Alpine ILX ILX-F903D Installation guide

Brand: Alpine ILX

Model: ILX-F903D

Category: Car video systems

Type: Installation guide

Printed in Korea

PART NO. 68-34732Z92-A

M3514663010

JEIL Moon Hwa Co.

18-6, 3Ga, Pil_dong, Jung_gu, Seoul, Korea

FOR CAR USE ONLY/NUR FÜR AUTOMOBIL GEBRAUCH/POUR APPLICATION AUTOMOBILE UNIQUEMENT/PARA USO

EN AUTOMÓVILES/SOLO PER L’UTILIZZO IN AUTOMOBILE/ENDAST FÖR BILBRUK/ALLEEN VOOR GEBRUIK IN DE

AUTO/ТОЛЬКО ДЛЯ ИСПОЛЬЗОВАНИЯ В АВТОМОБИЛЯХ/DO UŻYCIA TYLKO W SAMOCHODZIE

9-inch Digital Media Station

iLX-F903D

• INSTALLATION MANUAL

• INSTALLATIONSANLEITUNG

•GUIDE D’INSTALLATION

•MANUAL DE INSTALACIÓN

• MANUALE DI INSTALLAZIONE

• INSTALLATIONSHANDBOK

• INSTALLATIEHANDLEIDING

• РУКОВОДСТВО ПО УСТАНОВКЕ

• INSTRUKCJA MONTAŻU

ALPINE ELECTRONICS MARKETING, INC.

1-7, Yukigaya-Otsukamachi, Ota-ku,

Tokyo 145-0067, JAPAN

Phone: 03-5499-4531

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone 03-8787-1200

ALPINE ELECTRONICS GmbH

Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany

Phone 089-32 42 640

ALPINE ELECTRONICS OF U.K. LTD.

Alpine House

Fletchamstead Highway, Coventry CV4 9TW, U.K.

www.alpine.co.uk

ALPINE ELECTRONICS France S.A.R.L.

184 allée des Erables

CS 52016 – Villepinte

95 945 Roissy CDG cedex

FRANCE

Phone : + 33(0)1 48 63 89 89

ALPINE ITALIA S.p.A.

Viale Cristoforo Colombo 8,

20090 Trezzano sul Naviglio MI, Italy

Phone +39 02 484781

ALPINE ELECTRONICS DE ESPAÑA, S.A.

Portal de Gamarra 36, Pabellón, 32

01013 Vitoria (Alava)-APDO 133, Spain

Phone 945-283588

ENGLISH

1-EN

Contents

WARNING ...................................................... 2

CAUTION ....................................................... 2

Precautions ................................................... 3

Accessory List ........................................................ 3

Installation .............................................................. 3

Caution concerning the installation

location ............................................................ 3

Adjust the front-back position of the Display

unit (Optional) ...............................................4

Attach the Sheet cap (Only necessary when

the front-back position of the Display unit

is in the forward position) ............................4

Mounting the GPS Antenna inside the

vehicle .............................................................. 4

Mounting the Microphone ............................... 5

Installation example using the Original

Mounting Bracket ..........................................5

Install the display unit .......................................6

Connections ...........................................................9

If an ACC power supply is not available ......11

System Example ...................................................12

Position Adjustment and Mounting

Dimensions of the Display .............................18

2-EN

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE REACH OF

CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult

a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire,

electric shock or other injury.

MAKE THE CORRECT CONNECTIONS.

Failure to make the proper connections may result in fire or

product damage.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may

result in fire, etc.

BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY

TERMINAL.

Failure to do so may result in electric shock or injury due to

electrical shorts.

DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING

OBJECTS.

Arrange wiring and cables in compliance with the manual to

prevent obstructions when driving. Cables or wiring that obstruct

or hang up on places such as the steering wheel, shift lever, brake

pedals, etc. can be extremely hazardous.

DO NOT SPLICE INTO ELECTRICAL CABLES.

Never cut away cable insulation to supply power to other

equipment. Doing so will exceed the current carrying capacity of

the wire and result in fire or electric shock.

DO NOT DAMAGE PIPE OR WIRING WHEN DRILLING HOLES.

When drilling holes in the chassis for installation, take precautions

so as not to contact, damage or obstruct pipes, fuel lines, tanks or

electrical wiring. Failure to take such precautions may result in fire.

DO NOT USE BOLTS OR NUTS IN THE BRAKE OR STEERING SYSTEMS TO

MAKE GROUND CONNECTIONS.

Bolts or nuts used for the brake or steering systems (or any other

safety-related system), or tanks should NEVER be used for

installations or ground connections. Using such parts could disable

control of the vehicle and cause fire etc.

DO NOT INSTALL IN LOCATIONS WHICH MIGHT HINDER VEHICLE

OPERATION, SUCH AS THE STEERING WHEEL OR SHIFT LEVER.

Doing so may obstruct forward vision or hamper movement etc.

and results in serious accident.

DO NOT INSTALL THE MONITOR NEAR THE PASSENGER SEAT AIR BAG.

If the unit is not installed correctly the air bag may not function

correctly and when triggered the air bag may cause the monitor to

spring upwards causing an accident and injuries.

HAVE THE WIRING AND INSTALLATION DONE BY EXPERTS.

The wiring and installation of this unit requires special technical

skill and experience. To ensure safety, always contact the dealer

where you purchased this product to have the work done.

USE SPECIFIED ACCESSORY PARTS AND INSTALL THEM SECURELY.

Be sure to use only the specified accessory parts. Use of other than

designated parts may damage this unit internally or may not

securely install the unit in place. This may cause parts to become

loose resulting in hazards or product failure.

ARRANGE THE WIRING SO IT IS NOT CRIMPED OR PINCHED BY A SHARP

METAL EDGE.

Route the cables and wiring away from moving parts (like the seat

rails) or sharp or pointed edges. This will prevent crimping and

damage to the wiring. If wiring passes through a hole in metal, use a

rubber grommet to prevent the wire’s insulation from being cut by

the metal edge of the hole.

DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST.

Avoid installing the unit in locations with high incidence of

moisture or dust. Moisture or dust that penetrates into this unit may

result in product failure.

WARNING

This symbol means important instructions. Failure

to heed them can result in serious injury or death.

CAUTION

This symbol means important instructions. Failure

to heed them can result in injury or material

property damage.

3-EN

Precautions

• Be sure to disconnect the cable from the (–) battery post before

installing your unit. This will reduce any chance of damage to the

unit in case of a short-circuit.

• Be sure to connect the colour coded leads according to the

diagram. Incorrect connections may cause the unit to

malfunction or damage to the vehicle’s electrical system.

• When making connections to the vehicle’s electrical system, be

aware of the factory installed components (e.g. on-board

computer). Do not tap into these leads to provide power for this

unit. When connecting the unit to the fuse box, make sure the

fuse for the intended circuit of the unit has the appropriate

amperage. When in doubt, consult your Alpine dealer.

• The unit uses female RCA-type jacks for connection to other

units (e.g. amplifier) having RCA connectors. You may need an

adaptor to connect other units. If so, please contact your

authorized Alpine dealer for assistance.

• Be sure to connect the speaker (–) leads to the speaker (–)

terminal. Never connect left and right channel speaker cables to

each other or to the vehicle body.

Accessory List

Main unit............................................................................................................. 1

Display unit ........................................................................................................ 1

Owner’s Manual ......................................................................................... 1set

Power cable........................................................................................................ 1

GPS Antenna...................................................................................................... 1

Antenna mounting plate .............................................................................. 1

Cable clamp for antenna......................................................................... 1set

USB extension cable ....................................................................................... 1

PRE OUT cable................................................................................................... 1

Microphone ....................................................................................................... 1

CAN I/F cable..................................................................................................... 1

W.REMOTE cable .............................................................................................. 1

HDMI Bracket..................................................................................................... 1

Flush head screw (M5×8).............................................................................. 4

Screw (M5×8) .................................................................................................... 4

POWER PLATE.................................................................................................... 1

Cover rear L........................................................................................................ 1

Cover rear R........................................................................................................ 1

Flush head screw (M4×13) ....................................................................2(

*1)

Screw (M4×6) .............................................................................................7(

*2)

Screw (M3×4) .............................................................................................2(

*3)

Sheet cap .....................................................................................................4(*4)

• Amounts of Display unit mounting parts marked with * include

spare parts provided in case of loss. Store them safely.

*1 Number of spares for up-down adjustment of the Display.

*2 Includes 3 spares for fixing and adjusting the angle of the Display.

*3 Includes 1 spare for fixing the Cover middle.

*4 Includes 2 spares for blocking the display screen.

Installation

Angle of installation

Install at an angle between horizontal and 30°. Note that installing at

an angle outside of this range will result in a loss of performance and

possibly damage.

Mounting

Consult “Position Adjustment and Mounting Dimensions

of the Display” (page 18) in advance so that this unit does

not obstruct your field of vision or impair driving when

mounted.

Caution concerning the installation location

Caution

• Do not block the unit’s fan, thus preventing air

circulation. If blocked, heat will accumulate inside

the unit and may cause a fire.

Air ventilation hole

Rear of the Unit

• When installing the display unit and main unit, do not

touch the connectors with your hands.

Connectors

0 - 30°

4-EN

Depending on the vehicle, it may be necessary to adjust the front-

back position of the Display unit when mounting it.

If front-back position adjustment is necessary, set the slider to the

back position before mounting the display unit to the vehicle.

[Default setting: forward position]

1 Remove 4 flush head screws from the Top and Bottom of

the main unit.

2 Push the slider to the back position (To return the slider

to the forward position, pull it forward).

3 Tightly fix the slider using the 4 screws that were

removed in Step 1.

Only attach the Sheet cap when the front-back position of the Display

unit is in the forward position.

1 Clean the mounting location.

2 Put on the GPS Antenna mounting plate.

3 Mount the GPS Antenna.

• Do not mount the GPS Antenna inside the centre console.

- Mount the GPS Antenna on a flat plane of the dash board or rear

tray.

- Make sure the GPS Antenna is not covered (obstructed) by any

metallic surface or object.

Adjust the front-back position of the Display

unit (Optional)

WARNING

MAGNETIC SCREWDRIVER REQUIRED TO

CAREFULLY REMOVE SCREWS.

Flush head screw

Main unit

Slider

Attach the Sheet cap (Only necessary when

the front-back position of the Display unit is in

the forward position)

Mounting the GPS Antenna inside the vehicle

Flush head screw

Sheet cap

Antenna mounting plate

GPS Antenna

This unit

5-EN

• If the GPS Antenna is mounted near the unit, the reception becomes

poor, and the location of your vehicle may not be displayed correctly.

- Mount the GPS Antenna far away enough from the unit.

- Bundle the GPS Antenna cable away from the rear of the unit.

• Some thermal reflection type or thermal absorption type glass may

interrupt high frequency waves. If reception is poor with the antenna

installed inside the car, try to mount the antenna outside the car.

For safe use, make sure of the following:

• Location is stable and firm.

• Does not interfere with safety equipment.

• Driver’s view and operations are not obstructed.

• Microphone is located where the driver’s voice can be easily

picked up (for example, on the sun visor).

When you speak into the microphone, you should not have to change

your driving posture. This may cause a distraction, taking your

attention away from safely driving your vehicle. Carefully consider

direction and distance while mounting the microphone. Confirm that

the driver’s voice can be easily picked up at the selected location.

1 Mount the original mounting bracket to the main unit

using the supplied screws.

• If you do not have the original mounting bracket, mount the Double din

KIT* (provided with the side mounting bracket), etc. to the main unit.

* Sold separately.

2 Connect all other leads of the main unit according to

details described in the “Connections” (page 9).

Note on using HDMI Connection Cables (HDMI Cable not

included)

When using HDMI connection cables, secure the cables to the HDMI

Terminals with the supplied HDMI Bracket.

1) Slide the HDMI Bracket into the grooves (A).

2) Secure it with the screw (B).

3 Mount the main unit in a car.

• Fix the cables carefully. Do not damage them by mounting them into

movable parts, such as the seat rail, or by locating them against sharp or

pointed edges.

4 Reattach the removed vehicle parts (panels, etc.) or

other aftermarket dash kit back onto the vehicle.

Mounting the Microphone

Installation example using the Original

Mounting Bracket

Microphone

Cable clamp

(Sold separately)

Original Mounting Bracket

Screws (M5×8)

(Included)

HDMI Terminal

(A)

(B)

HDMI Bracket

(Included)

(A)

6-EN

1 Remove the 2 angle adjustment screws (M4×6) fixing the

left and right sides of the Display unit and pull the top of

the display forward.

• Vertical positioning screws may need to be removed earlier (See Step 4)

in order to manipulate the screen enough to install the POWER PLATE.

2 Fix the Display unit to the slider of the main unit using 4

screws (M4×6).

3 Mount the POWER PLATE using a screw (M3×4).

• If you do not attach the POWER PLATE, the display will not turn on.

Make sure to attach the POWER PLATE.

Install the display unit

Angle adjustment screws (M4×6) (left and right)

Display unit

Screw (M4×6) (Included)

POWER PLATE (Included)

Screw (M3×4) (Included)

7-EN

4 Adjust the mounting position of the display.

• The available adjustment positions of the Display differ depending on

the front-back/up-down/angle positions. Consult “Position Adjustment

and Mounting Dimensions of the Display” (page 18) for details.

1) Hold the Display up vertically, remove the 4 flush head

screws (M4×13) on the left and right sides for up-down

adjustment, and adjust the up-down position of the display.

2) After adjustment, tightly fix the display with the 4 Flush head

screws (M4×13) for up-down adjustment.

3) Adjust the angle of the display.

Flush head screw (M4×13)

(left and right)

Flush head screw (M4×13)

(left and right)

0°

-20°

45°

20°

8-EN

4) After adjustment, secure the display with the 2 angle

adjustment screws (M4×6) (left and right) that were removed

in Step 1 on page 6.

5 Attach Cover rear-L/R to the left and right sides of the

display unit.

• When removing Cover rear-L/R, push in the tab and slide it.

0° -20°

45°

20°

2-b

2-a

Refer to the illustration below to use the screw holes for angle

adjustment.

•Example:

To install the display at the angle of 20°, use the screw holes 2

and b.

2-c

Angle adjustment screws (M4×6)

(left and right)

Cover rear L

(Included)

Cover rear R (Included)

Tab

9-EN

Connections

SPEED SENSOR

Antenna

(Green/White)

CAMERA

CONNECT2 I/F

AUX INPUT

REMO

(Blue/White)

REVERSE

(Orange/White)

PARKING BRAKE

(Yellow/Blue)

Power cable

(Green)

(Green/Black)

W.REMOTE cable

STEERING REMOTE

SUBW

MIC IN

FRONT OUT

REAR OUT

ISO Antenna Plug

GPS Antenna (Included)

To the vehicle speed pulse line

To RCA Rear camera

To CAN Interface box

To AUX output device

To amplifier or equalizer

To plus side of the back lamp signal

lead of the car

To the parking brake signal lead

To power antenna

Rear Left

Front Left

Front Right

Rear Right

Speakers

To steering remote control interface

Microphone (Included)

To input terminal of amplifier when

adding an external amplifier

ACC

(Red)

GND

(Black)

P. A NT

(Blue)

BATT

(Yellow)

PRE OUT cable

(White)

(White/Black)

(Grey/Black)

(Grey)

(Violet/Black)

(Violet)

CAN I/F cable

Ignition key

Battery

10-EN

Radio Antenna Receptacle

ISO/JASO Antenna Adapter (sold separately)

ISO/JASO Antenna Adapter may be required, depending on the

vehicle.

Speed Sensor Lead (Green/White)

Improper connection of the speed pulse line may cause

important safety features of the vehicle to fail (such as the

brakes or air bags). Such failures may result in an accident and

loss of life. We strongly recommend that the installation be

performed by a trained, authorized Alpine dealer.

CAMERA Input RCA Connector

Use when connecting a camera with RCA Output Connector.

CAN Interface Connector

To CAN Interface box

AUX Input Connector

Input lead for AUX video/audio signal.

• A separately sold AV/RCA interface cable (4-pole mini AV plug to

3-RCA) is required. For details on using an AV/RCA interface

cable (4-pole mini AV plug to 3-RCA), see “Usable AV/RCA

Interface Cable (4-pole mini AV plug to 3-RCA)” (page 10).

Remote Turn-On Lead (Blue/White)

Connect this lead to the remote turn-on lead of your amplifier or

signal processor.

Reverse Lead (Orange/White)

Parking Brake Lead (Yellow/Blue)

Connect this lead to the power supply side of parking brake

switch to transmit the parking brake status signals to the unit.

ISO Power Supply Connector

Switched Power Lead (Ignition) (Red)

Connect this lead to an open terminal on the vehicle’s fuse box

or another unused power source that provides (+) 12V only

when the ignition is turned on or in the accessory position.

Ground Lead (Black)

Connect this lead to a good chassis ground on the vehicle.

Make sure the connection is made to bare metal and is securely

fastened using the sheet metal screw provided.

Power Antenna Lead (Blue)

Connect this lead to the +B terminal of your power antenna, if

applicable.

• This lead should be used only for controlling the vehicle’s power

antenna. Do not use this lead to turn on an amplifier or a signal

processor, etc.

Battery Lead (Yellow)

Connect this lead to the positive (+) post of the vehicle’s battery.

Fuse Holder (15A)

ISO Connector (Speaker Output)

Left Rear (+) Speaker Output Lead (Green)

Left Rear (–) Speaker Output Lead (Green/Black)

Left Front (+) Speaker Output Lead (White)

Left Front (–) Speaker Output Lead (White/Black)

Right Front (–) Speaker Output Lead (Grey/Black)

Right Front (+) Speaker Output Lead (Grey)

Right Rear (–) Speaker Output Lead (Violet/Black)

Right Rear (+) Speaker Output Lead (Violet)

Steering Remote Control Interface Connector

To steering remote control interface.

For details about connections, consult your nearest Alpine dealer.

MIC Input Connector

To microphone (Included)

Subwoofer RCA Connectors

RED is right and WHITE is left.

Front Output RCA Connectors

Can be used as Front Output RCA Connectors. RED is right and

WHITE is left.

Rear Output RCA Connectors

Can be used as Rear Output RCA Connectors. RED is right and

WHITE is left.

GPS Antenna Receptacle

Connect to GPS antenna (Included).

CAN I/F Connector

USB Connector

To USB flash drive, iPod/iPhone or Android smartphone.

HDMI Input Connector

Power Supply Connector

W.REMOTE Connector

PRE OUT Connector

DAB Antenna Connector

To DAB Antenna (sold separately).

Usable AV/RCA Interface Cable (4-pole mini AV plug to

3-RCA)

Wiring convention of this system is as follows;

• Configuration commercially available 4-pole mini AV plugs is not

standardised.

Audio L (White)

Audio R (Red)

Ground

Video (Yellow)

(Yellow)

(Red)

(White)

Video input terminal

Audio input terminal (R, L)

11-EN

Connection Diagram of SPST Switch (sold separately)

• If your vehicle has no ACC power supply, add an SPST (single-pole, single-throw) switch (sold separately) and fuse (sold separately).

• The diagram and the fuse amperage shown above are in the case when the unit is used individually.

• If the switched power (ignition) lead of the unit is connected directly to the positive (+) post of the vehicle’s battery, the unit draws some current (several

hundred milliamperes) even when its switch is placed in the OFF position, and the battery may be discharged.

If an ACC power supply is not available

iLX-F903D

(Red)

(Yellow)

SPST SW (Optional)

FUSE (5A)

(Optional)

FUSE (20A)

(Optional)

Battery

ACC

BATTERY

To prevent external noise from entering the audio system.

• Locate the unit and route the leads at least 10 cm away from the car harness.

• Keep the battery power leads as far away from other leads as possible.

• Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis.

• If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise

suppressors, contact them for further information.

• Your Alpine dealer knows best about noise prevention measures so consult your dealer for further information.

12-EN

System Example

Connection of an iPod/iPhone

• Do not leave an iPod/iPhone in a vehicle for a long time. Heat and humidity may damage the iPod/iPhone, and you may not be able to play it again.

When connecting to an iPod/iPhone with a Lightning connector

USB connector

USB extension cable (Included)

iPod/iPhone with a Lightning

connector (sold separately)

Lightning to USB Cable

KCU-471i (sold separately)

iPhone 4S

(sold separately)

USB extension cable (Included)

When connecting to iPhone 4S

USB connector

Included with iPhone 4S

13-EN

Connection of a Flash Drive

• Do not leave a flash drive in a vehicle for a long time. Heat and humidity may damage the flash drive.

Connection of an HDMI Device (iPhone with a Lightning connector)

* When connecting an HDMI connection cable, be sure to secure it using the supplied HDMI Bracket. For details on how to secure it, see “Note on using

HDMI Connection Cables (HDMI Cable not included)” (page 5).

• Set the HDMI Setup to “HDMI.” For details, refer to “HDMI Setup” in the OWNER’S MANUAL (CD-ROM).

USB connector

USB Flash Drive (sold separately)

USB extension cable (Included)

USB connector

Lightning Digital AV Adapter

(Apple Inc., products)

(sold separately)

HDMI connection kit KCU-610HD (sold separately)

HDMI input connector*

USB extension cable

(Included)

Lightning to USB Cable

KCU-471i (sold separately)

iPhone with a Lightning

connector (sold separately)

14-EN

Connection of an HDMI Device (Android device)

• A connection kit or adapter kit suitable for the type of terminal on the connecting device is required.

• Set the HDMI Setup to “HDMI.” For details, refer to “HDMI Setup” in the OWNER’S MANUAL (CD-ROM).

* When connecting an HDMI connection cable, be sure to secure it using the supplied HDMI Bracket. For details on how to secure it, see “Note on using

HDMI Connection Cables (HDMI Cable not included)” (page 5).

USB connector

HDMI Type-D

conversion adapter

HDMI input connector*

USB extension cable

(Included)

HDMI connection kit KCU-610HD (sold separately)

Android device with

HDMI connector

(sold separately)

HDMI connection cable

Micro USB conversion cable

Android device with

MHL connector (sold

separately)

MHL conversion adapter

MHL connection kit KCU-610MH (sold separately)

HDMI connection cable

Micro USB conversion cable

15-EN

Connection of an External Device

AUX Input Connector AV/RCA Interface Cable (4-pole mini AV plug to 3-RCA)

(sold separately)

RCA Extension Cable (sold separately)

• You can change the name of an external device. For details, refer to “Setting the Auxiliary (AUX) Name” in the OWNER’S MANUAL (CD-ROM).

• For details on using an AV/RCA interface cable (4-pole mini AV plug to 3-RCA), see “Usable AV/RCA Interface Cable (4-pole mini AV p l ug t o 3- R C A ) ”

(page 10).

CAN I/F connector

AUX INPUT

(Yellow)

(White)

(Red)

To Video Output terminal

To Audio Output terminal

External Device

(sold separately)

CAN I/F cable

16-EN

Connection of an External Amplifier

Remote Turn-On Lead (Blue/White)

Subwoofer RCA Connectors

Front Output RCA Connectors

Rear Output RCA Connectors

RCA Extension Cable (sold separately)

PRE OUT connector

Power Supply connector

(Blue/White)

REMOTE ON

(Blue/White)

Subwoofer

REMO

Amplifier for subwoofer

(sold separately)

To subwoofer input terminal

(Red)

(White)

SUBW

FRONT OUT

REAR OUT

To front input terminal

Amplifier 4 ch

(sold separately)

To rear input terminal

Front speaker

Rear speaker

REMOTE ON

(Blue/White)

(Red)

(White)

(Red)

(White)

Power cable

PRE OUT cable

17-EN

Connection of a Rearview camera

CAMERA Input RCA Connector

Reverse Lead (Orange/White)

RCA Extension Cable (sold separately)

• Set the Camera Select to “Rear.” For details, refer to “Setting the Camera Input” in the OWNER’S MANUAL (CD-ROM).

CAN I/F connector

Reverse

Connect to the plus side of the car’s reverse lamp.

To Video Output terminal

Power Supply connector

CAMERA

(Orange/White)

Camera with RCA video output (sold

separately)

Power cable

CAN I/F cable

18-EN

Position Adjustment and Mounting Dimensions of the Display

The mounting position of this unit’s Display can be adjusted (front-back/up-down/angle). When mounting the Display, confirm the mounting

position and mounting dimensions so that it does not obstruct your field of vision or impair driving.

Display mounting dimensions and adjustable positions

Display unit size

Front-back position

Adjustable Display angle and up-down position

* Depending on the up-down position of the forward and back positions, there are certain positions in which the angle cannot be adjusted.

Consult “Mounting Dimensions for Angle Adjustment of the Display” (page 19) for details.

WARNING

• In the following cases, the display cannot be mounted.

- It impairs operation of the steering wheel or various levers (gearshift, windshield wiper switch, turn signal switch, etc.)

- It impairs operation of the airbag

- It significantly impairs operation of the hazard switch

- It impairs identification or operation of any other control switches

- It impairs confirmation of gauges or warning indicators

- It interferes with vehicle equipment (switches, panels, etc.)

* Depending on the vehicle, the glove compartment or cup holders may become inaccessible, or air conditioner ventilation ducts may be covered.

235.2 mm (MAX)

70 mm

28 mm

50 mm

8 mm

152.2 mm (MAX)

50 mm

-15 mm

-30 mm

-45 mm

-60 mm

45°

20°

0°

-20°

Page is loading ...

Alpine ILX ILX-F903D Installation guide

Brand: Alpine ILX

Model: ILX-F903D

Category: Car video systems

Type: Installation guide

Download PDF

report

Alpine ILX ILX-F903D Installation guide

Alpine ILX ILX-F903D Installation guide

Related papers

Other documents
