INSTALLATION INSTRUCTIONS

SQF, SQAZ and SQHZ

Mounting Frames

Upon receipt, thoroughly inspect for any

freight damage which should be brought

to the attention of the delivery carrier. Com-

pare the catalog description listed on the

packing slip with the label on the carton to

ensure that you have received the correct

merchandise.

CJ520004 Rev. B

1 of 2 6/10

Figure 3

Figure 1

Figure 2

IMPORTANT SAFETY INFORMATION

For Your Protection, Read Carefully

WARNING: Risk of fire. Do not install

insulation within 3 inches of fixture sides

or wiring compartment, nor above the fix-

ture in such a manner as to entrap heat.

1. Electric current can cause painful

shock or serious injury unless handled

properly. For your safety, always

remember the following:

· Turn off the power supply.

· Ground the fixture to avoid poten-

tial electrical shocks.

· Do not handle an energized fixture

or energize any fixture with wet

hands, when standing on a wet or

damp surface, or in water.

2. Specific safety information concerning

lamps:

· Match wattage of fixture and lamp

exactly.

· Do not remove or insert lamp when

power is on.

· Do not scratch glass or subject lamp

to undue pressure as either may

cause lamp breakage.

· Protect operating lamp from sources

of moisture.

· If lamp is marked it contains

mercury. Follow disposal laws. See:

www.lamprecycle.org.

NEW INSTALLATION FOR SQ

Lay-in panel T-bar ceiling:

1. Cut ceiling opening slightly larger

than the outside diameter of the

mounting frame.

2. Position mounting frame through

opening in ceiling. Release clamp-

ing latch arms and adjust channel

bars to the correct spacing be-

tween T-bar as shown in Figure 1.

Secure channel bars to T-bar by

means of wire ties, screws or by

bending ends onto T-bar as shown

in Figure 2.

3. Once mounting frame has been

secured in structure, adjust the

mounting frame vertically to align

the bottom edge to either flush or

slightly above (1/8" max) the ceiling

line (Figure 3). Secure mounting

frame into position by closing the

clamping latch arm. The notch

located in the draw-down flange of

the housing can be used to assist

with alignment of multiple fixtures

(Figure 4).

4. If additional security is required, a

No. 8 sheet metal screw, wire tie or

wire (not supplied) may be used to

tie the latch arm to the mounting

frame as shown in Figure 1.

5. Remove knockouts on junction box to

feed power supply to fixture as

shown in Figure 5. Supply wire must

meet applicable electrical codes

and be rated for a minimum of 75

Junction box is thru-wire rated for 8-

No. 12 AWG conductors (4 in-4 out).

6. Complete necessary wire connec-

tions. Snap the door onto the junc-

tion box.

7. To adjust trim after installation, see

“ Trim-Post Installation Adjustment.”

Bent tab

T-Bar

Wire tie

Channel

bar

SAVE THESE INSTRUCTIONS

Open

Closed

Clamping

latch arms

Mounting

frame

Ceiling

Flush or

slightly above

ceiling line

Sight

Notches

Figure 4

Figure 5

Remove

knockouts

as needed

CJ520004 Rev. B

2 of 2 6/10

SQF, SQAZ and SQHZ Mounting Frames Installation Instructions

TRAHCGNITOOHSELBUORT

nimelborpehtetacol,noitidnocdoognimeesyehtfI.eludomni-emarfropmalehtotegamadelbis

ivynarofkcehC

.snoitcaevitcerrocdnasesuacelbissopfotsilgniwollofeht

motpmySesuaCelbissoPnoitcAevitcerroC

OTSLIAFPMAL

THGIL

dezigrenetonerutxifehtgnideeftiucriC·

noitcennocelud

omrotiucricnirorregniriW·

pmalytluaF·

tuptuotsallabroeniL·

tuodenrubtsallaB·

wolooterutarepmettneibmA·

.dezigrenesitiucrictahterusneotesufrorekaerbtiucrickcehC·

erasnoitcennoctahterusneotxobecilpserutxifenimaxE·

.tcerroc

ylbareferp,pmalrehtonaetutitsbusdnapmalytluafehtevomeR·

lanigiroehtecalper,sthgilpmalehtfI.

thgilotnwonksitahteno

.enowenahtiw

.egatlovtiucricnepokcehC.erutxiftaegatlovenilkcehC·

.ytiunitnoctiucri

ckcehC·

.snoitidnoclatnemnorivnegnitsixetsniagagnitartsallabkcehC·

TUOSEOGPMAL

GNITHGILRETFA

pmalytluaF· n

ahtrehtarmotpmyssihttibihxelliwpmalayllanoisaccO·

.pmalwenaetutitsbuS.thgilotgniliafylpmis

NOSELCYCPMAL

FFODNA

erutxifotesolcootsinoitalusnI·

hgihootegattawpmaL·

wolegatlovtuptuotsallaB·

)"3tsaelta(eludomdnuoramorfnoitalusnievomeR·

.gnisuohnideificepsegattawpmalllatsnI·

.egatlovtiucricnepokcehC.erutxifehttaegat

lovenilkcehC·

NEW INSTALLATION FOR SQ

Non-accessible ceiling (plaster, drywall,

etc.):

For microflange (MFLG) installation,

an additional component (shipped

separately) is required to be installed

PRIOR TO drywall installation and ver-

tical alignment of this fixture.

2. Release clamping latch arms and

adjust channel bars to the correct

spacing between joists as shown in

Figure 1.

Mounting Channel Bar-Flexible

Wiring Method

Bend ends of channel bars 90° and

adjustment at its lowest point on the

mounting frame. Make sure bottom

of the flange is flush with the bottom

of the joists. Secure mounting frame

into position by closing the clamping

latch arm. Channel bars will accom-

modate mount to joists with vertical

up to 24” O.C. joists. The notch located

in the draw-down flange of the housing

can be used to assist with alignment of

multiple fixtures.

Non-Flexible Wiring Method

If non-flexible wiring methods are used,

follow procedure for Flexible Wiring

Method, then lower mounting frame

equal to the thickness of the finished

ceiling or slightly above, as shown in

Figure 3. The notch located in the draw-

down flange of the housing can be used

to assist with alignment of multiple fix-

tures.

4. Remove knockouts on junction box to

feed power supply to fixture as shown

in Figure 5. Supply wire must meet ap-

plicable electrical codes and be rated

for a minimum of 90

C. Junction box is

thru-rated for 8-No. 12 AWG conductors

(4in- 4out).

Figure 6

Figure 9

Pull

down

Grip

edge of

flange

1. Loosen

screws

in key

slots

2. Pull

socket

cup

through

aper-

ture

Figure 7

1. Loosen speed nuts

2. Adjust aperture

3. Retighten speed nuts

1. Loosen

main screw

and dis-

engage

from key

slots

3. Remove socket cup

from upper reflector

2. Pull downupper

reflector

Figure 8

Trim Post Installation Adjustment

In the event that the trim is in need of

alignment after installation, adjust-

ment can be made to the housing.

1. Remove lower trim by gripping

edge of flange and pulling it out

of upper reflector and disengage

safety chain(Figure 6).

2. Remove lamp.

3. Loosen screws in key hole slots

of upper reflector, disengage from

slots and pull socket cup through

aperture (Figure 7).

4. Loosen screws in upper reflector,

disengage from keyhole slot and

remove upper reflector from hous-

ing (Figure 8).

5. To adjust housing for trim align-

ment, reach through aperture and

loosen two speed nuts. Adjust

housing as required and retighten

nuts (Figure 9).

6. Reinstall upper reflector, socket

cup, lamp and lower trim in reverse

order. If needed, refer to trim in-

stallation instructions.
