Lexmark 16L0000 - X 422 MFP B/W Laser Setup Manual

Category
Multifunctionals
Type
Setup Manual

This manual is also suitable for

X422 MFP
Setup Guide
January 2004
Lexmark and Lexmark with diamond design are trademarks of Lexmark
International, Inc., registered in the United States and/or other countries.
© 2004 Lexmark International, Inc.
740 West New Circle Road
Lexington, Kentucky 40550
English
Edition: January 2004
The following paragraph does not apply to any country where such
provisions are inconsistent with local law: LEXMARK
INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS”
WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULARPURPOSE.
Some states do not allow disclaimer of express or implied warranties in
certain transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical
errors. Changes are periodically made to the information herein; these
changes will be incorporated in later editions. Improvements or changes
in the products or the programs described may be made at any time.
Comments about this publication may be addressed to Lexmark
International, Inc., Department F95/032-2, 740 West New Circle Road,
Lexington, Kentucky 40550, U.S.A. In the United Kingdom and Eire, send
to Lexmark International Ltd., Marketing and Services Department,
Westhorpe House, Westhorpe, Marlow Bucks SL7 3RQ. Lexmark may
use or distribute any of the information you supply in any way it believes
appropriate without incurring any obligation to you. You can purchase
additional copies of publications related to this product by calling 1-800-
553-9727. In the United Kingdom and Eire, call +44 (0)8704 440 044. In
other countries, contact your point of purchase.
References in this publication to products, programs, or services do not
imply that the manufacturer intends to make these available in all countries
in which it operates. Any reference to a product, program, or service is not
intended to state or imply that only that product, program, or service may
be used. Any functionally equivalent product, program, or service that
does not infringe any existing intellectual property right may be used
instead. Evaluation and verification of operation in conjunction with other
products, programs, or services, except those expressly designated by the
manufacturer, are the users responsibility.
Lexmark and Lexmark with diamond design are trademarks of Lexmark
International, Inc., registered in the United States and/or other countries.
PostScript® is a registered trademark of Adobe Systems Incorporated.
Other trademarks are the property of their respective owners.
© 2004 Lexmark International, Inc.
All rights reserved.
UNITED STATES GOVERNMENT RIGHTS
This software and any accompanying documentation provided under this
agreement are commercial computer software and documentation
developed exclusively at private expense.
Conventions
It may help you to recognize the caution and warning conventions used in
this document.
CAUTION: A caution identifies something that could cause you harm.
Warning: A warning identifies something that could damage your product
hardware or software.
Safety information
CAUTION: Do not use the fax feature during a lightning storm. Do not set
up this product or make any electrical or cabling connections, such as the
power cord or telephone, during a lightning storm.
Connect the power cord to a properly grounded electrical outlet
that is near the product and easily accessible.
Use only a 26 AWG or larger telecommunications (RJ-11) cord
when connecting this product to the public switched telephone
network.
Refer service or repairs, other than those described in the
operating instructions, to a professional service person.
This product is designed, tested, and approved to meet strict
global safety standards with the use of specific Lexmark
components. The safety features of some parts may not always
be obvious. Lexmark is not responsible for the use of other
replacement parts.
This product contains mercury in the lamp (<5mg Hg). Disposal of
mercury may be regulated due to environmental considerations. For
disposal or recycling information, please contact your local authorities or
the Electronic Industries Alliance: www.eiae.org.
Static sensitivity notice
This symbol identifies static-sensitive parts. Do not
touch in the areas near these symbols without first
touching the metal frame of the printer.
iii
Contents
Contents
Step 1: Install drivers for local printing and scanning . . . .1
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
UNIX/Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Step 2: Unpack the MFP . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Placing the MFP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Step 3: Set up MFP and options . . . . . . . . . . . . . . . . . . . . . .9
Installing options on your MFP . . . . . . . . . . . . . . . . . . . . . . . . .9
Setting up the optional 250-sheet or 500-sheet drawer . . . . .10
Attach the scanner automatic document feeder (ADF) tray . .11
Unlock the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Step 4: Install optional memory cards . . . . . . . . . . . . . . . .13
Opening the side door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Removing the system board access shield . . . . . . . . . . . . . .14
Installing an MFP memory card . . . . . . . . . . . . . . . . . . . . . . .15
Installing an optional flash memory or font card . . . . . . . . . . .15
Reattaching the system board access shield . . . . . . . . . . . . .17
Reattaching the side door . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Step 5: Prepare the MFP . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Raising the paper rest . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Attaching a control panel overlay . . . . . . . . . . . . . . . . . . . . . .20
iv
Contents
Step 6: Install the print cartridge . . . . . . . . . . . . . . . . . . . . .21
Removing the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Preparing the print cartridge . . . . . . . . . . . . . . . . . . . . . . . . . .22
Step 7: Load media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Changing Paper Size and Paper Type settings . . . . . . . . . . .26
Loading the trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Loading the multipurpose feeder . . . . . . . . . . . . . . . . . . . . . .30
Loading envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Loading the scanner automatic document feeder (ADF) . . . .34
Step 8: Attach cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Attaching the telephone cord . . . . . . . . . . . . . . . . . . . . . . . . .35
Attaching a USB cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Verifying the USB queue . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Attaching a network cable . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Step 9: Power on the MFP . . . . . . . . . . . . . . . . . . . . . . . . . .39
Turn on the MFP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Step 10: Configure for TCP/IP . . . . . . . . . . . . . . . . . . . . . .41
Assigning an MFP IP address . . . . . . . . . . . . . . . . . . . . . . . .41
Verifying the IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Using the resident Web page . . . . . . . . . . . . . . . . . . . . . . . . .42
Step 11: Verify MFP setup . . . . . . . . . . . . . . . . . . . . . . . . . .43
Printing a menu settings page . . . . . . . . . . . . . . . . . . . . . . . .43
Printing a network setup page . . . . . . . . . . . . . . . . . . . . . . . .44
Printing a local test page . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Printing Quick Reference documentation . . . . . . . . . . . . . . . .45
v
Contents
Step 12: Install drivers for network printing . . . . . . . . . . .47
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
UNIX/Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
NetWare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Step 13: Set default copy settings . . . . . . . . . . . . . . . . . . .55
Step 14: Set up to send and receive faxes . . . . . . . . . . . .57
Configuring fax setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Sending a fax from your MFP . . . . . . . . . . . . . . . . . . . . . . . . .58
Step 15: Set up your e-mail server . . . . . . . . . . . . . . . . . . .59
Other sources of information . . . . . . . . . . . . . . . . . . . . . . .63
Publications CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Drivers CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Lexmark Web site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
vi
Contents
1
Install drivers for local printing and scanning
Step 1: Install drivers for local
printing and scanning
For local printing and scanning, it is important that you install the
drivers for your multifunction printer (MFP) on your computer before
you install the actual hardware.
A local MFP is an MFP attached to your computer using a USB cable.
If your MFP is attached to a network instead of your computer, skip this
step and go to Step 2: “Unpack the MFP” on page 5.
Note: Use the drivers CD to
install your print and scan
drivers. Launch the CD and
follow the instructions to
install MFP software.
A print driver is software that lets your computer communicate with
your MFP. The procedure to install drivers depends on the operating
system you are using.
A scan driver is software that lets you acquire and adjust a scan.
Again, the procedure to install drivers depends on the operating
system you are using.
Select your operating system from the following table to find driver
installation instructions.
Operating system Go to page...
Windows Server 2003, Windows 2000,
Windows XP, Windows 98, and Windows Me
Note: Windows 95 and Windows NT are not
supported operating systems.
2
Macintosh 3
UNIX/Linux 4
* For local installation, do not attach a USB cable while your MFP and
computer are turned on. Install the drivers first.
2
Install drivers for local printing and scanning
Windows Some Windows operating systems may already include a system
driver that is compatible with your MFP. This may seem automatic in
later versions of Windows. System print drivers work well for simple
printing, but they may contain less functionality than our enhanced
custom driver.
Note: Installing a custom
driver does not replace the
system driver. A separate
print object is created and
appears in the Printers
folder.
Use the drivers CD that shipped with your MFP to install the custom
print driver and obtain all of the enhanced print features and
functionality.
Drivers are also available in downloadable software packages on
Lexmark’s Web site at www.lexmark.com.
Using Windows Server
2003, Windows 2000,
Windows XP, and
Windows 98/Me
1 Insert the drivers CD into your CD-ROM drive of your computer.
If the CD does not auto launch, click Start Æ Run, and then
type D:\Setup.exe in the Run dialog box.
Note: Some Windows
operating systems require
that you have administrative
access to install print drivers
on your computer.
2 Click Install Software.
3 Click Printer and Software.
4 Click Agree to accept the license agreement.
5 Select Suggested, and then click Next.
The Suggested option is the default installation for local and
attached setup. If you need to install utilities, change settings, or
customize device drivers, select Custom, and follow the
instructions on your screen.
6 Select Local Attached, and then click Next.
Follow the instructions on your screen to complete installing the
drivers.
What do I do next?
Task Go to page…
After you have installed the drivers on your computer, you
are ready to set up the MFP.
5
3
Install drivers for local printing and scanning
Macintosh In order to print locally to a USB-attached MFP, you must create a
queue in Print Center (Mac OS X).
Note: Visit our Lexmark
Web site,
www.lexmark.com, for
Macintosh 8.6–9.x printing
support.
Mac OS X In order to print to an MFP, you must install a PostScript™ Printer
Description (PPD) file on your computer.
1 Insert the drivers CD into your CD-ROM drive.
2 Double-click the installer package for your MFP.
Note: A PPD file provides
detailed information about
the capabilities of an MFP to
your Macintosh computer.
3 On the Authorization screen, choose Click the lock to make
changes.
4 Enter your password, and then click OK.
5 Click Continue on the Welcome screen and again after you
view the Readme file.
Note: A PPD for your MFP
is also available in a
downloadable software
package on our Lexmark
Web site at
www.lexmark.com.
6 Click Continue after you view the license agreement, and then
click Agree to accept the terms of the agreement.
7 Select a Destination, and then click Continue.
8 On the Easy Install screen, click Install. All the necessary
software is installed on your computer.
9 Click Close when installation is complete.
To verify that your MFP is properly connected, continue with set up and
see “Verifying the USB queue” on page 36.
What do I do next?
Task Go to page…
After you have installed the drivers on your computer, you
are ready to set up the MFP.
5
4
Install drivers for local printing and scanning
UNIX/Linux Local printing is supported on many UNIX and Linux platforms, such
as Sun Solaris and Red Hat.
The Sun Solaris and Linux packages are available on the drivers CD
and on our Lexmark Web site at www.lexmark.com.
The driver package for Sun Solaris supports USB connections to Sun
Ray appliances and Sun workstations.
Visit our Lexmark Web site at www.lexmark.com for a complete list of
supported UNIX and Linux platforms.
What do I do next?
Task Go to page…
After you have installed the drivers on your computer, you
are ready to set up the MFP.
5
5
Unpack the MFP
Step 2: Unpack the MFP
Unpacking 1 Select a location for your MFP.
CAUTION: The MFP weighs 46 lbs. (21 kg) and requires
at least two people to lift it safely. Leave the MFP in the
box until you are ready to install it. Ask someone to help
you lift the MFP.
Leave enough room to open the
MFP trays, covers, doors, and
options. It is also important to
allow space around the MFP for
proper ventilation.
6
Unpack the MFP
Placing the MFP
Provide the proper environment:
A firm, level surface
Away from the direct airflow of
air conditioners, heaters, or
ventilators
Free of sunlight, humidity
extremes, or temperature
fluctuations
Clean, dry, and free of dust
Warning: Allow at least 7.62 cm (3 in.) clearance on the
right side of the MFP for the cooling fan to function
properly.
7.62 cm
(3 in.)
40.64 cm
(16 in.)
78.74 cm
(31 in.)
7
Unpack the MFP
2 Remove all items from the box.
Make sure you have the following items:
(1) MFP with one installed standard
250-sheet tray
(2) Automatic Document Feeder (ADF)
tray
(3) Language overlays
(4) Installation Pointer sheet
(5) Setup Guide
(6) Quick Reference sheet
(7) Telephone cord
(8) Power cord
(9) Publications CD (shipped inside the
Setup Guide)
(10) Drivers CD
(11) Document Management CD,
containing your scanning software.
This CD is optional and is used only
for locally-connected MFPs.
(12) One print cartridge (inside MFP)
If any items are missing or damaged,
refer to the publications CD for the
designated Lexmark support phone
number for your country or region.
1
2
4
7
9
3
10
11
5
6
8
12
8
Unpack the MFP
Save the carton and packing material in
case you need to repack the MFP.
What do I do next?
Task Go to page…
After you have unpacked the MFP, you are ready to set up
the MFP and install any options you may have purchased.
9
9
Set up MFP and options
Step 3: Set up MFP and options
Installing options on your MFP You have the option of installing an extra
paper drawer on your MFP to increase
the amount of available media. To
purchase an additional drawer, contact
your sales representative.
Lexmark ABC MFP Base Model and Options
MFP
250-sheet
drawer
500-sheet
drawer
MFP
10
Set up MFP and options
Setting up the optional 250-sheet or
500-sheet drawer
After you have installed the drivers, you
are ready to set up the optional 250-
sheet or 500-sheet drawer.
1 Remove the tray from the support
unit. Remove all of the packing
material and tape from both the
support unit and tray.
2 Place the support unit on top of a
firm, flat surface where you plan to
use the MFP.
3 Place the MFP on top of the
support unit.
Adding an optional drawer for Mac OS X users When adding an optional drawer to an
MFP that will be used by way of USB in
Mac OS X, additional setup is required to
allow the optional drawer to be used as a
source when printing.
1 Go to /Applications/Utilities and
launch Print Center.
2 Select the MFP from the Printer
List and choose Show Info from
the Printers menu.
3 Select Installable Options from
the pop-up menu at the top of the
Printer Info window and modify the
Trays pop-up menu to reflect the
number of trays connected to the
MFP.
4 Click Apply Changes and close
the Printer Info window.
11
Set up MFP and options
Attach the scanner automatic
document feeder (ADF) tray
1 Remove the ADF tray from the
box.
2 Align the tabs on the tray with the
slots located on top of the scanner.
3 Push the tray down so that the
tabs slide into the slots.
4 Slide the tray forward until it locks
into place.
12
Set up MFP and options
Unlock the scanner After you have finished assembling your
MFP, you must unlock the scanner.
Note: The scanner is shipped in a locked position to
prevent damage. We highly recommend that you lock the
scanner anytime you move the MFP.
To unlock the scanner:
1 Locate the scanner lock under the
left side of the scanner flatbed on
the MFP.
2 Move the locking mechanism
toward the front of the MFP.
To lock the scanner (if you move your
MFP after initial setup):
1 Make sure the scanner is in the
Ready (idle) state.
2 Turn off and unplug the scanner.
3 Move the locking mechanism
toward the back of the MFP. This
locks the scanner.
What do I do next?
Task Go to page…
After you have installed MFP optional drawers, attached
the ADF tray, and unlocked the scanner, you are now
ready to install optional memory cards.
13
  • Page 1 1
  • Page 2 2
  • Page 3 3
  • Page 4 4
  • Page 5 5
  • Page 6 6
  • Page 7 7
  • Page 8 8
  • Page 9 9
  • Page 10 10
  • Page 11 11
  • Page 12 12
  • Page 13 13
  • Page 14 14
  • Page 15 15
  • Page 16 16
  • Page 17 17
  • Page 18 18
  • Page 19 19
  • Page 20 20
  • Page 21 21
  • Page 22 22
  • Page 23 23
  • Page 24 24
  • Page 25 25
  • Page 26 26
  • Page 27 27
  • Page 28 28
  • Page 29 29
  • Page 30 30
  • Page 31 31
  • Page 32 32
  • Page 33 33
  • Page 34 34
  • Page 35 35
  • Page 36 36
  • Page 37 37
  • Page 38 38
  • Page 39 39
  • Page 40 40
  • Page 41 41
  • Page 42 42
  • Page 43 43
  • Page 44 44
  • Page 45 45
  • Page 46 46
  • Page 47 47
  • Page 48 48
  • Page 49 49
  • Page 50 50
  • Page 51 51
  • Page 52 52
  • Page 53 53
  • Page 54 54
  • Page 55 55
  • Page 56 56
  • Page 57 57
  • Page 58 58
  • Page 59 59
  • Page 60 60
  • Page 61 61
  • Page 62 62
  • Page 63 63
  • Page 64 64
  • Page 65 65
  • Page 66 66
  • Page 67 67
  • Page 68 68
  • Page 69 69
  • Page 70 70
  • Page 71 71
  • Page 72 72
  • Page 73 73
  • Page 74 74
  • Page 75 75
  • Page 76 76
  • Page 77 77
  • Page 78 78
  • Page 79 79
  • Page 80 80
  • Page 81 81
  • Page 82 82

Lexmark 16L0000 - X 422 MFP B/W Laser Setup Manual

Category
Multifunctionals
Type
Setup Manual
This manual is also suitable for

Ask a question and I''ll find the answer in the document

Finding information in a document is now easier with AI
