FMI FB36CB User manual

Brand: FMI

Model: FB36CB

Category: Fireplaces

Type: User manual

This manual is also suitable for

Save this manual for future reference.

WARNING: If the information in this manual is not

followed exactly, a fire or explosion may result

causing property damage, personal injury, or loss

of life.

— Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other

appliance.

— WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any

phone in your building.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s in-

structions.

• If you cannot reach your gas supplier, call the fire

department.

— Installation and service must be performed by a

qualified installer, service agency, or the gas

supplier.

WARNING: Improper installa-

tion, adjustment, alteration,

service, or maintenance can

cause injury or property dam-

age. Refer to this manual for

correct installation and opera-

tional procedures. For assis-

tance or additional informa-

tion consult a qualified in-

staller, service agency, or the

gas supplier.

WARNING: For use only with

decorative type unvented room

heaters. Do not build a wood fire.

UNVENTED (VENT-FREE)

LogMate

UNIVERSAL FIREBOX

OWNER’S OPERATION AND INSTALLATION MANUAL

FB36NCA, NLFB36NC, and FB42NC

Non-circulating Models

FB36CB, NLFB36C, and FB42CA

Circulating Models

This firebox has been tested and

approved by I.A.S. under their

REQ. 2-97 for use with any ANS

Z21.11.2 approved gas logs.

This appliance may be installed in an aftermarket*, permanently located, manufactured

(mobile) home, where not prohibited by local codes.

This appliance is only for use with the type of gas indicated on the rating plate. This

appliance is not convertible for use with other gases.

*Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

SAFETY

INFORMATION

IMPORTANT: Read this owner’s

manual carefully and completely

before trying to assemble, oper-

ate, or service this firebox. Im-

proper use of this firebox can cause

serious injury or death from burns,

fire, explosion, electrical shock, or

carbon monoxide poisoning.

CAUTION: Carefully review

the instructions supplied with the

decorative type unvented room

heater for the minimum fireplace

size requirement. Do not install

the appliance in this firebox un-

less this firebox meets the mini-

mum dimensions required for the

installation.

WARNINGS

WARNING: Any change to

this firebox or its controls can be

dangerous.

1. Do not use this firebox as a wood-burn-

ing fireplace. Use only decorative

unvented room heaters (log sets).

2. Do not add extra logs or ornaments

such as pine cones, vermiculite, or rock

wool. Using these added items can

cause sooting.

3. Do not use blower accessory with Mod-

els FB36NCA, NLFB36NC, or FB42NC

Series. Use only the provided hood, or

appropriate polished brass hood acces-

sory. See Accessories on page 15.

4. Vent-free gas log heaters installed in

these fireboxes require fresh air venti-

lation to run properly. See Air for Com-

bustion and Ventilation, pages 5

through 7.

5. Do not run firebox

• where flammable liquids or vapors

are used or stored

• under dusty conditions

6. Do not use this firebox to cook food or

burn paper or other objects.

7. Turn firebox off and let cool before ser-

vicing. Only a qualified service person

should service and repair firebox.

8. Operating firebox above elevations of

4,500 feet could cause pilot outage.

9. Do not use the firebox if it has been

under water due to the shock hazard

that could result with the blower acces-

sary (if installed) in place.

WARNING: Do not allow fans

to blow directly into the firebox.

Avoid any drafts that alter burner

flame patterns. Ceiling fans can

create drafts that alter burner

flame patterns. Altered burner

patterns can cause sooting.

WARNING: Do not use a

blower insert, heat exchanger

insert, or other accessory not ap-

proved for use with this firebox.

Do not place clothing or other

flammable material on or near

the appliance. Never place any

objects in the firebox or on logs.

Firebox front and screen be-

comes very hot when running

firebox. Keep children and adults

away from hot surfaces to avoid

burns or clothing ignition. Fire-

box will remain hot for a time

after shutdown. Allow surfaces

to cool before touching.

Carefully supervise young chil-

dren when they are in the room

with firebox.

You must operate this fireplace

with the provided fireplace screen,

hood, and brick liner, if provided,

in place. Make sure these parts

are in place and screens are closed

before running firebox. The sup-

plied hood may not be replaced

with a hood which may be pro-

vided with a log heater.

Keep the fireplace area clear and

free from combustible materials,

gasoline, and other flammable

vapors and liquids.

107317

OWNER’S MANUAL

LOCAL CODES

Install and use fireplace with care. Follow all

local codes. In the absence of local codes, use

the latest edition of The National Fuel Gas

Code ANS Z223.1, also known as NFPA 54*.

Firebox must be electrically grounded in

accordance with the National Electrical Code,

ANS/NFPA70 (latest edition).

*Available from:

American National Standards Institute, Inc.

1430 Broadway

New York, NY 10018

National Fire Protection Association, Inc.

Batterymarch Park

Quincy, MA 02269

UNPACKING

1. Use utility knife to cut carton all the

way around above the staples on the

bottom tray. Lift carton off the firebox

and discard.

2. Remove all protective packaging from

inside firebox. Carefully lift the fire-

box off the bottom corrugated tray.

3. Check carton contents for the

following:

• Screen assembly

• Screen support rod

• Hardware and parts bag containing

the following:

- Owner’s Operation and Installa-

tion Manual

- 2 - Black #10 x 3/8" Phillips

screws for mounting screen sup-

port rods

If any items are missing, inform dealer

where you bought firebox.

4. Check all items for any shipping dam-

age. If damaged, promptly inform

dealer where you bought firebox.

Notice:

The firebox identification

label (including model number,

serial number, clearances, etc.)

is located either on the left front

edge of the firebox or behind the

left side firebrick panel. See Fig-

ure 16, page 12.

PRODUCT

FEATURES

OPERATION

This firebox is designed for use with ap-

proved ANS Z21.11.2 decorative type

unvented room heaters. (Physical size limi-

tations apply. Refer to minimum firebox

requirements supplied with log heater.) It

requires no outside venting or chimney mak-

ing installation easy and inexpensive. When

used without the blower, the firebox requires

no electricity making it ideal for emergency

backup heat.

BLOWER ACCESSORY

The FB36CB, NLFB36C, or FB42CA fire-

boxes will accept the GA3700 accessory.

The variable blower allows you to select the

fan speed you desire. The blower circulates

heated air from the firebox into the room.

Use of blower is optional.

BRICK LINER

Your firebox may feature a concrete brick

liner. As with all concrete liners, this liner

may develop slight cracks when exposed to

heat. These cracks will not affect the perfor-

mance of the fireplace or vent-free gas logs.

LOCATING

FIREBOX

PLANNING

Plan where you will install the firebox. This

will save time and money later when you

install the firebox. Before installation, con-

sider the following:

1. Where the firebox will be located. Al-

low for wall and ceiling clearances (see

Installation Clearances, pages 8 and 9).

2. Everything needed to complete instal-

lation.

3. These models CANNOT be installed

in a bedroom unless the maximum Btu

rating of the installed vent-free log set

is less than 10,000 Btu/hr.

4. Proper air for combustion and ventila-

tion (page 5).

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

PRODUCT

SPECIFICATIONS

Figure 1 - Firebox Front View

Figure 2 - Firebox Side View

" (36" models) 47

" (42" models)

36" (36" models) 42" (42" models)

35"

Built-in Nailing

Flanges

Standoffs

Louvers

(Models FB36CB,

NLFB36C, and

FB42CA only)

Diameter Holes

Standoffs

Electrical Access Hole

Strain relief fitting for electrical cable when hard

wiring firebox for built-in installations (strain relief

fitting included on circulating models only)

Gas Line Access

Hole (either side)

Electrical Access

Hole (for use

when using

blower power

cord with external

electrical outlet.

See Blower Kit

Instructions)

Figure 3 - Firebox Top View

/8" (36" Models) 36

/8" (42" Models)

/8" (36" Models) 48

/8" (42" Models)

*Interior Dimensions Within Brick Liner

(NLFB36C and NLFB36NC Models

Will Differ Slighty)

36" (36" Models) 42" (42" Models)

41" (36" Models) 47" (42" Models)

34" (36" Models) 40" (42" Models)*

/8" (36" Models) 35

/8" (42" Models)

/4" (36" Models)

/4" (42" Models)*

/2"

/4"

5/8"

107317

OWNER’S MANUAL

PROVIDING ADEQUATE

VENTILATION

The following are excerpts from National

Fuel Gas Code, NFPA 54/ANS Z223.1, Sec-

tion 5.3, Air for Combustion and Ventilation.

All spaces in homes fall into one of the three

following ventilation classifications:

1. Unusually Tight Construction

2. Unconfined Space

3. Confined Space

The information on pages 5 through 7 will

help you classify your space and provide

adequate ventilation.

Unusually Tight Construction

The air that leaks around doors and win-

dows may provide enough fresh air for

combustion and ventilation. However, in

buildings of unusually tight construction,

you must provide additional fresh air.

Unusually tight construction is de-

fined as construction where:

a. walls and ceilings exposed to the

outside atmosphere have a con-

tinuous water vapor retarder with

a rating of one perm (6 x 10

-11

per pa-sec-m

) or less with open-

ings gasketed or sealed

and

b. weather stripping has been

added on openable windows and

doors

and

c. caulking or sealants are applied

to areas such as joints around

window and door frames, be-

tween sole plates and floors, be-

tween wall-ceiling joints, be-

tween wall panels, at penetra-

tions for plumbing, electrical, and

gas lines, and at other openings.

If your home meets all of the three

criteria above, you must provide ad-

ditional fresh air. See

Ventilation Air

From Outdoors

, page 7.

If your home does not meet all of the

three criteria above, proceed to

Deter-

mining Fresh-Air Flow for Firebox

Location,

page 6.

Today’s homes are built more energy effi-

cient than ever. New materials, increased

insulation, and new construction methods

help reduce heat loss in homes. Home owners

weather strip and caulk around windows and

doors to keep the cold air out and the warm air

in. During heating months, home owners

want their homes as airtight as possible.

While it is good to make your home energy

efficient, your home needs to breathe. Fresh

air must enter your home. All fuel-burning

appliances need fresh air for proper com-

bustion and ventilation.

Exhaust fans, fireboxes, clothes dryers, and

fuel burning appliances draw air from the

house to operate. You must provide ad-

equate fresh air for these appliances. This

will insure proper venting of vented fuel-

burning appliances.

AIR FOR

COMBUSTION AND

VENTILATION

WARNING: This firebox shall

not be installed in a confined space

or unusually tight construction

unless provisions are provided

for adequate combustion and ven-

tilation air. Read the following in-

structions to insure proper fresh

air for this and other fuel-burning

appliances in your home.

Confined and Unconfined Space

The National Fuel Gas Code, ANS Z223.1

defines a confined space as a space whose

volume is less than 50 cubic feet per 1,000

Btu per hour (4.8 m

per kw) of the aggre-

gate input rating of all appliances installed

in that space and an unconfined space as a

space whose volume is not less than 50

cubic feet per 1,000 Btu per hour (4.8 m

per

kw) of the aggregate input rating of all

appliances installed in that space. Rooms

communicating directly with the space in

which the appliances are installed*, through

openings not furnished with doors, are con-

sidered a part of the unconfined space.

This heater shall not be installed in a con-

fined space or unusually tight construction

unless provisions are provided for adequate

combustion and ventilation air.

* Adjoining rooms are communicating only

if there are doorless passageways or ventila-

tion grills between them.

Continued

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

Example:

Gas water heater 40,000 Btu/Hr

Vent-free firebox

with log heater + 39,000 Btu/Hr

Total = 79,000 Btu/Hr

DETERMINING FRESH-AIR FLOW FOR FIREBOX LOCATION

Determining if You Have a Confined or Unconfined Space

Use this work sheet to determine if you have a confined or unconfined space.

Space: Includes the room in which you will install firebox plus any adjoining rooms with doorless passageways or ventilation grills

between the rooms.

1. Determine the volume of the space (length x width x height).

Length x Width x Height = ________cu. ft. (volume of space)

Example:

Space size 22 ft. (length) x 18 ft. (width) x 8 ft. (ceiling height) = 3168 cu. ft. (volume of space)

If additional ventilation to adjoining room is supplied with grills or openings, add the volume of these rooms to the total volume of

the space.

2. Divide the space volume by 50 cubic feet to determine the maximum Btu/Hr the space can support.

_____________ (volume of space) ÷ 50 cu. ft. = (Maximum Btu/Hr the space can support)

Example:

3168 cu. ft. (volume of space) ÷ 50 cu. ft. = 63.3 or 63,300 (maximum Btu/Hr the space can support)

3. Add the Btu/Hr of all fuel burning appliances in the space.

Vent-free firebox _______________ Btu/Hr

Gas water heater* _______________ Btu/Hr

Gas furnace _______________ Btu/Hr

Vented gas heater _______________ Btu/Hr

Gas firebox logs _______________ Btu/Hr

Other gas appliances* + ______________ Btu/Hr

Total = ______________ Btu/Hr

* Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.

4. Compare the maximum Btu/Hr the space can support with the actual amount of Btu/Hr used.

______________ Btu/Hr (maximum the space can support)

______________ Btu/Hr (actual amount of Btu/Hr used)

Example:

63,300 Btu/Hr (maximum the space can support)

79,000 Btu/Hr (actual amount of Btu/Hr used)

The space in the above example is a confined space because the actual Btu/Hr used is more than the maximum Btu/Hr the space can support.

You must provide additional fresh air. Your options are as follows:

A. Rework work sheet, adding the space of an adjoining room. If the extra space provides an unconfined space, remove door to adjoin-

ing room or add ventilation grills between rooms. See Ventilation Air from Inside Building, page 7.

B. Vent room directly to the outdoors. See Ventilation Air from Outdoors, page 7.

C. Install a lower Btu/Hr firebox, if lower Btu/Hr size makes room unconfined.

If the actual Btu/Hr used is less than the maximum Btu/Hr the space can support, the space is an unconfined space. You will need no

additional fresh air ventilation.

AIR FOR

COMBUSTION AND

VENTILATION

Continued

WARNING: If the area in which the firebox and gas log heater may be operated is smaller than that defined as

an unconfined space or if the building is of unusually tight construction, provide adequate combustion and

ventilation air by one of the methods described in the

National Fuel Gas Code, ANS Z223.1, Section 5.3

applicable local codes.

107317

OWNER’S MANUAL

AIR FOR

COMBUSTION AND

VENTILATION

Continued

VENTILATION AIR

Ventilation Air From Inside

Building

This fresh air would come from an adjoining

unconfined space. When ventilating to an

adjoining unconfined space, you must pro-

vide two permanent openings: one within

12" of the ceiling and one within 12" of the

floor on the wall connecting the two spaces

(see options 1 and 2, Figure 4). You can also

remove door into adjoining room (see op-

tion 3, Figure 4). Follow the National Fuel

Gas Code, NFPA 54/ANS Z223.1, Section

5.3, Air for Combustion and Ventilation for

required size of ventilation grills or ducts.

Figure 5 - Ventilation Air from Outdoors

Ventilation Air From Outdoors

Provide extra fresh air by using ventilation

grills or ducts. You must provide two per-

manent openings: one within 12" of the

ceiling and one within 12" of the floor.

Connect these items directly to the outdoors

or spaces open to the outdoors. These spaces

include attics and crawl spaces. Follow the

National Fuel Gas Code, NFPA 54/ANS

Z223.1, Section 5.3, Air for Combustion and

Ventilation for required size of ventilation

grills or ducts.

IMPORTANT:

Do not provide openings for

inlet or outlet air into attic if attic has a

thermostat-controlled power vent. Heated air

entering the attic will activate the power vent.

Figure 4 - Ventilation Air from Inside Building

Remove

Door into

Adjoining

Room,

Option

Ventilation Grills

Into Adjoining Room,

Option 2

Ventilation

Grills

Into Adjoining

Room,

Option 1

12"

Outlet

Air

Ventilated

Attic

Outlet

Air

Inlet

Air

Inlet Air

Ventilated

Crawl Space

Crawl

Space

To Attic

WARNING: Rework work-

sheet, adding the space of the

adjoining unconfined space. The

combined spaces must have

enough fresh air to supply all

appliances in both spaces.

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

Mantel Clearances for Built-In

Installation

If placing custom mantel above built-in

firebox, you must meet the minimum allow-

able clearance between mantel shelf and top

of firebox opening shown in Figure 7. These

are the minimum allowable mantel clear-

ances for a safe installation. Use larger clear-

ances wherever possible to minimize the

heating of objects and materials placed on

the mantel.

CAUTION: Do not allow the

vent-free gas log heater to touch

or extend beyond the fireplace

screen.

INSTALLATION

CLEARANCES

WARNING: Maintain the mini-

mum clearances. If you can, pro-

vide greater clearances from

floor, ceiling, and adjoining wall.

Carefully follow the instructions below. This

will ensure safe installation.

Minimum Wall and Ceiling

Clearances (see Figure 6)

A. Clearances from the side of the fire-

place cabinet to any combustible ma-

terial and wall should follow diagram

in Figure 6.

Example:

The face of a mantel, book-

shelf, etc. is made of combustible ma-

terial and protrudes 3

/2" from the wall.

This combustible material must be 4"

from the side of the fireplace cabinet

(see Figure 6).

B. Clearances from the top of the firebox

opening to the ceiling should not be less

than 42 inches.

C. When the firebox is installed on car-

peting or other combustible material,

other than wood flooring, the firebox

should be installed on a metal or wood

panel extending the full width and

depth of the enclosure.

D. Clearances from the bottom of firebox

to the floor is 0 inches.

These fireboxes can be installed as free-

standing units against a wall with the ap-

proved, optional cabinet mantels (see Ac-

cessories, page 15) or as a built-in unit. The

clearances are the same for either installa-

tion method.

INSTALLATION

CAUTION: Log heaters in-

stalled in this firebox create warm

air currents. These currents move

heat to wall surfaces next to fire-

box. Installing firebox next to vi-

nyl or cloth wall coverings or

operating firebox where impuri-

ties (such as tobacco smoke, aro-

matic candles, cleaning fluids,

oil or kerosene lamps, etc.) in the

air exist, may discolor walls.

IMPORTANT:

Vent-free gas log heaters add

moisture to the air. Although this is beneficial,

installing firebox in rooms without enough

ventilation air may cause mildew to form from

too much moisture. See Air for Combustion

and Ventilation, pages 5 through 7.

IMPORTANT:

Make sure the firebox is

level. If firebox is not level, log set will not

work properly.

Note:

Your Vanguard firebox is designed to

be used in zero clearance installations. Wall or

framing material can be placed against any

exterior surface on the rear, sides or top of your

firebox, except where standoff spacers are

integrally attached. If standoff spacers are

attached to your firebox, these spacers can be

placed directly against wall or framing mate-

rials. Use the dimensions shown for rough

opening to create the easiest installation.

Use dimensions shown for rough openings

to create the easiest installation (see Built-In

Firebox Installation, page 9).

CAUTION: Do not install the

firebox directly on carpet or vinyl.

WARNING: A qualified ser-

vice person must install firebox.

Follow all local codes.

WARNING: Never install the

firebox

• in a bedroom or bathroom*

• in a recreational vehicle

• where curtains, furniture,

clothing, or other flammable

objects are less than 42 inches

from the front, top, or sides of

the firebox

• in high traffic areas

• in windy or drafty areas

* Unless the installed log set is

rated at 10,000 Btu/Hr or less.

Figure 6 - Minimum Clearance for

Combustible to Wall

*Minimum 16 inches from Side Wall

.5 2

7/16

7/8

1 4 6 8 10 12 14 16

FIREBOX

INCHES

Example

107317

OWNER’S MANUAL

1. Frame in rough opening. The firebox

framing should be constructed of 2 x 4

lumber or heavier. Use dimensions in

Table 1 and rough opening layout in

Figure 8a. Adjust framing so that fire-

box flushes with finished wall surface.

If installing in a corner, use dimensions

in Figures 8b and 8c for rough opening.

2. Install gas piping to firebox location.

See Installing Gas Line on page 11 and

Connecting to Gas Supply in log set

owner’s manual.

IMPORTANT:

If installing blower acces-

sory (circulating models with louvers only),

see Hard-Wiring Firebox, page 13.

Figure 8 - Rough Opening for Installing in Wall

BUILT-IN FIREBOX

INSTALLATION

Built-in installation of this firebox involves

installing firebox into a framed-in enclo-

sure. This makes the front of firebox flush

with wall. Optional brass trim accessories

are available (see Accessories, page 15). The

brass trim will extend past sides of firebox

approximately 1/2 inch. This will cover the

rough edges of the wall opening. If installing

a mantel above the firebox, you must follow

the clearances shown in Figure 7. Follow the

instructions below to install the firebox in

this manner.

FRONT WIDTH DEPTH

MODEL (Inside to Inside) HEIGHT (Minimum)

36" 41

/4" 37" 20"

42" 47

/4" 37" 20"

ROUGH OPENING DIMENSIONS FOR

BUILT-IN INSTALLATION

Depth

(Minimum)

Width

(Inside to Inside)

Height

TABLE 1

Figure 8a

36"

41-1/4"

50-29/32"

72"

45°

TOP VIEW

FOR 36" MODE

Height - 37" for

35 1/2"

55-5/32"

78"

39"

47-1/4"

45°

TOP VIEW

FOR 42" MODELS

Height - 37" for FB

35 1/2" for

Figure 8b

Figure 8c

INSTALLATION

Continued

Figure 7 - Minimum Mantel Clearances for Built-In Installation

Continued

FOR 42" MODELS

Height - 37" for FB42NC Series

/2" for FB42CA Series

Supplied Firebox

Hood Must Be

Used at All Times

Wire-mesh

Screen

Firebox

Noncombustible

Material May

Project Off this

Surface above

the Firebox Hood

Mantel Shelf

13" 16" 19" 21"

/2"

10"

Note:

All vertical

measurements are

from top of fireplace

hood opening to bottom

of mantel shelf.

These minimum

clearances replace any

other recommended

clearances supplied with

your ANS Z21.11.2

approved gas logs.

Wall board or facing

material (above

firebox) may be of

combustible material,

including decorative

mantel ornaments or

other similar projec-

tions off of the facing

material.

Framing

Material

FOR 36" MODELS

Height - 37" for FB36NCA

and NLFB36NC

Series

/2" for FB36CB

and NLFB36C

Series

NOTICE: If your installation does

not meet the minimum clearances

shown, you must do one of the

following:

• raise the mantel to an accept-

able height

• remove the mantel

NOTICE: Surface temperatures of

adjacent walls and mantels be-

come hot during operation. Walls

and mantels above the firebox

may become hot to the touch. If

installed properly, these tempera-

tures meet the requirement of the

national product standard. Fol-

low all minimum clearances

shown in this manual.

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

INSTALLATION

Continued

3. Carefully set firebox in front of rough

opening with back of firebox inside wall

opening.

IMPORTANT:

If installing

Brass Trim Kit GA6091 or GA6092,

see instructions included with brass trim

accessory. You must install shoulder

screws from brass trim kit now.

4. Carefully insert firebox into rough

opening.

5. Attach firebox to wall studs using nails

or wood screws through holes in nail-

ing flange (see Figure 9).

6. If using optional GA6091 or GA6092

Brass Trim Kit, install the trim after fi-

nal finishing and/or painting of wall.

See instructions included with brass

trim accessory for attaching brass trim.

7. Install and properly test gas log heater.

Follow installation instructions in-

cluded with the vent-free gas log heater

that is being installed.

IMPORTANT:

When finishing your fire-

box, combustible materials such as wall

board, gypsum board, sheet rock, drywall,

plywood, etc. may be butted up next to the

sides and top of the firebox. Combustible

materials should never overlap the firebox

front facing.

Figure 9 - Attaching Firebox to Wall Studs

WARNING: Do not allow any

combustible materials to overlap

the firebox front facing.

IMPORTANT:

Noncombustible materials

such as brick, tile, etc. may overlap the front

facing, but should never cover any neces-

sary openings like louvered slots.

WARNING: Do not allow

noncombustible materials to

cover any necessary openings

like louvered slots.

WARNING: Use only noncom-

bustible mortar or adhesives

when overlapping the front fac-

ing with noncombustible facing

material.

WARNING: Never modify or

cover the louvered slots on the

front of the firebox except when

using approved Vanguard brass

accent trim (see

Accessories

page 15).

This firebox may be installed using a cabi-

net mantel accessory against a wall in your

home. The firebox and cabinet mantel can

be installed directly on the floor. A brass

trim kit is included with the mantel acces-

sory GM103U or GM105U (see Accesso-

ries, page 15).

1. Assemble cabinet mantel accessory and

the brass trim kit. Assembly instruc-

tions are included with each accessory.

2. If using an optional GA3700 Blower

(circulating models only), install a

properly grounded, 120 volt three-

prong electrical outlet at firebox loca-

tion if an outlet is not there. If possible,

locate outlet so cabinet mantel will

cover it when installed (see Figure 10).

3. Install gas piping to firebox location.

See Installing Gas Line, page 11. You

may have to cut an access hole in the

floor or wall to run gas line to firebox.

Make sure to locate access hole so cabi-

net mantel will cover it when installed

(see Figure 10).

Figure 10 - Installing Cabinet Mantel

WARNING: A qualified ser-

vice person must install firebox.

Follow all local codes.

4. Place cabinet mantel on floor in desired

location. Make sure mantel is flush

against wall.

5. Break off nailing flanges with hammer

or pliers (see Figure 11).

INSTALLING FIREBOX

USING OPTIONAL

ACCESSORY MANTELS

Cabinet

Mantel

Gas Line

Access Hole

(Either Side

of Firebox)

Gas

Piping

Electrical

Outlet

Figure 11 - Location of Nailing Flanges

(Two on Each Side)

Nailing Flanges

Nailing

Flanges

Nails or

Wood

Screws

107317

OWNER’S MANUAL

INSTALLING OPTIONAL

BLOWER ACCESSORY

NOTICE: If a log set is installed in

the firebox, disconnect log set

from gas supply and remove from

firebox. Contact a qualified ser-

vice person to do this.

Figure 14 - Location of Knockout for Gas

Line

INSTALLING GAS LINE

NOTICE: A qualified service per-

son must connect heater to gas

supply. Follow all local codes.

IMPORTANT:

See Connecting to Gas Sup-

ply in your log set owner’s manual for details

on gas hookup.

You may run the gas line from either side of

the firebox (see Figure 13). Decide which

side you want to run the gas line from.

Note:

This is one option for installing shutoff

valve. Check local codes for equipment

shutoff valve location requirements.

Figure 13 - Installing Gas Line and

Equipment Shutoff Valve

CAUTION: Do not use exces-

sive force to remove the knock-

out. Too much force may dam-

age the firebrick concrete insert.

6. Install the brass trim kit furnished with

mantel. See instruction sheet included

with the mantel now.

7. If installing the optional GA3700

Blower (circulating models only), see

Installing Optional Blower Accessory,

column 3.

8. Carefully insert firebox into cabinet

mantel. Be careful not to scratch fire-

box, cabinet mantel, flooring, etc. when

installing (see Figure 12).

9. Install and properly test gas log heater.

Follow installation instructions in-

cluded with the vent-free gas log heater

that is being installed.

INSTALLATION

Continued

Figure 12 - Inserting Firebox Into Cabinet

Mantel

Knockout Locations

(Knock Out One Hole)

Gas Line Hole

Equipment

Shutoff

Valves

(Install

One)

Locate the recessed knockout in one of the

firebrick sidewall liners (see Figures 13 and

14). Firmly tap the center of the knockout

with a chisel until it is released. Carefully

chisel the rough edges of the hole you have

made to smooth edges. This hole will line up

with the hole in the outer casing.

3/4" Thick Liner

Knockout

Chisel

Firebrick Side

Wall

Remove

this Area

Side

View

Continued

Figure 15 - Removing Firebrick Floor from

Firebox

Firebrick Floor

Note:

Appearance of firebox may vary de-

pending on model.

1. If firebrick is installed, carefully lift and

remove the concrete firebrick floor from

the firebox (see Figure 15). Some model

fireboxes require that you remove the

side and rear panels first. Follow the di-

rections below to remove the side and

rear firebrick panels for those fireboxes.

a.Using a Phillips screwdriver, re-

move the screw and retainer bracket

at the top of the brick liner panel on

the left side. Carefully remove the

left panel from the firebox (see Fig-

ure 16, page 12).

b.Repeat the removal steps for the

brick liner panel on the right side.

c.Remove the screw and retainer

bracket at the top of the brick liner

panel at the rear of the firebox.

IMPORTANT:

Do not let panel fall

after the bracket has been removed.

Carefully remove the rear panel from

the firebox (see Figure 17, page 12).

d.Carefully lift and remove the con-

crete firebrick floor from the firebox

if installed (see Figure 15).

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

WARNING: If there is a duplex

electrical outlet installed in the right

side of the bottom of the fireplace

base area, be sure that the electri-

cal power to the outlet is turned off

before proceeding with blower in-

stallation. Failure to do this may

result in serious injury.

Figure 21 - Attaching Speed Control to

Firebox

Speed

Control

Shaft

Locknut

Control Knob

INSTALLATION

Continued

2. Remove the firebox bottom.

a. Remove the 4 screws that secure the

bottom of the firebox (see Figure 18).

b.Carefully raise and remove the fire-

box bottom from the firebox.

3. Attach the power cord to the blower motor

by firmly pushing the two female termi-

nals at the end of the power cord onto the

two spade terminals on the blower motor.

4. Attach green ground wire from power cord

to blower housing using screw provided

(see Figure 19). Tighten screws securely.

5. Place the blower against the lower rear

wall of the firebox outer wrapper with

the exhaust port directed upward. Align

the holes in top mounting tabs of blower

with holes in wall of wrapper (see Fig-

ure 19). Using 2 screws provided, mount

blower and tighten screws securely.

6. Be certain that all wire terminals are

securely attached to terminals on

blower motor and that the screw retain-

ing the green ground wire is tight.

7. Locate the plastic hole plug installed

in the 3/8" diameter opening in the

lower right side of the firebox front

panel (see Figure 20). Remove the

plastic plug and discard.

8. Place speed control against inner wall

of front panel, pushing the plastic con-

trol shaft forward through the opening.

9. While supporting speed control, secure

control shaft with lock nut by pushing and

turning lock nut with pliers clockwise un-

til it is tight against front panel. Place con-

trol knob provided on shaft (see Figure 21).

10. Turn on power to duplex outlet if pre-

viously turned off per the warning at

the top of column 1.

Blower

Screws

Top

Mounting

Tab

Exhaust Port

Lower Rear Wall of

Firebox Wrapper

Figure 19 - Mounting Blower to Firebox

Screw

Figure 20 - Installing Plastic Bushing for

Power Cord

/2" Hole

Plastic

Bushing

Plastic

Hole Plug

Screws

Finger

Holes

Firebox

Bottom

Screws

Figure 18 - Removing Firebox Bottom

Product

Identification

Label

Figure 16 - Removing Left Panel from Firebox

Left

Panel

Retainer Bracket

Screw

Figure 17 - Removing Back Panel from

Firebox

Back

Panel

Retainer Bracket

Screw

Identification

Label

107317

OWNER’S MANUAL

INSTALLATION

Continued

HARD-WIRING FIREBOX

For Built-in Installation of

Circulating Models Only

NOTICE: A qualified electrician

must connect electrical wiring

to duplex outlet for built-in in-

stallation. Follow all local

codes. In absence of local codes

The National Electric

Code ANS/NFPA 70.

Models FB36CB, NLFB36C, and FB42CA

Series can be hard-wired to the duplex outlet

located inside the firebox bottom if desired.

This allows the GA3700 Blower Accessory

to be plugged into the duplex outlet.

WARNING: Never touch the

blower wheel while in operation.

Variable

Fan Switch

WhiteWhite

Black

Green

110/115

V.A.C.

Blower

Motor

Black

Off

Figure 22 - Location of Wiring Diagram

Decal

Wiring Diagram

Decal 12" in Front of

Blower

Floor

Supports

/2"

Hole

WARNING: A qualified ser-

vice person must install heater.

Follow all local codes.

Note:

Discard the remaining hardware items.

OPERATING THE BLOWER

Light your gas appliance with the blower

off. After about 15 minutes, turn the blower

on to deliver heated air at the top louvers.

The blower features a variable control which

allows you to select the speed you desire.

Note:

Periodically check the louvers of the

firebox and remove any dust, dirt, or other

obstructions.

11. Plug in blower power cord.

a. If your firebox is installed as a free-

standing unit with an accessory

mantel, determine whether the power

cord will exit the left side or the right

side of the firebox. Install 1 plastic

bushing provided into the 1

/2" hole

in the floor support on the exit side.

Install the second plastic bushing pro-

vided into the 1

/2" hole in the outer

casing through which the power cord

will exit (see Figure 20, page 12 and

Figure 22). Route power cord through

both plastic bushings and plug the

power cord into a wall receptacle near

the firebox.

b.If your firebox installation is recessed

and/or pre-wired, plug the power cord

into the duplex outlet provided. Refer

to your firebox owner’s manual for in-

structions on wiring the duplex outlet.

12. Check to make sure that the power cord

is completely clear of the blower wheel

and that there are no other foreign ob-

jects in blower wheel. Turn blower on

and check for operation. Turn blower

off by turning knob fully counterclock-

wise before continuing.

13. Peel off the backing paper and stick the

supplied wiring diagram decal on the

firebox bottom approximately 12" in

front of the blower (see Figure 22).

14. Replace and reattach firebox bottom us-

ing 4 screws removed in step 2 (see

Figure 18, page 12).

15. If previously removed, carefully re-

place the firebrick side panels and/or

floor in the firebox (see Figure 15, page

11 and Figures 16 and 17, page 12).

16. Install the log set heater according to

the installation instructions supplied

with the heater.

If Firebrick Is Installed

1. Using Phillips screwdriver, remove the

screw and retainer bracket at the top of

the firebrick liner panel on the left side

(see Figure 16, page 12). Carefully re-

move the left panel from the firebox. Re-

peat for firebrick liner panel on right side.

2. Remove the screw and retainer

bracket at the top of the brick liner panel

in the back of the firebox. Do not let

the panel fall after the bracket is re-

moved. Carefully remove the rear fire-

brick liner panel from the firebox (see

Figure 17, page 12).

CAUTION: Do not let the fire-

brick liner panel fall after the

bracket is removed.

3. Carefully lift and remove the bottom

firebrick floor from bottom of firebox.

Remove the four Phillips screws in fire-

box bottom (see Figure 18, page 12).

4. Use the two finger holes in the firebox

bottom to carefully lift up and remove

the firebox bottom.

5. Locate duplex outlet mounted to sup-

port bracket in lower right hand side of

firebox. Remove screw holding duplex

outlet to support bracket in bottom of

firebox. Remove duplex outlet (see Fig-

ure 23).

Continued

Screw

Duplex

Outlet

Support

Bracket

Electric

Cables

Figure 23 - Removing Duplex Outlet

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

TECHNICAL

SERVICE

You may have further questions about in-

stallation, operation, or troubleshooting.

If so, contact DESA International’s Techni-

cal Service Department at 1-800-DESA LOG

(1-800-337-2564).

You can also visit DESA International’s

technical services web site at

www.desatech.com.

Note

: Use only original replacement parts.

This will protect your warranty coverage

for parts replaced under warranty.

PARTS UNDER WARRANTY

Contact authorized dealers of this product.

If they can’t supply original replacement

part(s), call DESA International’s Technical

Service Department at 1-800-DESA LOG

(1-800-337-2564).

When calling DESA International, have ready

• your name

• your address

• model and serial numbers of your firebox

• how firebox was malfunctioning

• type of gas used (propane/LP or natural gas)

• purchase date

Usually, we will ask you to return the defec-

tive part to the factory.

PARTS NOT UNDER

WARRANTY

Contact authorized dealers of this product. If

they can’t supply original replacement

part(s), call DESA International’s Parts De-

partment at 1-800-972-7879 for referral in-

formation.

When calling DESA International, have ready

• model number of your firebox

• the replacement part number

Note

: The firebox identification label (in-

cluding model number, serial number, clear-

ances, etc.) is located either on the left front

edge of the firebox or behind the left side

firebrick panel. See Figure 18, page 11.

REPLACEMENT

PARTS

INSTALLATION

Continued

INSTALLING FIREPLACE

HOOD AND SCREEN

1. Attach hood to firebox using (7)

#10 x 3/8" phillips screws provided

(see Figure 25).

2. Insert each rod through all rings located

at top of screen.

3. Insert first rod into rear hole in left side

of firebox. Fasten rod to rear hole near

center of firebox using #10 x 3/8"

Phillips screw provided (see Figure 26).

4. Insert other rod into front hole on right

side of firebox and fasten using remain-

ing Phillips screw.

Figure 25 - Screw and Hood Placement

Figure 26 - Installing Fireplace Screen

(Models FB36CB and FB42CA Shown)

Screw

Rear Hole

Top View of

Rod Layout

Rod

Front Hole

Ring

Screen

6. Clamp electrical cable hard-wiring into

firebox through smallest hole using strain

relief fitting provided (see Figure 24).

7. Connect electrical cable to duplex out-

let. Match wire colors to those on duplex

outlet. Be sure to connect ground wire.

8. Replace duplex outlet with screw.

9. You may now install GA3700 Blower

Accessory if desired, see Installing Op-

tional Blower Accessory, pages 11

through 13.

10. Replace firebox bottom with four

Phillips screws removed in step 1.

11. If removed previously, carefully re-

place firebrick panels in the reverse

order they were removed. See Figures

15 through 17, pages 11 and 12.

Figure 24 - Installing Strain Relief Fitting

into Electrical Access Hole

Strain

Relief

Fitting

Small Hole

Electric

Cables

107317

OWNER’S MANUAL

BRASS TRIM ACCESSORY

(Not Shown)

GA6091 (36" Models)

GA6092 (42" Models)

Optional with built-in installation. Provides

a finished appearance covering rough and/

or unfinished mantel or wall opening edges.

ACCESSORIES

Purchase these firebox accessories from your

local dealer. If they can not supply these

accessories, call DESA International’s Sales

Department at 1-800-432-2382 for infor-

mation. You can also write to the address

listed on the back page of this manual.

CABINET MANTEL

ACCESSORY WITH

FIREBOX PERIMETER

BRASS TRIM

GM103U Series - Unfinished

Birch Veneer (36" Models)

Dimensions (WxHxD): 63" x 51" x 24

GM105U Series - Unfinished

Birch Veneer (42" Models)

Dimensions (WxHxD): 69" x 51" x 24

BLOWER ACCESSORY -

GA3700

Use with Models FB36CB, NFLB36C, or

FB42CA Series only. The variable blower

allows you to select the desired speed. The

blower circulates heated air from the fire-

place into the room.

EQUIPMENT SHUTOFF

VALVE - GA5010

Equipment shutoff valve with 1/8" NPT tap.

BRASS HOOD ACCESSORY

(Not Shown)

GA6097 (36" Models)

GA6098 (42" Models)

Decorative polished brass hood enhances

the appearance of the firebox.

BRASS ACCENT TRIM

ACCESSORY

GA6088 (42" MODELS)

GA6089 (42" MODELS)

Seven piece magnetic polished brass trim

enhances the appearance of the firebox.

CLEANING KIT - GCK

(Not Shown)

Your vent-free gas appliance requires regu-

lar cleaning and maintenance to prevent

performance problems. This kit gives you

the tools and instructions to make it easy to

clean all critical areas of your appliance.

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

ILLUSTRATED

PARTS

BREAKDOWN

FB36NCA

NLFB36NC

FB42NC

*Not Included with Model NLFB36NC Series

107317

OWNER’S MANUAL

PARTS LIST

This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions

listed under Replacement Parts on page 14 of this manual.

FB36NCA

NLFB36NC

FB42NC

KEY PART NUMBER

NO. FB36NCA NLFB36NC FB42NC DESCRIPTION QTY.

1 103437-01 103437-01 103437-02 Firebox Top 1

2 103608-01 * 103608-01 Firebrick Retainer 3

3 02033 * 01888 Rear Firebrick 1

4 01889 * 01889 Left Side Firebrick 1

5 01890 * 01890 Right Side Firebrick 1

6 01926 * 01887 Bottom Firebrick 1

7 103796-01 103796-01 103796-02 Outer Casing 1

8 103440-01 103440-01 103440-02 Outer Casing Bottom 1

9 103797-01 103797-01 103797-02 Firebox Wrapper 1

10 103297-02 103297-02 103297-02 Screen Assembly 2

11 103444-01CK 103444-01CK 103444-02CK Hood 1

12 103442-02CK 103442-02CK 103442-04CK Front Assembly 1

13 103445-01 103445-01 103445-02 Firebox Bottom 1

14 103452-01 103452-01 103452-02 Screen Rod 2

15 101348-01 101348-01 101348-01 Firebox Supports 2

16 103438-01 103438-01 103438-02 Outer Casing Top 1

17 M11084-26 M11084-26 — Hex Head Screw, #10-16 57

— — M11084-26 Hex Head Screw, #10-16 60

18 098304-01 — 098304-01 Phillips Pan Head Screw 22

— 098304-01 — Phillips Pan Head Screw 19

19 098194-02 098194-02 098194-02 Standoff Bracket 3

20 103436-01 103436-01 103436-02 Deflector 1

*Not Included with Model NLFB36NC Series

107317

UNVENTED (VENT-FREE) LOGMATE

FIREBOX

VANGUARD

ILLUSTRATED

PARTS

BREAKDOWN

FB36CB

NLFB36C

FB42CA

*Not Included with Model NLFB36C Series

107317

OWNER’S MANUAL

PARTS LIST

This list contains replaceable parts used in your firebox. When ordering parts, follow the

instructions listed under Replacement Parts on page 14 of this manual.

FB36CB

NLFB36C

FB42CA

KEY PART NUMBER

NO. FB36CB NLFB36C FB42CA DESCRIPTION QTY.

1 103437-03 103437-03 103437-04 Firebox Top 1

2 103608-01 * 103608-01 Firebrick Retainer 3

3 103717-01 * 103717-02 Rear Firebrick 1

4 103718-01 * 103718-01 Left Side Firebrick 1

5 103719-01 * 103719-01 Right Side Firebrick 1

6 103720-01 * 103720-02 Bottom Firebrick 1

7 103796-01 103796-01 103796-02 Outer Casing 1

8 103440-01 103440-01 103440-02 Outer Casing Bottom 1

9 103797-01 103797-01 103797-02 Firebox Wrapper 1

10 103297-02 103297-02 103297-02 Screen Assembly 2

11 103444-01CK 103444-01CK 103444-02CK Hood 1

12 103442-01CK 103442-01CK 103442-03CK Front Assembly 1

13 103445-01 103445-01 103445-02 Firebox Bottom 1

14 103452-01 103452-01 103452-02 Screen Rod 2

15 101348-01 101348-01 101348-01 Firebox Supports 2

16 103438-01 103438-01 103438-02 Outer Casing Top 1

17 M11084-26 M11084-26 — Hex Head Screw, #10-16 50

— — M11084-26 Hex Head Screw, #10-16 53

18 098304-01 — 098304-01 Phillips Pan Head Screw 22

— 098304-01 — Phillips Pan Head Screw 19

19 103771-01 103771-01 103771-01 Strain Relief Fitting 1

20 103769-01 103769-01 103769-01 Duplex Outlet 1

21 M12461-2 M12461-2 M12461-2 Outlet Mounting Screw 1

22 098194-02 098194-02 098194-02 Standoff Bracket 8

*Not Included with Model NLFB36C Series

LIMITED WARRANTY

VENT-FREE FIREBOX

DESA International warrants this product to be free from defects in materials and components for four (4) years from the date of first

purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To

make a claim under this warranty the Bill of Sale or cancelled check must be presented.

This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this heater to proper

operating condition and an allowance for labor when provided by a DESA Authorized Service Center. Warranty part(s) MUST be obtained

through authorized dealers of this product and/or DESA International who will provide original factory replacement parts. Failure to use

original factory replacement parts voids this warranty. The heater MUST be installed by a qualified installer in accordance with all local

codes and instructions furnished with the unit.

This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become damaged

as a result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. As with all concrete liners, this liner

may develop slight cracks when exposed to heat. This cracking is considered normal. Travel, diagnostic cost, labor, transportation and any

and all such other costs related to repairing a defective heater will be the responsibility of the owner.

TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE PRODUCT;

THIS EXPRESS WARRANTY EXCLUDES ANY AND ALL OTHER EXPRESSED WARRANTIES AND LIMITS THE DURATION

OF ANY AND ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE TO FOUR (4) YEARS ON ALL COMPONENTS FROM THE DATE OF FIRST PURCHASE; AND DESA

INTERNATIONAL’S LIABILITY IS HEREBY LIMITED TO THE PURCHASE PRICE OF THE PRODUCT AND DESA INTERNA-

TIONAL SHALL NOT BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL OR

CONSEQUENTIAL DAMAGES.

Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential

damages, so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.

This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.

For information about this warranty write:

2701 Industrial Drive

P.O. Box 90004

Bowling Green, KY 42102-9004

www.desatech.com

INTERNATIONAL

KEEP THIS WARRANTY

WARRANTY INFORMATION

Model

Serial No.

Date Purchased

Always specify model and serial numbers when communicating with the factory.

We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty. We

make no other warranty, expressed or implied.

107317-01

Rev. B

08/00

NOT A UPC

107317 01

FMI FB36CB User manual

Brand: FMI

Model: FB36CB

Category: Fireplaces

Type: User manual

This manual is also suitable for

Download PDF

report

FMI FB36CB User manual

This manual is also suitable for

FMI FB36CB User manual

Related papers

Other documents
