Lenses / Lens accessories

ZVL-LM35FC24M

Article number: 11700793

Overview

■

Kowa lens

■

35 mm

■

F 1,8-16

■

format 1,1"

■

M.O.D. 0,2 m

■

C-mount

Technical data

General data

Manufacturer Kowa

Mechanical data

Lens mount C-mount

Dimensions 45 mm × 71,6 mm

Max. outer diameter 45 mm (without knurled screws)

55 mm (with knurled screws)

Max. length (excl. thread) 66 mm

Weight ≤ 205 g

Filter thread M 40,5 × 0,5

Lens data

Lens resolution 24 MP

Focal length 35 mm

Lens data

Focal range ≥ 25 mm … < 50 mm

Format 1,1″

Aperture F1,8-16

Aperture control Manual

M.O.D. 0,2 m

Horizontal angle of view 22,1 °

Vertical angle of view 16,7 °

Diagonal angle of view 27,5 °

At image format 10,6 × 14,1 mm

Environmental conditions

Operating temperature -10 … +50 °C

2021-01-05 The product features and technical data specified do not express or imply any warranty. Technical modifications subject to change.

www.baumer.com Data sheet – ZVL-LM35FC24M Page 1 of 1

/
