Buehler 11-2180 User manual

Type
User manual

This manual is also suitable for

IsoMet
®
1000 Precision Saw
MA112180_33 6/27/2005
Declaration of Conformity
Manufacturer:
BUEHLER, Ltd.
Of:
41 Waukegan Road
Lake Bluff, Illinois 60044
IsoMet
®
1000 Precision Saw
Declares the following product:
To be in accordance with EC Directive(s);
Safety of Machinery: EMC Directive:
89/392/EEC and 91/368/EEC and 93/44/EEC
according to the following standards:
89/336/EEC and 92/231/EEC according to the
following standards:
EN 292 PART 1 1991
EN 292 PART 2 1991
EN 60204 PART 1 1993
EN 50081-2: 1998
Position: Engineering Manager
Name: Boyd Schindler
Signature:
Date: 6/27/2005
THIS MANUAL IS A CUSTOM GENERATED DOCUMENT. IT INCLUDES ALL
REVISIONS RELATIVE TO THIS SPECIFIC BUEHLER ITEM AS OF THE DATE
SHOWN BELOW.
The items covered in this communication including all attachments may be subject to the export laws of the United States
of America, including without limitation the Export Administration Regulations and the Office of Foreign Asset Control
Regulations. The export, re-export or diversion of these items in contravention of these or other applicable regulations is
strictly prohibited.
This information contained in this communication is intended only for the use of the individual or entity to which it is
addressed and may contain information that is privileged, confidential and exempt from disclosure under applicable law.
2
MA112180_33 6/27/2005
OPERATION AND MAINTENANCE
INSTRUCTIONS
BUEHLER
®
IsoMet
®
1000 Precision Saw
3
MA112180_33 6/27/2005
Table of Contents
IsoMet
®
1000 Precision Saw ............................................................................................................5
Warranty ...........................................................................................................................................5
Unpacking.........................................................................................................................................5
Safety Information.............................................................................................................................7
Machine Use and Care ............................................................................................................. 7
Installation.........................................................................................................................................8
Electrical Installation ................................................................................................................. 8
Activating the IsoMet
®
1000 Precision Saw ....................................................................... 9
Blade Installation....................................................................................................................... 9
Gang Sawing .................................................................................................................... 10
Flanges............................................................................................................................. 10
Blade Dressing ................................................................................................................. 10
Lubrication ........................................................................................................................ 11
Operation ........................................................................................................................................12
IsoMet
®
1000 Front Control Panel .......................................................................................... 13
Sample Arm ............................................................................................................................ 14
Loading the Saw ..................................................................................................................... 15
End of Cut Adjustment ............................................................................................................ 16
Cutting a Sample..................................................................................................................... 16
Maintenance ...................................................................................................................................18
Trouble Shooting Chart........................................................................................................... 18
IsoMet
®
1000 Accessories..............................................................................................................19
Chucks .................................................................................................................................... 19
Flanges ................................................................................................................................... 19
Other ....................................................................................................................................... 19
Wafering Blades...................................................................................................................... 20
4
MA112180_33 6/27/2005
IsoMet
®
1000 Precision Saw
The IsoMet
®
1000 Precision Saw offers increased speed, load, and blade size that enables a
wide variety of specimen samples to be cut quickly and with low deformation.
The IsoMet
®
1000 cutting compartment is fully enclosed and can be removed and replaced with
the accessory Table Saw Attachment for sectioning larger samples. The coolant tray can be
easily removed from the front of the machine for fast cleaning and for easy retrieval of cut
samples.
With a 7-inch diamond blade capacity and a wide selection of accessories, the IsoMet
®
1000
Precision Saw offers increased versatility and power for sectioning today’s advance materials.
Warranty
This unit is guaranteed against defective material and workmanship for a period of two (2) years /
2000 hours from the date of receipt by the customer. The warranty is void if inspection shows
evidence of abuse, misuse, unsafe use, or unauthorized repair. This warranty covers all Buehler
costs associated with the replacement of defective materials (e.g., parts, labor, and travel).
If for any reason this unit must be returned to Buehler Ltd. for warranty service, please apply for
prior authorization with shipping instructions. Please include the following information:
Customer Purchase Order Number
Buehler Invoice Number and Date
Serial Number
Reason for return
Unpacking
The IsoMet
®
1000 Precision Saw has been carefully packaged to protect it during transit from the
factory to your location. Carefully unpack and check the contents. If any components are
missing or damaged, save the packing list and materials and advise the carrier and Buehler, Ltd.
of the discrepancy.
Carefully unpack and check that the following items have been received:
11-1184 Bar and Tube Stock Chuck Hex Wrench inch
11-1185 Irregular Specimen Chuck Hex Wrench
3
32
inch
11-1186 Wafering Chuck Hex Wrench
5
32
inch
11-1187 Small Single Saddle Chuck Hex Wrench
5
64
inch
Pint IsoCut
®
Fluid Open End Hex ½ - inch
Series 15LC 6-inch Diamond Wafering Blade
2 3-inch Flanges
WARNING! Equipment Damage. The IsoMet
®
1000 Precision Saw weighs 75 lbs
(34 kg) and two persons are required to safely lift the unit from the shipping
carton.
5
MA112180_33 6/27/2005
The IsoMet
®
1000 Precision Saw is bolted to a wood base for protection during shipping. Open
areas are provided at the corners of the base for ease of lifting. Lift IsoMet
®
1000 Precision Saw
out of the carton and position it on a table so it overhangs on the edge. Remove the bolts
securing the IsoMet
®
1000 Precision Saw to the wood base.
Note: Do not remove the four bolts securing the motor to the IsoMet
®
1000 housing
(see Figure 1).
Securing Bolt (2)
Securing Bolt (1)
4 Bolts securing motor to
IsoMet
®
1000 housing.
Figure 1 IsoMet
®
1000 Wood Base
6
MA112180_33 6/27/2005
Safety Information
The IsoMet
®
1000 Precision Saw is designed to section metallurgical and petrographic materials
with recommended cutting wheels.
For safe installation and operation of this equipment, carefully read and understand the contents
of this manual. Improper operation, handling, or maintenance can result in equipment damage
and personal injury.
The IsoMet
®
1000 Precision Saw is designed for use in dry, indoor laboratory and workshop
environments away from strong electromagnetic fields and with normal temperature ranges
(41° F to 104° F / 5° C to 40° C) and non-condensing humidity ranges (30-90%).
Machine Use and Care
Dress properly. Do not wear loose clothing or jewelry and contain long hair. They can
be caught in moving parts and can result in severe personal injury. Protective equipment
should be worn to handle samples, which may be sharp or hot.
Do not operate machine in explosive atmospheres, such as in the presence of
flammable liquids, gases, or dust. Sparks may ignite the dust or fumes.
Always use safety glasses. Flying debris and liquids can cause severe eye injury.
Maintain the IsoMet
®
1000 Precision Saw with care. Properly maintained machines
are less likely to bind and are easier to control. Any alteration or modification is a misuse
and may result in a dangerous situation.
Maintain machine guards and interlocks. Do not attempt to enter the cutting bay when
the IsoMet
®
1000 Precision Saw is in use.
Only qualified repair personnel must perform machine service. Service or
maintenance performed by unqualified personnel could result in a risk of injury.
Replace damaged or defective parts immediately and use only identical
replacement parts. Use of unauthorized parts or failure to follow maintenance
instructions may create a risk of electrical shock or injury.
Check for misalignment or binding of moving parts, breakage of parts, and any
other condition that may affect the machine operation. If damaged, have the
machine serviced before using. Poorly maintained machines cause many accidents.
Do not abuse the power cord. Never use the cord to cart the machine or pull the
plug from an outlet. Keep the cord away from heat, oil, sharp edges, or moving
parts. Replace damage cords immediately. Damage cords increase the risk of
electrical shock.
Use of extension cords is not recommended for Buehler machines and equipment.
Machine coolant can present a biological hazard if not maintained correctly.
Change the coolant regularly in accordance with local regulations and safety practices.
Coolant must be suitable for grinding cut-off use and protect against electrolytic
action between sample material and machine.
7
MA112180_33 6/27/2005
Installation
CAUTION! Equipment Damage. Follow all locally approved procedures and safety
practices when lifting and installing this machine. Improper lifting can result in machine
damage.
Select a location for your IsoMet
®
1000 Precision Saw that provides an adequate working space
and a power source.
The IsoMet
®
1000 Precision Saw is 15 ½ inches (394 mm) wide, 21 inches (533 mm) deep, and
12 inches (305 mm) high. Placement of the IsoMet
®
1000 Precision Saw should be on a sturdy,
level bench. Buehler TECH-MET
®
tables are highly recommended.
Allow 6 inches (150 mm) of space at the back of the IsoMet
®
1000 Precision Saw for raising the
hood. Make sure to leave sufficient space on both sides for sectioning long bars.
Electrical Installation
WARNING! Electrical Shock Hazard. Do not change the power plug in any
way. Buehler machines are equipped with a polarized plug (one blade is wider
than the other) and a ground pin. Polarized plugs reduce the risk of electrical
shock. This plug will fit in a polarized outlet only one way.
Check that Specification Plate values for voltage, current, and power consumption are
compatible with the intended electrical supply before installation.
The IsoMet
®
1000 Precision Saw can be plugged into an outlet rated for the voltage and
frequency listed on the Specification Plate.
WARNING! Electrical Shock Hazard. A qualified electrical technician should
perform electrical maintenance.
Disconnect the power supply before making any electrical adjustments.
Capacitors inside the machine may retain a charge even if the machine
is disconnected from the power supply.
Installation of the IsoMet
®
1000 Precision Saw must comply with local
electrical standards or codes of practice.
IsoMet
®
1000 Precision Saw Voltage / Frequency
11-2180 85 – 264 Volts / 50 – 60 Hz
Table 1 IsoMet
®
1000 Electrical Data
8
MA112180_33 6/27/2005
Activating the IsoMet
®
1000 Precision Saw
To activate power to the IsoMet
®
1000 Precision Saw flip the power switch on the back of
the machine to the UP position.
The IsoMet
®
1000 power switch is also a two-pole circuit breaker that will provide
protection for the machine in the event of an overload.
If at any time the Front Control Panel buttons or the motor does not operate, reset the
IsoMet
®
1000 by flipping the power switch to the DOWN position then back to the UP
position.
Blade Installation
1. Remove the thumbscrew, end cap bushing, and outer flange from the arbor shaft
(see Figure 2).
2. Install the blade on the arbor shaft against the inner flange.
3. Slide the outer flange, the end cap bushing, and the thumbscrew on to the arbor
shaft.
4. Hand tightened the thumbscrew to secure the blade.
Inner Flan
g
e
Blade
A
rbor Shaft
Outer Flan
g
e
End Cap Bushin
g
Thumbscrew
Figure 2 Blade Installation
9
MA112180_33 6/27/2005
Gang Sawing
Several blades can be installed to the IsoMet
®
1000 for gang sawing.
1. Install the blades with the appropriate spacers.
2. Slide the outer flange, the end cap bushing, and the thumbscrew on to the arbor
shaft.
3. Hand tightened the thumbscrew to secure the blades.
Flanges
CAUTION! Equipment Damage. Flanges provide support for wafering blades.
Failure to provide adequate flange support can result in curved cuts and
damaged blades.
Always select the maximum flange diameter to correspond with the sample size.
Before re-installing a wafering blade, clean the flanges, end cap bushing, and
thumbscrew. This will help prevent misalignment of the blade and prevent poor quality
cuts.
Blade Dressing
New wafering blades (including the original equipment blade) must be dressed before
making any cuts.
Blade dressing removes built up matrix metal and exposes the abrasive grain to provide
clean, aggressive cutting. New wafering blades should be dressed several times and
older blades should be dressed as required.
Note: When cutting metal, it may be necessary to dress the blade after each cut.
To dress a wafering blade:
1. Position the dressing stick in the dressing chuck.
From the front of the machine, pull the lubricant tank straight out until the blade
makes contact with the back of the tank. The dressing chuck will now be
exposed.
Position the dressing stick as needed.
Close the lubricant tank.
2. Close the hood.
3. Press the SAW button to activate the saw.
4. Rotate the Dressing Stick Feed Control knob clockwise to feed the dressing stick into
the wafering blade (see Figure 3).
10
MA112180_33 6/27/2005
5. Make as many cross cuts through the dressing stick as needed to dress the blade.
Three to five crosscuts usually work well.
Lubricant Tank
Dressing Chuck with a Dressing Stick
Dressing Stick Feed Control Knob
Figure 3 Dressing Chuck inside the Lubricant Tank
WARNING! Personal Injury. Feeding the dressing stick or any specimen
sample into the blade by hand can result in severe personal injury and equipment
damage.
Lubrication
The IsoMet
®
1000 Precision Saw uses the drag principle of lubrication. The lubricant is
carried to the sample on the edge of the rotating blade.
IsoCut
®
Plus Fluid reduces cutting time and produces superior cuts. IsoCut
®
Plus Fluid
is best for most metals and many non-metals. The use of IsoCut
®
Plus Fluid promotes
effective lubrication enables diamond particles to cut cleanly and minimizes loading of the
blade.
Fill the IsoMet
®
1000 lubricant tank with IsoCut
®
Plus Fluid to a level that will
immerse the blade approximately ¼-inch.
Discard the lubricant when becomes contaminated with sludge.
a. Remove the sample tray, wafering blade, and flanges from the arbor shaft.
b. From the front of the machine, pull the lubricant tank straight out.
c. Discard the lubricant in a safe and approved manner.
d. Clean the lubricant tank.
e. Reinstall the lubricant tank.
f. Refill the lubricant tank with fresh, clean lubricant.
g. Reinstall the wafering blade, flanges, and sample tray.
11
MA112180_33 6/27/2005
Operation
Sample Arm
Dressing Stick Feed Arm
End of Cut Adjustment Knob
Counterbalance Weight
Load Weight
Sample Positioning Knob
Lubricant Tank
Figure 4 IsoMet
®
1000 Precision Saw Components
12
MA112180_33 6/27/2005
IsoMet
®
1000 Front Control Panel
ZERO
INCH
MM
CHUCK BLADE
POWER
POSITION
SPEED
IsoMet 1000
PRECISION SAW
BUEHLER
Figure 5 IsoMet
®
1000 Front Control Panel
ZERO
POSITION (ZERO) Resets the blade position to zero. The POSITION LCD will
display 00.0.
INCH
MM
UNITS (MM / INCH) Displays either millimeters or inches as the unit of
measurement in the POSITION LCD.
The default unit of measurement is inches. The indicator light
will light up for the unit of measure selected.
POSITION FIELD Displays the distance of the blade from the set ZERO position.
INCREASE Increases the blade speed in increments of 25 rpms. Press and
hold the INCREASE button for rapid speed selection.
DECREASE Decreases the blade speed in increments of 25 rpms. Press and
hold the DECREASE button for rapid speed selection.
SPEED FIELD Displays the blade speed in rpms. The minimum blade speed is
100 rpms. The maximum blade speed is 950 rpms.
Note: The IsoMet
®
1000 will retain to the last selected speed.
CHUCK
CHUCK Only used with the Rotating Chuck accessory. Activates and
deactivates the Rotating Chuck. The indicator light will light up
when the chuck is activated.
13
MA112180_33 6/27/2005
BLADE
BLADE Activates and deactivates the blade. The indicator light will light
up when the blade is running.
POWER Activates and deactivates power to the IsoMet
®
1000.
Sample Arm
The Sample Arm has three positions to select from (see Figure 6). The position selected
depends on the diameter of the wafering blade (4-inch to 7-inch) and the angle of
engagement between the blade and the sample.
7-in
c
h Di
a
m
e
t
e
r Bl
ade
6
-in
c
h Di
a
m
e
t
e
r Bl
ade
5-inch Diameter Blade
4
-
inch Diameter Blade
3
-in
c
h Fl
a
n
ge
Chuck
Sample Arm
Sample Arm Positioning
Figure 6 Sample Arm Positioning
14
MA112180_33 6/27/2005
Loading the Saw
Counter-balance Weight
Weight Arm
Weight Arm on the ISOMET
®
1000
Sample Positioning
Knob
Load Weight
Figure 7 Weight Arm
1. On the left side of the IsoMet
®
1000 is the Weight Arm. Lift the Weight Arm to the
locked position.
2. Loosen the thumbscrew on the Load Weight.
3. Slide the weight to the zero setting.
4. Select the proper chuck for the application and clamp the sample in the chuck.
To clamp odd or irregular samples, it may be necessary to sandwich metal strips
between the sample and the chuck.
5. Attach the sample loaded chuck to the Sample Arm with the supplied screw (a socket
head cap).
6. Once the chuck is secure, rotate the Sample Positioning knob to move the Sample
Arm to the far left.
7. Lower the Weight Arm so it lays horizontal.
8. Slide the counter-balance weight up or down until a balance is achieved.
9. Tighten the thumbscrew on the counter-balance weight to secure the weight.
If a large chuck or a heavy sample is used, a balance may not be achieved.
If the sample is load sensitive, deduct the unbalanced weight from the Load
Weight setting.
10. Set the Load Weight to the desired load as marked on the Weight Arm.
The Weight Arm is calibrated from zero (0) to 500 grams. 300 grams of
additional weight can be added with the optional weight kit.
Lighter weights are recommended since heavier loads can cause greater surface
damage to the sample.
15
MA112180_33 6/27/2005
End of Cut Adjustment
The End of Cut Adjustment knob is located under the hood on the IsoMet
®
1000 housing
(see Figure 8).
The End of Cut Adjustment knob sets the total travel of the Sample Arm and stops the
blade when the travel is complete. This End of Cut feature can also be used to cut a
sample to a certain depth.
The arm travel can be set to stop the saw either just before a cut is complete or when a
cut is complete. By setting the End of Cut feature to deactivate the saw just before a cut
is complete reduces the weight on the sample and prevents the possible burring or
cleavage of fragile materials near the end of a cut.
An alternative for minimizing burring and to prevent cleavage of fragile materials is to use
a double saddle chuck.
Note: The End of Cut feature must be positioned and set to prevent the sample and/or
chuck from riding on the blade flanges after the cut is complete.
End of Cut Adjustment Knob
Figure 8 IsoMet
®
1000
Cutting a Sample
1. Using the appropriate chuck, load the sample and chuck on to the Sample Arm.
Note: Do not scratch the blade or drop a sample on the wafering blade’s edge.
2. Raise the Sample Arm to adjust the position of the sample.
3. Rotate the Sample Positioning knob to move the sample left or right.
The Front Control Panel will display the numerical movement of the sample.
4. Lower and hold the Sample Arm with the sample just above the wafering blade.
5. Rotate the Sample Positioning knob until the sample touches the side of the wafering
blade.
6. Press the DISPLAY (ZERO) button to reset the POSITION LCD to zero (00.0).
16
MA112180_33 6/27/2005
7. Raise the Sample Arm to the locked position.
8. Press the UNITS button to display millimeters or inches.
9. Advance the sample as required.
10. Close the hood.
11. Press the SAW (RUN/STOP) button to activate the blade.
12. Press the INCREASE or DECREASE buttons to set the blade speed.
Note: Faster speeds (and heavier weights) tend to damage the sample surface.
13. The cut cycle will begin.
14. If the End of Cut Adjustment has been set, the blade will automatically stop when the
cut is complete.
17
MA112180_33 6/27/2005
Maintenance
The IsoMet
®
1000 Precision Saw will continue to perform at optimum levels with proper care,
daily cleaning, and general maintenance.
The protective hood and touch-panel control pad should be cleaned using mild soap and water
applied with a soft cloth. Do not use ammonia-based cleaners, i.e. Windex
®
. Cloudiness and
cracking can occur.
Exterior painted surfaces, including the cutting chamber, should be cleaned with a non-abrasive
household cleaner.
Note: When the IsoMet
is used in a Hot Cell or Glove Box, the inert atmosphere may cause
excessive motor brush wear. Brushes may need to be replaced monthly. This
replacement is not covered under the warranty
Trouble Shooting Chart
Problem Possible Cause Correction
Check the power cord
connection.
The unit is not plugged in.
The IsoMet
®
does not
power on.
The unit is not powered on.
Check the rear power
switch.
Wrong blade for the
material.
Replace with correct blade.
Improper sample fixture
(primary cause).
Use correct sample fixture.
The blade keeps pinching.
Blade may need to be
dressed.
Dress blade.
Check the coolant for
proper mixture.
Improper coolant mixture.
The bed has rust on it.
The hood has been closed
too long with moisture build
up.
Open hood and keep hood
open when not in use.
Check the cable
connection.
Cable is disconnected.
The Rotating Chuck does
not work.
Rotating chuck is not
powered on.
Make certain the Rotating
Chuck is turned on.
Make certain the table is
level.
Table or unit is not level.
Coolant leaks from the
IsoMet
®
.
Coolant level too high.
Check the volume of
cutting fluid.
18
MA112180_33 6/27/2005
IsoMet
®
1000 Precision Saw Accessories
IsoMet
®
1000 Accessories
Catalog No. Description
Chucks
11-1183 Chuck ....................................... Double Saddle Type
11-1184 Chuck ....................................... For Bar and Tube Stock
11-1185 Chuck ....................................... For Irregular Shaped Specimens
11-1186 Chuck ....................................... For Wafers Single Crystals and Thin Sections
11-1187 Chuck ....................................... For Long Samples, Single Saddle Type
11-1188 Chuck ....................................... For Petrographic and Ceramographic Thin Sections
11-1189 Chuck ....................................... For 1-inch or 1 ½-inch Diameter Specimens (Requires
the use of 11-1192 Recessed Flanges)
11-2482 Fastener Chuck ........................ For Longitudinal Sectioning of Fasteners, Tubes, and
Solid Cylinders
11-2489 Specimen Chuck ...................... For 1 ½-inch and 40 mm Mounted Samples
11-2483 Double Saddle Chuck............... 1-inch Diameter Capacity
11-2484 Glass Slide Chuck .................... 27 mm x 46 mm Glass Slide for Thin Sections
11-2488 Glass Slide Chuck.................... 2-inch x 3-inch Glass Slide for Thin Sections
11-2496 Chuck Padding ......................... Applied to Chucks for Holding Brittle or Friable
Specimens
Flanges
11-1191 Flange....................................... 1 ½-inch Diameter, Recessed
11-1192 Flange....................................... 1 -inch Diameter, Recessed
(For use with 11-1188 Chuck and 11-1189 Chuck)
11-2282 Flange....................................... 3-inch Diameter
11-2283 Flange....................................... 4-inch Diameter
11-2284 Flange....................................... 5-inch Diameter
Other
11-1190 Dressing Stick .......................... For Dressing Series 15 and 20 Wafering Blades
11-1290 Dressing Stick .......................... For Dressing Series 5 and 10 Wafering Blades
11-2181 Rotating Chuck Accessory ....... For Holding and Rotating Samples up to
2-inch in Diameter
11-2182 Table Saw Attachment ............. For Hand-Cutting Long or Irregular Specimens
11-2186 Splash Shield ........................... For use with the 11-2182 Table Saw Attachment
11-2183 Accessory Weight Set .............. For Increasing Cutting Load to 800 gm
11-2185 IsoMet
®
1000 Goniometer ........ For Sectioning Crystals
11-2293-016 IsoCut
®
Cutting Fluid ........ 1 Pint (.48 liter)
19
MA112180_33 6/27/2005
IsoMet
®
1000 Precision Saw Accessories
Wafering Blades
Blade Series Diameter and Thickness
3" x 0.006"
(75 x 0.2 mm)
4" x 0.012"
(100 x 0.3 mm)
5" x 0.015"
(125 x 0.4 mm)
6" x 0.020"
(150 x 0.5mm)
7" x 0.025"
(180 x 0.6mm)
30 HC
11-4239** 11-4241**
For use with plastics, polymers, and rubber
20 HC
11-4215* 11-4237
For aggressive general sectioning of ferrous and non-ferrous materials
15 HC
11-4243 11-4244 11-4245 11-4246 11-4247
For routine use, metal matrix composites, PC boards, and thermal spray coatings
20 LC
11-4225* 11-4227
For use with hard/tough materials, structural ceramics, boron carbide, boron nitride, silicon nitride
15 LC
11-4253 11-4254 11-4255 11-4276 11-4277
For use with hard/brittle materials, structural ceramics, electronic substrates, alumina, zirconia,
silicon carbide
10 LC
11-4283 11-4285 11-4287
For use with medium to soft ceramics, electronic packages, GaAs, AIN, and glass fiber reinforced
composites
5 LC
11-4289 11-4295
For use with soft friable ceramics, composites with fine reinforcing media, CaF
2
, MgF
2
, and
carbon composites
ISOCUT
11-4263 11-4264 11-4265 11-4266 11-4267
Wafering Blades: For iron and cobalt based alloys, nickel base super alloys, and lead base alloys
**Alternate Blade Thickness of 0.020" (0.5 mm)
*Alternate Blade Thickness of 0.030" (0.8 mm)
20
MA112180_33 6/27/2005
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37

Buehler 11-2180 User manual

Type
User manual
This manual is also suitable for

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI
