Lenovo Flex System Fabric EN4093R 10 Gb Scalable Switch

User’s Guide

Important Product Information—

Before using this information and the product it supports, read Appendix B, “Notices” on page 51 of this manual. Also read the product

Warranty

Information document and the Important Notices document included with the product, and the Safety Information document,

the License Agreement for Machine Code (LAMC) document, and the Environmental Notices and User Guide document on the

Document

ation CD included with the product.

April 2015 Edition

Portions

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA”

contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

Lenovo and the Lenovo logo are trademarks of Lenovo in the United States, other countries, or both.

Contents

Safety Information . . . . . . . . . . . . . . . . . . . . . . . .5

Read the Safety Information . . . . . . . . . . . . . . . . . . . . .5

Safety Statements . . . . . . . . . . . . . . . . . . . . . . . . .7

UL Regulatory Information . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 1. The EN4093R 10 Gb Scalable Switch . . . . . . . . . . . .9

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 11

About this User’s Guide . . . . . . . . . . . . . . . . . . . . 11

Notices and Statements in this Document . . . . . . . . . . . . . 11

The Documentation CD . . . . . . . . . . . . . . . . . . . . 12

Related Documentation . . . . . . . . . . . . . . . . . . . . 12

Chapter 2. Installing and Removing the EN4093R. . . . . . . . . . . 13

Before Installing the EN4093R . . . . . . . . . . . . . . . . . . . 15

Recording Important Product Information . . . . . . . . . . . . . 15

Installation Guidelines . . . . . . . . . . . . . . . . . . . . . 16

System Reliability Guidelines . . . . . . . . . . . . . . . . . . 17

Handling Static-Sensitive Devices . . . . . . . . . . . . . . . . 17

Installing the EN4093R . . . . . . . . . . . . . . . . . . . . . . 18

Removing or Replacing the Switch. . . . . . . . . . . . . . . . . . 20

Connecting Switch Ports. . . . . . . . . . . . . . . . . . . . . . 21

The Serial Console Port . . . . . . . . . . . . . . . . . . . . 21

The RJ-45 Management Port . . . . . . . . . . . . . . . . . . 22

Handling Transceiver Modules. . . . . . . . . . . . . . . . . . 23

SFP+ Ports . . . . . . . . . . . . . . . . . . . . . . . . . 24

QSFP+ Ports . . . . . . . . . . . . . . . . . . . . . . . . 26

Locating the Information Panels, LEDs, and External Ports . . . . . . . . 28

Information Panel . . . . . . . . . . . . . . . . . . . . . . . 28

Information LEDs . . . . . . . . . . . . . . . . . . . . . . . 30

Chapter 3. Configuring the EN4093R . . . . . . . . . . . . . . . . 33

Establishing an Interface Through the CMM . . . . . . . . . . . . . . 35

Enabling Management Through Data Ports . . . . . . . . . . . . . . 36

Accessing the Switch Through the SSHv2/Telnet Interface . . . . . . . . 37

Accessing the Switch Through the Serial-Port Interface. . . . . . . . . . 38

Accessing the Switch Through the Browser-Based Interface. . . . . . . . 38

Initial Configuration . . . . . . . . . . . . . . . . . . . . . . . . 39

Chapter 4. Updating the Firmware and Licensing. . . . . . . . . . . 41

Determining the Level of Switch Firmware . . . . . . . . . . . . . . . 41

Obtaining the Latest Level of Switch Firmware . . . . . . . . . . . . . 42

Upgrading the Switch Firmware . . . . . . . . . . . . . . . . . . . 42

Resetting and Restarting the Switch . . . . . . . . . . . . . . . . . 44

Acquiring Feature Licenses . . . . . . . . . . . . . . . . . . . . 45

Installing Feature Licenses . . . . . . . . . . . . . . . . . . . . . 46

Chapter 5. Solving Problems . . . . . . . . . . . . . . . . . . . 47

Running POST . . . . . . . . . . . . . . . . . . . . . . . . . 47

POST Errors . . . . . . . . . . . . . . . . . . . . . . . . . . 47

4 EN4093R 10 Gb Scalable Switch User’s Guide

Appendix A. Getting Help and Technical Assistance . . . . . . . . . 49

Appendix B. Notices . . . . . . . . . . . . . . . . . . . . . . 51

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . 52

Recycling information. . . . . . . . . . . . . . . . . . . . . . . 53

Particulate Contamination . . . . . . . . . . . . . . . . . . . . . 54

Telecommunication Regulatory Statement . . . . . . . . . . . . . . 55

Electronic Emission Notices . . . . . . . . . . . . . . . . . . . . 55

Federal Communications Commission (FCC) Statement . . . . . . . 55

Industry Canada Class A Emission Compliance Statement . . . . . . 55

Avis de Conformité à la Réglementation d'Industrie Canada . . . . . . 55

Australia and New Zealand Class A Statement . . . . . . . . . . . 55

European Union EMC Directive Conformance Statement . . . . . . . 56

Germany Class A Statement . . . . . . . . . . . . . . . . . . 56

VCCI Class A Statement . . . . . . . . . . . . . . . . . . . . 57

Japan Electronics and Information Technology Industries Association

(JEITA) Statement . . . . . . . . . . . . . . . . . . . . 58

Korea Communications Commission (KCC) Statement . . . . . . . . 58

Russia Electromagnetic Interference (EMI) Class A Statement . . . . . 58

People’s Republic of China Class A Electronic Emission Statement . . . 58

Taiwan Class A Compliance Statement . . . . . . . . . . . . . . 58

Safety Information

Read the Safety Information

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Prije instalacije ovog produkta obavezno pročitajte Surgonosne Upute.

Před instalací tohoto produktu si přečtěte příručku bezpečnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.

Avant d'installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.’

Πριν εγκαταστήσετε το προϊόν αυτό, διαβάστε τις Πληροφορίες ασφαλείας

(safety information).

A termék telepítés előtt olvassa el a Biztonsági előírásokat!

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Πред да инсталира овој продукт, прочитајте информацијата за безбедност.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.

Przed zainstalowaniem tego produktu, należy zapoznać się z książką “Informacje

dotyczace bezpieczeństwa” (Safety Information).

6 EN4093R 10 Gb Scalable Switch User’s Guide

Antes de instalar este produto, leia as Informações sobre Segurança.

Перед установкой продукта прочтитe инcтрyкции по тexникe безопасности.

Pred inštaláciou tohto zariadenia si prečítajte Bezpečnostné predpisy.

Pred namestitvijo tega proizvoda preberite Varnostne informacije.

Antes de instalar este producto, lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

Bu ürünü kurmadan önce güvenlik bilgilerini okuyun.

Youq mwngz yungh canjbinj neix gaxgonq, itdingh aeu doeg aen canjbinj soengq

cungj vahgangj ancien suisik.

Safety Statements

Important—

Each caution and danger statement in this document is labeled with a number. This

number is used to cross reference the English-language caution or danger

statement with the translated versions of the caution or danger statement in the

Safety Information document.

For example, if a caution statement is labeled “Statement 1,” translations for that

caution statement are in the Safety Information document under “Statement 1.”

Be sure to read all caution and danger statements in this document before you

perform the procedures. Read any additional safety information that comes with the

system or optional device before you install the device.

Following is a compilation of the statements found throughout this manual.

Statement 1

DANGER

Electrical current from power, telephone, and communication cables is

hazardous.

To avoid a shock hazard:

•

Do not connect or disconnect any cables or perform installation,

maintenance, or reconfiguration of this product during an electrical

storm.

•

Connect all power cords to a properly wired and grounded electrical

outlet.

•

Connect to properly wired outlets any equipment that will be attached to

this product.

•

When possible, use one hand only to connect or disconnect signal

cables.

•

Never turn on any equipment when there is evidence of fire, water, or

structural damage.

•

Disconnect the attached power cords, telecommunications systems,

networks, and modems before you open the device covers, unless

instructed otherwise in the installation and configuration procedures.

•

Connect and disconnect cables as described in the following table when

installing, moving, or opening covers on this product or attached

devices.

To Connect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

To Disconnect:

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

8 EN4093R 10 Gb Scalable Switch User’s Guide

Statement 3

CAUTION:

When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or

transmitters) are installed, note the following:

•

Do not remove the covers. Removing the covers of the laser product could

result in exposure to hazardous laser radiation. There are no serviceable

parts inside the device.

•

Use of controls or adjustments or performance of procedures other than

those specified herein might result in hazardous radiation exposure.

DANGER

Class 1 Laser Product

Laser Klasse 1

Laser Klass 1

Luokan 1 Laserlaite

Appareil À Laser de Classe 1

Statement 25

CAUTION:

This product contains a Class 1M laser. Do not view directly with optical

instruments.

UL Regulatory Information

This device is for use only with listed Lenovo Flex System Enterprise Chassis.

Some laser products contain an embedded Class 3A or Class 3B laser

diode. Note the following.

Laser radiation when open. Do not stare into the beam, do not view directly

with optical instruments, and avoid direct exposure to the beam.

Chapter 1. The EN4093R 10 Gb Scalable Switch

Introduction

This User’s Guide provides information about the Lenovo

Flex System™ Fabric

EN4093R 10 Gb Scalable Switch (referred to as EN4093R or “switch” throughout

this document).

Figure 1. The

EN4093R

Note: The illustrations in this document might differ slightly from your hardware.

SFP+ module ports

QSFP+ module ports

RS-232 serial port

(management only)

RJ-45 External

management port

Switch status LEDs

10 EN4093R 10 Gb Scalable Switch User’s Guide

The EN4093R provides flexible, reliable, and high-performance features that meet

the demands of today's highly virtualized environments.

The EN4093R provides pay-as-you-grow scalability. With optional licensing, you

can easily and cost-effectively expand the number of available ports.

Depending on the installed licenses, the scalable switch can provide up to sixty-four

10 Gigabit Ethernet (GbE)

ports.

The base license provides support for twenty-four

10 GbE

ports:

•

Single compute node port capability (fourteen internal 10 GbE ports)

•

Ten external 10 GbE Small Form-factor Pluggable Plus (SFP+) ports

Additional ports are available with optional licenses. There are two upgrades that

are available for the EN4093R (see “Acquiring Feature Licenses” on page 45).

Upgrade 1 supports up to twenty-two additional ports (up to forty-six total):

•

Dual compute node port capability (fourteen additional internal ports)

•

Two external 40 GbE Quad Small Form Pluggable Plus (QSFP+) ports, each of

which can be optionally used as four SFP+ ports

Upgrade 2 supports eighteen additional ports (up to sixty-four total)

•

Triple compute node port capability (fourteen additional internal ports)

•

Four additional external SFP+ ports

Note:

Upgrade 1 is a prerequisite to Upgrade 2.

SFP+ ports

can be populated with 10 Gb optical or copper SFP+ transceiver

modules or Direct-Attach Cables (DACs), or legacy 1 Gb optical or copper SFP

transceiver modules.

QSFP+ ports can be populated with optical QSFP+ modules or DACs

, including

some that accept SFP+ or SFP modules.

In addition to port flexibility, you can manage and configure the EN4093R through

the following interfaces:

•

A Secure Shell (SSH) version 2 or Telnet connection to the embedded

Command-Line Interface (CLI)

•

A terminal emulation program connection to the serial port interface

•

A network management application using Simple Network Management Protocol

(SNMP)

•

A Web browser-based interface (HTTPS/HTTP) connection to the switch

Documentation

About this User’s Guide

This User’s Guide provides information and instructions for installing the EN4093R,

updating the firmware, and solving problems. For other information about

configuration and management of the switch, refer to the documents described in

“Related Documentation” on page 12.

Note:

•

The illustrations in this document might differ slightly from your hardware and

might not depict all included labels.

•

The console output described or referenced in this document might differ slightly

from that displayed by your system. Output varies according to the type of

Lenovo chassis and the firmware versions and options that are installed.

Notices and Statements in this Document

The caution and danger statements in this document are also in the multilingual

Safety Information document, which is on the included Documentation CD. Each

statement is numbered for reference to the corresponding statement in the Safety

Information document.

The following notices and statements are used in this document:

•

Note:

These notices provide important tips, guidance, or advice.

•

Important:

These notices provide information or advice that might help you

avoid inconvenient or problem situations.

•

Attention:

These notices indicate potential damage to programs, devices, or

data. An attention notice is placed just before the instruction or situation in which

damage could occur.

•

Caution:

These statements indicate situations that can be potentially hazardous

to you. A caution statement is placed just before the description of a potentially

hazardous procedure step or situation.

•

Danger:

These statements indicate situations that can be potentially lethal or

extremely hazardous to you. A danger statement is placed just before the

description of a potentially lethal or extremely hazardous procedure step or

situation.

12 EN4093R 10 Gb Scalable Switch User’s Guide

The Documentation CD

The included Documentation CD contains documentation for your switch in Portable

Document Format (PDF).

The Documentation CD includes the product Safety Information do

cument, the

License Machine Access Code (LAMC) document, and the Environmental Notices

and User Guide document.

The Documentation CD requires the following minimum hardware and software:

•

Microsoft Windows NT 4.0 (with Service Pack 3 or later), Windows 2000, or Red

Hat Linux.

•

100 MHz microprocessor.

•

32 MB of RAM.

•

Adobe Acrobat Reader 3.0 (or later), or xpdf (which comes with Linux operating

systems). Acrobat Reader software is required for reading documents on the CD.

To access the documents on the CD:

•

If you are using a Windows operating system, insert the CD into the CD or DVD

drive and from My Computer, double click the CD or DVD drive, then open the

folders and documents that support your product.

•

If you are using a Linux operating system, insert the CD into the CD or DVD drive

and run the following command from the

mnt/cd

directory:

sh.linux.sh

When the CD is mounted, open the directories and documents that support your

product.

Related Documentation

Additional or updated product documents may be available from the Lenovo

website. Such documents may cover features not described in the original

documentation that comes with the switch, or may include technical updates or

corrections.

You can obtain up-to-date information on the Lenovo support website:

http://support.lenovo.com/

Note: Changes are made periodically to the Lenovo website. Procedures for

locating firmware and documentation might vary slightly from what is

described in this document.

For information about switch hardware and firmware features, specifications, and

standards, including their configuration, see the Application Guide for your specific

switch and its installed firmware.

For information about the switch information, statistics, and individual configuration

parameters, see the Command Reference for your specific switch and its installed

firmware.

See the documentation that came with your Lenovo chassis for information about

the environmental conditions and specifications that are supported by the system.

Chapter 2. Installing and Removing the EN4093R

This chapter provides instructions for installing and removing the EN4093R in the

Lenovo Flex System chassis. See the documentation for your Lenovo Flex System

chassis for information about I/O bay locations and the components that can be

installed in them that is specific to your Lenovo Flex System chassis type.

The following illustration shows an example of a Lenovo Flex System chassis

(rear-view) with the I/O bays identified.

Figure 2. Flex System chassis I/O bays.

A Lenovo Flex System network adapter must be installed in each compute node

with which you want to communicate. To enable the switch to communicate with a

compute node, at least one switch must be installed in the Lenovo Flex System

chassis. For details about network adapter installation, configuration, and use, see

the documentation that comes with the Lenovo Flex System network adapter.

Installing a second switch enables a redundant path and a separate connection from

the compute node to the external Ethernet network.

The Lenovo Flex System chassis supports a maximum of four EN4093R modules.

The Lenovo Flex System chassis supports a maximum of twenty-eight network

adapters.

I/O Module

Bay 1

I/O Module

Bay 3

I/O Module

Bay 2

I/O Module

Bay 4

14 EN4093R 10 Gb Scalable Switch User’s Guide

Note:

•

I/O bays 1 and 2 support any standard

Lenovo

Flex System switch or pass-thru

module. When you install an I/O network adapter in the left-most fabric connector

on the compute node, these I/O bays support any switch with the same type of

network interface that is used by the corresponding network adapter.

•

I/O bays 3 and 4 support any standard

Lenovo

Flex System switch or pass-thru

module. When you install an I/O network adapter in the right-most fabric

connector on the compute node, these I/O bays support any switch with the

same type of network interface that is used by the corresponding network

adapter.

•

The compute nodes or

Lenovo

Flex System chassis that are described or shown

in this document might be different from your compute node or

Lenovo

Flex

System chassis. For additional information, see the documentation that comes

with your

Lenovo

Flex System chassis.

•

When the switch is installed in a

Lenovo

Flex System chassis, the internal ports

operate at 1 Gigabits per second (Gbps) or 10 Gbps. The external ports can

operate at 1 Gbps, 10 Gbps, or 40 Gbps, depending on the port type and

installed transceiver modules.

Before Installing the EN4093R

Recording Important Product Information

Attention:

Product information is required in order to register your EN4093R,

update its firmware, place a service call, or replace the unit.

Some of the product information labels may be hidden from view once the EN4093R

is installed. To prevent the need to remove the switch in order to read required

product information, locate and record the information shown on Table 1 on page 16

prior to installation.

An example of the product information labels is shown as follows:

Figure 3. Sample product labels from the switch

Note: These examples are to help locate and identify the information labels. The

actual labels and information for your specific switch may differ.

The identification labels on the EN4093R contain the serial number and part number

of the switch. These labels also include the Media Access Control (MAC) address

(on the uppermost handle) of the switch. Though helpful, the MAC address is not

required for opening a service call.

16 EN4093R 10 Gb Scalable Switch User’s Guide

Print this page and record product information below. Keep the information in a safe

place for future reference. You will need this information when you register the

switch or open a service call with Lenovo.

For convenience, once the EN4093R is installed and initialized, you can use the

show sys-info

command in the switch firmware interface to display the product

serial number and other required information.

Installation Guidelines

Before you install the switch in the Lenovo Flex System chassis, read the following

information:

•

Read the safety information that begins on page 5, “Handling Static-Sensitive

Devices” on page 17, and the safety statements in the

Lenovo

Flex System

chassis documentation. This information provides a safe working environment.

•

Observe good housekeeping in the area where you are working. Place removed

covers and other parts in a safe place.

•

Blue on a component indicates touch points, where you can grip the component

to remove it from or install it in the compute node or

Lenovo

Flex System chassis,

open or close a latch, and so on.

•

Orange on a component or an orange label on or near a component on the

switch, compute node, or

Lenovo

Flex System chassis indicates that the

component can be hot-swapped, which means that if the

Lenovo

Flex System

chassis and operating system support hot-swap capability, you can remove or

install the component while the

Lenovo

Flex System chassis is running. (Orange

can also indicate touch points on hot-swap components.) See the instructions for

removing or installing a specific hot-swap component for any additional

procedures that you might have to perform before you remove or install the

component.

•

You do not have to turn off the

Lenovo

Flex System chassis to install or replace

any of the hot-swap modules on the front or rear of the

Lenovo

Flex System

chassis.

•

When you install the switch in the

Lenovo

Flex System chassis, you must also

install a compatible I/O network adapter in the compute node to support the

switch.

•

When you are finished working on the compute node or

Lenovo

Flex System

chassis, reinstall all safety shields, guards, labels, and ground wires.

Table 1. Important product information

Product Name Lenovo Flex System Fabric EN4093R 10 Gb Scalable

Switch

Serial Number

Part Number

Media Access Control (MAC)

address for switch

MAC addresses for other

components

System Reliability Guidelines

To help ensure proper cooling, performance, and system reliability, make sure that

the following requirements are met:

•

Each of the bays on the rear of the

Lenovo

Flex System chassis contains either

a module or a filler module.

•

A removed hot-swap module is replaced with an identical module or filler module

within one minute of removal.

•

A removed hot-swap compute node is replaced with another compute node or

filler node within one minute of removal.

•

The ventilation areas on the sides of the compute node are not blocked.

•

You have followed the reliability guidelines in the documentation that comes with

the

Lenovo

Flex System chassis.

Handling Static-Sensitive Devices

Attention:

Static electricity can damage the switch and other electronic devices. To

avoid damage, keep static-sensitive devices in their static-protective packages until

you are ready to install them.

To reduce the possibility of electrostatic discharge, observe the following

precautions:

•

Limit your movement. Movement can cause static electricity to build up around

you.

•

The use of a grounding system is recommended. For example, wear an

electrostatic-discharge wrist strap, if one is available.

•

Handle the device carefully, holding it by its edges or its frame.

•

Do not touch solder joints, pins, or exposed printed circuitry.

•

Do not leave the device where others can handle and damage it.

•

While the device is still in its static-protective package, touch it to an unpainted

metal part of any unpainted metal surface on a grounded rack component in the

rack in which you are installing the device, for at least two seconds. This drains

static electricity from the package and from your body.

•

Remove the device from its package and install it directly into the switch without

setting it down. If it is necessary to set down the device, put it back into its

static-protective package. Do not place the device on a switch cover or on a

metal surface.

•

Take additional care when you handle devices during cold weather. Heating

reduces indoor humidity and increases static electricity.

•

Some types of

Lenovo

Flex System chassis come with electrostatic discharge

(ESD) connectors. If your unit is equipped with an ESD connector, see the

documentation that comes with the

Lenovo

Flex System chassis for using the

ESD connector.

18 EN4093R 10 Gb Scalable Switch User’s Guide

Installing the EN4093R

Note: The following illustration shows how to install the switch in a

Lenovo

Flex

System chassis. The appearance of your

Lenovo

Flex System chassis might

be different; see the documentation for your

Lenovo

Flex System chassis for

additional information.

Use the following instructions to install the switch in the Lenovo Flex System

chassis. You can install the switch while the Lenovo Flex System chassis is powered

on. For redundancy support, you must install I/O modules of the same type in I/O

bays 1 and 2, and I/O modules of the same type in bays 3 and 4 of the chassis.

To install the switch, complete the following steps.

1. Read the safety information that begins on

page 5

and “Installation Guidelines”

on page 16.

2. Select I/O bay in which to install the switch.

Note:

For details about I/O bay requirements and bay locations, see the

documentation for the

Lenovo

Flex System chassis.

3. Remove the filler module from the selected bay. Store the filler module for

future use.

4. If you have not already done so, touch the static-protective package that

contains the switch to an unpainted metal surface of the

Lenovo

Flex System

chassis or an unpainted metal surface on any other grounded rack-component

for at least 2 seconds.

5. Remove the switch from its static-protective package.

6. Make sure that the release levers on the switch are in the open position

(perpendicular to the switch).

7. Slide the switch into the applicable I/O bay until it stops.

8. Push the release levers on the front of the switch to the closed position. After

you insert and lock the switch, it is turned on (there may be a slight delay), and

a Power-On Self-Test (POST) occurs to verify that the switch is operating

correctly.

Note:

The switch may take up to two minutes to complete the POST. During

POST, the Power LED continuously flashes. Once POST has successfully

completed, the Power LED remains on and the Error LED is off.

9. Make sure that LEDs on the switch indicate that it is operating correctly (see

“Information LEDs” on page 30).

10. If you have another switch to install, repeat Step 3 through Step 9; otherwise,

go to the next step.

11. Install any port transceiver modules or Direct-Attach Cables (DACs) needed for

the switch. For information and instructions, see “Connecting Switch Ports” on

page 21 and the documentation that comes with the transceiver modules or

DACs.

12. Attach any cables that are required by the switch. For additional information

about cabling the switch, see “Connecting Switch Ports” on page 21, the

documentation that comes with the port transceiver modules, DACs, cables,

and the optional network devices to which the cables are connected.

13. Make sure that the data (non-management) ports on the switch are enabled

through the Chassis Management Module (CMM).

20 EN4093R 10 Gb Scalable Switch User’s Guide

Removing or Replacing the Switch

Note: The following illustration shows how to remove and replace the switch from

the

Lenovo

Flex System chassis. The appearance of your

Lenovo

Flex

System chassis might be different; see the documentation for your

Lenovo

Flex System chassis for additional information.

To replace the switch, complete the following steps.

1. Read the safety information that begins on

page 5

, and “Installation Guidelines”

on page 16.

2. Detach any cables that are attached to the switch you will be removing.

Note:

Detaching cables from the switch ports disrupts the network connection

from the switch to any connected external devices. If you plan to replace

the switch with another switch, you can reuse the existing cables, provided

they remains securely attached to the network.

3. Pull the release latches out from the switch. The switch moves out of the bay

approximately 0.6 cm (0.25 inch).

4. Slide the switch out of the bay and set it aside in a safe, static-free location.

5. Place either another switch or a filler module in the bay.

Important:

Complete this step within 1 minute. For more information, see

“Installing the EN4093R” on page 18.

6. If you placed the switch in the bay, reconnect the ports that you disconnected in

Step 2

and attach any additional cables that are required by the switch.

For additional information about connecting ports, see “Connecting Switch

Ports” on page 21, and also the documentation that comes with the port

transceiver modules, DACs, cables, and the optional network devices to which

the cables have been connected.

Page is loading ...

Lenovo Flex System Fabric EN4093R User manual

Lenovo Flex System Fabric EN4093R User manual

Lenovo Flex System Fabric EN4093R User manual

Related papers

Other documents
