AN-1455 LM5072 Evaluation Board
1 Introduction
The LM5072 evaluation board is designed to provide a low cost, fully IEEE 802.3af compliant Power over
Ethernet (PoE) power supply, capable of operating with both PoE and auxiliary (AUX) power sources. The
evaluation board features the LM5072 PoE Powered Device (PD) interface and controller integrated circuit
(IC) configured in the versatile flyback topology.
2 Features of the LM5072 Evaluation Board
Single Isolated 3.3V output (see Figure 1)
Dual Isolated 5V and 3.3V outputs supported (see Figure 15)
Non-Isolated outputs supported (see Figure 16)
Maximum output current 3A
Input voltage range for maximum output current (as configured):
With the installed wide-voltage-range EP13 transformer
PoE input voltage range: 38 to 60V
FAUX input voltage range: 24 to 60V
RAUX input voltage range: 16 to 60V
With the optional, efficiency-optimized EP13 transformer
PoE input voltage range: 38 to 60V
FAUX input voltage range: 24 to 60V
RAUX input voltage range: 24 to 60V
Measured maximum efficiency:
With the installed wide-voltage-range EP13 transformer
DC to DC converter efficiency: 81% at 3A
Overall efficiency (including diode bridge): 78.5% at 3A
With the optional, efficiency-optimized EP13 transformer
DC to DC converter efficiency: 84% at 3A
Overall efficiency (including diode bridge): 81.5% at 3A
Board Size: 2.75 x 2.00 x 0.66 inches
Operating frequency: 250 kHz
PoE input under-voltage lockout (UVLO) release: 39V nominal
PoE input UVLO hysteresis: 7V nominal
This application note focuses on the evaluation board. Please refer to the LM5072 Integrated 100V Power
Over Ethernet PD Interface and PWM Controller with Aux Support (SNV437) data sheet for detailed
information about the complete functions and features of the LM5072 IC.
All trademarks are the property of their respective owners.
1
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
A Note about Input Potentials
www.ti.com
3 A Note about Input Potentials
The LM5072 is designed for PoE applications that are typically -48V systems, in which the notations GND
and -48V normally refer to the high and low input potentials, respectively. However, for easy readability,
the LM5072 data sheet was written in the positive voltage convention with positive input potentials
referenced to the VEE pin of the LM5072. Therefore, when testing the evaluation board with a bench
power supply, the negative terminal of the power supply is equivalent to the PoE system’s -48V potential,
and the positive terminal is equivalent to the PoE system ground. To prevent confusion between the data
sheet and this application note, the same positive voltage convention is used herein.
4 A Note About the Maximum Power Capability
While the LM5072 provides a fully IEEE 802.3af compliant PD solution, it is also capable of supporting
higher power level applications with an input current up to 700 mA. However, this evaluation board is
designed for IEEE 802.3af compliant PD power levels less than 12.95W. This power limitation is mainly
due to the use of appropriately rated devices like the power transformer and power switch MOSFET,
which do not support higher power levels. It should be noted that when using the LM5072 at elevated
power levels, the thermal environment must be carefully considered.
No power conversion is 100% efficient. It should be noted that conversion efficiency lowers the amount of
power that can be delivered to the load to levels significantly below 12.95W. For example, 75% efficiency
limits the power delivered to 9.7W. Conversion efficiency must also be taken into account when
calculating board input current.
Finally, when configured for front auxiliary operation, the maximum power deliverable may be limited by
the hot swap MOSFET’s DC current limit function. This is especially true at lower input voltages. The
current limit can be adjusted via a single resistor on the DCCL pin.
5 Schematic of the Evaluation Board
Figure 1 shows the schematic of the LM5072 evaluation board. See Appendix A for the Bill of Materials
(BOM).
Figure 1. Schematic of the LM5072 Evaluation Board
2
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
RJ
45
PoE
Load
T1
S/N
xxxx
U1
J4
J5
J1
BR1
BR2
-
+
RAUX
+
P3
J3
-
-
+
P4
FAUX
+
P1
J2
-
-
+
P2
www.ti.com
Connection and Proper Test Methods
6 Connection and Proper Test Methods
Figure 2. LM5072 Evaluation Board Connections
Figure 2 shows the connections for the LM5072 evaluation board.
The LM5072 evaluation board has the following four ports for connections.
J1, the RJ45 connector for PoE input
J2, a PJ102A power jack, for Front Auxiliary (FAUX) input (also accessible with posts P1 and P2
located immediately behind the jack)
J3, the other PJ102A power jack, for Rear Auxiliary (RAUX) input (also accessible with posts P3 and
P4 immediately behind the jack)
The 3.3V output port accessible with posts J4 and J5
For the PoE input, two diode bridges (BR1 and BR2) steer the current to the positive and negative supply
pins of the LM5072. For both FAUX and RAUX inputs, the higher potential input voltages should feed into
the center pins of the PJ102A jacks, or to P1 and P3, respectively. It should be pointed out that P2 and
P4, the returns for the FAUX and RAUX inputs, should not be interchanged because they do not represent
the same potential in the circuit. The RAUX pin is not reverse protected, and an additional reverse
blocking diode will be required for complete RAUX input reverse protection.
For the output connection, the load can be either a passive resistor or active electronic load. Attention
should be paid to the output polarity when connecting an electronic load. Use of additional filter capacitors
greater than 20 µF total across the output port is not recommended unless the feedback loop
compensation is adjusted accordingly.
Sufficiently large wire such as AWG #18 or thicker is required when connecting the source supply and
load. Also, monitor the current into and out of the circuit board. Monitor the voltages directly at the board
terminals, as resistive voltage drops along the connecting wires may decrease measurement accuracy.
Never rely on the bench supply’s voltmeter or ammeter if accurate efficiency measurements are desired.
When measuring the dc-dc converter efficiency, the converter input voltage should be measured across
C4, as this is the input to the converter stage. When measuring the evaluation board overall efficiency
(which is more relevant), both input and output voltages should be read from the terminals of the
evaluation board.
7 Source Power
To fully test the LM5072 evaluation board, a DC power supply capable of at least 60V and 1A is required
for the PoE input. For the auxiliary source power, either FAUX or RAUX, use a DC power supply capable
of 3A. Use the output over-voltage and over-current limit features of the bench power supplies to protect
the board against damage by errant connections.
3
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
Loading / Current Limiting Behavior
www.ti.com
8 Loading / Current Limiting Behavior
A resistive load is optimal, but an appropriate electronic load specified for operation down to 2.0V is
acceptable. The maximum load current is 3.3A. Exceeding this current at low input voltage may cause
oscillatory behavior as the part will go into current limit mode. Current limit mode is triggered whenever the
average current through the PoE connector exceeds 440 mA (default nominal). The current limit can be
programmed to any desired level up to 800 mA by selecting a resistor value for R23 (see the LM5072
datasheet for further details). If current limit is triggered, the switching regulator is automatically disabled
by discharging the softstart capacitor C26 through the SS pin. The module is then allowed to restart, but
the unit will operate in an automatic re-try (hiccup) mode as long as the over-current condition remains.
Switching regulator shut down during a fault condition such as current limit can be delayed by adding
additional filtering capacitance to the nPGOOD pin.
9 Power Up
It is suggested to apply PoE power first. During the first power up, the load should be kept reasonably low.
Check the supply current during signature and classification modes before applying full power. During
signature mode, the module should have the I-V characteristics of a 25 k resistor in series with two
diodes. During classification mode, current draw should be about 700µA at 16V; the RCLASS pin is left
open, defaulting to class 0. If the proper response is not observed during both signature and classification
modes, check the connections closely. If no current is flowing it is likely that the set of conductors feeding
PoE power have been incorrectly installed.
Once the proper setup has been established, full power can be applied. A voltmeter across the output
terminals J4 (+3.3V) and J5 (3.3V RTN), will allow direct measurement of the 3.3V output line. If the 3.3V
output voltage is not observed within a few seconds, turn the power supply off and review connections.
A final check of efficiency is the best way to confirm that the unit is operating properly. Efficiency
significantly lower than 80% at full load indicates a problem.
After proper PoE operation is verified, the user may apply auxiliary power to the FAUX or RAUX inputs. It
is recommended that the application of the auxiliary power follow the same precautions as those taken
when applying PoE. If no output voltage is observed, it is likely that the auxiliary power feed polarity is
reversed. After successful operation is observed in both FAUX and RAUX modes, full power testing can
begin.
10 PD Interface Operating Modes
When connecting into the PoE system, the evaluation board’s Powered Device interface will go through
the following operating modes in sequence: PD signature detection, power level classification (optional),
and application of full power. Refer to the SNV437 data sheet and IEEE 802.3af for detailed information
about these operating modes.
11 Signature Detection
The 25 k PD signature resistor is integrated into the LM5072 IC. The PD signature capacitor is
implemented with a 100 nF capacitor at C27 or C29, depending on the auxiliary input configuration.
It should be noted that when either FAUX or RAUX power is applied first, it will not allow the Power
Sourcing Equipment (PSE) to identify the PD as a valid device because the auxiliary voltage will cause the
current steering diode bridges to be reverse biased during detection mode. This prevents the PSE from
applying power, so the evaluation board will only draw current from the auxiliary source.
12 Classification
PD classification is implemented with R22. The evaluation board is set to the default Class 0 by leaving
the RCLASS pin open (R22 position not populated). To activate a specific class instead of Class 0, install
R22 according to the following table.
4
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Input UVLO and UVLO Hysteresis
Class P
MIN
P
MAX
I
CLASS
(MIN) I
CLASS
(MAX) R22 Selection
0 0.44W 12.95W 0mA 4mA Open
1 0.44W 3.84W 9mA 12mA 130
2 3.84W 6.49W 17mA 20mA 71.5
3 6.49W 12.95W 26mA 30mA 46.4
4 Reserved Reserved 36mA 44mA 31.6
13 Input UVLO and UVLO Hysteresis
The input Under Voltage Lock-Out (UVLO) is an integrated function of the LM5072. The UVLO release
threshold is set to approximately 38.5V (at the pins of the IC) and the UVLO hysteresis is approximately
7V.
14 Inrush and DC Current Limit Programming
The LM5072 allows the user to independently program the inrush and DC current limits of the internal Hot
Swap MOSFET. The evaluation board sets the inrush limit to the default 150 mA by leaving R19
unpopulated, and the DC current limit to the default 440 mA by leaving the DCCL pin open (R23 not
populated). In applications where it is desirable to adjust these values, install R19 and R23, respectively,
according to the recommendations in the LM5072 datasheet. Please note that by leaving the DCCL pin
open, the default 440 mA DC current limit will be elevated to 550 mA during FAUX operation. When R23
is used to program the DC current limit, it applies to both PoE and FAUX power modes, and it should be
considered a firm limit”, that is, independent of operating mode.
15 FAUX Power Option
For the FAUX power option, the ICL_FAUX pin of the LM5072 senses the FAUX input voltage through D7
and R6. When the current flowing into the ICL_FAUX pin is greater than 50 µA at 8.5V nominal, it will
establish a state at the ICL_FAUX pin that forces UVLO release in order to allow operation at an auxiliary
input voltage as low as 18V (17V seen by the VIN pin of the LM5072 IC). One should not try to use the
ICL_FAUX as a stable, accurate UVLO threshold, the front auxiliary supply should pull the pin up well past
the voltage and current thresholds.
It should be pointed out that the minimum operative FAUX input voltage for the maximum output current is
24V. This is mainly limited by the default 540 mA FAUX input DC current limit of the LM5072’s internal hot
swap MOSFET. By lowering the FAUX input voltage, the input current will exceed the said limit unless the
output current is reduced accordingly.
If the FAUX power option is not used in a new design, delete C1, D3, D7, R6, and J2 from the circuit to
reduce the BOM cost.
16 RAUX Power Option
For the rear auxiliary power option, the RAUX pin of the LM5072 senses the RAUX input voltage through
R13. When the current flowing into the RAUX pin is greater than 20 µA at 2.5V nominal, it will establish a
state at the RAUX pin that forces switching regulator controller operation at input voltages as low as 10V
(9V seen by the pins of the LM5072 IC). When the current flowing into the RAUX pin is greater than 250
µA at 6V nominal, which is the preset configuration of the evaluation board, auxiliary dominance is
selected. During auxiliary dominance, the RAUX power source will always supply the current to the PD
regardless if PoE power is present or not. This is accomplished by forcing a shut down of the hot swap
MOSFET. If the PSE has implemented DC Maintain Power Signature, it will remove the 48V supply thus
freeing up power to be allocated to other ports. If only AC Maintain Power Signature is implemented, the
PSE may or may not remove power. Note that auxiliary non-dominance does not imply PoE dominance.
PoE dominance is very difficult to achieve without additional circuitry. Contact Texas Instruments for a
schematic of a robust PoE dominant solution.
5
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
Auxiliary Dominant in RAUX Power Option
www.ti.com
Because the LM5072’s input hot swap feature is not applicable to the RAUX input, two 2 resistors (R1
and R2) in parallel are used to achieve transient protection. Unlimited inrush currents can wear on board
traces, connector contacts, and various board components, as well as create dangerous transient
voltages. Nevertheless, these two resistors will cause power loss in the RAUX power mode, and they also
reduce the effective RAUX input voltage level sensed by the VIN pin of the LM5072. The resistors should
be made as large as is practical for the application. But, with a low RAUX input voltage (<16V), R1 and R2
may need to be reduced to a lower value.
During RAUX operation, the hot swap MOSFET is turned off. Consequently, the substrate of the IC no
longer has a low impedance path to power return. It is advised that the user remove C27 and populate
C29. A capacitor across the hot swap MOSFET will act as both the signature capacitor and a high
frequency short for any substrate noise.
If the RAUX power option is not used in a new design, delete C3, D1, D2, R1, R2, R13, R29 and J3 from
the circuit to lower the BOM cost.
17 Auxiliary Dominant in RAUX Power Option
The evaluation board is populated for auxiliary dominance in the RAUX power option. This is achieved by
selecting 4.99 k for R13. In applications where auxiliary dominance is not desirable, change the installed
R13 to a higher value. Please refer to the LM5072 SNV437 data sheet for assistance in selecting this
value.
18 Auxiliary Input “OR-ing” Diode Selection
Special attention should be paid to the selection of D1 and D3. They need not be high speed diodes
because there is no switching action during operation associated with these components, but they should
be low reverse leakage current devices. Otherwise, the leakage current during operation may create a
false signal at the ICL_FAUX pin, the RAUX pin, or both, as if the circuit is powered from the FAUX or
RAUX source. Leakage current into the ICL_FAUX pin may also corrupt inrush current programming, if
implemented. Most diode and transistor data sheets provide information on the maximum leakage current
at both 25°C and 125°C, although the data for the intermediate temperatures are not often supplied. It can
be approximated that the leakage current doubles for every 10°C rise in temperature.
The junction temperature of these devices should not reach 125°C because the only dissipation inside
these devices is caused by the leakage current. Therefore, it is not necessary to select the devices based
on the maximum leakage current specified at 125°C. The evaluation board design considered 55°C as the
maximum junction temperature of these devices, which is acceptable for most PoE applications. Simple
circuit adjustments can be made if higher leakage currents are expected.
Resistors R29 and C1 (note that a resistor is installed at the C1 location on the evaluation board to
achieve the function similar to R29’s) are both 24.9 k, providing paths for the leakage currents of D1 and
D3, respectively. These two resistors are meant to sink all of the leakage current from the diodes and
prevent false states at the ICL_FAUX and RAUX pins. Please see the LM5072 SNV437 data sheet for
more details about the selection of these two resistors.
19 Flyback Converter Topology
The dc-dc converter stage of the LM5072 evaluation board features the flyback topology, which employs
the minimum number of power components to implement an isolated power supply at the lowest possible
cost.
A unique characteristic of the flyback topology is its power transformer. Unlike an ordinary power
transformer that simultaneously transfers the power from the primary to the secondary, the flyback
transformer first stores the energy in the transformer core while the main switch is turned on, then
releases the stored energy to the load during the rest of the cycle. When the stored energy is not
completely released before the main switch is turned on again, it is said that the flyback converter
operates in continuous conduction mode (CCM). Otherwise, it is in discontinuous conduction mode
(DCM).
6
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Factors Limiting the Minimum Operating Input Voltage
Major advantages of CCM over DCM include (i) lower ripple current and ripple voltage, requiring smaller
input and output filter capacitors; and (ii) lower RMS current, thus reducing the conduction losses. To keep
the flyback converter in CCM at light load, the transformer’s primary inductance should be designed as
large as is practical.
Major drawbacks of CCM, as compared to DCM, are (i) the presence of the right-half-plane zero, which
may limit the achievable bandwidth of the feedback loop, and (ii) the need for slope compensation to
stabilize the feedback loop at duty cycles greater than 50%.
The flyback topology can have multiple secondary windings for several isolated outputs. One or more of
these secondary channels are normally utilized internally by the converter itself to provide necessary bias
voltages for the controller.
The evaluation board uses a small power transformer having a primary inductance of 32 µH. This is a
compromise made to allow the small transformer to operate over a wide input voltage range from 13V to
60V. However, with this transformer, the flyback converter runs in CCM at full load for input voltages lower
than 42V, and in DCM for higher input voltages or light loads. The LM5072’s built-in slope compensation
helps stabilize the feedback loop when the duty cycle exceeds 50% during low input voltage operation.
A transformer winding is used to provide the bias voltage (V
CC
) to the LM5072 IC. Although the LM5072
controller includes an internal startup regulator which can support the bias requirement indefinitely, the
transformer winding produces an output about 2V higher than the startup regulator output, thus shutting
off the startup regulator and reducing the power dissipation inside the IC. Given the low current limit value
(15 mA nominal) of the high voltage startup regulator, the V
CC
line is not meant to be a linear regulator for
external loads.
20 Factors Limiting the Minimum Operating Input Voltage
The LM5072 supports operation with low voltage auxiliary power sources. The minimum FAUX voltage is
24V for the maximum output current. It can be reduced to 18V if the output current is reduced to 2A. The
voltage drop caused by the FAUX input OR-ing diode D3 reduces the VIN pin potential to 17V. This is
because at lower FAUX input voltages the maximum power that can be delivered to the load will be
greatly reduced by the hot swap MOSFET’s current limit function. This is one of the drawbacks of FAUX
operation, though DC current limit can be adjusted by adding / changing the value of the DCCL resistor.
The minimum RAUX voltage of the evaluation board is 16V (voltage drops caused by the inrush limit
resistors R1 and R2 and the RAUX input OR-ing diode D1 reduce the VIN pin potential to about 15V),
although the LM5072 can function with a minimum of 9V seen at VIN. The 13V RAUX operating voltage
limit is mainly determined by three factors; the value of the RAUX inrush current limit resistor R1 and R2,
the flyback power transformer design, the values of the current sense resistors R14 and R15, and mainly
the dropout of the startup regulator.
The installed R1 and R2 are 2 resistors. Under full load conditions, these two resistors significantly
reduce the effective RAUX voltage seen by the DC-DC converter stage. In order to operate the evaluation
board at a lower input voltage, it is required to reduce R1 and R2 to 1 or lower values.
The installed EP13 type power transformer (DA2257-AL or DCT13EP-U12S005) is a low cost, area
efficient solution to operate with a wide auxiliary input voltage range. However, the small cross-sectional
area of the EP13 magnetic core also limits the maximum flux it can support. To use such a small
transformer from 16V to 60V input under the full load condition, a compromise between the minimum
operating input voltage and maximum inductance of the transformer must be made such that the peak
current at 16V input will not cause the peak flux density to exceed 3000 Gauss (saturation). A drawback of
this low cost solution is that the RMS current flowing through the dc-dc converter stage is increased and
the efficiency of the dc-dc converter suffers by about 3%.
Replacing the installed transformer with the optional power transformer DA2383-AL from Coilcraft
improves the efficiency, but the minimum operating input voltage will be limited to 24V. To use this
optional transformer for lower input voltage, the load level should be scaled down accordingly, as shown in
Figure 3.
7
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
<
f
SW
x L
m
k
t
x (V
O
+ V
F
)
R14 x R15
1.8 x D
max
R14 + R15
2 x D
max
- 1
x
x 10
-4
0
10 20 30 40 50 60
V
IN
(V)
1.0
1.5
2.0
2.5
3.0
3.5
MAX I
OUT
(A)
70
DA2257-AL or
DCT13EP-
U125005
DA2383-AL
Factors Limiting the Minimum Operating Input Voltage
www.ti.com
Figure 3. Maximum Load Current vs. Minimum Input Voltage as Limited by Different EP13 Type Power
Transformers
To optimize efficiency over the maximum input voltage range of 10.5V to 60V (9V min seen at the VIN pin,
after R1 and R2 are replaced with 1), a larger magnetic core like the EFD20 should be used. The EFD20
core has adequate cross-sectional area to handle the peak currents observed with a 10.5V input.
The effects of the current sense resistors R14 and R15 also limit the minimum RAUX input operating
voltage. The LM5072’s internal slope compensation stabilizes the feedback loop of the dc-dc converter
when the duty cycle exceeds 50% for input voltages lower than 22V. However, the relative magnitude of
the slope compensation is inversely proportional to the values of R14 and R15. The maximum values of
R14 and R15 are governed by the following relation:
(1)
where
D
max
is the duty cycle at the minimum AUXILIARY input voltage;
f
sw
the switching frequency, in kHz
L
m
the flyback transformer primary inductance, in µH
k
t
the transformer’s primary to secondary turns ratio
V
o
the output voltage, in volts
V
F
the forward drop of the output diode D5, in volts
Selecting 0.30 for both R14 and R15 will allow a minimum operating voltage of 16V. For lower RAUX
input voltages, Dmax is greater and hence R14 and R15 must be reduced accordingly. However, smaller
resistors increase the effect of internal slope compensation. Increasing the slope compensating makes the
feedback loop appear more like voltage mode than current mode. This in turn requires the use of a low
ESR capacitor for C16, rather than the low cost capacitor initially installed on the evaluation board.
In summary, the 16V minimum operating RAUX input voltage of the evaluation board is limited by the low
cost solution, and also by the dropout of the startup regulator. In order to use the evaluation board with a
lower RAUX source, the power transformer T1, the output capacitor C16, R14, and R15 should be
modified, in addition to the installation of D2.
D2 should be installed whenever the voltage at the VIN pin is less than 15V. This ensures the V
CC
regulator has enough voltage to start given its relatively high drop out requirement. One must also be
careful not to violate the VCC pin’s absolute maximum voltage rating under this configuration. Accordingly,
a 15V nominal auxiliary supply may be difficult to design for, as it will require the installation of D2 and
violate the pin’s absolute maximum rating. Additional circuitry may be required, or the selection of a
different auxiliary input voltage.
8
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Performance Characteristics
21 Performance Characteristics
21.1 PoE Input Power-up Sequence
The high level of integration designed into the LM5072 allows all power sequencing communications to
occur within the IC. Very little system management design is required by the user. The power up
sequence is as follows. Note that the RTN pin (IC pin 8) is isolated from the +3.3V RTN output pin of the
board:
1. Before power-up, all nodes in the non-isolated section of the power supply remain at high potential
until UVLO is released and the drain of the internal hot swap MOSFET is pulled down to VEE (IC pin
7).
2. The V
CC
regulator powers up during the inrush sequence. During V
CC
regulator startup, it draws current
on the order of 20mA, but this will likely not be noticed by the user. Once the RTN pin of the IC drops
below 1.5V (referenced to VEE), and the gate of the hot swap MOSFET rises, power good is asserted
by pulling the nPGOOD pin low.
3. Once power good has been asserted, the SS (Soft-Start) pin is released. The SS pin will rise at a rate
equal to the SS current source, typically 10µA, divided by the SS pin capacitance, C26.
4. As the switching regulator achieves regulation, the auxiliary winding will raise the V
CC
voltage to about
11V, thus shutting down the internal regulator and increasing efficiency.
Figure 4 shows the voltage at the RTN pin (referenced to VEE), output voltage V
OUT
and input current
during a normal startup sequence. The RTN voltage gradually drops as the input current charges the input
capacitors. When the charging process is completed, the RTN voltage drops to below 1.5V, followed by
the soft start of the converter.
Figure 5 shows the V
CC
voltage during startup. The V
CC
of about 8V is first produced by the internal startup
regulator. When the output regulation is established, V
CC
is elevated to about 11V through cross-
regulation.
Horizontal Resolution: 5 ms/Div.
Trace 1: VOUT, 2V/Div.
Trace 2: RTN pin (referenced to VEE), 20V/Div.
Trace 3: Input Current, 200 mA/Div.
Figure 4. Normal PoE input Startup Sequence
9
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
Performance Characteristics
www.ti.com
Horizontal Resolution: 5 ms/Div.
Trace 1: VOUT, cross-regulating VCC after output regulation is established. 2V/Div.
Trace 2: VCC, first regulated by startup regulator at 7.6V, then elevated by auxiliary winding to 11V. 2V/Div.
Trace 3: Input Current, 0.5A/Div.
Figure 5. VCC During Startup
21.2 Auxiliary Input Power-up Sequence
The FAUX input power up sequence is similar to that of the PoE input, with the exception that the 38V
UVLO release threshold is overridden when the ICL_FAUX pin is pulled up.
The RAUX input power up sequence is simpler:
1. Auxiliary application quickly charges the input capacitors. There should not be any overshoot observed
as the series resistors should limit the inrush.
2. When the V
CC
regulator establishes 7.6V, soft start of the PWM controller begins.
3. As the switching regulator achieves regulation, the auxiliary winding will raise the V
CC
voltage to about
10V, thus shutting down the internal regulator and increasing efficiency.
Figure 6 and Figure 7 shows the FAUX and RAUX input power up sequence, respectively.
Horizontal Resolution: 5 ms/Div.
Trace 1: VOUT, 2V/Div.
Trace 2: VCC, 5V/Div.
Trace 3: Input Current, 0.5A/Div.
Figure 6. Normal FAUX input Startup Sequence
10
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Performance Characteristics
Horizontal Resolution: 5 ms/Div.
Trace 1: VOUT, 2V/Div.
Trace 2: VCC, 5V/Div.
Trace 3: Input Current, 0.5A/Div.
Figure 7. Normal RAUX input Startup Sequence
Figure 8 shows the normal 3.3V output voltage startup, along with the SS pin for reference.
Horizontal Resolution: 1 ms/Div.
Trace 1: VOUT, 1V/Div.
Trace 2: SS pin voltage (referenced to RTN), 1V/Div
Trace 3: Input current (AC coupled), 200 mA/Div
Figure 8. Output Voltage Vout (+3.3V) Soft-start Detail
21.3 Output Dead Short Fault Response
The evaluation board survives the output dead short condition by running into a re-try mode (hiccup).
Applying a dead short to the +3.3V line causes a number of protection mechanisms to occur sequentially.
They are:
1. The feedback signal increases the duty cycle in an attempt to maintain the output voltage. This initiates
cycle-by-cycle over-current limiting which turns off the main switch when the current sense (CS) pin
exceeds the current limit threshold.
2. The current in the internal hot swap MOSFET rises until it is current limited around 440 mA. Some
overshoot in the current will be observed, as it takes time for the current limit amplifier to react and
change the operating mode of the MOSFET.
3. Because linear current limit is accomplished by driving the MOSET into the saturation region, the drain
voltage (RTN pin) rises. When it reaches 2.5V with respect to VEE, power good is de-asserted and the
nPGOOD pin rises in voltage.
4. The de-assertion of power good causes the discharge of the softstart capacitor, which disables all
11
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
Performance Characteristics
www.ti.com
switching action in the dc-dc converter.
5. Once the switching stops, the current in the internal MOSFET will decrease and the drain voltage will
fall back below 1.5V with respect to VEE. When power good is re-asserted, the dc-dc converter will
automatically restart with a new softstart sequence.
Figure 9 shows the cycle-by-cycle peak current limit providing the over-current protection under output
short-circuit condition. The short-circuit condition causes a large over current such that it intends to
saturate the power transformer. Consequently, a large peak current of about 4.33A is produced in the
primary circuit. This large peak current causes the current-sense voltage at CS pin to exceed the peak
limit threshold (>0.5V). Therefore the PWM duty cycle is cut short, leading to a limited input current (the
average current of the current pulses) at about 0.34A.
Horizontal Resolution: 1 µs/Div.
Trace 1: Voltage at the CS pin, 200 mV/Div.
Trace 2: Input Current, 0.5A/Div.
Vin=48V. Iin=0.34A
Figure 9. Cycle-by-Cycle Peak Current Limit Protection Under Output Short-Circuit Condition
Figure 10 shows the over-current protection by the hot swap MOSFET’s dc current limit under the output
short circuit condition. The circuit operates in the FAUX power configuration, and the FAUX input voltage
is set to 24V. The input current will exceed the 440 mA DC current limit of the hot swap MOSFET, and
causes the voltage at the RTN pin to rise rapidly. It also discharges the soft start capacitor C26 connected
to the SS pin, and the circuit enters the automatic retry mode until the over-current condition is removed.
The voltage at the SS pin is observed to rise quickly as the LM5072 reacts to the fault. This is because
the internal soft-start circuitry is referenced to RTN, while all scope measurements are referenced to VEE.
Horizontal Resolution: 5 ms/Div.
Trace 1: RTN pin voltage (referenced to VEE), 2V/Div.
Trace 2: Softstart pin (referenced to VEE), 5V/Div.
Trace 3: Input current, 0.5A/Div.
FAUX input=24V
Figure 10. Shorted Output Fault Condition / Automatic Re-try
12
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Performance Characteristics
21.4 Step Response
Figure 11 shows the step load response at Vin = 48V.
Horizontal Resolution: 0.2 ms/Div.
Trace 1: Output voltage (AC coupled), 200 mV/Div.
Trace 2: Output current (DC coupled), 0.5 A/Div.
Figure 11. Regulator Response to Step Load
21.5 Ripple Voltage Current
Figure 12 shows the output ripple voltage and input ripple current for 48V input voltage and 3.3A output.
The input ripple current is reduced to less than 5 mA pk-pk by the input filter inductor.
Horizontal Resolution: 0.2 ms/Div.
Trace 1: Output voltage (AC coupled), 20 mV/Div.
Trace 2: Input current (AC coupled), 50 mA/Div.
Vin=48V, Iout=3.3A
Figure 12. Ripple Currents and Voltages
21.6 FLYBACK Transformer Waveforms
Figure 13 and Figure 14 show typical flyback transformer waveforms: the drain to source voltage of the
main switch Q1 and the reverse voltage of the rectifier diode D5, respectively, at 48V input voltage and
3.3A output.
13
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
Reconfiguration of the Evaluation Board for 3.3V And 5V Dual Outputs
www.ti.com
Horizontal Resolution: 1 µs/Div.
Trace 1: Drain to source voltge of main switch Q1, 50V/Div.
Vin=48V, Iout=3.3A
Figure 13. Flyback Transformer Waveforms
Horizontal Resolution: 1 µs/Div.
Trace 1: Reverse voltage across output rectifier diode D5, 5V/Div.
Vin=48V, Iout=3.3A
Figure 14. Flyback Transformer Waveforms
22 Reconfiguration of the Evaluation Board for 3.3V And 5V Dual Outputs
The standard evaluation circuit can be easily reconfigured into a 2A 3.3V and 0.6A 5.5V dual output power
supply. To reconfigure the board for dual output, populate the components for the 5.5V output rail as
shown in Figure 15. These components are listed in Section A.1.
23 Reconfiguration of the Evaluation Board for Non-Isolated Output
For applications where output isolation is not required, the non-isolated version of the evaluation board
can be used to reduce the BOM cost. Reconfiguration of the circuit board to the non-isolated version can
be accomplished in the following four steps:
1. Delete the unused parts from the circuit board as well as the BOM: C20, C22, C25, C28, R7, R11,
R16, R17, R24, U2 and U3.
2. Connect test points P5 and P6 with a bus wire of AWG 26.
3. Short C28 pads by installing a 0 resistor of R2010 size, or by soldering a piece of AWG 26 bus wire.
4. Change C30 to 3.3 nF, C31 to 1.0 nF and R20 to 10 k.
Figure 16 shows the schematic for non-isolated circuit with a single 3.3V output. Similar changes also
apply to the dual output version.
14
AN-1455 LM5072 Evaluation Board SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
A Note For Using The Efficiency Optimized EP13 Power Transformer DA2383
Figure 15. The Schematic for Dual Outputs
Figure 16. The Schematic for Non-Isolated Output
24 A Note For Using The Efficiency Optimized EP13 Power Transformer DA2383
Please note that the DA2383 is a single output transformer. When using a DA2383 to obtain better
efficiency (See Figure 3 for the applicable load and AUX input voltage levels), also remember to connect
D5's cathode to DA2383's pin 9 with a short jumper wire. This is because the secondary winding of
DA2382 uses Pins 6 through 9 of the transformer bobbin, unlike DA2257 that only uses of Pins 7 and 8 for
the secondary winding. The maximum converter stage efficiency at 3.3A will be expected to be greater
than 84%.
15
SNVA154AMarch 2006Revised May 2013 AN-1455 LM5072 Evaluation Board
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Appendix A LM5072 Evaluation Board Bill of Materials
Table 1. LM5072 Evaluation Board Bill of Materials
ITEM PART NUMBER DESCRIPTION VALUE
BR1 CBRHD-01 DIODE BRIDGE, SMDIP, CENTRAL 0.5A, 100V
BR2 CBRHD-01 DIODE BRIDGE, SMDIP, CENTRAL 0.5A, 100V
C1 CRCW08052492F RESISTOR 24.9K
C2 C0805C681F5GAC CAPACITOR, CER, CC0805, KEMET 680p, 50V
C3 NU
C4 C5750X7R2A475M CAPACITOR, CER, CC2220, TDK 4.7µF, 100V
C5 NU
C6 EEV-HA2A220P CAPACITOR, AL ELEC, PANASONIC 22µF, 100V
C7 C3216X5R0J106M CAPACITOR, CER, CC1206, TDK 10µF, 6.3V
C8 C3216X5R0J106M CAPACITOR, CER, CC1206, TDK 10µF, 6.3V
C9 C3216X5R0J106M CAPACITOR, CER, CC1206, TDK 10µF, 6.3V
C10 C3216X5R0J106M CAPACITOR, CER, CC1206, TDK 10µF, 6.3V
C15 C3216X5R0J106M CAPACITOR, CER, CC1206, TDK 10µF, 6.3V
C16 EMVY6R3ADA331MF80G CAPACITOR, AL ELEC, CHEMI-ON 330µF, 6.3V
C19 C2012X5R1C105K CAPACITOR, CER, CC0805, TDK 1.0µF, 16V
C20 C2012X5R1C474K CAPACITOR, CER, CC0805, TDK 0.47µF, 16V
C21 C0805C473K5RAC CAPACITOR, CER, CC0805, KEMET 47nF, 50V
C22 C0805C102K5RAC CAPACITOR, CER, CC0805, KEMET 1nF, 50V
C23 C0805C102K5RAC CAPACITOR, CER, CC0805, KEMET 1nF, 50V
C25 C0805C331K5RAC CAPACITOR, CER, CC0805, KEMET 330pF, 50V
C26 C0805C473K5RAC CAPACITOR, CER, CC0805, KEMET 47nF, 50V
C27 C3216X7R2A104K CAPACITOR, CER, CC1206, TDK 100nF, 100V
C28 C4532X7R3D222K CAPACITOR, CER, CC1812, TDK 2.2nF, 2 kV
C31 C0805C473K5RAC CAPACITOR, CER, CC0805, KEMET 47nF, 50V
D1 S3BB-13 DIODE, SMB, DIODE INC 3A, 100V
D2 NU
D3 CMR1U-01M DIODE, SMA, CENTRAL 1A, 100V
D4 CMHD4448 DIODE, SOD123, CENTRAL 125mA, 75V
D5 12CWQ03FN SCHOTTKY, TO252, IR 12A, 30V
D6 CMR1U-01M DIODE, SMA, CENTRAL 1A, 100V
D7 CMHD4448 DIODE, SOD123, CENTRAL 125mA, 75V
J1 RJ-45-8N-B RJ-45 CONNECTOR
J2 PJ-102A POWER JACK
J3 PJ-102A POWER JACK
J4 3104-2-00-01-00-00-080 POST, MILL MAX
J5 3104-2-00-01-00-00-080 POST, MILL MAX
L1 DO3308P-103MLD SM INDUCTOR, COILCRAFT 10µH
L3 DO1813P-331HC SM INDUCTOR, COILCRAFT 0.33µH
LED1 SSL-LXA228GC-TR11 LED,GREEN, LUMEX
P1 5012K-ND TEST POINT, KEYSTONE
P2 5012K-ND TEST POINT, KEYSTONE
P3 5012K-ND TEST POINT, KEYSTONE
P4 5012K-ND TEST POINT, KEYSTONE
Q1 SUD15N15-95 MOSFET, N-CH, TO252, VISHAY 150V, 15A
R1 CRCW2512200J RESISTOR 2, 1W
16
LM5072 Evaluation Board Bill of Materials SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
www.ti.com
Appendix A
Table 1. LM5072 Evaluation Board Bill of Materials (continued)
ITEM PART NUMBER DESCRIPTION VALUE
R2 CRCW2512200J RESISTOR 2, 1W
R3 CRCW080520R0F RESISTOR 20
R4 CRCW120610R0F RESISTOR 10
R5 CRCW08053321F RESISTOR 3.3k
R6 CRCW08051002F RESISTOR 10k
R7 CRCW080510R0F RESISTOR 10
R9 CRCW08051000F RESISTOR 100
R11 CRCW08051002F RESISTOR 10k
R12 CRCW08052432F RESISTOR 24.3k
R13 CRCW08054991F RESISTOR 4.9k
R14 CRCW12060R301F RESISTOR 0.301
R15 CRCW12060R301F RESISTOR 0.301
R16 CRCW08051001F RESISTOR 1k
R17 CRCW08051001F RESISTOR 1k
R18 CRCW08051472F RESISTOR 14.7k
R19 NU
R20 CRCW08056340F RESISTOR 634
R21 CRCW08052102F RESISTOR 21.0k
R22 NU
R23 NU
R24 CRCW08050R0J RESISTOR 0
R25 CRCW08050R0J RESISTOR 0
R28 CRCW08053320F RESISTOR 332
R29 CRCW08052492F RESISTOR 24.9k
T1A DA2257-AL XFMR, FLYBACK, COILCRAFT 32µH
T1B DCT13EP-U12S005 XFMR, FLYBACK, TDK 32µH
U1 LM5072 POE PI AND PWM CTRL, TEXAS INSTRUMENTS LM5072
U2A PS2801-1-L OPTO-COUPLER, NEC PS2801
U2B PC3H7D OPTO-COUPLER, SHARP PC3H7D
U3 LMV431 REFERENCE, SOT23-3, TEXAS INSTRUMENTS LMV431
Z1 CMZ5944B Zener, 60V, CENTRAL CMZ5938B
Z2 SMAJ58A TVS, 58V, DIODE INC SMAJ58A
17
SNVA154AMarch 2006Revised May 2013 LM5072 Evaluation Board Bill of Materials
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
Additional BOM to Add An 1A, 5.5V Output Rail
www.ti.com
A.1 Additional BOM to Add An 1A, 5.5V Output Rail
ITEM PART NUMBER DESCRIPTION VALUE
C12 C3216X5R1A106M CAPACITOR, CER, CC1206, TDK 10µF, 10V
C13 C3216X5R1A106M CAPACITOR, CER, CC1206, TDK 10µF, 10V
C14 C3216X5R1A106M CAPACITOR, CER, CC1206, TDK 10µF, 10V
C17 EMVY100ADA101MF55G CAPACITOR, AL ELEC, CHEMI-ON 100µF, 10V
D8 CMSH2-60 DIODE, SMA, CENTRAL 2A, 60V
J6 3104-2-00-01-00-00-080 POST, MILL MAX
J7 3104-2-00-01-00-00-080 POST, MILL MAX
L2 DO1813P-181MLD SM INDUCTOR, COILCRAFT 0.18µH
Z4 CMZ5920B ZENER, SMA, CENTRAL 6.2V
NOTE: The total load of the dual outputs should be limited below 10W maximum.
18
LM5072 Evaluation Board Bill of Materials SNVA154AMarch 2006Revised May 2013
Submit Documentation Feedback
Copyright © 2006–2013, Texas Instruments Incorporated
IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other
changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest
issue. Buyers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All semiconductor products (also referred to herein as “components”) are sold subject to TI’s terms and conditions of sale
supplied at the time of order acknowledgment.
TI warrants performance of its components to the specifications applicable at the time of sale, in accordance with the warranty in TI’s terms
and conditions of sale of semiconductor products. Testing and other quality control techniques are used to the extent TI deems necessary
to support this warranty. Except where mandated by applicable law, testing of all parameters of each component is not necessarily
performed.
TI assumes no liability for applications assistance or the design of Buyers’ products. Buyers are responsible for their products and
applications using TI components. To minimize the risks associated with Buyers’ products and applications, Buyers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any patent right, copyright, mask work right, or
other intellectual property right relating to any combination, machine, or process in which TI components or services are used. Information
published by TI regarding third-party products or services does not constitute a license to use such products or services or a warranty or
endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the
third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of significant portions of TI information in TI data books or data sheets is permissible only if reproduction is without alteration
and is accompanied by all associated warranties, conditions, limitations, and notices. TI is not responsible or liable for such altered
documentation. Information of third parties may be subject to additional restrictions.
Resale of TI components or services with statements different from or beyond the parameters stated by TI for that component or service
voids all express and any implied warranties for the associated TI component or service and is an unfair and deceptive business practice.
TI is not responsible or liable for any such statements.
Buyer acknowledges and agrees that it is solely responsible for compliance with all legal, regulatory and safety-related requirements
concerning its products, and any use of TI components in its applications, notwithstanding any applications-related information or support
that may be provided by TI. Buyer represents and agrees that it has all the necessary expertise to create and implement safeguards which
anticipate dangerous consequences of failures, monitor failures and their consequences, lessen the likelihood of failures that might cause
harm and take appropriate remedial actions. Buyer will fully indemnify TI and its representatives against any damages arising out of the use
of any TI components in safety-critical applications.
In some cases, TI components may be promoted specifically to facilitate safety-related applications. With such components, TI’s goal is to
help enable customers to design and create their own end-product solutions that meet applicable functional safety standards and
requirements. Nonetheless, such components are subject to these terms.
No TI components are authorized for use in FDA Class III (or similar life-critical medical equipment) unless authorized officers of the parties
have executed a special agreement specifically governing such use.
Only those TI components which TI has specifically designated as military grade or “enhanced plastic” are designed and intended for use in
military/aerospace applications or environments. Buyer acknowledges and agrees that any military or aerospace use of TI components
which have not been so designated is solely at the Buyer's risk, and that Buyer is solely responsible for compliance with all legal and
regulatory requirements in connection with such use.
TI has specifically designated certain components as meeting ISO/TS16949 requirements, mainly for automotive use. In any case of use of
non-designated products, TI will not be responsible for any failure to meet ISO/TS16949.
Products Applications
Audio www.ti.com/audio Automotive and Transportation www.ti.com/automotive
Amplifiers amplifier.ti.com Communications and Telecom www.ti.com/communications
Data Converters dataconverter.ti.com Computers and Peripherals www.ti.com/computers
DLP® Products www.dlp.com Consumer Electronics www.ti.com/consumer-apps
DSP dsp.ti.com Energy and Lighting www.ti.com/energy
Clocks and Timers www.ti.com/clocks Industrial www.ti.com/industrial
Interface interface.ti.com Medical www.ti.com/medical
Logic logic.ti.com Security www.ti.com/security
Power Mgmt power.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com
OMAP Applications Processors www.ti.com/omap TI E2E Community e2e.ti.com
Wireless Connectivity www.ti.com/wirelessconnectivity
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2013, Texas Instruments Incorporated
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19

Texas Instruments AN-1455 LM5072 Evaluation Board (Rev. A) User guide

Category
Voltage regulators
Type
User guide

Texas Instruments AN-1455 LM5072 Evaluation Board (Rev. A) is a low-cost, fully IEEE 802.3af compliant Power over Ethernet (PoE) power supply, capable of operating with both PoE and auxiliary (AUX) power sources. It features the LM5072 PoE Powered Device (PD) interface and controller integrated circuit (IC) configured in the versatile flyback topology. The evaluation board has a single isolated 3.3V output, and can support dual isolated 5V and 3.3V outputs or non-isolated outputs.

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI
