Instruction manual
V1
Thanks for choosing our V83 voice recorder pen!
In order for you to become familiar with the
operation of this machine as soon as possible,
we are equipped with a detailed user manual,
from which you can obtain product introduction
knowledge, usage, system settings and safety
precautions. Before you use this product, please
be sure to read all the materials provided with it
carefully, which will help you use this product
better.
aftersale service: [email protected]
1
When writing this manual, we are very careful
and rigorous, and believe that the information
provided in this manual is correct and reliable. If
there are omissions, please bear with me and
warmly welcome your corrections. If you find any
problems during the use of the product, please
contact us(email: [email protected]) in
time, thank you for your cooperation!
aftersale service: [email protected]
Package Content
Main unit
A USB Cable 4 Pen Refills
One
instruction
manual
One Earphone
2
aftersale service: [email protected]
Basic Feature of this pen recorder
Omni-directional microphone recording, using
professional recording DSP chip, built-in digital
noise reduction technology;
Exquisite pen design, recording&writing
two-in-one design;
All-metal stainless steel material, CNC
processing, paint process design, excellent
touch feeling, strong and durable;
Recording time setting function (time stamp),
suitable for learning and writing, and supports
MP3 music playback;
USB charging/headphone two-in-one interface
design, headphone socket automatic
identification technology;
Recording files can be deleted on this machine
independently;
Lossless WAV recording format, PCM
high-quality recording up to 192Kbps;
Intelligent battery detection, automatically save
recording files before the battery runs out;
3
This product includes the following hosts and
accessories.
Warning: Failure to follow these safety
instructions may result in injury and danger!
1. main machine 1pc
aftersale service: [email protected]
2. user manual 1pc
3. headphone 1pc
4. USB Cable 1pc
5. Refills 4pcs
Product safety information
Attachment
Note: If the above accessories are changed,
please refer to the actual product in the box.
Do not drop or hit the machine violently,
otherwise it will cause serious damage or
malfunction.
Do not open or disassemble the machine,
there are no parts that require maintenance.
If you do not use it for a long time, please
charge and discharge the product every 3
months.
This product is not suitable for use in humid
and high temperature environments. Do not
put this product in water or any liquid, do not
expose this product to sunlight, and do not put
this product in a fire or a waste bin. The
battery will exploded and caught fire.
5
1. Turn on: the red and blue lights keeps on;
3. Recording: the red light flashes;
4. Play: the blue light keeps on;
2. Turn off: the red light and blue light flash at the
same time then go out;
5. Low battery: the red light and blue light flash
at the same time then power off;
6. Charging: the red light keeps on when
charging, red light go off when fully charged.
aftersale service: [email protected]
1. Power On & Recording
Indicator light description
Function Description
Previous/Volume +
Rotate the pen
cap to the right to
start recording
Red light and
blue light flash at
the same time
means recording
started
1
1
Pause/Play
2
Next/Volume -
3
3
2
6
aftersale service: [email protected]
The red indicator flashes when the headset is
not plugged in after power on, it means
recording is in progress, and the recording file
is named REC0001.WAV (Note: The red light
flashes 10 times and then keeps on in the
recording state, indicating that the memory is
full, and supports up to 9999 recording files)
When playing with headphones, press the line
control “pause” button to enter the pause
status, press the "+" key twice to enter the
delete status; press the "+" key twice again to
delete the current file, and press the "+" key
three times to delete All files. (In the delete
mode, the red and blue lights keeps on, the red
and blue lights are off during the deletion
process, and the blue lights flash quickly then
go off after the deletion is completed) (Note:
Power Off& Save recordings
2. Built-in microphone recording
3. Delete Recording Files
Rotate the pen
cap to the left to
start recording
When saving, the
red and blue light
flash at the same
time then shut
down automatically
7
aftersale service: [email protected]
You cannot restore it after deletion. Please pay
attention to the backup the recording files.
During the process of deleting files, the bigger
files you need to delete, the longer it will take;
when all files are deleted, after inserting the
playback headset, the red light will be on for
about 5 seconds. The blue light then stays on
for 3 seconds, then the blue light flashes and
the light goes out.)
Insert the earphone and turn it to the right to
start the recording and play. When you need to
pause, short press the line control pause
button, and it will automatically shut down if
there is no operation for 5 minutes in the pause
state; unplug the earphone during the pause
and turn it off and automatically enter the
recording state.
In the status of playing with headphones, long
press the "+" button to increase the volume,
and long press the "-" button to decrease the
volume.
4. Play Recordings
5. Volume Adjustment
In the status of playing with headphones, short
press the "+" button for the next song, and
short press the "-" button for the previous song.
6. Previous/Next
8
aftersale service: [email protected]
When paused, double-click the previous
button(-), MP3 play/recording will switch; (the
blue light keeps on when switching.)
7. How to switch music file/recording file?
Connect the recorder to the computer with
the included cable and charge it. When the
red light goes out,indicates that the recorder
is fully charged (2-3 hours). Next, remove
the recorder from the computer
How to charge the voice recorder
1Twist the
pen body
RECORD
2) connect to PC via
supplied USB cable.
You may also connect
the enclosed cable
with our voice
recorder and other
USB socket for
charging (USB wall
charger, or USB
charge adapter)
RECORD
9
aftersale service: [email protected]
1Please connect to a PC and set the correct
time first when using for the first time. (Note: The
Set-Time tool is only available for Windows PCs.
2Connect the device to a computer with the
included USB cable. Then open the removable
disk, find the “Set-Time” application and
double-click on it. Time-setting is complete when
the following message appears.
How to set time
success on setting device time 2020-12-27 15:03:33!
How to connect to computer
1Connect the pen to
computer via usb
cable,when connected
Successfully,you will
see the connection icon
After we successfully
connect to a computer,
we may delete, or
transfer files in and
out from the recorder
like normal flash drive.
2A removable disk named
“V83 (D:)” will be shown in file.
10
aftersale service: [email protected]
Format V83 Drive on Computer Directly
How to Play Recordings on PC or MAC
1. For Mac users, please download the free VLC Media
Player and play the recording.
(Website: http://www.videolan.org/)
2.For Windows users, please download free VLC Media
Player or select "Windows Media Player" to play
After successfully
connecting the recorder
to your computer, right
click on the removable
e disk, “V83 (D:)”,
click ‘Format’,
and confirm format it.
Notice：All data will be
erased utterly after
formatting the device
, so please backup before
formatting.
Failed Connecting to a computer
Here are some suggestions for fixing this problem:
A.Do not swing the
Micro-USB cable when
connecting to a computer
in case of unstable
connection
B.Sometimes failed connection
is due to a broken Micro-USB
cable or a loose USB socket
Contact seller for a new cableor
connect to another USB socket,
or simply reboot
your computerIf the issue still
exists after all the actions
above,please contact us ,we will
be always here to assist you.
V83
11
aftersale service: [email protected]
Product specifications
Item name Voice Recorder
Item Model V83
charging time About 2-3 hours
Material High quality alloy
Charge input 3.7V 110mAh
Microphone Built-in microphone:
Omnidirectional microphone
Support audio WAV32Kbps 192Kbps
Signal / noise
ratio(S / N) ≥70dB
memory 8G / 16G / 32G three types (based
on the actual ordered product)
Continuous
recording storage
memory
8GB can record for 18 hours
16GB can record for 36 hours
32GB can record for 72 hours
(Based on the actual order product
Playback format MP332Kbps 384Kbps
WMA: 32Kbps192Kbps
Transferinterface 8GB6 hours 16GB12 hours
32GB: 24 hours
Recording format WAV
Headphone output two-channel output
Headphone output 48KHz
Supporte dinterfaces WINDOWS XP
VISTA/WINDOWS 10
Play time About 5 hours
Product weight 40 grams
(Please refer to the real item.)
Product size 12*12*145MM
Connectionmethod USB 2.0
Recording sampling rate FAT32
File system -540
Operatingtemperature 3.5MM Micro-USB Cable
Recording sound
quality 192Kbps
aftersale service: [email protected]
12
Frequently Asked Questions
questions 1) Can I delete a recording from my computer
answer Yes, once successfully connected the device to
computer, the removable drive named "L80A" will
be found and all recordings will be saved in a folder
named "RECORD" on the drive. Right click on the
file you want to delete and click "Delete"
questions
questions
2Can't find the recording on the recorder?
3Memory is full
answer
answer
answer
This is mainly because the file was not saved
properly or you cannot connect to your computer to
find the recording.
1. The recorded file was not saved properly: Press
the top button to start recording and save the
recording
2. Connect the pen to the computer, find the
removable disk, click the entire disk and select
"Format"
Due the audio would cause background noise,so
do not record near computers, fans, air
conditioners, or sound bars
When the memory is full, you can back up all
recording files to your computer and format the
recorder.We will periodically update the e-Book
based on customer feedback. If you have any
problems, please feel free to contact us.
I will help you. Thank you for your support
-
1
-
2
-
3
-
4
-
5
-
6
-
7
-
8
-
9
-
10
-
11
-
12
-
13
Ask a question and I''ll find the answer in the document
Finding information in a document is now easier with AI
Other documents
-
Zetronix Pico User manual
-
Spycentre Security 9048 1080P Flash Drive Micro USB Spy Camera User manual
-
SpyCentre 6677 USB Audio Recorder User manual
-
Spycentre Security 6677 Quick start guide
-
Spycentre Security 6817 Quick start guide
-
Spycentre Security 1758-1 Quick start guide
-
Mini Gadgets DV720P User manual
-
Advantech DLT-V83 User manual
-
Kmart 42901938 User manual
-
SpyCentre 6810 1080P Hidden Button Camera User manual
