

 Always comply with all state and local lighting

and marking requirements.

(Safety Rules continued on next page)

Safety is a primary concern in the design and

manufacture of our products. Unfortunately, our

efforts to provide safe equipment can be wiped

out by an operator’s single careless act.

In addition to the design and configuration of

equipment, hazard control and accident preven-

tion are dependent upon the awareness, concern,

judgement, and proper training of personnel

involved in the operation, transport, maintenance

and storage of equipment.

It has been said “The best safety device is an

informed, careful operator.” We ask you to be that

kind of operator.

AFETY RULE

ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

6 Safety

RB750/850-4 SR (Rev. 2/22/2006)

(Safety Rules continued from previous page)

 Never allow riders on power unit or attachment.

 Power unit must be equipped with ROPS or

ROPS cab and seat belt. Keep seat belt securely

fastened. Falling off power unit can result in death

from being run over or crushed. Keep foldable

ROPS systems in “locked up” position at all times.

 Always sit in power unit seat when operating

controls or starting engine. Securely fasten seat

belt, place transmission in neutral, engage brake,

and ensure all other controls are disengaged

before starting power unit engine.

 Look down and to the rear and make sure area

is clear before operating in reverse.

 Do not operate on steep slopes.

 Do not stop, start, or change directions sud-

denly on slopes.

 Use extreme care and reduce ground speed on

slopes and rough terrain.

 Watch for hidden hazards on the terrain during

operation.

 Stop power unit and equipment immediately

upon striking an obstruction. Turn off engine,

remove key, inspect, and repair any damage before

resuming operation.

 Before changing positions of manual swing, tilt,

or angle positions:

• Park tractor on level ground, apply parking

brake, level implement boom, shut off tractor,

and remove key.

• Make manual changes slowly and carefully

to prevent hazardous movement of mecha-

nisms.

• Never stand in positions where you could

become entrapped during adjustment changes

or if the 3-point hitch suddenly lowers.

 Always secure lock pins with safety pins to pre-

vent lock pins from bumping out of the positioning

holes. Failure to do so may result in accidents and/

or damage to blade.

TRANSPORTATION

 Before transporting, pivot the unit so red reflec-

tors face the rear.

 Always comply with all state and local lighting

and marking requirements.

 Never allow riders on power unit or attachment.

 Do not operate or transport on steep slopes.

 Do not operate or transport equipment while

under the influence of alcohol or drugs.

MAINTENANCE

 Before dismounting power unit or performing

any service or maintenance, follow these steps:

disengage power to equipment, lower the 3-point

hitch and all raised components to the ground,

operate valve levers to release any hydraulic pres-

sure, set parking brake, stop engine, remove key,

and unfasten seat belt.

 Before working underneath, read manual

instructions, securely block up, and check stability.

Secure blocking prevents equipment from drop-

ping due to hydraulic leak down, hydraulic system

failure, or mechanical component failure.

 Always wear relatively tight and belted clothing

to avoid entanglement in moving parts. Wear

sturdy, rough-soled work shoes and protective

equipment for eyes, hair, hands, hearing, and head.

 Do not modify or alter or permit anyone else to

modify or alter the equipment or any of its compo-

nents in any way.

 Make sure attachment is properly secured,

adjusted, and in good operating condition.

 Never perform service or maintenance with

engine running.

 Keep all persons away from operator control

area while performing adjustments, service, or

maintenance.

 Tighten all bolts, nuts and screws to torque

chart specifications. Check that all cotter pins are

installed securely to ensure equipment is in a safe

condition before putting unit into service.

 Make sure all safety decals are installed.

Replace if damaged. (See Safety Decals section for

location.)

 Do not disconnect hydraulic lines until machine

is securely blocked or placed in lowest position

and system pressure is released by operating

valve levers.

STORAGE

 Secure equipment parking stand(s) in park posi-

tion before detaching.

 Keep children and bystanders away from stor-

age area.

SAFETY RULES

ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

Safety 7

MAN0160 (Rev. 8/19/2005)

1 - SERIAL NUMBER PLATE

MODEL NO. SERIAL NO.

Woods Equipment Company

Oregon, Illinois, U.S.A.

Check for leaks with cardboard; never use hand.

Before loosening fittings: lower load, release pressure, and

be sure oil is cool.

Consult physician immediately if skin penetration occurs.

WARNING

19924-B

2 - PN 19924

6 - PN 57123

RED REFLECTOR 9"

7 - PN 1002940

YELLOW REFLECTOR 9"

SAFETY & INSTRUCTIONAL DECALS

ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

Replace Immediately If Damaged!

(Safety Decals continued on next page)

8 Safety

MAN0160 (Rev. 8/19/2005)

CRUSHING AND

PINCHING HAZARD

 Be extremely careful

handling various parts of the

machine. They are heavy and

hands, fingers, feet, and

other body parts could be

crushed or pinched between

tractor and implement.

 Operate tractor controls from

tractor seat only.

 Do not stand between tractor

and implement when tractor

is in gear.

 Make sure parking brake is

engaged before going

between tractor and

implement.

 Stand clear of machine while

in operation or when it is

being raised or lowered.

FAILURE TO FOLLOW THESE

INSTRUCTIONS COULD

RESULT IN SERIOUS INJURY

OR DEATH.

WARNING

1002941-A

3 - PN 1002941

TO AVOID SERIOUS

INJURY OR DEATH:

 Read Operator's Manual

before operating, servicing,

or repairing equipment.

Follow all safety rules and

instructions. (Manuals are

available from dealer or call

1-800-319-6637.)

 Operate from tractor seat

only.

 Lower equipment to ground,

stop engine, remove key,

and set brake before

dismounting tractor.

 Never allow children or

untrained persons to operate

equipment.

 Never allow riders.

 Keep bystanders away from

equipment during operation.

 Keep all shields in place and

in good condition.

FAILURE TO FOLLOW THESE

INSTRUCTIONS CAN RESULT

IN INJURY OR DEATH.

1004250

WARNING

4 - PN 1004250

Unit must not extend

more than 4 feet left of

center of the tractor when

driving on public roads.

WARNING

1003193-A

8 - PN 1003193

WARNING

55121--C

FALLING OFF CAN RESULT IN BEING RUN OVER.

 Tractor must be equipped with ROPS (or ROPS CAB) and

seat belt. Keep foldable ROPS systems in “locked up”

position at all times.

 Buckle Up! Keep seat belt securely fastened.

 Allow no riders.

RAISED IMPLEMENT CAN DROP AND CRUSH.

 Never go underneath raised implement which can drop

from equipment or tractor 3-point hitch hydraulic leak

down, hydraulic system failures, movement of control

levers or mechanical linkage failures.

 Service work does not require going underneath

implement. Read manual instructions.

FALLING OFF OR GOING UNDERNEATH IMPLEMENT

CAN RESULT IN SERIOUS INJURY OR DEATH.

5 - PN 55121

BE CAREFUL!

Use a clean, damp cloth to clean

safety decals.

Avoid spraying too close to decals

when using a pressure washer;

high-pressure water can enter

through very small scratches or

under edges of decals causing

them to peel or come off.

Replacement safety decals can be

ordered free from your Woods

dealer. To locate your nearest

dealer, check the Dealer Locator at

www.WoodsEquipment.com, or in

the United States and Canada call

1-800-319-6637.

SAFETY & INSTRUCTIONAL DECALS

ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!

Replace Immediately If Damaged!

(Safety Decals continued from previous page)

Operation 9

MAN0160 (Rev. 2/22/2006)

OPERATION

 Never allow children or untrained persons to

operate equipment.

 Do not allow bystanders in the area when oper-

ating, attaching, removing, assembling, or servic-

ing equipment.

 Before working underneath, read manual

instructions, securely block up, and check stability.

Secure blocking prevents equipment from drop-

ping due to hydraulic leak down, hydraulic system

failure, or mechanical component failure.

 Never allow riders on power unit or attachment.

 Keep all persons away from operator control

area while performing adjustments, service, or

maintenance.

 Keep hands and body away from pressurized

lines. Use paper or cardboard, not hands or other

body parts to check for leaks. Wear safety goggles.

Hydraulic fluid under pressure can easily penetrate

skin and will cause serious injury or death.

 Make sure that all operating and service person-

nel know that if hydraulic fluid penetrates skin, it

must be surgically removed as soon as possible by

a doctor familiar with this form of injury or gan-

grene, serious injury, or death will result. CON-

TACT A PHYSICIAN IMMEDIATELY IF FLUID

ENTERS SKIN OR EYES. DO NOT DELAY.

 A minimum 20% of tractor and equipment

weight must be on the tractor front wheels when

attachments are in transport position. Without this

weight, tractor could tip over, causing personal

injury or death. The weight may be attained with a

loader, front wheel weights, ballast in tires or front

tractor weights. Weigh the tractor and equipment.

Do not estimate.

 Always wear relatively tight and belted clothing

to avoid entanglement in moving parts. Wear

sturdy, rough-soled work shoes and protective

equipment for eyes, hair, hands, hearing, and head.

MOUNT BLADE TO TRACTOR

IMPORTANT

■ The RB750-4 & RB850-4 should be mounted on

tractors with a maximum horsepower rating of 100

hp (75 kW).

The Rear Blade is a 3-point Category 2 implement. It

will attach to ASAE standard Category 2 quick-attach-

ing coupler or on 3-point Category 3 tractor, using a

bushing kit.

NOTE: Only use on Category 3, 3-point hitch trac-

tor whose lower lift arms adjust to 32" (813 mm)

apart.

1. Set the tractor drawbar in short-high position.

2. Attach tractor draft links to the A-frame with 1-1/8"

pin (21) and secure with Klik pins (44).

3. Connect the tractor top link to top hole in A-frame,

using 1 x 4-29/32" heat-treated pin (20) and cotter

pin (31). Use 1 x 1-1/4" bushing (23) and 1-1/8 x 1-

7/16" heat-treated bushing (24) with Category 2

quick- attaching coupler and category 3, 3-point

hitch tractor.

4. Level the boom by adjusting lift and top link.

5. Position sway blocks to eliminate side sway or

install sway braces if required.

NOTE: The drawbar may have to be removed on

some tractors. Make sure blade is at least 6" (152

mm) from tractor tires throughout operating range

of 3-point hitch.

Figure 1. A-Frame Components

CAUTION

CD5979-1

1. A-Frame

20. Clevis pin 1 x 4-29/32 HT

21. Hitch pin 1-1/8

23. Sleeve 1 x 1-1/4 x 2

24. Sleeve 1-1/8 x 1-7/16 x 2-5/8

31. Cotter pin 1/4 x 1-3/4

44. Klik pin 7/16 x 11/32 HT

10 Operation

MAN0160 (Rev. 2/22/2006)

BLADE ANGLE ADJUSTMENT

 Before changing positions of manual swing, tilt,

or angle positions:

• Park tractor on level ground, apply parking

brake, level implement boom, shut off tractor,

and remove key.

• Make manual changes slowly and carefully

to prevent hazardous movement of mecha-

nisms.

• Never stand in positions where you could

become entrapped during adjustment changes

or if the 3-point hitch suddenly lowers.

 Always secure lock pins with safety pins to pre-

vent lock pins from bumping out of the positioning

holes. Failure to do so may result in accidents

and/or damage to blade.

Mechanical

The blade may be angled 15, 30, 45 and 60 degrees

for forward grading, and 15 and 30 degrees for backfill-

ing to right or left from center position without unhook-

ing the blade from the tractor.

1. Raise the blade a few inches off the ground by

operating the lift control lever of the tractor 3-point

hitch.

2. Remove the safety pin (10) and lock pin (2).

3. Set blade at desired position and replace pins.

Figure 2. Mechanical Configuration Assembly

Hydraulic

The blade may be angled 45 degrees or to any position

in between, to the right or left by hydraulic remote con-

trol from the tractor seat.

1. Raise the blade a few inches off the ground by

operating the lift control lever of the tractor.

2. Actuate the control valve the angling cylinder is

connected to.

3. On tractors with two circuit selector valves, select

angling circuit and actuate the tractor control valve

connected to selector valve.

NOTE: Do not operate the selector valve under

load.

Figure 3. Hydraulic Configuration Assembly

REVERSE BLADE

The blade is reversible without removing it from the

tractor.

1. Raise blade off the ground.

2. Mechanical – Remove the lock pin (2), Figure 2,

and rotate it counter-clockwise to the desired

position and replace pins.

3. Hydraulic – Detach the angling cylinder (7) from

the hydraulic angle arm (1), Figure 3, and rotate it

counter-clockwise to the desired position. Attach

angling cylinder (7) to hydraulic angle arm (1).

NOTE: In some cases it may be necessary to offset to

the right and tip up the right end of the blade to rotate it.

CAUTION

CD5980-1

2. Lock Pin Assembly

10. 3/16 Safety Pin

CD5999-1

Angle

Tilt

Swing

1. Hydraulic Angle Arm Assembly

5. Hyd Cylinder 3.5 x 1.5 x 16

Operation 11

MAN0160 (Rev. 2/22/2006)

TILT ADJUSTMENT

Figure 4. Mechanical Configuration - Tilt

Mechanical

The blade may be tilted 15 and 30 degrees up and

down.

To tilt blade:

1. Remove tilt lock pin (1),

2. Rotate the blade to the desired position, and

3. Replace the pin.

NOTE: Additional tilting may be obtained by adjusting

the draft links of the 3-point hitch.

Figure 5. Hydraulic Configuration - Tilt

Hydraulic

The blade may be tilted 22 degrees up or down and to

any position in between.

To prevent damage to the blade and hydraulic cylinder,

do not use lock pin (1, Figure 4).

NOTE: In some cases it may not be possible to fully tilt

and angle and still be able to raise the blade high

enough to clear the ground. In this case, use less tilt.

NOTE: It is possible for the blade to contact other com-

ponents if the blade is tilted when angled. Operate

blade slowly when angling blade.

OFFSET (SWING)

Mechanical Adjustment

The blade may be offset 12" (305 mm) and 24" (610

mm), either side from the center position.

To offset the blade:

1. Park the tractor on level ground.

2. Apply parking brake and raise blade 2" (51 mm)

above the ground.

3. Shut off the engine and level the boom.

4. Remove safety pin (10) and lock pin (16), swing

the boom to the desired position and replace the

pins.

Figure 6. Mechanical Configuration - Offset

Adjustment with Hydraulic Swing Cylinder

The swing cylinder rotates the boom 30 degrees right

or left or to any position in between, resulting in a max-

imum of 24" (610 mm) offset to right or left.

CD5980-1

1. Tilt Lock Pin

CD5999-1

Angle

Tilt

Swing

4. Hyd Cylinder 3.5 x 1.25 x 8

5. Hyd Cylinder 3.5 x 1.5 x 16

CD5980-1

10. 3/16 Safety Pin

16. Lock Pin

12 Operation

MAN0160 (Rev. 2/22/2006)

To angle the blade:

1. Raise blade a few inches above the ground by

operating the lift control lever of the tractor.

2. Actuate the control valve to which the swing

cylinder is connected.

3. On tractors having two circuit selector valves,

select swing circuit and actuate tractor control

valve connected to selector valve.

NOTE: Do not operate the selector valve under load.

Figure 7. Hydraulic Configuration - Offset

OPERATING TIPS

 Look down and to the rear and make sure area

is clear before operating in reverse.

 Do not operate on steep slopes.

 Do not stop, start, or change directions sud-

denly on slopes.

 Use extreme care and reduce ground speed on

slopes and rough terrain.

 Watch for hidden hazards on the terrain during

operation.

 Before working underneath, read manual

instructions, securely block up, and check stability.

Secure blocking prevents equipment from drop-

ping due to hydraulic leak down, hydraulic system

failure, or mechanical component failure.

 Stop power unit and equipment immediately

upon striking an obstruction. Turn off engine,

remove key, inspect, and repair any damage before

resuming operation.

BACKFILLING

For backfilling ditches or trenches, reverse the blade by

rotating counter-clockwise and back push.

LEVELING AND GRADING

Set the blade to the desired position of offset, angle

and tilt for leveling and grading.

PRE-OPERATION CHECK LIST

(OPERATOR’S RESPONSIBILITY)

___ Review and follow all safety rules and safety

decal instructions on pages 5 through 8.

___ Check that equipment is properly and securely

attached to tractor.

___ Check that all safety decals are installed and in

good condition. Replace if damaged

___ Check that all hardware and cotter pins are prop-

erly installed and secured.

___ Check that all lubrication points are greased.

___ Check that blade cutting edge is in good condi-

tion.

___ Check that all hydraulic hoses and fittings are in

good condition and not leaking before starting

tractor. Check that hoses are not twisted, bent

sharply, kinked, frayed or pulled tight. Replace

any damaged hoses immediately.

CD5999-1

Angle

Tilt

Swing

4. Hyd Cylinder 3.5 x 1.25 x 8

5. Hyd Cylinder 3.5 x 1.5 x 16

CAUTION

Owner Service 13

MAN0160 (Rev. 2/22/2006)

OWNER SERVICE

 Keep hands and body away from pressurized

lines. Use paper or cardboard, not hands or other

body parts to check for leaks. Wear safety goggles.

Hydraulic fluid under pressure can easily penetrate

skin and will cause serious injury or death.

 Make sure that all operating and service person-

nel know that if hydraulic fluid penetrates skin, it

must be surgically removed as soon as possible by

a doctor familiar with this form of injury or gan-

grene, serious injury, or death will result. CON-

TACT A PHYSICIAN IMMEDIATELY IF FLUID

ENTERS SKIN OR EYES. DO NOT DELAY.

 Before working underneath, read manual

instructions, securely block up, and check stability.

Secure blocking prevents equipment from drop-

ping due to hydraulic leak down, hydraulic system

failure, or mechanical component failure.

 Never perform service or maintenance with

engine running.

 Before dismounting power unit or performing

any service or maintenance, follow these steps:

disengage power to equipment, lower the 3-point

hitch and all raised components to the ground,

operate valve levers to release any hydraulic pres-

sure, set parking brake, stop engine, remove key,

and unfasten seat belt.

 Keep all persons away from operator control

area while performing adjustments, service, or

maintenance.

 Always wear relatively tight and belted clothing

to avoid entanglement in moving parts. Wear

sturdy, rough-soled work shoes and protective

equipment for eyes, hair, hands, hearing, and head.

BLADE CUTTING EDGE

To reverse the cutting edge

1. Remove the 5/8" plow bolts.

2. Remove the cutting edge from the moldboard and

reinstall with the sharp edge down.

3. Replace cutting edge when both edges are worn.

LUBRICATION

Weekly

Oil the pivot pins with SAE 30 oil.

8 Hours

Grease optional skid shoes.

BOLTS

1. Check bolts periodically to be sure they are tight.

2. Replace bolts as needed.

NOTE: Replacement bolts must have the same

strength markings on the heads. Refer to bolt torque on

page 47.

CLEANING

After Each Use

● Remove large debris such as clumps of dirt, grass,

crop residue, etc. from machine.

● Inspect machine and replace worn or damaged

parts.

● Replace any safety decals that are missing or not

readable.

Periodically or Before Extended Storage

● Clean large debris such as clumps of dirt, grass,

crop residue, etc. from machine.

● Remove the remainder using a low-pressure water

spray.

1. Be careful when spraying near scratched or torn

safety decals or near edges of decals as water

spray can peel decal off surface.

2. Be careful when spraying near chipped or

scratched paint as water spray can lift paint.

3. If a pressure washer is used, follow the advice

of the pressure washer manufacturer.

● Inspect machine and replace worn or damaged

parts.

● Sand down scratches and the edges of areas of

missing paint and coat with Woods spray paint of

matching color (purchase from your Woods

dealer).

● Replace any safety decals that are missing or not

readable (supplied free by your Woods dealer).

See Safety Decals section for location drawing.

CAUTION

14 Assembly

MAN0160 (Rev. 2/22/2006)

ASSEMBLY

 Before dismounting power unit or performing

any service or maintenance, follow these steps:

disengage power to equipment, lower the 3-point

hitch and all raised components to the ground,

operate valve levers to release any hydraulic

pressure, set parking brake, stop engine, remove

key, and unfasten seat belt.

 Before working underneath, read manual

instructions, securely block up, and check stabil-

ity. Secure blocking prevents equipment from

dropping due to hydraulic leak down, hydraulic

system failure, or mechanical component failure.

 Keep all persons away from operator control

area while performing adjustments, service, or

maintenance.

 Keep hands and body away from pressurized

lines. Use paper or cardboard, not hands or other

body parts to check for leaks. Wear safety gog-

gles. Hydraulic fluid under pressure can easily

penetrate skin and will cause serious injury or

death.

 Make sure that all operating and service per-

sonnel know that if hydraulic fluid penetrates

skin, it must be surgically removed as soon as

possible by a doctor familiar with this form of

injury or gangrene, serious injury, or death will

result. CONTACT A PHYSICIAN IMMEDIATELY IF

FLUID ENTERS SKIN OR EYES. DO NOT DELAY.

 Always wear relatively tight and belted cloth-

ing to avoid entanglement in moving parts. Wear

sturdy, rough-soled work shoes and protective

equipment for eyes, hair, hands, hearing, and

head.

 Tighten all bolts, nuts and screws to torque

chart specifications. Check that all cotter pins are

installed securely to ensure equipment is in a safe

condition before putting unit into service.

DEALER SET-UP INSTRUCTIONS

Assembly of this equipment is the responsibility of the

Woods dealer. It should be delivered to the owner

completely assembled, lubricated, and adjusted for

normal operating conditions.

Assembly will be easier if components are aligned

and loosely assembled before tightening hardware.

Recommended torque values for hardware are

located on page 47.

ASSEMBLY TABLE OF CONTENTS

MAIN ASSEMBLY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

MANUAL CONFIGURATION

OFFSET LINKAGE - MODELS: M & MT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

HYDRAULIC ANGLE KIT - MODELS: MA, SA, TA, AND OPTIONAL KIT 1004870 . . . . . . . . . . 19

HYDRAULIC TILT KIT - MODELS: MT & TA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

HYDRAULIC OFFSET KIT - MODEL: SA AND OPTIONAL KIT 1004872 . . . . . . . . . . . . . . . . . . 22

HYDRAULIC CONFIGURATION

MODEL H . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

SELECTOR VALVE KIT 1004873 (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

OPTIONAL EQUIPMENT - ALL MODELS

PNEUMATIC TAIL WHEEL (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

SKID SHOE KIT 18296 (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

END PLATE KIT 22658 (OPTIONAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

PRE-DELIVERY & DELIVERY CHECK LISTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

CAUTION

Assembly 15

MAN0160 (Rev. 2/22/2006)

MAIN ASSEMBLY - All Models

Attach Blade to Pivot Assembly

Assemble the main portion of the blade before start-

ing on any of the optional configurations.

1. Place blade assembly (11) on floor with pivot

attachment pointing up.

2. Raise the top end approximately 4" (102 mm)

above the ground with a wooden block. Place pivot

assembly (9) on blade assembly (11).

3. Stack two shim washers (53) on each of the four

holes in blade. Place retainer assembly (10) on wash-

ers.

4. Place washers (52) and lock washers (51) on

bolts (50) and insert through retainer (10), washers

(53), and pivot attachment (9).

5. Secure by placing washers (52) and nuts (54) on

bolts and torque to 300 lbs.-ft (403 N-m).

Figure 8. Blade and Pivot Assembly

9. Pivot assembly

10. Retainer assembly

11. RB750 Molboard assembly

11. RB850 Molboard assembly

50. Screw, HHCS 3/4 NC x 3 GR5

51 Washer, Lock 3/4

52. Washer, Flat 3/4 Standard

53. Washer, Shim .75 x 1.50 x 18ga

54. Nut, Hex 3/4 NC

Attach Boom to Pivot Assembly

1. Grease inside of tube on rear of boom (4).

2. Set blade assembly upright. Place a block of

wood under pivot assembly to secure.

3. Place boom parallel to blade and insert greased

tube over post of pivot assembly (9). Rotate boom 90

degrees to lock lip on rear of boom over pivot assem-

bly.

4. Place jack stand under boom so boom is in a hor-

izontal position.

4. Boom

9. Pivot assembly

Figure 9. Boom and Blade Assembled

CD5979-2

CD5979-3

Grease Tube

Lip

16 Assembly

MAN0160 (Rev. 2/22/2006)

Attach A-Frame

1. Position A-frame (1) over end of boom and insert

pivot pin (22). Secure with cotter pin (40).

2. Attach parking stand (2) in parking position as

shown in Figure 10. Secure with clevis pin (45) and

safety pin (30).

1. A-Frame

2. Parking Stand Assembly

22. Pin, Pivot

30. Pin, Safety 3/16

40. Pin, Cotter 3/8 x 2-1/2

45. Pin, Clevis 5/8 x 3-3/4

Figure 10. A-Frame to Boom Assembly

Install Manual Tube

1. Place manual tube (3) over holes on right side of

A-Frame as shown in Figure 11.

2. Secure into position using three cap screws (41),

six flat washers (42), (one on each side), and lock

nuts (43).

3. Manual Tube

41. Cap Screw, 3/8 NC x 1 GR5

42. Washer, Flat 3/8

43. Nut, Lock 3/8 NC

Figure 11. Manual Tube Installation

CD5979-4

Parking Position

Storage Position

CD4311

CD4312

Assembly 17

MAN0160 (Rev. 2/22/2006)

Install Slow Moving Vehicle Sign

NOTE: If installing optional hydraulic kits that include

double relief valves on Model SA or the complete

hydraulic system for Model H, do not install bracket

(5, Step 1) at this time. Begin with Step 2.

Refer to Figure 12.

1. Place bracket (5) to top of boom and secure with

two carriage bolts (34), flat washers (36), lock wash-

ers (37), and hex nut (38).

2. Attach SMV socket (6) to bracket (5) using two

carriage bolts (34), flat washers (36), lock washers

(37), and hex nuts (38).

3. Attach SMV sign (8) to SMV sign bracket (7)

using two round head screws (32) and nuts (33).

4. Insert sign and bracket assembly into socket (6)

to display SMV sign.

5. Bracket - SMV Sign

6. Socket, SMV Emblem

7. SMV Bracket

8. Slow Moving Vehicle Sign

32. Screw, Round Head 1/4 NC x 1/2

33. Nut, Hex 1/4 NC

34. Bolt, Carriage 5/16 NC x 1-1/4

36. Washer, Flat 5/16 Standard

37. Washer, Lock 5/16

38. Nut, Hex 5/16 NC

Figure 12. Slow Moving Vehicle Sign Installation

Proceed to page listed below to complete desired blade assembly.

M = All Manual: Angle, Tilt & Swing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

MT = Manual Swing & Angle: Hydraulic Tilt for tractors with at least one hydraulic port . . 18

MA = Manual Swing & Tilt: Hydraulic Angle for tractors with at least one hydraulic port . . 19

SA = Manual Tilt: Hydraulic Swing & Angle for tractors with at least two hydraulic ports . . 19

TA = Manual Swing: Hydraulic Tilt & Angle for tractors with at least two ports. . . . . . . . . . 19

H = All Hydraulic: Angle, Tilt & Swing for tractors with three hydraulic ports . . . . . . . . . . 23

CD5979-5

18 Assembly

MAN0160 (Rev. 2/22/2006)

Models: M & MT

Install Offset Linkage

1. Model M only - Place boom and pivot assembly to

desired position. Align holes at bottom of pivot

assembly and insert tilt lock pin (1) as shown. Rotate

pin to lock into position.

2. With boom 90 degrees to the blade, place retain-

ing cap (3) on boom as shown in Figure 13.

3. Install three cap screws (12), lock washers (14),

and flat washers (13) to secure boom to blade assem-

bly.

NOTE: For model MT, do not install front cap screw,

(12) at this time.

4. Rotate boom to desired position. Install lock pin

assembly (2) through end of boom and pivot assem-

bly. Secure with safety pin (10).

5. Insert inner swing link (4) into outer swing link (5).

6. Attach outer swing link to the A-Frame and insert

clevis pin (15). Secure with cotter pin (11).

7. Attach inner swing link (4) to the boom and insert

clevis pin (15). Secure with cotter pin (11).

8. Rotate A-Frame to desired position. Align holes in

inner and outer swing links and insert lock pin (16).

Secure with safety pin (10).

Figure 13. Manual Configuration

NOTE: For Model MT, proceed to page 20 for hydraulic tilt cylinder installation instructions.

CD5980-2

1. Tilt lock Pin

2. Lock Pin Assembly

3. Retaining Cap

4. Link, Inner Swing

5. Link, Outer Swing

10. Pin, Safety 3/16

11. Pin, Cotter 1/4 x 1-3/4

12. Screw, HHCS 3/4 NC x 2-1/4 GR5

13. Washer, Flat 3/4 SAE

14. Washer, Lock 3/4

15. Pin, Clevis 1 x 2-1/2 HT

16. Pin, Swing Lock

Assembly 19

MAN0160 (Rev. 2/22/2006)

Models: MA, SA, & TA or Optional

Hydraulic Angle Kit 1004870

Install Hydraulic Angle Cylinder

Refer to Figure 14.

1. Remove lock pin assembly (2) and safety pin (10)

from rear of boom, if previously installed. See Figure

13 on page 18 for lock pin assembly location.

2. Remove hardware and retaining cap (3) from top

of boom if previously installed. See Figure 13 on page

18 for retaining cap location.

3. Place hydraulic angle arm assembly (4) on boom

as shown Figure 14.

4. Secure into position using three cap screws (27),

lock washers (25), and flat washers (26).

5. Attach hydraulic cylinder (6) to boom and hydrau-

lic angle arm assembly as shown. Secure with pins

supplied with the cylinder.

6. Attach hose holder (5) to A-Frame using carriage

bolt (24), flat washer (23), and lock nut (22).

7. Install adjustable elbows (7) and hoses (8) (Mod-

els MA and TA) to cylinder.

NOTE: Do not install 84” hoses (8) if Hydraulic Offset

cylinder is to be installed.

8. Route hoses as shown in Figure 15.

4. Hyd Angle Arm Assembly

5. Hyd Hose Holder

6. Hyd Cylinder 3-1/2 x 16

7. Elbow, 3/4 ORBM 3/4 JICM 90

8 Hose, 3/8 84 1/2 NPTM 3/4 JICF

9. Strap, Binding 14-1/2

22. Nut, Lock 3/8

23. Washer, Flat 3/8 Standard

24. Bolt, Carriage 3/8 NC x 1-1/4 GR1

25. Washer, Lock 3/4

26. Washer, Flat 3/4 SAE

27. Cap Screw, 3/4 NC x 3 GR5

Figure 14. Angle Kit Installation

Figure 15. Angle Kit Hose Routing

NOTE: For model SA, Proceed to page 22 for hydraulic offset cylinder and relief valve installa-

tion instructions.

CD5986

CD5998

20 Assembly

MAN0160 (Rev. 2/22/2006)

Models: MT & TA

Install Hydraulic Tilt Kit 1004871

Refer to Figure 16

NOTE: Remove tilt lock pin (1) before installing

hydraulic tilt kit. See Figure 13 on page 18 for lock pin

location

1. Attach hydraulic cylinder (1) to blade assembly

and pivot assembly as shown. Secure with pins sup-

plied with the cylinder.

2. Install adjustable elbows (2) and hoses (6) to cyl-

inder.

3. Attach hose holder (4) to A-Frame using carriage

bolt (18), flat washer (19), and lock nut (20). For mod-

els with hydraulic angle (TA) proceed to page 21 for

hose routing.

4. Attach hose clamp (3) to hose support (5) using

cap screw (15), lock washer (16), and hex nut (17).

Do not tighten at this time.

5. Remove cap screw (21), lock washer (23), and

flat washer (22) from forward position on retaining cap

as shown.

6. Position hose support (5) over hole and reinstall

hardware.

7. Route hoses as shown in Figure 17.

8. Position hose support (5) and tighten hardware.

9. Place hoses in hose clamp (3) and tighten hard-

ware. Leave adequate slack in hoses to allow for tilt

and angling of blade.

1. Hyd Cylinder 3-1/2 x 8

2. Elbow, 3/4 ORBM 3/4 JICM 90

3. Hose Clamp 5/8

4. Hyd Hose Holder

5. Link, Hose Support

6 Hose, 3/8 138 1/2 NPTM x 3/4 JICF

7. Binding Strap 14-1/2

15. Cap Screw 5/16 NC x 1 GR5

16. Washer, Lock 5/16

17. Nut, Hex 5/16 NC

18. Bolt, Carriage 3/8 NC x 1-1/4 GR5

19. Washer, Flat 3/8 Standard

20. Nut, Lock 3/8

21. Cap Screw 3/4 NC x 2-1/4 GR5

22. Washer, Flat 3/4 SAE

23. Washer, Lock 3/4

Figure 16. Tilt Kit Installation with Manual

Angle Control

Figure 17. Tilt Kit Hose Routing

5985

CD5993

Page is loading ...

Woods Equipment RB750-4 User manual

Brand: Woods Equipment

Model: RB750-4

Category: Motor vehicle accessories & components

Type: User manual

This manual is also suitable for

Download PDF

report

Woods Equipment RB750-4 User manual

This manual is also suitable for

Woods Equipment RB750-4 User manual

Related papers

Other documents
