Connect 26
Flexibility comes in a new size.
Technical information
Loewe LCD TV with 66 cm screen
diagonal and HD ready.
DVB-T and DVB-T reception and radio
FM integrated.
A variety of connections and flexible
set-up options.
High Gloss Black68416W80 4011880105095
High Gloss White68416U80 4011880111607
Chrome Silver68416T80 4011880105088
Article number EAN Colour options
Function depends on signal format emitted by station.[2]
Works only with channels broadcasting service information data.[1]
Technical specifications, delivery conditions, and other
information are subject to change without notice.
Image:
Brightness cd/m²: 450
Contrast ratio static: 2.000 : 1
Downscaling/upscaling
Format options: 16 : 9, 4 : 3, Panorama, Cine, Zoom
Fully digitised signal processing
HD LCD Technology
HD ready
Horizontal and vertical viewing angle: 178° / 178°
Image resolution: 1.366 x 768
PIP (AV)
Picture format: 16 : 9
Response time: 8 ms
Screen diagonal in cm: 66
Split Screen TV/Teletext
Audio:
Audio output power in Watts: 2 x 10
Number of speakers: 2
Tone effects: Stereo, Panorama, 3D Surround
Two-channel stereo sound
Radio:
DVB radio
FM radio
Operation:
Assist+
Automatic Channel Programming (ACP)
Automatic Signal Switch (ASS)
Automatic Volume Control (AVC) [2]
Channel identification
Content-sensitive help
Electronic Instruction Manual
Electronic Program Guide (EPG) [1]
Favourites list
Index
On Screen Display (OSD) in foreign languages:
D-GB-F-I-NL-E-P-TR-GR-RUS-DK-CZ-PL
Parental Lock
Power switch
Programme positions (incl. AV and radio): 4,000
Remote control: Assist 2
Teletext: TOP-/FLOF-Teletext
Teletext page memory: 1,000
via control unit: 5 keys
Reception:
Audio standard: FM Two-channel/AM, Nicam
Colour standard: PAL, SECAM, NTSC, NTSC-V, PAL-V (60 Hz)
Decoding System Audio: MPEG
Decoding System Video: MPEG 2
Television standard: B/G, D/K, I, L, M, N
Tuner: DVB-T, DVB-C; analogue: cable, antenna, FM radio
Connectors:
Antenna (FM radio): 1
Antenna (analogue/digital): 1
Audio In: 3.5 mm
Audio Out, controlled (Cinch)
Common Interface: 1
Euro-AV/Scart total: 1
Euro-AV/Scart, of which the following number are
RGB-ready: 1
Euro-AV/Scart, of which the following number are
S-VHS/Hi8-ready: 1
HDMI including HDCP: 2
Headphones: 3.5 mm
RS 232 C: RJ 12
S-Video In
Side AV Video-/S-VHS, Hi-8 ready
VGA
Video In (cinch)
Accessories:
Set-up solutions: Floor Stand C 22/26
Standard feature: Table Stand
Wall Mount: WM Flex 26 S
Miscellaneous:
Kensington lock
Mains voltage: 220 - 240 V / 50/60 Hz
Power consumption in watts: 0.9
Power consumption in watts when the set is turned off: 0
Rated wattage to EN 62087: 75
VDE-safety standard (inspection seal)
VESA 100 x 100 mm
Weight (approx.) in kg: 10.5
-
