Operating Instructions - Hardware Guide
Personal Computer
VPCS11 Series
2
nN
Contents
Before Use.......................................................................... 4
Finding More about Your VAIO Computer .................... 5
Ergonomic Considerations ............................................ 7
Getting Started.................................................................... 9
Locating Controls and Ports........................................ 10
About the Indicator Lights ........................................... 15
Connecting a Power Source ....................................... 16
Using the Battery Pack................................................ 18
Shutting Down Your Computer Safely ........................ 25
Using the Power Saving Modes .................................. 26
Updating Your Computer ............................................ 29
Using Your VAIO Computer.............................................. 30
Using the Keyboard..................................................... 31
Using the Touch Pad................................................... 34
Using Special-function Buttons ................................... 35
Using the Built-in Camera ........................................... 36
Using the Optical Disc Drive ....................................... 37
Using "Memory Stick".................................................. 45
Using Other Modules / Memory Cards........................ 51
Using the Internet........................................................ 58
Using the Network (LAN) ............................................ 59
Using the Wireless LAN .............................................. 60
Using the Bluetooth Function ......................................65
Using Fingerprint Authentication .................................71
Using Peripheral Devices..................................................78
Connecting a Docking Station .....................................79
Connecting External Speakers or Headphones ..........87
Connecting an External Display ..................................88
Selecting Display Modes .............................................93
Using the Multiple Monitors Function ..........................94
Connecting an External Microphone ...........................96
Connecting a USB Device ...........................................97
Connecting an i.LINK Device.......................................99
Customizing Your VAIO Computer..................................101
Setting the Password.................................................102
Using Intel(R) VT .......................................................113
Using the VAIO Control Center .................................114
Using the VAIO Power Management.........................115
Protecting the Hard Disk............................................116
Upgrading Your VAIO Computer.....................................117
Adding and Removing Memory .................................118
3
nN
Precautions..................................................................... 124
Safety Information ..................................................... 125
Care and Maintenance Information........................... 128
Handling Your Computer........................................... 129
Handling the LCD Screen ......................................... 131
Using the Power Source ........................................... 132
Handling the Built-in Camera .................................... 133
Handling Discs .......................................................... 134
Using the Battery Pack.............................................. 135
Handling "Memory Stick"........................................... 136
Handling the Built-in Storage Device ........................ 137
Using Fingerprint Authentication ............................... 138
Troubleshooting .............................................................. 139
Computer Operations................................................ 141
System Update / Security.......................................... 147
Recovery ................................................................... 149
Battery Pack.............................................................. 151
Built-in Camera ......................................................... 153
Networking (LAN/Wireless LAN) ............................... 155
Bluetooth Technology ............................................... 159
Optical Discs ............................................................. 163
Display ...................................................................... 167
Printing ...................................................................... 171
Microphone ............................................................... 172
Speakers ...................................................................173
Touch Pad .................................................................175
Keyboard ...................................................................176
Floppy Disks ..............................................................177
Audio/Video ...............................................................178
"Memory Stick" ..........................................................180
Peripherals ................................................................181
Docking Station .........................................................182
Trademarks .....................................................................183
Notice ..............................................................................185
4
nN
Before Use >
Before Use
Congratulations on your purchase of this Sony VAIO
®
computer and welcome to the on-screen Hardware Guide. Sony has
combined leading-edge technology in audio, video, computing, and communications to provide you with a state-of-the-art
computing experience.
!
External views illustrated in this manual may look slightly different from those of your computer.
How to find specifications
Some features, options, and supplied items may not be available on your computer.
To find out about the configuration of your computer, see the Specifications (supplied with your computer).
5
nN
Before Use >
Finding More about Your VAIO Computer
Finding More about Your VAIO Computer
This section provides support information about your VAIO computer.
1. Printed Documentation
Quick Start Guide — An overview of components connection, set-up information, etc.
Specifications — The hardware configurations of your VAIO computer.
Recovery, Backup and Troubleshooting Guide
Safety Regulations
2. On-screen Documentation
VAIO Manual — General information and technical assistance for your VAIO computer.
To access VAIO Manual, double-click VAIO Manual on the desktop.
Windows Help and Support — A comprehensive resource for practical advice, tutorials, and demonstrations to help you
learn to use your computer.
To access Windows Help and Support, click Start and Help and Support, or press and hold the Microsoft Windows
key and press the F1 key.
6
nN
Before Use >
Finding More about Your VAIO Computer
3. Support Web Sites
Sony online support web site
The Sony online support web site provides instant access to information on commonly encountered problems:
http://www.sony-asia.com/support/vaio/onlinesupport
Online registration
You can register your computer online at the following URL:
http://www.sony-asia.com/support/vaio/registration
Contact information
You can find how to contact us at the following URL:
http://www.sony-asia.com/support/vaio/contactus
Before contacting VAIO Helpdesk by telephone, try to solve the problem by reading the supplied documentation and visiting
other Sony web sites.
For other Sony products, visit the web site at http://www.sony.net
.
For available optional accessories, visit the following web sites:
http://vaio-online.sony.com/
(English)
http://vaio-online.sony.co.kr/
(Korean)
http://www.sonystyle.com.tw/vaio/
(Traditional Chinese)
7
nN
Before Use >
Ergonomic Considerations
Ergonomic Considerations
You will be using your computer as a portable device in a variety of environments. Whenever possible, you should attempt
to take account of the following ergonomic considerations for both stationary and portable environments:
Position of your computer – Place the computer directly in front of you. Keep your forearms horizontal, with your wrists
in a neutral, comfortable position while using the keyboard or the pointing device. Let your upper arms hang naturally at
your sides. Take frequent breaks while using your computer. Excessive use of the computer may strain eyes, muscles, or
tendons.
Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet are flat on the
floor. A footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning
far backwards.
8
nN
Before Use >
Ergonomic Considerations
Viewing angle of the computer display – Use the display tilting feature to find the best position. You can reduce eye
strain and muscle fatigue by adjusting the tilt of the display to the proper position. Adjust the brightness level of the display
as well.
Lighting – Choose a location where windows and lights do not cause glare and reflection on the display. Use indirect
lighting to avoid bright spots on the display. Proper lighting adds to your comfort and work efficiency.
Positioning an external display – When using an external display, set the display at a comfortable viewing distance.
Make sure the display screen is at or slightly below eye level when you are sitting in front of the monitor.
9
nN
Getting Started >
Getting Started
This section describes how to get started using your VAIO computer.
Locating Controls and Ports (page 10)
About the Indicator Lights (page 15)
Connecting a Power Source (page 16)
Using the Battery Pack (page 18)
Shutting Down Your Computer Safely (page 25)
Using the Power Saving Modes (page 26)
Updating Your Computer (page 29)
10
nN
Getting Started >
Locating Controls and Ports
Locating Controls and Ports
Take a moment to identify the controls and ports shown on the following pages.
!
The appearance of your computer may be different from those illustrated in this manual due to variations in specifications. It may also vary in some
countries or regions.
Front
A Built-in MOTION EYE camera (page 36)
B Built-in MOTION EYE camera indicator (page 15)
C LCD screen (page 131)
D VAIO button (page 35)
E ASSIST button (page 35)
F Ambient light sensor (page 33), (page 170)
Measures ambient light intensity for automatically adjusting the
LCD brightness to an optimum level.
G Built-in speakers (stereo)
H Built-in microphone (monaural)
I Keyboard (page 31)
J Touch pad (page 34)
K Right button(page 34)
L Fingerprint sensor
*
(page 71)
M Left button (page 34)
* On selected models only.
11
nN
Getting Started >
Locating Controls and Ports
A Num lock indicator (page 15)
B Caps lock indicator (page 15)
C Scroll lock indicator (page 15)
D SD memory card slot (page 54)
E Media Access indicator (page 15)
F "Memory Stick Duo" slot
*
(page 45)
G WIRELESS indicator (page 15)
H Charge indicator (page 15)
I Disc drive indicator (page 15)
J WIRELESS switch (page 60), (page 65)
K Headphones jack (page 87)
L Microphone jack (page 96)
M Drive eject button (page 35), (page 37)
* Your computer supports only Duo-size "Memory Stick".
12
nN
Getting Started >
Locating Controls and Ports
Right
A Optical disc drive (page 37)
B Manual eject hole (page 163)
C ExpressCard/34 slot (page 51)
D USB ports
*
(page 97)
E Network (LAN) port (page 59)
F Power button/Power indicator (page 15)
* Compliant with the USB 2.0 standard and support high-/full-/low- speeds.
13
nN
Getting Started >
Locating Controls and Ports
Left
A DC IN port (page 16)
B Air vent
C Security slot
D HDMI output port
*1
(page 91)
E Monitor port
*2
(page 88)
F USB port
*3
(page 97)
G i.LINK 4-pin (S400) port (page 99)
*1
On models with the NVIDIA video controller, there may be no sound from an
output device connected to the HDMI output port for the first few seconds
after playback starts. This is not a malfunction.
*2
Not functional when your computer is attached to the docking station.
*3
Compliant with the USB 2.0 standard and supports high-/full-/low- speeds.
14
nN
Getting Started >
Locating Controls and Ports
Back/Bottom
A Air vents
B Battery connector (page 18)
C Docking station connector
*
(page 81)
D Memory module compartment cover (page 118)
* On selected models only.
15
nN
Getting Started >
About the Indicator Lights
About the Indicator Lights
Your computer is equipped with the following indicator lights:
Indicator Functions
Power 1 Illuminates in green while the computer is on, blinks slowly in orange while the computer is in Sleep mode, and
turns off when the computer is turned off or enters Hibernate mode.
Charge
Illuminates while the battery pack is charging. See Charging the Battery Pack (page 21) for more information.
Media Access Illuminates while data access to a memory card, such as "Memory Stick" and an SD memory card, is in
progress. (Do not place the computer into Sleep mode or turn it off while this indicator light is lit.) When the
indicator light is unlit, the memory card is not in use.
Built-in MOTION EYE camera Illuminates while the built-in camera is in use.
Disc drive
Illuminates while data access to the built-in storage device or the optical disc drive is in progress. Do not place
the computer into Sleep mode or turn it off while this indicator light is lit.
Num lock
Press the Num Lk key to activate the numeric keypad. Press it a second time to deactivate the numeric keypad.
The numeric keypad is not active when the indicator light is unlit.
Caps lock
Press the Caps Lock key to type letters in uppercase. Letters appear in lowercase if you press the Shift key
while the indicator light is lit. Press the key a second time to turn off the indicator light. Normal typing resumes
when the Caps lock indicator light is turned off.
Scroll lock
Press the Fn+Scr Lk keys to change how you scroll the display. Normal scrolling resumes when the Scroll lock
indicator light is turned off. The Scr Lk key functions differently depending on the program you are using and
does not work with all programs.
WIRELESS Illuminates while one or more wireless options are enabled.
16
nN
Getting Started >
Connecting a Power Source
Connecting a Power Source
You can use either an AC adapter or a rechargeable battery pack for supplying power to your computer.
Using the AC Adapter
While your computer is directly connected to an AC power source and has a battery pack installed, it uses power from the
AC outlet.
Use only the supplied AC adapter for your computer.
To use the AC adapter
1 Plug one end of the power cord (1) into the AC adapter (3).
2 Plug the other end of the power cord into an AC outlet (2).
3 Plug the cable from the AC adapter (3) into the DC IN port (4) on the computer or on the optional docking station
*
.
* Available only for models with a docking station connector. See the specifications to find out whether your model has the docking station connector.
!
The shape of the DC In plug varies depending on the AC adapter.
17
nN
Getting Started >
Connecting a Power Source
To disconnect your computer completely from an AC power source, unplug the AC adapter from the AC outlet.
Make sure that the AC outlet is easily accessible.
If you do not intend to use your computer for an extended period of time, place the computer into Hibernate mode. See Using Hibernate Mode (page
28).
18
nN
Getting Started >
Using the Battery Pack
Using the Battery Pack
The battery pack supplied with your computer is not fully charged at the time of delivery.
Installing/Removing the Battery Pack
To install the battery pack
1 Turn off the computer and close the LCD screen lid.
2 Slide the battery LOCK switch (1) inward.
19
nN
Getting Started >
Using the Battery Pack
3 Slide the battery pack diagonally into the battery compartment until the projection (2) on either side of the battery
compartment fits into the U-shaped cut (3) on either side of the battery pack.
4 Push the battery pack down into the compartment until it clicks into place.
5 Slide the battery LOCK switch outward to secure the battery pack on the computer.
20
nN
Getting Started >
Using the Battery Pack
To remove the battery pack
!
You may lose data if you remove the battery pack while your computer is on and not connected to the AC adapter or if you remove the battery pack
while the computer is in Sleep mode.
1 Turn off the computer and close the LCD screen lid.
2 Slide the battery LOCK switch (1) inward.
3 Slide and hold the battery RELEASE latch (2) inward, put your fingertip underneath the tab (3) on the battery pack, and
lift the battery pack in the direction of the arrow, and then slide it away from the computer.
!
For your safety, it is highly recommended that you use genuine Sony rechargeable battery packs and AC adapters that meet the quality assurance
standards and supplied by Sony for your VAIO computer. Some VAIO computers may operate only with genuine Sony battery packs.
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81
  • Page 82 82
  • Page 83 83
  • Page 84 84
  • Page 85 85
  • Page 86 86
  • Page 87 87
  • Page 88 88
  • Page 89 89
  • Page 90 90
  • Page 91 91
  • Page 92 92
  • Page 93 93
  • Page 94 94
  • Page 95 95
  • Page 96 96
  • Page 97 97
  • Page 98 98
  • Page 99 99
  • Page 100 100
  • Page 101 101
  • Page 102 102
  • Page 103 103
  • Page 104 104
  • Page 105 105
  • Page 106 106
  • Page 107 107
  • Page 108 108
  • Page 109 109
  • Page 110 110
  • Page 111 111
  • Page 112 112
  • Page 113 113
  • Page 114 114
  • Page 115 115
  • Page 116 116
  • Page 117 117
  • Page 118 118
  • Page 119 119
  • Page 120 120
  • Page 121 121
  • Page 122 122
  • Page 123 123
  • Page 124 124
  • Page 125 125
  • Page 126 126
  • Page 127 127
  • Page 128 128
  • Page 129 129
  • Page 130 130
  • Page 131 131
  • Page 132 132
  • Page 133 133
  • Page 134 134
  • Page 135 135
  • Page 136 136
  • Page 137 137
  • Page 138 138
  • Page 139 139
  • Page 140 140
  • Page 141 141
  • Page 142 142
  • Page 143 143
  • Page 144 144
  • Page 145 145
  • Page 146 146
  • Page 147 147
  • Page 148 148
  • Page 149 149
  • Page 150 150
  • Page 151 151
  • Page 152 152
  • Page 153 153
  • Page 154 154
  • Page 155 155
  • Page 156 156
  • Page 157 157
  • Page 158 158
  • Page 159 159
  • Page 160 160
  • Page 161 161
  • Page 162 162
  • Page 163 163
  • Page 164 164
  • Page 165 165
  • Page 166 166
  • Page 167 167
  • Page 168 168
  • Page 169 169
  • Page 170 170
  • Page 171 171
  • Page 172 172
  • Page 173 173
  • Page 174 174
  • Page 175 175
  • Page 176 176
  • Page 177 177
  • Page 178 178
  • Page 179 179
  • Page 180 180
  • Page 181 181
  • Page 182 182
  • Page 183 183
  • Page 184 184
  • Page 185 185
  • Page 186 186

Sony VPCS117GH User guide

Category
Notebooks
Type
User guide

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI
