SA1355/02
Specifications Product highlights
Flash audio player
1GB*
Date of issue 2007-06-02
Version: 1.0
12 NC: 8670 000 28734
EAN: 87 12581 32729 3
© 2007 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
Picture / Display
• Backlight
• Display screen type: OLED
• Lines of text: 4
• Resolution: 128 x 64 pixels
Sound
• Equaliser customisable
• Equaliser settings: Classic, Dance, Funk, Hip
Hop, Jazz, Rock
• Frequency response: 30-18000 Hz
• Output power: 2 x 5 mW (16 Ohm)
• Signal to noise ratio: > 85dB
Audio Playback
• Compression format: MP3, WAV, Windows
Media™ Audio
• ID3 tag support: Track title and artist name
• MP3 bit rates: 8-320 kbps and VBR
• MP3 sample rates: 8, 11.025, 16, 22.050, 32, 44.1,
48
kHz
• WMA bit rates: 5-192 kbps
• WMA sample rates: 8, 11.025, 16, 22.050, 32,
44.1, 48 kHz
Audio Recording
• Audio file format: WAV
•FM recording
• Record your own voice
Audio capturing
• Built-in microphone: Mono
• Voice recording: ADPCM
Storage Media
• Built-in memory capacity: 1 GB
• Built-in memory type: NAND Flash
• Music memory capacity, MP3: Up to 250 tracks
(128 kbps)*
• Music memory capacity, WMA: Up to 380 tracks
(64 kbps)*
Tuner / Reception / Transmission
• Tuner bands: FM stereo
• Frequency range: 87.5 - 108 MHz
• Number of preset channels: 30
• Auto digital tuning
Connectivity
• Headphone: 3.5 mm
• USB: USB 2.0
Convenience
• Firmware upgradeable
• Function: Keypad lock
Accessories
•CD-ROM
• Headphones: AY3809
• Quick start guide: Printed-
EN,FR,ES,DE,IT,NL,RU
• USB cable: AY3914
• User Guide on CD-ROM: EN, FR, ES, NL, DE,
PO, SV, IT, SU, DA, CS, RU, HU, EL, PL, SL
Software
• Device manager: Firmware Manager
System Requirements
•CD-ROM drive
• Hard disc space: 50 MB
• Internet connection: Preferable
• PC OS: Windows Me, 2000 or XP
• Processor: Pentium II or better
• RAM memory: 64 MB
•Sound card
• USB: Free USB port
•Video card
Dimensions
• Packaging type: Clamshell
• Product dimensions (W x H x D):
31.5
x 80.5 x 15 mm
• Product weight: 0.04 kg
Power
• Battery capacity: 300mAh
• Battery type: LI-Polymer
• Charging time: 4 hr
•
Voice Recording Function
Voice Recording Function converts your player into a
handy dictation machine. Besides playing music or
listening to radio, you can also record notes or
reminders for work or school, record shopping lists and
phone numbers – even song lyrics. By pressing the
recording button and speaking into the built-in
microphone, voice messages are compressed and
stored either in the built-in internal memory or on to the
external memory card. Voice Recording Function gives
you a highly portable voice recorder allowing you to
record anything, anytime and anywhere!
Direct USB
Devices with direct USB can be plugged directly into the
USB port of your PC without the need for any cables.
Your computer will automatically recognise the device
as a removable USB mass storage device (Windows 98
requires additional drivers) allowing you to easily drag
and drop files via Windows Explorer (or Apple Folders)
between your computer and device.
Two-colour OLED display
2-colour OLED display offers colour combination (e.g.
yellow and blue) in a super-bright display and also
allows for animation. This makes for easier reading of
the display, and for fun sharing with friends
Equalizer
Equaliser allows you to select preset modes that
optimise certain frequency bands to enhance specific
music styles. Players with Equaliser, utilise graphic
equalising technology to automatically set the optimum
sound frequency balance for a chosen music style. The
Equaliser allows you to enjoy the optimum sound
depending on the music style.
