SPEEDLINK 2 in1 Force Vibration Racing Wheel User guide

2in1 Force Vibration Racing Wheel

SL-6693-SBK

User‘s Guide

Bedienungsanleitung

Mode d‘emploi

Instrucciones de manejo

Manuale di istruzioni

2

Inhalt / Content 2/3

Deutsch

Einleitung 5

Produkteigenschaften 5

Lieferumfang 5

Aufbau 5

Anschluss an eine Spielekonsole oder den PC

6

Digital/Analog-Modus 7

Betriebseigenschaften 8

Einstellung der Lenkempndlichkeit

8

Programmierfunktion 9

Tastenfunktion 1

0

Problembehebung 11

Garantie 11

Falls Sie Hilfe benötigen... 1

1

English

Introduction 13

Features 13

Included in the Delivery 1

3

Setup 13

Connecting to a games console or PC 1

4

Digital/Analogue mode 1

5

Automatic functions 1

5

Adjusting the steering sensitivity 1

6

Programming function 1

7

Button/key functions 1

8

Problem Solving

19

Warranty 19

Should you need assistance... 1

9

Français

Introduction 2

1

Caractéristiques 2

1

Éléments fournis 2

1

Montage 2

1

Raccordement à une console ou à l’ordinateur 2

2

Conguration requise 2

2

Mode numérique/analogique 2

3

Caractéristiques lors de l’utilisation 2

4

Réglage de la sensibilité du volant 2

4

Fonction de programmation 2

5

Page is loading ...

GB

important Safety information

Important!

Before using this product, read the

instruction manual for important safety

information. Please retain this manu

-

al for future reference and warranty

information.

Excemption from Liability

No liability will attach to Jöllenbeck

GmbH if any damage, injury or ac

-

cident is attributable to inattentive,

inappropriate, negligent or incorrect

operation of the machinery whether or

not caused deliberately.

Troubleshooting & Servicing

Do not attempt to service or repair the

device yourself. Refer all servicing to

qualied service personnel. Do not

attempt to modify the device in any

way. Doing so could invalidate your

warranty.

Moisture and heat sources

Do not use this apparatus near water

(for example, sinks, baths, pools) or

expose it to rain, moisture, or dripping

or splashing liquids. Do not expose the

unit to high temperatures, high humidi

-

ty or direct sunlight.

Cleaning

When cleaning the device, please use

a soft, dry cloth. Never use benzine,

paint thinner, or other chemicals on the

device.

Location

Place the device in a stable location,

so it will not fall causing damage to the

device or bodily harm.

Intended use

• The product may only be used with

the original parts intended for it.

• The product may only be used in

closed and dry rooms.

• The intended use includes adhe

-

rence to the specied installation

instructions. The manufacturer ac-

cepts no liability for damage arising

due to improper use.

12

GB

13

Introduction

Thank you for purchasing the 2in1 Force Vibration Racing Wheel. The multi-

compatible steering wheel has been specically designed for use with the Play-

Station

®

2 and PC. Dualshock

TM

feedback effects make for captivating realism

during your game.

Features

• Dual Vibration for a thrilling driving experience

• Suitable for PC and PlayStation

®

2

• Steering wheel rim covered in articial leather – excellent grip and comfort

• Pedal block with analogue gas and brake pedal

• Table clamp and thigh support for optimal playing position without

movement

• Two control paddles

• Easily programmable pedals and buttons

• Adjustable steering sensitivity

• Extremely large steering lock of 250°

Included in the Delivery

• Steering wheel

• Pedal block

• Thigh support

• Table clamp

• Operating manual

• Driver CD

Setup

Note: Make sure the surface on which the steering wheel is mounted is level.

GB

14

Table mounting

1. Fix the table clamp to the underside of the steering wheel (see picture be

-

low).

2. Place the steering wheel on the table and turn the table clamp screw suf-

ciently tight enough so that the steering wheel cannot slip.

Thigh support

1. Unpack the thigh supports.

2. Turn the steering wheel upside down and fasten the supports in the holes

provided.

3. Place the steering wheel on your thighs as shown in the picture.

Connecting to a games console or PC

Connecting to PlayStation

®

2

Note: Do not connect the steering wheel to the PlayStation

®

2 using the USB

connector on the cable! It will only work with the PlayStation

®

2 when you use

the steering wheel’s PlayStation

®

2 connector.

1. Switch off your PlayStation

®

2 games console.

2. Connect the PlayStation

®

2 plug on your steering wheel to Port 1 on your

PlayStation

®

2 console.

3. Connect the pedal block to the 6-pin cable of the steering wheel.

4. Switch on the TV and games console.

Note:

For automatic detection of the steering wheel, DO NOT touch the steering

wheel! The steering wheel congures itself automatically.

Connecting to a PC via the USB port

Note:

1. USB operation is not supported by Windows

®

95/NT.

2. Do not connect the steering wheel to a USB hub. It will only work when con-

nected directly to the USB port of your PC.

System requirements:

• IBM PC

• Windows

®

98 or higher

• Free USB port

• 20 MB free hard disk space

Connect the USB connector to the USB port on your PC.

GB

15

Driver installation for Windows

®

98 and higher

1. The steering wheel must be connected to the PC before installing the driver.

Insert the supplied driver CD into your CD-ROM drive.

2. If the installation menu does not start automatically, click on

Start > Run >

Browse and select your CD-ROM drive.

3. Double click on the le setup.exe

4. If a window requesting a digital signature for Windows appears, acknowl-

edge the message to continue installation. Follow the on-screen instruc-

tions.

5. Reboot your PC once the installation has completed.

After rebooting, select

Start > Settings > Control Panel. Double click on Game

Controllers. In the window that opens, your steering wheel should be listed with

status “OK”.

Click on

Properties to test the steering wheel.

It is not necessary to calibrate the steering wheel. The steering wheel sup

-

ports dynamic calibration, which takes place automatically when plugging in the

device.

Digital/Analogue mode:

For PlayStation

®

2, you can choose between analogue and digital mode with

this steering wheel.

To select a mode, press the mode button until you are in the required mode.

Digital mode Analogue mode

LED display

--- Red

Note:

With some games, such as GT3™, the steering wheel only works in analogue

mode. Digital mode ensures compatibility with older games.

Automatic functions

Auto-centring

On connecting the steering wheel to the console, the wheel is automatically

centred so you don’t have to make laborious settings in the game’s options

menu.

Automatic detection of the widest possible steering lock

This function automatically sets the greatest possible steering lock for the steer

-

ing wheel so you don’t have to make laborious settings in the game’s options

menu.

GB

16

Adjusting the steering sensitivity

You can choose between 6 sensitivity levels.

Level 1 is the default setting.

To change the sensitivity, proceed as follows:

1. Simultaneously press the Select button and the right directional button.

The ashing LEDs indicate which sensitivity level has been set (see table

below).

2. Repeat this until you have set the required steering sensitivity.

LED display with the individual sensitivity levels:

Green LEDs Yellow LEDs Red LEDs

Level 1

XX

Level 2 XX

Level 3 XX

Level 4

XX XX

Level 5 XX XX

Level 6 XX XX

Note:

The LEDs ash for 5 seconds after setting the steering angle. Four LEDs will

ash respectively for Levels 4-6.

GB

17

Programming function:

Remapping a button function to another button

Press Select. All LEDs will ash. Programming mode is now active.

Press the button whose function you want to remap to another button. Either

four LEDs for the pedals or two LEDs for the control paddles will now start

to ash.

Press the button which you want to remap the function to. All LEDs will ash

continuously. Repeat steps 2 and 3 for remaining buttons.

To exit programming mode, press Select again or wait six seconds, after

which the steering wheel will automatically exit programming mode.

PlayStation

®

2

The right and left control paddles are set to R2 and L2 as factory default. Pe

-

dals are set to gas and brake and have the same functions as the buttons X and

.

The control paddles and pedals can be remapped to the following buttons:

,

X, , , L1, L2, R1, R2, L3 (ß), R3 (à) and RY axis (áâ).

Some games use the right analogue stick for gas and brake as standard. To

transfer the pedal function to the right analogue stick press START + left direc

-

tional button + gas pedal, followed by START + left directional button + brake

pedal. This function is only supported in analogue mode. The setting is dele-

ted if the steering wheel is switched to digital mode or if the games console is

switched off.

PC

The right and left control paddles are set to Keys 1 and 2 as factory default. The

pedals are set to Y axis up and down.

The control paddles and pedals can be remapped to the following keys: 1, 2, 3,

4, 5, 6, 7, 8, 11, 12, Y axis.

Resetting all changes made

Either press „Mode“ for three seconds, or unplug the steering wheel from the

games console, or turn the games console off.

GB

18

Button/key functions

Button marking PC

PS

®

2

Direction pad POV (direction keys) Direction pad

Steering wheel left/right X1 axis Left and right movement of the

left stick

Left pedal

Y1 axis (

) Analogue  button

Right pedal

Y1 axis (

)

Analogue X button



Key 1

 button



Key 4

 button



Key 2

 button



Key 3

 button

Mode Key 10 Mode button

Start Key 10 Start button

Select Key 9 Select button

L1 Key 7 L1

L2 Key 6 L2

R2 Key 5 R2

R1 Key 8 R1

Left control paddle Key 2 L2

Right control paddle Key 1 R2

Problem Solving

The steering wheel doesn’t respond.

1. Check that the game you have chosen supports the current operating mode.

If necessary, switch off the console and remove all cables. Reconnect ca

-

bles and switch the console on again.

The pedals don’t respond.

1. Check the cable connection between pedals and steering wheel.

2. Check that the pedals are activated in the game.

3. If the pedals don’t work in the game, you can reassign the gas and brake

functions to other buttons or simply use the X and

 buttons.

GB

19

Warranty

We guarantee this product to be free of defects in workmanship and materials

for a period of two (2) years from the original date of purchase.

Should you need assistance...

Our technical support team will be happy to help with any technical problems.

The hotline number can be found on the back of this manual.

Page is loading ...

SL-6693-SBK

Version 1.0

may be trademarks or registered trademarks and are the property of their respective owners.

Information contained herein is subject to change without notice. This publication or parts of

it may not be reproduced without the express consent of the publisher.

Jöllenbeck GmbH

Kreuzberg 2

D-27404 Weertzen

Germany

Phone: +49 (0) 4287 9244 690

Web: www.speed-link.com

SPEEDLINK 2 in1 Force Vibration Racing Wheel User guide

SPEEDLINK 2 in1 Force Vibration Racing Wheel User guide

in other languages

Related papers

Other documents
