Philips HTS3566D/37 User manual

Brand: Philips

Model: HTS3566D/37

Category: DVD players

Type: User manual

This manual is also suitable for

HTS3565D

HTS3566D

www.philips.com/welcome

EN DVD Home Theater System 6

FR_CA Système Home Cinéma DVD 60

ES_LA Sistema de Home Theater con DVD 116

Thank you for choosing Philips.

Need help fast?

Read your Quick Start Guide and/or

User Manual first for quick tips

that make using your Philips product

more enjoyable.

get support at

www.philips.com/welcome

or call

1-888-PHILIPS (744-5477)

while with your product

(and Model / Serial number)

STO

Philips vous remercie de

votre confiance.

Besoin d'une aide

rapide?

Le Guide rapide de début et

Manuel de l'utilisateur regorgent

d'astuces destinées à simplifier

l'utilisation de votre produit Philips.

ou formez le

1-800-661-6162 (Francophone)

1-888-PHILIPS (744-5477)

(English speaking)

Veillez à avoir votre produit à

portée de main

(et model / serial nombre)

RÊT

Gracias por escoger Philips

Necesita ayuda

inmediata?

Lea primero la Guía rápida del

comienzo o el Manual del usuario,

en donde encontrará consejos que

le ayudarán a disfrutar plenamente

de su producto Philips.

o llame al teléfono

1-888-PHILIPS (744-5477)

y tenga a mano el producto

(y número de model / serial)

ALTO

Enregistrez votre produit et

accédez à l'assistance sur

www.philips.com/welcome

Visite

www.philips.com/welcome

para registrar su producto y

obtener información de

contacto y asistencia.

1_hts3565-66D_37_eng2_final813.i1 11_hts3565-66D_37_eng2_final813.i1 1 2008-03-27 3:11:49 PM2008-03-27 3:11:49 PM

Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out.

Complete and return your Product Registration Card at once, or register online at www.philips.com/welcome to

ensure:

Return your Product Registration Card or register online at

www.philips.com/welcome today to get the very most from your purchase.

Visit our World Wide Web Site at http://www.philips.com/welcome

Congratulations on your purchase,

and welcome to the “family!”

Dear PHILIPS product owner:

Thank you for your confidence in PHILIPS.You’ve selected one of

the best-built, best-backed products available today.We’ll do every-

thing in our power to keep you happy with your purchase for many

years to come.

As a member of the PHILIPS “family,” you’re entitled to protection

by one of the most comprehensive warranties and outstanding

service networks in the industry.What’s more, your purchase guar-

antees you’ll receive all the information and special offers for which

you qualify, plus easy access to accessories from our convenient

home shopping network.

Most importantly, you can count on our uncompromising commit-

ment to your total satisfaction.

All of this is our way of saying welcome - and thanks for investing

in a PHILIPS product.

P.S. To get the most from your PHILIPS purchase, be

sure to complete and return your Product Registration

Card at once, or register online at:

www.philips.com/welcome

For Customer Use

Enter below the Serial No. which is locat-

ed on the rear of the cabinet. Retain this

information for future reference.

Model No.__________________________

Serial No. ________________________

Know these

safetysymbols

This “bolt of lightning” indicates unin-

sulated material within your unit may

cause an electrical shock. For the safety of

everyone in your household, please do not

remove product covering.

The “exclamation point” calls atten-

tion to features for which you should

read the enclosed literature closely to pre-

vent operating and maintenance problems.

WARNING: To reduce the risk of fire or

electric shock, this apparatus should not be

exposed to rain or moisture and objects

filled with liquids, such as vases, should not

be placed on this apparatus.

CAUTION: To prevent electric shock,

match wide blade of plug to wide slot, fully

insert.

ATTENTION: Pour éviter les choc élec-

triques, introduire la lame la plus large de la

fiche dans la borne correspondante de la

prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

*Proof of

Purchase

Returning the enclosed card guarantees

that your date of purchase will be on file,

so no additional paperwork will be

required from you to obtain warranty

service.

*Product Safety

Notification

By registering your product, you'll receive

notification - directly from the manufac-

turer - in the rare case of a product

recall or safety defect.

*Additional Benefits

Registering your product guarantees that

you'll receive all of the privileges to

which you're entitled, including special

money-saving offers.

Ensure that the power outlet is always within reach. If abnormal situations occur, fully

disconnect power: unplug the power cord from the power outlet.

1_hts3565-66D_37_eng2_final813.i2 21_hts3565-66D_37_eng2_final813.i2 2 2008-03-27 3:11:53 PM2008-03-27 3:11:53 PM

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near

water.

6. Clean only with dry cloth.

7. Do not block any ventilation

openings. Install in accordance with

the manufacturer´s instructions.

8. Do not install near any heat sources

such as radiators, heat registers, stoves, or

other apparatus (including ampliﬁers) that

produce heat.

9. Do not defeat the

safety purpose of the

polarized or

grounding-type plug.

A polarized plug has two blades with one

wider than the other. A grounding type plug

has two blades and a third grounding prong.

The wide blade or the third prong are

provided for your safety. If the provided plug

does not ﬁt into your outlet, consult an

electrician for replacement of the obsolete

outlet.

10.

Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

11.

Only use attachments/accessories

speciﬁed by the manufacturer.

12.

Use only with the cart, stand,

tripod, bracket, or table speciﬁed

by the manufacturer or sold with

the apparatus. When a cart is

used, use caution when moving

the cart/apparatus combination

to avoid injury from tip-over.

13 .

Unplug this apparatus during lightning

storms or when unused for long periods of

time.

14 .

Refer all servicing to qualiﬁed service

personnel. Servicing is required when the

apparatus has been damaged in any way,

such as power-supply cord or plug is

damaged, liquid has been spilled or objects

have fallen into the apparatus, the apparatus

has been exposed to rain or moisture, does

not operate normally, or has been dropped.

15.

Battery usage CAUTION – To

prevent battery leakage which may result in

bodily injury, property damage, or damage

to the unit:

● Install all batteries correctly, + and - as

marked on the unit.

● Do not mix batteries (old and new or

carbon and alkaline, etc.).

● Remove batteries when the unit is not used

for a long time.

IMPORTANT SAFETY INSTRUCTIONS

AC Polarized

Plug

16. Apparatus shall not be exposed to

dripping or splashing.

17. Do not place any sources of danger

on the apparatus (e.g. liquid filled

objects, lighted candles).

18. This product may contain lead and mercury.

Disposal of these materials may be regulated

due to environmental considerations.

For disposal or recycling information,

please contact your local authorities

or the Electronic Industries Alliance :

www.eiae.org.

EL 6475-E005: 04/01

Class II equipment symbol

This symbol indicates that the unit has

a double insulation system

‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH

DEFINITION TELEVISION SETS ARE FULLY

COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE

ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN

CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE

PROBLEMS, IT IS RECOMMENDED THAT THE USER

SWITCH THE CONNECTION TO THE ‘STANDARD

DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS

REGARDING OUR TV SET COMPATIBILITY WITH THIS

MODEL 525p AND 625p DVD PLAYER, PLEASE

CONTACT OUR CUSTOMER SERVICE CENTER.’

1_hts3565-66D_37_eng2_final813.i3 31_hts3565-66D_37_eng2_final813.i3 3 2008-03-27 3:11:54 PM2008-03-27 3:11:54 PM

LASER

Type Semiconductor laser

GaAIAs

Wave length 645 - 660 nm (DVD)

770 - 800 nm (CD)

Output Power 6 mW (DVD)

7 mW (VCD/CD)

Beam divergence 60 degrees

Canada

English:

This digital apparatus does not exceed

the Class B limits for radio noise

emissions from digital apparatus as set

out in the Radio Interference

Regulations of the Canadian

Department of Communications.

This Class B digital apparatus complies

with Canadian ICES-003.

Français:

Cet appareil numérique n’emet pas de

bruits radioélectriques dépassant les

limites applicables aux appareils

numériques de Class B prescrites dans

le Règlement sur le Brouillage

Radioélectrique édicté par le Ministère

des Communications du Canada.

Cet appareil numérique de la classe B est

conforme à la norme NMB-003 du Canada.

This warning label is located on the rearside

and inside this laser product.

CAUTION

INVISIBLE

LASER RADIATION

WHEN OPEN. DO NOT STARE INTO BEAM.

DANGER

INVISIBLE LASER RADIATION WHEN OPEN.

AVOID DIRECT EXPOSURE TO BEAM.

VARO!

AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET

ALTTIINANAKYMATTOMAALLE LASERSATEILYLLE. ALA

KATSO SATEESEEN.

VARNING!

OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD.

OCH SPARREN AR URKOPPLAD. BETRAKTA EJ STRÅLEN.

DANGER - Invisible laser radiation when open.

AVOID DIRECT EXPOSURE TO BEAM.

CAUTION

Use of controls or adjustments or

performance of procedures other than

herein may result in hazardous radiation

exposure or other unsafe operation.

ATTENTION

L’utilisation des commandes ou réglages

ou le non-respect des procédures ciincluses

peuvent se traduire par une

exposition dangereuse à l’irradiation.

ATENCIÓN

El uso de mando o ajustes o la ejecucción

de métodos que no sean los aquí descritos

puede ocasionar peligro de exposición a

radiación.

Declaration of Conformity

Model number: HTS3565D, HTS3566D

Trade Name: Philips

Responsible Party: Philips Consumer Electronics

A Division of Philips Electronics

North America Corp.

P. O. Box 671539

Marietta, GA 30006-0026

1-800-PHILIPS (744-5477)

Environmental information

All unnecessary packaging has been omitted.

We have tried to make the packaging easy to

separate into three materials: cardboard

(box), polystyrene foam (buffer) and

polyethylene (bags, protective foam sheet.)

Your system consists of materials which can

be recycled and reused if disassembled by a

specialized company. Please observe the local

regulations regarding the disposal of

packaging materials, exhausted batteries and

old equipment.

1_hts3565-66D_37_eng2_final813.i4 41_hts3565-66D_37_eng2_final813.i4 4 2008-03-27 3:11:54 PM2008-03-27 3:11:54 PM

EnglishFrançaisEspañol

Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic and the

double-D symbol are trademarks of Dolby

Laboratories.

DivX, DivX Ultra Certi ed, and associated

logos are trademarks of DivX, Inc. and are

used under license.

Of cial DivX® Ultra Certi ed product.

Plays all versions of DivX® video (including

DivX® 6) with enhanced playback of DivX®

media  les and the DivX® Media Format.

Windows Media and the Windows logo are

trademarks, or registered trademarks of

Microsoft Corporation in the United States

and/or other countries.

HDMI, and HDMI logo and High-De nition

Multimedia Interface are trademarks or

registered trademarks of HDMI licensing LLC.

The USB-IF Logos are trademarks of

Universal Serial Bus Implementers Forum,

Inc.

ENERGY STAR and the ENERGY STAR mark

are registered U.S. marks

Index

English ------------------------------------ 6

Français ---------------------------------- 60

Español -------------------------------- 116

iPod is a trademark of Apple Computer, Inc.,

registered in the U.S. and other countries.

This product incorporates copyright protection

technology that is protected by method claims of

certain U.S. patents and other intellectual property

rights owned by Macrovision Corporation and

other rights owners. Use of this copyright

protection technology must be authorized by

Macrovision Corporation, and is intended for

home and other limited viewing uses only unless

otherwise authorized by Macrovision Corporation.

Reserve engineering or disassembly is prohibited.

NOTE: This equipment has been tested and found to

comply with the limits for a Class B digital device, pursuant

to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause

harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to radio

or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and

receiver.

- Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician

for help.

1_hts3565-66D_37_eng2_final813.i5 51_hts3565-66D_37_eng2_final813.i5 5 2008-03-27 3:11:55 PM2008-03-27 3:11:55 PM

English

Table of contents

General

General Information ........................................................................................................ 8

Setup precautions .................................................................................................................................................8

Accessories supplied ...........................................................................................................................................8

Cleaning discs ........................................................................................................................................................8

About recycling .....................................................................................................................................................8

Product Overview

Main Unit ...........................................................................................................................9

Remote Control .........................................................................................................10-12

Using the remote control ................................................................................................................................12

Connections

Basic Connections .....................................................................................................13-18

Step 1: Placing the speakers .............................................................................................................................13

Step 2: Connecting to TV ..........................................................................................................................14-16

Option 1: Using the Video jack ...............................................................................................................14

Option 2: Using the S-Video jack ...........................................................................................................14

Option 3: Connecting to a Progressive Scan TV or component video input ............................15

Option 4: Connecting to a HDMI-compatible TV ............................................................................15

Option 5: Using an accessory RF modulator ......................................................................................16

Step 3: Connecting speakers and subwoofer .............................................................................................17

Step 4: Connecting the power cord ..............................................................................................................18

Optional Connections .................................................................................................... 19

Connecting audio from cable box/recorder/game console or TV .......................................................19

Basic Setup

Getting Started ......................................................................................................... 20-25

Finding the correct viewing channel ............................................................................................................ 20

Switching to different play source ................................................................................................................ 20

Setting language preferences .....................................................................................................................21-22

On-screen display (OSD) language ........................................................................................................21

Audio, Subtitle and Disc Menu language for DVD playback .....................................................21-22

Setting up Progressive Scan feature ..............................................................................................................23

Setting the speakers’ channels ........................................................................................................................24

Setting the EasyLink control .......................................................................................................................... 25

One touch control ..................................................................................................................................... 25

Disc Playback

Disc Operations ........................................................................................................ 26-34

Playable discs .......................................................................................................................................................26

Playing a disc ........................................................................................................................................................26

Basic playback controls .....................................................................................................................................27

Selecting various repeat/shuf e functions ...................................................................................................27

Repeating a speci c section (A-B) ................................................................................................................ 28

Other playback features for video discs (DVD/VCD/SVCD) ......................................................... 28-31

Using the Disc Menu ................................................................................................................................. 28

Viewing playback information ..................................................................................................................29

Zooming.........................................................................................................................................................29

Changing subtitle language .......................................................................................................................29

Switching camera angles ............................................................................................................................29

Changing sound track language .............................................................................................................. 30

Setting the delay times for audio playback .......................................................................................... 30

Playback Control ........................................................................................................................................ 30

Preview function ..........................................................................................................................................31

1_hts3565-66D_37_eng2_final813.i6 61_hts3565-66D_37_eng2_final813.i6 6 2008-03-27 3:11:56 PM2008-03-27 3:11:56 PM

English

Table of contents

Playing a MP3/ WMA disc ................................................................................................................................32

Playing a JPEG photo  le (slide show) ...........................................................................................................33

Preview function ..........................................................................................................................................33

Zooming.........................................................................................................................................................33

Skip/Rotate picture .....................................................................................................................................33

Playing music and photo  les simultaneously ............................................................................................ 34

Playing a DivX® disc ......................................................................................................................................... 34

Playback other supported devices

Playback - iPod ................................................................................................................35

Playing music from compatible iPod device ................................................................................................35

Preparing the docking station ..................................................................................................................35

Playing from iPod .........................................................................................................................................35

Playback - USB Device ................................................................................................... 36

Playing from USB device ...................................................................................................................................36

Playback - Other Audio Player ..................................................................................... 37

Playing from other portable audio player ....................................................................................................37

Setup Options

Setup Menu Options ................................................................................................. 38-48

Accessing the setup menu ............................................................................................................................... 38

General Setup ..............................................................................................................................................39

Audio Setup ...........................................................................................................................................40-41

Video Setup ............................................................................................................................................42-45

Preferences ............................................................................................................................................46-48

Radio Tuning

Radio Operations ...................................................................................................... 49-50

Tuning to radio stations ....................................................................................................................................49

Presetting radio stations ..................................................................................................................................49

Using auto install .........................................................................................................................................49

Using automatic preset ..............................................................................................................................50

Using manual preset ...................................................................................................................................50

Selecting a preset radio station ......................................................................................................................50

Deleting a preset radio station .......................................................................................................................50

Others

Sound and Volume Controls ......................................................................................... 51

Volume control ...................................................................................................................................................51

Selecting surround sound .................................................................................................................................51

Selecting digital sound effects .........................................................................................................................51

Other Features................................................................................................................ 52

Turning on the sleep timer ..............................................................................................................................52

Installing the latest software ...........................................................................................................................52

Troubleshooting ........................................................................................................ 53-55

Glossary...................................................................................................................... 56-57

Speci cations ..................................................................................................................58

1_hts3565-66D_37_eng2_final813.i7 71_hts3565-66D_37_eng2_final813.i7 7 2008-03-27 3:11:56 PM2008-03-27 3:11:56 PM

English

General Information

WARNING!

This unit does not contain any user-

serviceable parts. Please leave all

maintenance work to quali ed

personnel.

Setup precautions

Finding a suitable location

– Place this unit on a  at, hard and

stable surface. Never place the unit on a

carpet.

– Never place this unit on top of other

equipment that might heat it up (e.g.,

receiver or ampli er.)

– Never put anything under this unit

(such as, CDs, magazines.)

– Install this unit near the AC outlet

where the AC power plug can be easily

reached.

Space for ventilation

– Place this unit in a location with

adequate ventilation to prevent internal

heat build up. Allow at least 10 cm (4”)

clearance from the rear and the top of

this unit and 5cm (2”) from the left and

right to prevent overheating.

Avoid high temperature, moisture,

water and dust

– This unit must not be exposed to

dripping or splashing.

– Never place any object or items that

can damage this unit (e.g., liquid  lled

objects, lighted candles.)

Accessories supplied

– 1 subwoofer

– 1 center speaker

– 2 front and 2 rear speakers

– 1 remote control with batteries

– 1 composite video cable (yellow)

– 1 docking station for Apple iPod

– 1 FM wire antenna

– Speaker cables (for HTS3566D tallboy

speakers)

– 2 screws (for tallboy speakers

connection)

– Quick Start Guide

Cleaning discs

To clean a disc, use a micro  ber cleaning

cloth and wipe the disc from the center

to the edge in a straight line.

CAUTION!

Never use solvents such as benzene,

thinner, commercially available cleaners,

or anti-static sprays intended for discs.

About recycling

These operating instructions have been

printed on non-polluting paper. The

electronic equipment contains a large

number of materials that can be recycled.

If you are disposing of an old machine,

please take it to a recycling center.

Please observe the local regulations

regarding disposal of packaging materials,

exhausted batteries and old equipment.

1_hts3565-66D_37_eng2_final813.i8 81_hts3565-66D_37_eng2_final813.i8 8 2008-03-27 3:11:56 PM2008-03-27 3:11:56 PM

English

Main Unit

3 4

5 6

7 9

a 2 (Standby-On)

– Turns on this unit or turns off to standby

mode.

b Disc tray

c ç (Open/Close)

– Opens/closes the disc tray.

d Display panel

– Shows information about the current

status of the unit.

e VOLUME

– Adjusts the volume level.

f ./ M= (Previous/Next)

– DISC: skips to the previous or next title/

chapter/track.

– DISC: press and hold this button for fast

forward and backward search.

– RADIO: selects a preset radio station.

u (Play/Pause)

– DISC: starts/pauses playback.

– RADIO: starts auto radio installation for

 rst time setup.

x (Stop)

– Exits an operation.

– DISC: stops playback.

– RADIO: press and hold this button to

erase the current preset radio station.

g SOURCE

– Selects the relevant active source mode:

DISC, USB, FM, AUX1, AUX2,

DI (DIGITAL IN), MP3 LINK or DOCK.

Note:

The following jacks are under the  ap at

the right corner of the front pa

nel,

OPEN .

h MP3 LINK jack

– Phono input for connecting to the

headphone out jack on your portable

audio player.

i (USB) jack

– Input for USB  ash drive or USB memory

card reader.

1_hts3565-66D_37_eng2_final813.i9 91_hts3565-66D_37_eng2_final813.i9 9 2008-03-27 3:11:57 PM2008-03-27 3:11:57 PM

English

Remote Control

a 2 (Standby-On)

– Turns on this unit or turns off to standby

mode.

b ç (Open/Close)

– Opens/closes the disc tray.

c Source buttons

– AUX (MP3 LINK): switches to AUX1,

AUX2, DI (DIGITAL IN) or MP3 LINK

external source mode.

– RADIO: switches to FM band.

– USB: switches to USB mode.

– DISC: switches to DISC mode.

– DOCK: switches to the iPod that is

connected to the docking station.

d INFO

– Displays the current status or disc

information.

e OPTIONS

– Enters or exits the system setup menu.

f u (Play/Pause)

– DISC: starts/pauses playback.

– RADIO: starts auto radio installation for

 rst time setup.

g Ç (Stop)

– Exits an operation.

– DISC: stops playback.

– RADIO: press and hold this button to

erase the current preset radio station.

h SOUND MODES +/-

– Selects a prede ned sound effect.

i AUDIO SYNC

– DISC: selects an audio language/channel.

– Sets the audio output delay times if the

video playback is slower than the audio

output.

j ZOOM

– Zoom in or out the picture on the TV.

k SLEEP

– Sets the sleep timer.

1_hts3565-66D_37_eng2_final813.i10 101_hts3565-66D_37_eng2_final813.i10 10 2008-03-27 3:11:57 PM2008-03-27 3:11:57 PM

English

Remote Control (continued)

l OK

– Con rms an entry or selection.

m b B v V

– DISC: selects movement direction in the

menu.

– DISC: press left or right for fast forward

and backward search.

– RADIO: press up or down to tune the

radio frequency.

– RADIO: press left or right to start auto

search.

n MENU (BACK)

– DVD: go back to title menu.

– VCD/SVCD:

During playback (PBC ON mode only)

return to the PBC menu.

o í / ë (Previous/Next)

– DISC: skips to the previous or next title/

chapter/track.

– RADIO: selects a preset radio station.

p % (Mute)

– Mutes or restores the volume.

q VOL +/-

– Adjusts the volume level.

r SURROUND

– Selects multi-channel surround, stereo or

party mode.

s Numeric keypad 0-9

– Enters a track/title/chapter number of the

disc.

– Enters a number of a preset radio station.

t SUBTITLE

– Selects a DVD subtitle language.

u REPEAT A-B

– Repeat playback a speci c section on a

disc.

v REPEAT (PROGRAM)

– DISC: selects various repeat or shuf e

modes; turns off repeat or shuf e mode.

– RADIO: press this button to start manual

preset programming.

– RADIO: press and hold this button to

start automatic preset programming.

1_hts3565-66D_37_eng2_final813.i11 111_hts3565-66D_37_eng2_final813.i11 11 2008-03-27 3:11:57 PM2008-03-27 3:11:57 PM

English

Remote Control (continued)

Using the remote control

A Push to open the battery compartment.

B Insert two batteries type R03 or AAA,

following the indications (+-) inside

the compartment.

C Close the cover.

D Point the remote control directly at the

remote sensor (iR) on the front panel.

E Select the source you wish to control by

pressing the AUX (MP3 LINK), RADIO,

USB, DOCK or DISC button on the

remote control.

F Then select the desired function (for

example í, ë.)

CAUTION!

– Remove batteries if they are

exhausted or if the remote control

is not to be used for a long time.

– Never mix batteries (old and new

or carbon and alkaline, etc.).

– Batteries contain chemical

substances, they should be disposed

of properly.

1_hts3565-66D_37_eng2_final813.i12 121_hts3565-66D_37_eng2_final813.i12 12 2008-03-27 3:11:57 PM2008-03-27 3:11:57 PM

English

Basic Connections

Step 1: Placing the speakers

The Philips Home Theater System is

simple to install. However, proper

system placement is critical to ensure an

optimum sound experience.

A Place the front left and right speakers at

equal distances from the TV and at an

angle of approximately 45 degrees from

the listening position.

B Place the center speaker above the TV or

the main unit so that the center channel’s

sound is localized.

C Place the rear speakers at normal

listening ear level facing each other or

hang on the wall.

D Place the subwoofer at the corner of the

room. Otherwise, keep it at least one

meter away from the TV.

Helpful Hints:

– The placement diagram shown here is only

a guideline that provides great system

performance. You may  nd other placement

choices that are more suitable for your room

layout that provide the sound experience you

enjoy.

– To avoid magnetic interference, never

position the front speakers too close to your

TV.

– The rear speakers are labeled as REAR

LEFT or REAR RIGHT.

– The front speakers are labeled as

FRONT LEFT or FRONT RIGHT.

– For speaker setting, see ‘Getting Started -

Setting the speakers’ channels.’

FRONT

RIGHT

FRONT

LEFT

CENTER

REAR

RIGHT

REAR

LEFT

SUBWOOFER

* Tallboy rear speakers for HTS3566D model.

1_hts3565-66D_37_eng2_final813.i13 131_hts3565-66D_37_eng2_final813.i13 13 2008-03-27 3:11:58 PM2008-03-27 3:11:58 PM

English

AUX 1AUX 2

Step 2: Connecting to TV

This connection enables you to view the

video playback from this unit. You only

need to choose one of the options

below to make the video connection.

– For a standard TV, follow option 1 or

– For a progressive scan TV, follow

option 3.

– For a HDMI TV, follow option 4.

– For TV with only a single antenna

input jack, follow option 5.

Helpful Hints:

– It is important to connect this unit directly

to the TV in order to enjoy optimum video

quality.

– To hear the TV audio through this unit,

see chapter ‘Optional Connection -

Connecting audio from cable box/recorder/

game console or TV’ for details.

Option 1

Option 2

Option 1: Using the Video jack



Use the supplied composite video cable

(yellow) to connect the CVBS jack on

the main unit to the video input jack (or

labeled as A/V In, Video In, Composite or

Baseband) on the TV.

 It provides good picture quality.

Option 2: Using the S-Video jack



Use an S-video cable (not supplied) to

connect the S-VIDEO jack on the main

unit to the S-Video input jack (or labeled

as Y/C or S-VHS) on the TV.

 It provides good picture quality.

Basic Connections (continued)

1_hts3565-66D_37_eng2_final813.i14 141_hts3565-66D_37_eng2_final813.i14 14 2008-03-27 3:11:58 PM2008-03-27 3:11:58 PM

English

Basic Connections (continued)

Option 3: Connecting to a

Progressive Scan TV or component

video input

The progressive scan video quality is only

available when using Y Pb Pr connection

and a progressive scan TV is required. It

provides superior picture quality when

watching DVD movies.

A Use the component video cables (red/

blue/green - not supplied) to connect the

Y Pb Pr jacks on the main unit to the

corresponding component video input

jacks (or labeled as Y Pb/Cb Pr/Cr or

YUV) on the TV.

 It provides better picture quality.

B If your TV accepts progressive signals,

proceed to chapter ‘Getting Started -

Setting up Progressive Scan feature’ for

detailed progressive feature setup.

Option 4: Connecting to a HDMI-

compatible TV

HDMI (High De nition Multimedia

Interface) is a digital interface that allows

pure digital video transmission without

the loss of image quality.



Use the HDMI cable (not supplied) to

connect the HDMI OUT on the main

unit to the HDMI IN on a HDMI-

compatible device (e.g., HDMI TV, HDCP

compliant DVI TV.)

 It provides best picture quality.

Note:

This unit is HDMI CEC compatible.

It enables connected devices to control

each other over HDMI, see ‘Setup Menu

Options - { Video Setup > HDMI Setup >

EasyLink }’ for details.

Helpful Hints:

– The HDMI is backward compatible with

some DVI devices using an appropriate

adaptor plug.

– If a DVI device is connected, an additional

audio cable is required for audio transmission.

AUX 1

Option 4

AUX 1

Option 3

1_hts3565-66D_37_eng2_final813.i15 151_hts3565-66D_37_eng2_final813.i15 15 2008-03-27 3:11:58 PM2008-03-27 3:11:58 PM

English

C Connect the Antenna or Cable TV

service signal to the ANTENNA IN or

RF IN jack on the RF modulator. (It may

have been connected to your TV

previously. Disconnect it from the TV.)

Basic Connections (continued)

Option 5: Using an accessory RF

modulator

If your TV has only a single Antenna

Input jack (labeled as 75 ohm or RF In,)

you need an RF modulator in order to

view the DVD playback on the TV. See

your electronics retailer or contact

Philips for details about RF modulator

availability and operations.

A Use the supplied composite video cable

(yellow) to connect the CVBS jack on

the main unit to the video input jack on

the RF modulator.

B Use an RF coaxial cable (not supplied) to

connect ANTENNA OUT or TO TV

jack on the RF modulator to the

ANTENNA IN jack on the TV.

AUX 1AUX 2

Antenna

Back of RF Modulator

(example only)

1_hts3565-66D_37_eng2_final813.i16 161_hts3565-66D_37_eng2_final813.i16 16 2008-03-27 3:11:59 PM2008-03-27 3:11:59 PM

English

AUX 1AUX 2

Basic Connections (continued)

REAR LEFT

REAR RIGHT

SUBWOOFER

FRONT CENTER

FRONT

LEFT

FRONT

RIGHT

Step 3: Connecting speakers

and subwoofer

Before you start...

For Tallboy speakers (HTS3566D):

– Connect the speaker cables to the

speakers.

– Assemble the rear speakers to the

proper position.

A Connect the speaker cables to the

matching colour sockets on the speakers

or speaker stands.

B Attach the speakers to the speaker

stands and secure the position with the

supplied screws.

Connect all the speakers and subwoofer

to the matching sockets at the rear of the

main unit. Make sure that the colours of

the cables and sockets are matched.

Helpful Hint:

– To prevent unwanted noise, never place

the speakers too close to the main unit,

subwoofer, AC power adapter, TV or any

other radiation sources.

* Tallboy rear speakers for HTS3566D model.

1_hts3565-66D_37_eng2_final813.i17 171_hts3565-66D_37_eng2_final813.i17 17 2008-03-27 3:11:59 PM2008-03-27 3:11:59 PM

English

Basic Connections (continued)

AUX 1AUX 2

Step 4: Connecting the

power cord

After everything is connected

properly, connect the AC power

cord into the power outlet.

The standby LED on the main unit lights

up.

Helpful Hints:

– Refer to the type plate at the rear or

bottom of the product for identi cation and

supply ratings.

– Before making or changing any

connections, make sure that all the devices

are disconnected from the power outlet.

1_hts3565-66D_37_eng2_final813.i18 181_hts3565-66D_37_eng2_final813.i18 18 2008-03-27 3:12:00 PM2008-03-27 3:12:00 PM

English

Optional Connections

Connecting audio from cable

box/recorder/game console

or TV

This unit provides analog and digital audio

connection. You can connect the audio

output from an audio/video device (e.g.

DVD Recorder, VCR, Cable/Satellite

Box, game console or TV) to this Home

Theater System in order to enjoy the

multi-channel surround sound capabilities.



Use an audio cable (not supplied) to

connect the AUDIO IN-AUX1 or

AUDIO IN-AUX2 jacks on the main

unit to the AUDIO OUT jacks on the

connected device.

To listen to the audio output from this

connection, press AUX (MP3 LINK)

repeatedly until ‘AUX1’ or ‘AUX2’ is

displayed on the front panel.

AUDIO OUT

DIGITAL

OUT

AUX 1

AUX 2

Cable/Satellite Box

DVD Recorder/VCR



Use a coaxial cable (not supplied) to

connect the DIGITAL IN-COAXIAL

jack on the main unit to the DIGITAL

output jack on the connected device.

To listen to the audio output from this

connection, press AUX (MP3 LINK)

repeatedly until ‘DI’ is displayed on the

front panel.

1_hts3565-66D_37_eng2_final813.i19 191_hts3565-66D_37_eng2_final813.i19 19 2008-03-27 3:12:00 PM2008-03-27 3:12:00 PM

English

Finding the correct viewing

channel

A Press 2 to turn on the unit.

B Press DISC on the remote control.

C Turn on the TV and switch it to the

correct video-in channel.

 You may go to the lowest channel on

your TV, then press the Channel Down

button on your TV remote control until

you see the Video In channel.

 You may press

button repeatedly

on your TV’s remote control.

 Usually this channel is between the

lowest and highest channels and may be

called FRONT, A/V IN, VIDEO, etc..

 If you are using a RF modulator, set

the TV to channel 3 or 4.



Refer to your TV user manual on how

to select the correct input on your TV.

Getting Started

Switching to different play

source

On the main unit



Press the SOURCE button on the main

unit repeatedly to select:

DISC  USB  FM  AUX1  AUX2

 DI  MP3 LINK  DOCK  DISC ...

On the remote control



Press DISC to switch to DISC mode.



Press USB to switch to USB mode.



Press RADIO to switch to FM band.



Press DOCK to switch to iPod mode.



Press AUX (MP3 LINK) repeatedly to

hear the audio output from the external

device.

 ‘AUX1’ for device connected to

AUDIO IN-AUX1 jacks.

 ‘AUX2’ for device connected to

AUDIO IN-AUX2 jacks.

 ‘DI’ for device connected to DIGITAL

IN-COAXIAL jack.

 ‘MP3 LINK’ for device connected to

MP3 LINK jack.

1_hts3565-66D_37_eng2_final813.i20 201_hts3565-66D_37_eng2_final813.i20 20 2008-03-27 3:12:01 PM2008-03-27 3:12:01 PM
