Avanti CHAIR, Avanti Bar Side Chair Assembly Instructions

  • Hello! I've reviewed the instructions for the Avanti Bar Side Chair AV 0604. This document provides a detailed assembly guide, including a list of parts and step-by-step instructions. I can answer questions about the assembly process, parts included, and features of the chair.
  • How many back rests are included?
    How many colored screws are included?
    What is the first step in the assembly process?
BREEZESTA tm
Recycled Poly Furniture
AVANTI BAR SIDE CHAIR
RIGHT SIDE ASSEMBLY STEP 1
LEFT SIDE ASSEMBLY
STEP 2
SPREADERS
FRONT/BACK RAILS
BACK RESTS
STEP 3
Step 2. Place spreaders into mortise (pocket)
inside assemblies as shown. Loosely attach
with screws "A." Follow this procedure with
rails and slats, followed by back rests.
LIST OF PARTS
Right Side (1)
Left Side (1)
Slats (5)
Spreaders (3)
Front Rail (1)
Back Rail (1)
Back Rests (3)
Colored Screws "A" (22)
Insert Bit Tool (1)
A-2.5"(22 pcs.)colored
Step 1. Align right and left side assemblies
as shown.
AV-0604
/
