RC4WD 1980 Toyota Land Cruiser FJ55 Lexan Body Set is designed for hobbyists who enjoy building and customizing their own RC vehicles. With its durable lexan material and a range of included accessories, this body set allows you to create a realistic and detailed replica of the classic 1980 Toyota Land Cruiser FJ55. You'll have the freedom to paint and customize the body to your liking, making it a unique representation of your own style and preferences in the RC hobby.
RC4WD 1980 Toyota Land Cruiser FJ55 Lexan Body Set is designed for hobbyists who enjoy building and customizing their own RC vehicles. With its durable lexan material and a range of included accessories, this body set allows you to create a realistic and detailed replica of the classic 1980 Toyota Land Cruiser FJ55. You'll have the freedom to paint and customize the body to your liking, making it a unique representation of your own style and preferences in the RC hobby.
RC4WD 1980 Toyota Land Cruiser
FJ55 Lexan Body Set
(Foam safe CA, Shoe Goo or E6000, Styrene Glue, Epoxy)
Cross head screwdriver (Small)
Side Cutters
Hobby Knife
Curved Lexan Scissors
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
I
RC4WD non-electrical products are warranted to be free of defects in materials and workmanship when
new. Our limited warranty does not cover damages due to normal wear and tear, user error of assembly or
installation, user modifications, user's failure to perform routine maintenance, addition of aftermarket parts or
option parts. This warranty lasts 30 days after arrival for original purchaser.
In the event of a defect under this warranty, RC4WD will, at our discretion, replace the product, provided our
inspection indicates that an original defect exists. RC4WD reserves the right to replace any product which is
no longer available with a product of comparable value and function. If RC4WD determines the repair is not
covered under warranty guidelines, we will contact you to discuss your options. If you have any questions,
please contact us via email at [email protected].
RC4WD warranties its electronics for 30 days from date of arrival. This covers all electrical items except items
that are already noted on the individual product page.
1. Carefully remove all pieces from parts trees with a hobby knife or side cutters. Take care to trim the
injection point from the parts.
2. Test fit everything before gluing. Many areas will require extra attention to detail to ensure proper alignment.
Recommendations for building your RC4WD 1980 Toyota Land Cruiser FJ55 Lexan Body Set.
Apply Thread Lock
CA Glue
Repeat or Build Multiple
Glue
Cut with Scissors
Apply Grease
Attention
x2
Build Right and Left
Remove
Build Front and Rear
Paint
Drill Hole Body ReamerTrim with Hobby Knife
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
II
325-1195
325-1197
325-1196
325-1198
325-1199 325-1200
325-1201
325-1202
X2
325-1203
325-1204
325-1205
325-1206
325-
1207
325-1208
325-1209
325-1210
325-1211
325-1212
325-1213
325-1213
325-1214
X2
325-1215
325-1215
X2
325-1216
325-1216
325-1217
325-1218
325-
1219
325-1220
325-1221
X2
325-1222
X2
325-1223
325-1224
X4
325-1225
X6
325-1226 325-1227
325-1228
325-1229
325-1230 325-1231325-1232
325-1233
325-1234325-1235
325-1236
325-
1237
325-1238
325-1239 325-1240
325-1242
Velcro A
25x100mm
X2
325-1243
Velcro B
25x100mm
X2
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
III
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
IV
Lexan bodies come with an outer film to protect
them during painting. Do NOT remove this
covering until painting is complete.
1
1
After washing, apply the supplied window
masks to the interior of the body. Take care to
firmly press the edge of the masks down to the
body for best results and to prevent paint runs.
4
4
Lexan bodies come with a invisible residue from
the mold and needs to be washed off for best
paint results. Wash the body with dish detergent
using warm water to rinse completely. Take care
to dry with a lint free cloth or air dry completely
before painting.
3
3
Lexan bodies are painted on the inside. Please take
care to make all of the mounting holes and trim the
body completely before painting. Test fit all of the
hard plastic parts before painting. Do NOT glue any
accessory parts to the body before painting.
2
2
How to Paint your Lexan Body
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
V
How to Paint your Lexan Body
Once you are comfortable with your masking of the
body, it is time to apply paint. Be sure to fully read
and understand the directions of the paint you are
using as supplied on the can. We recommend using
lexan (polycarbonate) paint only. Normal household
paints will not yield good results.
6
6
Once the paint is dry, it is time to remove the
protective outer covering. This can be done by
using the tip of your hobby knife or finger to gently
peel up a corner and pulling it completely off.
7
7
Now is it time to apply the supplied decals to meet
your own personal style. You may now complete
the installation of the plastic accessories.
8
8
5
5
You can take this time to design a custom masking
design or paint in one solid color. There are many
advanced lexan body painting techniques available
online. We are only covering the basic techniques.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
VI
5.5mm & 4mm 5.5mm & 4mm
2.16mm
Step 2
Step 1
4.5mm
1.7mm 3mm 1.7mm 3mm
5.5mm
4.5mm
3mm
Use this page as a
reference for hole
sizes. Do NOT drill
any holes until
directed in Step 12
and 13.
Use this page as a
reference for hole
sizes. Do NOT drill
any holes until
directed in Step 14.
5.5mm
4mm
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
1
*Use a hobby knife to trim excess material
after drilling holes.
*Do not drill holes now.
*Do not drill holes now.
2mm
4.5mm
3.5mm
22mm
120°
Step 4
Step 3
7.5mm
4.5mm
3mm
2mm
4.5mm
4.5mm
5.5mm
Use this page as a
reference for hole
sizes. Do NOT drill
any holes until
directed in Step
15.
Use this page as a
reference for hole
sizes. Do NOT drill
any holes until
directed in Step 10
and 11.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
2
*Do not drill holes now.
*Do not drill holes now.
Test fit parts before
gluing. Parts may
need to be trimmed
to fit correctly.
Step 6
Step 5
325-1217
325-1216
325-1216
325-1219
325-1224
325-1198
M3X10mm
M3X10mm
325-1224
Left
Right
M3X10mm
X2
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
3
*Use Tamiya Translucent Paint in the areas with colors on
the outside of the lights if you are not using the stickers.
Test fit parts before
gluing. Parts may
need to be trimmed
to fit correctly.
Step 8
Step 7
325-1207
325-1213
325-1213
325-1208
M2X8mm
325-1240
325-1195
325-1239
M2X8mm
X1
Left
Right
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
4
Step 10
Step 9
325-1196
M3X10mm
M3X10mm
325-1224
325-1224
325-1222
325-1222
325-1221
325-1221
325-1223
325-1223
Body
M1.4X6mm
M1.4X6mm
M3X10mm
X2
M1.4X6mm
X6
Refer to Step 3 for
hole shape. Take
your time and
make sure the
holes are trimmed
correctly.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
5
5.5mm
4mm
Step 12
Step 11
M2X8mm
325-1220
325-1218
M2X8mm
325-1197
M2X8mm
M2X8mm
X7
M2X8mm
X2
Refer to Step 2 for
hole shape. Take
your time and
make sure the
holes are trimmed
correctly.
Refer to Step 3 for
hole shape. Take
your time and
make sure the
holes are trimmed
correctly.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
6
*Use a hobby knife to trim excess material
after drilling holes.
Step 14
325-1202
325-1202
Step 13
M2X8mm M1.4X6mm
M1.4X6mm
325-1205
325-1214
325-1214
325-1206
325-1215
325-1215
Drill the forward
most hole first (side
view mirror) for the
inner panel. Use
panel as a template
to mark the rest of
the holes.
When installing the
door handles check
the hole location
carefully to ensure
you have them
located properly.
Refer to Step 4 for
hole shape. Take
your time and make
sure the holes are
trimmed correctly.
M2X8mm
X2
M1.4X6mm
X4
Start by drilling a
smaller hole than
needed. Wipers
are designed to
snap into place.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
7
*Wipers may require glue on the inside to hold them in place. Use a clear drying glue.
Do not use CA as it will dry foggy. Shoe goo or E6000 will ruin paint. Canopy paint will
work.
When installing the interior tray you may need to trim some small holes to clear the
Wiper posts.
You may need to
enlarge some
holes to get the
rear LED bracket
to install. Take
your time here.
Refer to Step 4 for
hole shape. Take
your time and
make sure the
holes are trimmed
correctly.
Step 16
M1.4X6mm
325-1228
325-1215
Step 15
325-1210
M2X8mm
325-1233
325-1236
M2X8mm
325-1234
325-1235
325-1209
325-1211
325-1238
325-1237
325-1212
M1.4X6mm
M2X8mm
M1.4X6mm
Before drilling holes
in the interior, insert
into the body and
use a marker to
mark each hole.
The front and rear
vent brackets hold
the interior to the
main body.
M1.4X6mm
X1
M2X8mm
X6
M1.4X6mm
X2
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
8
*Use Tamiya Translucent
Paint in the areas with
colors on the outside of
the lights if you are not
using the stickers.
Step 18
Step 17
325-1231
325-1227
325-1232
325-1230
325-1229
M2X8mm
325-1204
325-1203
M2X8mm
Drill the center
hole first. Install
the bumper then
mark the holes
with a marker for
the outer posts.
M2X8mm
X3
M2X8mm
X12
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
9
*Use Tamiya Translucent
Paint in the areas with
colors on the outside of
the lights if you are not
using the stickers.
Step 20
Step 19
150-0101
150-0101
325-1201
325-1226
150-0101
150-0101
150-0101
M3 x 10mm FHCS
X2
150-0101
M3 x 10mm FHCS
X2
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
10
Step 22
Step 21
325-1243
325-1199
325-1242
Velcro A
Velcro B
Velcro A
Velcro B
150-0063
150-0063
325-1200
150-0063
325-1242
150-0063
325-1243
325-1225
X6
150-0063
M3 x 10mm BHCS
X4
325-1225
325-1225
325-1225
The front part of
the car needs to
be installed with 4
buckles, two on
the top and two on
the bottom.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
11
*For all windows with black outline trim the center section of the window can be cut out to have a
non tinted / clear window.
*The side door tinted windows do not need to be installed if you want a clearer view of the interior.
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
12
RC4WD 1980 Toyota
Land Cruiser FJ55 Lexan Body Set
13
