MOTO Z6w
Quick Start Guide
v513156.eps 9/10/2007 11:18:49 AM
2
HELLOMOTO
Feel It, See It, Hear It!
Your MOTO Z6w phone is made
to be held and seen!
• Install, charge up, and get going!
It’s easy to
install your
SIM card
(page 12) and
memory
card
(page 13). After you install and charge your
battery
(page 14), you’re ready to
turn on
your
phone (page 16) and
make a call
(page 16).
• YOUR music on YOUR phone!
Load
your
favorite music to your computer (page 20),
transfer
it quickly and easily to your phone
(page 21), then
play
it on your phone’s music
player (page 23).
3
•
Read and answer
text messages
(page 28).
•Personalize
the phone to make it your very own
(page 30).
• Search the Web
search using the GOOGLE®
Web site (page 32).
• Check your email
on the go (page 33).
For more information:
To read feature instructions on
your phone, press the center key
s
to open the main
menu, then select
V
Help
. To learn more about your
phone and accessories, go to
www.hellomoto.com
.
Note: Before using the phone for the first
time, review the Important Safety and Legal
Information guide included in the box.
Periodically review this information so you
remember how to safely use your phone.
4
Tip:
Press the center key
s
to open the main menu
and select menu options. Press the clear/back key
D
to
delete letters or numbers, or to go back one menu.
Center Select Key
Open main menu &
select menu items.
Power/End Key
Turn on/off, hang
up, exit menus.
Right Soft Key
Left Soft Key
Go online.
Push Bar
Push down
to close slider.
Send Key
Make &
answer calls.
Navigation Key
Scroll up, down,
left, or right.
Clear/Back Key
5
Camera Lens
(on back of phone)
I
Voice Key
Use voice
commands to
make calls &
perform basic
phone functions.
Volume Keys
Smart/Speaker-
phone Key
Mini-USB Port
Insert battery
charger & phone
accessories.
I
Camera Key
6
contents
menu map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
get started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
insert your SIM card. . . . . . . . . . . . . . . . . . . . . . . . . 12
insert & remove a memory card . . . . . . . . . . . . . . . 13
insert the battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
charge the battery . . . . . . . . . . . . . . . . . . . . . . . . . . 14
turn phone on & off . . . . . . . . . . . . . . . . . . . . . . . . . 16
make a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
answer a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
end a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
store a phone number . . . . . . . . . . . . . . . . . . . . . . . 17
call a stored phone number . . . . . . . . . . . . . . . . . . . 18
your phone number . . . . . . . . . . . . . . . . . . . . . . . . . 18
music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1. load music on your computer. . . . . . . . . . . . . . . 20
2. transfer music to your phone . . . . . . . . . . . . . . . 21
3. play music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
listen with Bluetooth® stereo headphones . . . . . . 24
adjust audio settings . . . . . . . . . . . . . . . . . . . . . . . 25
create a playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
play a playlist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
turn off music player . . . . . . . . . . . . . . . . . . . . . . . 27
7
messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
read & reply to a message. . . . . . . . . . . . . . . . . . . 28
send a message. . . . . . . . . . . . . . . . . . . . . . . . . . . 29
personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
home screen shortcuts . . . . . . . . . . . . . . . . . . . . . 30
wallpaper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
clock style . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
GOOGLE® search . . . . . . . . . . . . . . . . . . . . . . . . . 32
email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
check your email account. . . . . . . . . . . . . . . . . . . . 33
accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
8
menu map
main menu
q
Recent Calls
L
Contacts
m
Office Tools
• Calendar
•MOTOSYNC
• Download
Manager
• File Manager
•Memory Card
• My Blog*
• Music and
Sounds
•Pictures
• Videos
•Voice Note
• Application
Downloads
• Unrecognizable
Files
•My
Documents
•Alarm Clock
• World Clock
• Calculator
• Dialing Services
• Task List
• Notes
•Help
1
Web Access
•Browser
•My Bookmarks
• My Web Pages
•History
•Go to URL
•Browser Setup
g
Messages
• Create Message
• Inbox
• My Folders
• Templates
•Drafts
•Outbox
• Create Postcard*
•Email
• Call Voicemail
(continued next page)
* optional features
9
main menu (continued)
j
Multimedia
• Media Finder
•Games
•Camera
• Video Camera
• Voice Recorder
6
WiFi
• Current
Connection
•Available
Networks
• Saved Networks
• Quick Connect
• Set Up WiFi
u
Settings
• (see next page)
V
Help
This is the standard main menu
layout.
Your phone’s menu
may be different.
To change your home screen
shortcuts and main menu
appearance, see page 30.
* optional features
10
settings menu
•Profiles
• Themes
• Home Screen
• Navigation Keys
• Change Wallpaper
•ClockStyle
•Date
• Screen3*
• Connections
• Bluetooth®
• USB Setting
• Media Syn-
chronization
•Memory Card
• Modem
•USB Printing
•Tools
• Voice Networks
• Voice Over IP
•Network
Settings
• Data Connections
•Adda
Connection
•Edit a
Connection
•Removea
Connection
• Call Settings
• Speed Dial
• Call Forward
•In-Call Setup
•My Caller ID
•In-Call Timer
•Answer
Options
•In-Call
Message Alert
• Roam Alert
• Call Waiting
• Auto-Redial
• Call Drop Tone
•DialingSetup
•My Caller ID
•DTMF
• Dialing Prefix
• Call Barring*
• Fixed Dialing
•My SIM Number
• Active Line *
(continued next page)
* optional features
11
settings menu (continued)
• Phone Settings
• Display Settings
•Display
Timeout
• Screensaver
• Brightness
• Airplane Mode
•Battery Meter
•Time & Date
• Slide Closed
• Language
• Talking Phone
• Text Entry
•Reset
•Reset All
Settings
• Delete All
Data
• Delete
Memory
Cards
•View Memory
• Properties
• Java™ System
• OTA Updates
• Headset Settings
• Auto-Answer
•Voice Dial
• TTY Settings
•Security
• Phone Lock
• Keypad Lock
• Application Lock
• SIM Lock
• Change Passwords
• Certificates
•Network
• Current Network
•Scan Avail.
Networks
• Find New Network
• My Network List
• Search Setup
• Service Tone
* optional features
12
get started
get st arted
insert your SIM card
Caution:
Don’t bend or scratch your SIM card. Keep it
away from static electricity, water, and dirt.
Yo u r Subscriber Identity Module (SIM) card stores your
phone number and other information.
12
3
13
get started
insert & remove a memory
card
You can store music, photos, and other
multimedia files on an optional removable
microSD memory card.
Note:
Your phone can use a memory card with up to
4 GB capacity (greater than 1 GB storage guaranteed
only for SanDisk microSD cards).
To insert the memory card:
To remove the memory card:
1
Grasp the end of the card.
2
Pull the card up slightly, then pull it out.
14
get started
insert the battery
charge the battery
New batteries are not fully charged.
You can charge the battery with the
travel charger
:
1
Open the protective cover
on your phone’s mini-USB
port.
2
Insert the small plug on
the travel charger into the
phone’s mini-USB port.
Insert the other plug on
the travel charger into an
electrical outlet.
12
15
get started
You can also charge the battery with the
desktop
charger
:
1
Insert the small plug
on the travel charger
into the mini-USB
port on the back of
the desktop charger.
Insert the other plug
on the travel charger
into an electical outlet.
2
Slide the phone into
the charger as
shown.
The battery charge indicator light on your phone shows
when the battery is charging. The display shows
Charge Complete
when finished.
16
get started
turn phone on
& off
Press and hold
O
for a few
seconds, or until the display turns on or off.
make a call
Enter a phone number and
press
N
.
Tip:
To
voice dial
a call, see your User’s Guide.
answer a call
When your phone rings and/or
vibrates, press
N
to answer.
end a call
To “hang up,” press
O
.
17
get started
store a phone number
You can store a phone number in your list of
Contacts
.
Note:
You can store a new contact in
phone memory
, or
store the contact both in phone memory and on your
SIM card
. When you choose to store a contact to both
locations, only the contact’s name and phone number are
stored on the SIM card.
To store a phone number:
1
Enter a phone number in the home screen.
2
Press
Save
.
3
Enter a name for the phone number, and enter other
information as desired.
4
Press
Save
to store the contact.
Tip:
To learn more about storing phone numbers and
email addresses on your phone, see your User’s Guide.
18
get started
call a stored phone number
To call a number stored in your contact list:
Find it:
s
>
L
Contacts
1
Scroll to the contact.
Shortcut:
In the contact list, press keypad keys to
enter the first letters of the contact you want.
Press
s
to go to the contact.
2
Press
N
to call the contact.
your phone number
To see your phone number:
Find it:
s
>
u
Settings
>
Call Settings
>
My SIM Number
To see your phone number while you’re on a call, press
Options
, then select
My Telephone Numbers
.
To store or edit your name and phone number on your
SIM card, scroll the field you want to edit and press the
center key
s
. If you don’t know your phone number,
contact your service provider.
19
music
mus ic
introduction
To listen to music on your phone, you need to:
1
Load music on your computer.
2
Transfer music from the computer to your phone.
3
Use the music player to play and manage music files
on your phone.
20
music
1. load music on your
computer
To create a music library on your computer, you can
purchase Microsoft® Windows® Media DRM-protected
music files from supported on-line music stores (such as
Urge, Yahoo, and Napster).
You can also
load song files from a music CD
onto your
computer:
1
Insert the music CD in your computer’s CD drive.
2
Launch Microsoft Windows Media Player 11.
3
Copy the music CD to the media player library (also
called ripping the CD).
If your computer is connected to the Internet, the media
player may retrieve CD information such as song titles,
album name, artist name, and album artwork. This
information will display in your phone’s music player.
To minimize song file size, or convert iTunes® song files
to a format compatible with Windows Media Player 11,
see your User’s Guide.
21
music
2. transfer music to your
phone
Use Windows Media Player 11 to transfer music from
the computer to your phone. (If necessary, you can
download Windows Media Player 11 at
www.microsoft.com/windowsmedia
).
Note:
Windows Media Player 11 requires Windows XP™
or later to run. If you are using an earlier version of
Windows OS, see your User’s Guide to manually transfer
music to your phone.
Note:
Windows Media Player 11 can copy and sync
music files only to the memory card in your phone. To
copy or sync files stored in phone memory, see your
User’s Guide.
on your phone
Insert a memory card in your phone (see page 13), then:
Find it:
s
>
u
Settings
>
Connections
>
USB Setting
>
Media Synchronization
22
music
Attach the Motorola Original USB cable to
the mini-USB port on your phone and to an
available USB port on your computer. A
Motorola Original USB cable and supporting
software may be included with your phone. These tools
are also sold separately.
on your computer
Run Windows Media Player 11. Your phone appears in
the upper right corner of the Windows Media Player 11
screen, and the music files stored on the phone’s
memory card are listed on the left side of the screen.
1
Select the “Sync” tab in Windows Media Player 11.
2
Drag and drop songs or playlists onto the “Sync
List” on the right side of the Windows Media
Player 11 screen.
3
Click “Start Sync” to copy the songs onto the
phone’s memory card.
4
When you finish, disconnect your phone from the
computer.
23
music
3. play music
Find it:
s
>
j
Multimedia
>
Media Finder
>
Music Library
Select a song or playlist from these categories:
Recently Played
,
Shuffle Songs
(play all songs in random order),
All Songs
,
Playlists
,
Artists
,
Albums
,
Genres
, or
Composers
.
Note: If you receive a call during a song
, the music
player pauses the song until the call is over.
album
artwork
Return to previous
screen.
Select & adjust
music player options.
10/10/2008--910 Kb
song.name
01:15 02:40
Options Back
Song Title
Artist
Album
Timer Shows
% Played
Use navigation
key
S
to
control song
playback.
24
music
listen with Bluetooth®
stereo headphones
Connect your phone with optional Bluetooth
stereo headphones to listen to music stored on
your phone.
To connect your phone to a set of Bluetooth stereo
headphones for the first time
, make sure the
headphones are
on
and
ready
in pairing or bonding
mode (see the device user’s guide).
Find it:
s
>
u
Settings
>
Connections
>
Bluetooth
1
Press
Options
and select
Search For Device
.
2
Select
Headset
.
Your phone lists the Bluetooth audio devices it finds
within range.
3
Scroll to the Bluetooth stereo headphones in the list.
4
Press
s
to connect with the stereo headphones.
25
music
adjust audio settings
You can adjust audio settings to optimize the sound
quality when listening to music through the phone
speaker, stereo headphones, or headset.
To change playback volume
, press the volume keys on
the side of your phone.
To change the equalizer setting
, press
Options
and select
Setup
. Select
Equalizer
, then select the music type.
To set stereo separation
, press
Options
and select
Setup
,
then select
Stereo Effects
. Next, select
Spatial Audio
, then select
separation level.
To set bass boost
, press
Options
and select
Setup
, then
select
Stereo Effects
. Next, select
Bass Boost
, then select
bass level.
26
music
create a playlist
create a playlist on your computer
On your computer
: Use Windows Media Player 11 (or
your computer’s media player program) to create a
playlist of music files stored on the computer.
On your phone
:
Find it:
s
>
u
Settings
>
Connections
>
USB Setting
>
Memory Card
Connect your phone to the computer
through a USB
cable connection, then drag and drop the playlist onto the
phone or memory card.
create a playlist on your phone
Find it:
s
>
j
Multimedia
>
Media Finder
>
Music Library
>
Playlists
1
Press
Options
and select
Create New Playlist
.
2
Enter a name for the playlist.
3
Select a storage location for the playlist (
Memory Card
or
Phone Memory
), then press
Save
.
27
music
4
Scroll to the playlist, and press
s
to select it.
5
Scroll to
Add Songs
, and press
s
to select it.
6
Scroll to
All Songs
,
Playlists
,
Artists
,
Albums
,
Genres
, or
Composers
,
and press
s
to select it.
7
Your phone shows a song list. Scroll to the songs
you want to add, and press
s
to select them.
8
Press
Add
to add the selected songs to the playlist.
9
Repeat the procedure to add more songs, or press
Back
to return to the
My Media
menu.
play a playlist
Find it:
[
>
Playlists
Scroll to the playlist and press
Options
, then select
Play
.
turn off music player
Press
Back
repeatedly until you return to the home screen.
or
Press
O
.
28
messages
messages
read & reply to a message
When you receive a message, your phone plays
an alert, and the internal display shows
New Message
with the new message indicator
U
.
To read and reply to the message:
1
Press
View
.
2
To answer the message, press
Options
, then select
Reply
.
3
Enter the text of your message.
or
To enter a prewritten text template, press
Options
and
select
Insert
, then select
Text Template
. Scroll to the text
template you want and press
Insert
.
4
Press
Send
to send your reply.
To learn more about sending and receiving messages
with your phone, see your User’s Guide.
29
messages
send a message
To send a message to a phone or to an email
address:
Find it:
s
>
g
Messages
>
Create Message
To learn more about sending and receiving messages
with your phone, see your User’s Guide.
30
personalize
persona lize
home screen shortcuts
From the home screen, you can press the
navigation key up, down, left, or right as shortcuts
to your favorite features. You can change the
shortcuts to suit your needs.
To
change
navigation key shortcut icons in the home
screen:
Find it:
s
>
u
Settings
>
Home Screen
>
Navigation Keys
>
Icon Display
>
Up
,
Down
,
Left
, or
Right
Select a direction, then choose the feature you want to
open when you press the navigation key in that direction.
To
show or hide
navigation key shortcut icons in the
home screen:
Find it:
s
>
u
Settings
>
Home Screen
>
Navigation Keys
>
Icon Display
>
Show
or
Hide
Note:
You can press
S
to select the features in the
home screen even when the icons are hidden.
31
personalize
wallpaper
Change the background wallpaper image in the home
screen:
Find it:
s
>
u
Settings
>
Home Screen
>
Change Wallpaper
Scroll to an image and press
Select
. The new wallpaper is
applied to the current theme.
clock style
Change the clock style in the home screen, or turn off
the clock:
Find it:
s
>
u
Settings
>
Home Screen
>
Clock Style
>
Home Screen Clock
date
Show or turn off the date in the home screen:
Find it:
s
>
u
Settings
>
Home Screen
>
Date
>
On
or
Off
32
web
web
GOOGLE® search
Use your phone’s browser to perform a Web
search using the GOOGLE Web site.
Note:
You must have browser service activated on your
phone to use this feature.
Find it:
s
>
1
Web Access
>
Browser
1
Press
Options
>
My Bookmarks
.
2
Press
S
to scroll to the
Google
bookmark, and
press
s
to select it.
3
Press
s
to select the GOOGLE text entry window.
4
Enter a search topic in the text entry window.
5
Press
S
down to scroll to the GOOGLE Search
button, and press
s
to select it.
The browser displays the results of your search.
To learn more about using the phone browser, see your
User’s Guide.
33
email
email
check your email account
Check your personal Web-based
email
account
(such as Hotmail®, Gmail
TM
, or Yahoo!®) on the
Web).
Note:
You must have browser service activated on your
phone to use this feature.
Find it:
s
>
1
Web Access
>
Browser
1
Press
Options
, then select
Go to URL
.
2
Enter the URL for your Web-based email account,
then press
Go
.
To learn more about using the phone browser, see your
User’s Guide.
34
accessories
acces sories
To see more accessories, visit
www.hellomoto.com
Bluetooth® Stereo
Headphones S9
Bluetooth® Stereo
Headphones HT820
Bluetooth® Slider
Headset H800
Bluetooth® Headset
H670
Bluetooth® Stereo
Controller S705
Bluetooth® Headset
H700
35
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and
settings of your service provider’s network. Additionally, certain
features may not be activated by your service provider, and/or the
provider's network settings may limit the feature’s functionality.
Always contact your service provider about feature availability and
functionality. All features, functionality, and other product
specifications, as well as the information contained in this user's
guide are based upon the latest available information and are
believed to be accurate at the time of printing. Motorola reserves the
right to change or modify any information or specifications without
notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. The Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under license. Java and all other
Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries. Microsoft and
Windows are registered trademarks of Microsoft Corporation; and
Windows XP and Windows Media are trademarks of Microsoft
Corporation. Hotmail is a registered trademark of Microsoft
Corporation. Macintosh and iTunes are registered trademarks of Apple
Computer, Inc. Yahoo! and the Yahoo! logo are trademarks and/or
registered trademarks of Yahoo! Inc. Gmail is a trademark of GOOGLE
Inc. All other product or service names are the property of their
respective owners.
© Motorola, Inc., 2007.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
Manual Number: 68XXXXX246-O
www.motorola.com
v467109.QSG.BACK.eps 8/28/2007 4:53:46 PM
-
1
-
2
-
3
-
4
-
5
-
6
-
7
-
8
-
9
Motorola MOTO Z6w Quick start guide
- Category
- Mobile phones
- Type
- Quick start guide
Ask a question and I''ll find the answer in the document
Finding information in a document is now easier with AI
Related papers
-
Motorola Motorokr U9 Quick start guide
-
Motorola MOTO U9 Quick start guide
-
Motorola MOTORAZR 2 V8 User manual
-
-
-
Motorola AURA - MANUAL 2 User guide
-
-
-
-
Motorola ROKR Quick start guide
