Smart lock Aqara Smart Door Lock
User guide
Overview
The smart lock uses the ZigBee wireless protocol, supports opening with a ngerprint,
password, contactless card and usual mechanical key, has the function of blocking
through the peephole and alarms, according with a device, that has a function of a
network gateway (hereinafter «gateway»), you can congure the alarm mode through
the gateway and synchronize the lock with other smart devices.
1 - Touch keypad for entering the password;
Reading area of the contactless card;
2 - Fingerprint sensor
3 - Handle;
4 - Micro-USB - power connector for emergency cases (Micro-USB);
5 - Keyhole for emergency cases;
6 - Battery cover slider for batteries;
7 - Hole of the reset button;
8 - Lock button for opening the handle through the door peephole (to open the door, hold
the button and pull the handle down)
9 - Swivel bolt for locking the lock from the back;
10 - To open the keyhole cover, simultaneously press the left and right bottom corner of
the cover.
Quick settings
1. Reset
Before using the product, open the battery
cover slider, press and hold the reset button
for 8 seconds to clear all data.
Press and hold the reset button for 8 seconds
until you hear «Initialize the system,» then
release the button.
2. Add an alministrator
According to the voice prompts of the lock, add a ngerprint, password and contactless
administrator card.
3. Add an user
First, conrm the administrator’s face, press «#», according to the voice prompts, add a
ngerprint, password and contactless user card.
4. Download the mobile app
This product is compatible with a Smart Mi Home platform,
it can be controlled using a mobile Mi Home application, the
device supports the MIUI system, can interact with other smart
devices of the Mi Home platform.
Enter «Mi Home» into the App Store / Play Store search bar or
scan the QR code below to download and install the Mi Home
application.
5. Connecting the lock to the network
Open the Mi Home application, select the gateway, to which the connection will be
made, in the Hardware section click Add Sub-Device, continue according to the prompts
in the application until you hear
«Device successfully connected» voice
notication.
If you are unable to add a device, place
the gateway closer to the smart lock
and try again.
* This product does not support Mi
Multifunctional Gateway of the 1st
generation.
Press and hold the reset button for 3
seconds until you hear «Network setting
reset», then release the button.
6. Buy more
To purchase more smart devices and other quality items, download Mi Home app and go
to the «Store» section, or scan the QR code below to browse the store’s website.
Video of settings
Scan the QR code to view the video of the lock setup.
Recommendations for synchronization
1. Automatic light up after opening the door.
Smart lock Smart switch
2. Automatically turn o alarm
Smart lock Multifunctional gateway
Main parameters
Model: ZNMS11LM;
Dimensions: 369 × 76 × 24mm (front panel, without handle);
Standard: GA 701-2007, GA 374-2001, GA / T 73-2015;
Input voltage: 6V DC;
Operating temperature: -10 ° C ~ + 55 ° C;
Operating humidity: Relative humidity 10% ~ 90%, non-condensing;
Wireless connection: ZigBee.
Name and content of harmful substances in the product
Manufacturer: Shenzhen Lumi United Technology Co., Ltd.
Address: 8th Floor, Jinqi Zhigu Bldg, No 1 Tangling Rd, Liuxian Ave, Taoyuan Subdistrict,
Nanshan District, Shenzhen City.
Support phone: 400-990-7930.
XIAOMI-MI.COM
