PNY VCGGT7201D3LXPB Datasheet

Category
Graphics cards
Type
Datasheet

PNY VCGGT7201D3LXPB is a graphics card that provides a good balance of performance and affordability. It is powered by the NVIDIA GeForce GT 720 GPU and has 1GB of DDR3 memory. The card has a low profile design and is passively cooled, making it ideal for compact builds or systems with limited airflow.

The VCGGT7201D3LXPB supports DirectX 11 and OpenGL 4.3, and it can output video to up to two monitors simultaneously. The card has a variety of video outputs, including DVI-D, VGA, and HDMI, so you can connect it to a wide range of displays.

PNY VCGGT7201D3LXPB is a graphics card that provides a good balance of performance and affordability. It is powered by the NVIDIA GeForce GT 720 GPU and has 1GB of DDR3 memory. The card has a low profile design and is passively cooled, making it ideal for compact builds or systems with limited airflow.

The VCGGT7201D3LXPB supports DirectX 11 and OpenGL 4.3, and it can output video to up to two monitors simultaneously. The card has a variety of video outputs, including DVI-D, VGA, and HDMI, so you can connect it to a wide range of displays.

Part # Product Name
Frame Buffer
Size
Memory Type
GPU
Cores
Core Speed Boost Speed Memory Speed
Memory
Interface
TDP
PCI-E
Bus Type
SLI
Concurrent
Screen Support
Power Input Size Output Warranty
VCGGTX9804XPB-CG GeForce® GTX 980 XLR8 CG 4GB NVIDIA Reference
4096 MB GDDR5 2048 1126 MHz 1216 MHz 7000 MHz 256-bit 165W 3.0 16x 3-Way 4 2x 6-pin
Dual-Slot
Full Height
DVI-I, HDMI, DisplayPort x 3
1 year
(Lifetime w Registration)
VCGGTX9704XPB GeForce® GTX 970 XLR8 4GB
4096 MB GDDR5 1664 1050 MHz 1178 MHz 7000 MHz 256-bit 145W 3.0 16x 3-Way 4 2x 6-pin
Dual-Slot
Full Height
DVI-I, Mini HDMI, Mini
DisplayPort X 3
1 year
(Lifetime w Registration)
VCGGTX780T3XPB-OC GeForce® GTX 780 Ti XLR8 3GB OverClocked
3072 MB GDDR5 2880 980 MHz 1046 MHz 7000 MHz 384-bit 250W 3.0 16x 3-Way 4 2x 8-pin
Triple-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX780T3XPB-CC-OC GeForce® GTX 780 Ti XLR8 3GB Customized OverClocked
3072 MB GDDR5 2880 980 MHz 1046 MHz 7000 MHz 384-bit 250W 3.0 16x 3-Way 4 2x 8-pin
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX780T3XPB-CC GeForce® GTX 780 Ti XLR8 3GB Customized
3072 MB GDDR5 2880 875 MHz 928 MHz 7000 MHz 384-bit 250W 3.0 16x 3-Way 4 2x 8-pin
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7803XPB-OC GeForce® GTX 780 XLR8 3GB OverClocked
3072 MB GDDR5 2304 1006 MHz 1059 MHz 6208 MHz 384-bit 250W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7803XPB-CC-OC GeForce® GTX 780 XLR8 3GB Customized OverClocked
3072 MB GDDR5 2304 902 MHz 954 MHz 6008 MHz 384-bit 250W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7803XPB-CC GeForce® GTX 780 XLR8 3GB Customized
3072 MB GDDR5 2304 863 MHz 902 MHz 6008 MHz 384-bit 250W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7704XPB-OC2 GeForce® GTX 770 XLR8 4GB OverClocked 2
4096 MB GDDR5 1536 1150 MHz 1202 MHz 7010 MHz 256-bit 230W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7704XPB-OC GeForce® GTX 770 XLR8 4GB OverClocked
4096 MB GDDR5 1536 1059 MHz 1111 MHz 7010 MHz 256-bit 230W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7702XPB-CG GeForce® GTX 770 XLR8 2GB NVIDIA Reference
2048 MB GDDR5 1536 1046 MHz 1085 MHz 7010 MHz 256-bit 230W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7702XPB-OC GeForce® GTX 770 XLR8 2GB OverClocked
2048 MB GDDR5 1536 1150 MHz 1202 MHz 7010 MHz 256-bit 230W 3.0 16x 3-Way 4
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7602XPB-OC GeForce® GTX 760 XLR8 2GB OverClocked
2048 MB GDDR5 1152 1111 MHz 1176 MHz 6208 MHz 256-bit 170W 3.0 16x 3-Way 4 2x 6-pin
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX7602XPB GeForce® GTX 760 XLR8 2GB
2048 MB GDDR5 1152 980 MHz 1033 MHz 6008 MHz 256-bit 170W 3.0 16x 3-Way 4 2x 6-pin
Dual-Slot
Full Height
DVI-I, DVI-D, HDMI,
DisplayPort
1 year
(Lifetime w Registration)
VCGGTX750T2XPB-OC GeForce® GTX 750 Ti XLR8 2GB OverClocked
2048 MB GDDR5 640 1202 MHz 1281 MHz 6008 MHz 128-bit 60W 3.0 16x No 3 PCI-E
Dual-Slot
Full Height
DVI-I, DVI-D, Mini-HDMI
1 year
(Lifetime w Registration)
VCGGTX750T2XPB GeForce® GTX 750 Ti XLR8 2GB
2048 MB GDDR5 640 1020 MHz 1085 MHz 5400 MHz 128-bit 60W 3.0 16x No 3 PCI-E
Dual-Slot
Full Height
DVI-I, DVI-D, Mini-HDMI
1 year
(Lifetime w Registration)
VCGGTX7501XPB GeForce® GTX 750 XLR8 1GB
1024 MB GDDR5 512 1020 MHz 1085 MHz 5000 MHz 128-bit 55W 3.0 16x No 3 PCI-E
Dual-Slot
Full Height
DVI-I, DVI-D, Mini-HDMI
1 year
(Lifetime w Registration)
VCGGT7401D3LXPB GeForce® GT 740 1GB Verto Low Profile
1024 MB DDR3 384 993 MHz 1792 MHz 128-bit 64W 3.0 16x No 3 PCI-E
Single-Slot
Half Height
DVI-D, VGA, HDMI 1 year
(3 Year w registration)
VCGGT7302D3LXPB GeForce® GT 730 2GB Verto Low Profile
2048 MB DDR3 96 700 MHz 1070 MHz 128-bit 48.8W 2.0 16x No 2 PCI-E
Single-Slot
Half Height
DVI-I, VGA, HDMI 1 year
(3 Year w registration)
VCGGT7301D5LXPB GeForce® GT 730 GDDR5 1GB Verto Low Profile
1024 MB GDDR5 384 902 MHz 5000 MHz 64-bit 38W 2.0 8x No 3 PCI-E
Single-Slot
Half Height
DVI-D, VGA, HDMI 1 year
(3 Year w registration)
VCGGT7201D3LXPB GeForce® GT 720 DDR3 1GB Verto Low Profile
1024 MB DDR3 192 797 MHz 1600 MHz 64-bit 14.5W 2.0 8x No 3 PCI-E
Single-Slot
Half Height
DVI-D, VGA, HDMI 1 year
(3 Year w registration)
VCGGT610XPB GeForce® GT 610 Verto
1024 MB DDR3 48 810 MHz 1000 MHz 64-bit 44W 2.0 16x No 2 PCI-E
Single-Slot
Low Profile
DVI, VGA, HDMI 1 year
(3 Year w registration)
VCGGT5201XPB-CG GeForce® GT 520 Verto (Trade Compliant)
1024 MB DDR3 48 810 MHz 1792 MHz 64-bit 27.7W 2.0 16x No 2 PCI-E
Single-Slot
Low Profile
DVI, VGA, HDMI 2 years
VCGG2101D3XPB GeForce® GT 210 Verto
1024 MB DDR3 16 520 MHz 1000 MHz 64-bit 24W 2.0 16x No 2 PCI-E
Single-Slot
Full Hight
DVI, VGA, HDMI 1 year
(3 Year w registration)
VCG84DMS1D3SXPB-CG GeForce® 8400GS DMS CG
1024 MB DDR3 8 520 MHz 800 MHz 64-bit 18W 2.0 16x No 2 PCI-E
Single-Slot
Low Profile
DMS-59 (DVI and DVI)
w/ 2x DVI to VGA Adapters
2 years
ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.
© 2014 PNY Technologies, Inc. 100 Jefferson Road, Parsippany, NJ 07054. The PNY logo and XLR8 logo are registered trademarks of PNY Technologies, Inc. All other trademarks are the property of their respective owners. All rights reserved. © 2014
© 2014 NVIDIA Corporation, NVIDIA, the NVIDIA Logo, and GeForce are regsitered trademarkets of NVIDIA Corporation in the U.S. and other countiries. All rights reserved.
