Thank you for purchasing a Rosewill Computer Case.

Please read the instruction manual before use and

retain for future reference.

• Product Overview

Disassembly ...................................................... 02

Accessory Box ................................................... 03

• Installation Guide

1. Open the Unit ................................................ 04

2. Install the Power Supply ................................ 05

3. Install Motherboard ........................................ 05

4. Install Add-on Card ........................................ 06

5. Install 3.5”/2.5” HDD/SDD ............................. 07

6. Care ............................................................... 08

7. Options .......................................................... 09

• Specications Table ........................................... 12

Front I/O Cable Pinout ....................................... 13

Front I/O ............................................................. 13

PRISM S / PRISM S-LITE

Gaming Case

Product Overview

Disassembly (components vary by country)

Cooling Fan

HDD Cage

SSD

Plates

Side Panel

Cooling Fan

(PRISM S-LITE provides one cooling fan)

Dust Filter

Front View Right Side View Rear View Left Side View

210 mm

477 mm

475 mm

SSD/HDD

Plate

Glass Panel

Gaming Case

PRISM S / PRISM S-LITE

Accessory Box

Image Part Name Qty Function/Component

Screw-A (6-32 x 6mm) 5 PSU

Screw-B (6-32 x 5mm) 22

Motherboard

3.5” HDD

Screw-C (M3 x 5mm) 20 2.5” SSD

Standoff 9

Motherboard

(Pre-Installed)

Nut Setter 1

Standoff Installation

(Optional: Standoffs are

Pre-Installed)

Cable Tie 10 Cable Management

Velcro Strap 4 Cable Management

Micro Fiber Towel 1 Tempered Glass Cleaning

PRISM S / PRISM S-LITE

Gaming Case

Installation Guide

1. Open the Unit

1-1. Loosen the thumbscrews and take off panel R and L (Figure 1).

•

Simply loosen screws to

remove side panel

Gaming Case

PRISM S / PRISM S-LITE

2. Install the Power Supply

2-1. Set the power supply unit (PSU) at the top of the case and secure with Screw-A (Figure 2).

3. Install Motherboard

3-1. Secure the motherboard down onto the pre-installed standoff with Screw-B (Figure 3).

PRISM S / PRISM S-LITE

Gaming Case

4. Install Add-on Card

4-1. Loosen the screws to open the cover panel/slot cover (Figure 4a).

4-2. Install the add-on card and secure with screws (Figure 4b).

Gaming Case

PRISM S / PRISM S-LITE

5f 5g 5h

5-2. Secure the 3.5" drive onto the tray/plate with Screw-B (Figure 5d/5e).

5-3. Secure the 2.5” drive onto the tray with Screw-C (Figure 5f/5g/5h).

* If drive is installed on 5e or 5g, water cooling radiator cannot be added.

5-4. Put the tray/plate back onto the chassis and secure with screws.

5. Install 3.5”/2.5” HDD/SDD

5-1. Take out the 3.5”/2.5” HDD/SDD trays/plates from the chassis (Figure 5a/5b/5c).

PRISM S / PRISM S-LITE

Gaming Case

6-2. Clean the dust lters on the bottom regularly to ensure adequate airow (Figure 6b).

6. Care

To prevent damage, keep all panels closed and secured.

6-1. Put the side panels back in place and secure with thumbscrews (Figure 6a).

Gaming Case

PRISM S / PRISM S-LITE

7. Options

7-1. LED Light Mode (only on PRISM S)

Press LED light button briefly:

RGB 1 (steady-rainbow) > RGB 2 (owing-rainbow) > RGB 3 > RGB 4 > RGB 5 (seven-

color-breath) > RGB 6 (seven-color-one-way-billboard) > (seven-color-two-way-billboard) >

Red > Green > Blue > White > Yellow > Cyan > Pink

Press LED light button and hold for >1.5 seconds:

LED light turns off.

7-2. Liquid Cooling Radiator Installation

Installing water cooling radiator on the side:

a. Unscrew to remove the drives plate (Figure 7a).

b. Secure the radiator with screws (Figure 7b).

PRISM S / PRISM S-LITE

Gaming Case

d. Secure the radiator with screws and put the dust lter back (Figure 7d).

Installing water cooling radiator on the bottom:

c. Remove the bottom dust lter (Figure 7c).

Gaming Case

PRISM S / PRISM S-LITE

7-3. GPU Card Holder

PRISM S/S-LITE provides GPU card holder to prevent your GPU from bend (gure 7e/7f):

PRISM S / PRISM S-LITE

Gaming Case

Specifications Table

Model

Model Name PRISM S / PRISM S-LITE

Specifications

Type ATX Mid Tower

Color White

Case Material Steel / Tempered Glass

With Power Supply No

Power Supply Mounted Top

Motherboard Compatibility E-ATX, ATX, Micro ATX

With Side Panel Window Yes / Tempered Glass Side Panel

Expansion

External 5.25" Drive Bays 0

Internal 3.5" Drive Bays 3 (0)

Internal 2.5" Drive Bays 2 (5)

Expansion Slots 7

Front Ports

2 x USB 3.0

HD Audio In/Out

LED Light Control/ Reset

Cooling System

120 mm Fans

3 x Bottom

2 x Side

1 x Rear

Physical Specifications

Dimensions 8.27” x 18.7” x 18.5” (W x H x D)

Weight 17.6 lbs

Features

• Supports up to 2 x 120mm Fans / 240mm Water-Cooling Radiator on the side, 3 x 120mm Fans

/ 360mm Water-Cooler on the bottom, 1 x 120mm Fan at the rear

• Supports up to 160mm tall CPU Cooler

• Supports up to 440mm Graphics Card

• Easy-Access Bottom Dust Filter

Gaming Case

PRISM S / PRISM S-LITE

Front I/O Cable Pinout

Front I/O

USB 3.0 CONNECTOR HD Audio CONNECTOR

Mic.

HD Audio

USB 3.0

LED Switch

or Reset

Power

PRISM S / PRISM S-LITE_A

Technical Support Information

[email protected] 1-800-575-9885

----------------------------------------------------------------------------------

Thank you for purchasing a quality Rosewill product.

Please register your product at www.rosewill.com

for complete warranty information and support for your product.
