ENGLISH

36

Safety instructions

Important Safety Instructions. Please read

the instructions carefully and keep them for

later use.

CAUTION

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

WARNING: SHOCK HAZARD - DO NOT OPEN

AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR

The lightning ﬂash with arrow

head within an equilateral triangle

is intended to alert the user to the

presence of uninsulated “dangerousvoltage”

within the product’s enclosure that may be

of su cient magnitude to constitute a risk of

electric shock to persons and animals.

The exclamation point within an

equilateral triangle is intended to

alert the user to the presence of

important operating and maintenance in-

structions in the literature accompanying the

device.

For safety reasons, this class II

product is provided with double or

reinforced insulation as indicated

by this symbol.

Danger! Excessive sound pressure

from earphones and headphones

can cause hearing loss. If you listen

to loud music for a long time, your hearing

may be impaired. Set to a moderate volume.

• This product is only intended for audio

entertainment. Do not use the product for

any other purpose than described in this

manual in order to avoid any hazardous

situation. Improper use is dangerous and

will void any warranty claim.

• For household use only. Do not use

outdoors.

• Danger of suocation! Keep all packag-

ing material away from children.

• Only use under normal room temperature

and humidity conditions.

• The product is only suitable for use at

moderate degrees of latitude. Do not

use in the tropics or in particularly humid

climates.

• Do not move the product from cold into

warm places and vice versa. Condensa-

tion can cause damage to the product

and electrical parts.

• Do not use attachments or accessories

other than recommended by the manu-

facturer or sold with this product. Install in

accordance with this user manual.

• When installing the product, leave suf-

ﬁcient space for ventilation (minimum

10cm around the product). Do not install

in bookcases, built-in cabinets or the like.

• Do not impede ventilation by covering the

ventilation openings with items, such as

newspapers, table-cloths, curtains, etc.

Do not insert any objects.

• Do not install near any heat sources such

as radiators, heat registers, stoves or

other products (including ampliﬁers) that

produce heat.

• Do not shift or move the product when

powered on.

• Do not touch, push or rub the surface

of the product with any sharp or hard

objects.

• Danger! To reduce the risk of ﬁre or elec-

tric shock, do not expose this product to

rain or moisture.

• The product shall not be exposed to

dripping or splashing and no objects

ﬁlled with liquids, such as vases, shall be

placed on the product.

• Care should be taken so that no objects

or liquids enter the enclosure through

openings.

• No naked ﬂame sources, such as light-

ed candles, should be placed on the

product.

• Refer all servicing to authorised service

agent. Do not attempt to repair the prod-

uct yourself. Servicing is required when

the product has been damaged in any

way, such as the supply cord or plug are

IM_PDR210-B/W_140618_V02_HR_1.indb 36 23/6/14 10:58 AM

37

ENGLISH

damaged, liquid has been spilled, objects

have fallen into the product, the enclo-

sure is damaged, the product has been

exposed to rain or moisture, does not op-

erate normally, or has been dropped.

• Before connecting the product to a sock-

et outlet, make sure the voltage indicated

on the product corresponds to your local

mains.

• Only use the provided adaptor.

• Only use the adapter that matches the

technical data.

• The adaptor power plug is used as the

disconnect device; the disconnect device

shall remain readily operable. To com-

pletely disconnect the power input, dis-

connect the adaptor power plug.

• The product may not function properly or

not react to the operation of any control

due to electrostatic discharge. Switch o

and disconnect the appliance; reconnect

after a few seconds.

• Protect the supply cord from being

walked on or pinched particularly at the

plug, convenience receptacles and the

point where it exits from the product.

• Disconnect the adaptor power plug in

case of faults during use, during lighten-

ing storms, before cleaning and when not

using the product for a longer period of

time.

• Danger! Before cleaning, switch the

product o and disconnect the adaptor

power plug from the socket.

• When the product has reached the end

of its service life, make it defective by dis-

connecting the adaptor power plug from

the socket and cutting the cord in two.

• Caution! There is danger of explosion

from improper replacement of the batter-

ies. Replace batteries only with the same

or equivalent type of battery.

• Always change the entire battery pack.

Do not mix old and new batteries, or bat-

teries with dierent charge state.

• Make sure the batteries are correctly in-

serted. Observe the polarity (+) plus / (-)

negative on the battery and the housing.

Improperly inserted batteries can lead to

leakage or, in extreme cases, a ﬁre or an

explosion.

• Never expose batteries to excessive

heat (e.g. bright sun, ﬁre), and never

throw them into ﬁre. The batteries could

explode.

• Remove used batteries. Remove the bat-

teries if you know that the product will

not be used for a longer period of time.

Otherwise, the batteries could leak and

cause damage.

• Keep batteries out of reach of small chil-

dren. If batteries have been swallowed,

seek immediate medical attention.

• Non-rechargeable batteries must not be

recharged.

• If the batteries leak, remove them with a

cloth and dispose of them accordingly.

Prevent battery acid from coming into

contact with skin and eyes. If you do

get battery acid in your eyes, ﬂush them

thoroughly with lots of water and consult

a physician immediately. If battery acid

comes into contact with your skin, wash

the aected area with lots of water and

soap.

IM_PDR210-B/W_140618_V02_HR_1.indb 37 23/6/14 10:58 AM

ENGLISH

38

Partlist

1

2

3

4

5

6

13

14 15 16

17

12

11

10

9

8

7

1 Display

2 MODE button

3 button

4 INFO button

5 BACK button

6 SELECT knob

7 Speaker

8 USB port

9 DC IN jack

10 MEMORY button

11 VOLUME - button

12 VOLUME + button

13 MENU button

14 Headphone jack

15 AUX IN jack

16 LAN socket

17 Telescope antenna

Accessories

1 x AC/DC Adaptor

1 x Remote control

1 x User manual

1 x Quick Manual Guide

IM_PDR210-B/W_140618_V02_HR_1.indb 38 23/6/14 10:58 AM

39

ENGLISH

View station/track info

Sleep/snooze mode

Change mode

Set up/call up alarm

Play/pause

Fast forward/Next

Select

Increase volume +

Battery compartment

Decrease volume –

Set up/call up memory

Turn o the sound

Fast rewind/Previous

Go to menu

navigation control

turn on / standby

Note

The keys on the remote control function the same way as the keys on the device. All main

functions can be accessed with the remote control. If the remote control does not work,

please check the followings:

– If there any object between the product and remote control causing obstruction.

– Try to darken the room or to reduce the distance between device and remote control.

– Batteries are installed with correct polarity (+ to +,- to -)?

– Try with brand new batteries.

Remote control

IM_PDR210-B/W_140618_V02_HR_1.indb 39 23/6/14 10:58 AM

ENGLISH

40

Connections

POWER SUPPLY

Connect the DC connector of the adaptor to

the DC IN-jack. Plug the adaptor to a power

socket.

AUX-IN

You can also listen to external audio devices

by connecting the cable (not included) to the

AUX-IN jack at the back of the product.

USB CONNECTION

Playback of music ﬁles

You can playback music ﬁles which are

saved on an USB stick by plug in the USB

stick.

Charging external devices

External devices can be charged via USB

with this speaker. Connect the device to the

USB port (output: 5V/ 1000mA)

LAN CONNECTION

Socket of LAN / Ethernet cable connection

for the cable connection of the device with

the cable-connected home network.

INSERTING BATTERY

1

2

Slide the battery compartment cover in the

direction of the arrow and pull it out. Insert

the new battery (CR2032, 3 V ) , paying

attention to correct polarity. Slide the battery

compartment cover back on and let it snap

into place.

Note

Remove the battery protection strip before

ﬁrst use.

IM_PDR210-B/W_140618_V02_HR_1.indb 40 23/6/14 10:58 AM

41

ENGLISH

Internet-radio conﬁgurationOperation

TURNING THE UNIT ON

Press the button to switch on the unit.

ADJUSTING THE ANTENNA

For optimal reception, extend the antenna,

move to fully extend and adjust it.

ADJUSTING THE VOLUME

The volume can be adjusted during playback

with the volume control.

There are two ways to connect the radio to

the internet using an access point:

• Wireless in WLAN-Mode

The WiFi-antenna of the radio receives

your DSL router signals.

• With cable using the radio’s LAN con-

nection in LAN-Mode

provided an ethernet network is

available.

WLAN-MODE CONFIGURATION

If you have a wireless network, the WLAN

mode is the direct way to connect your radio

to the Internet:

1. Simply switch the radio on and, as a

cable-free network client, it automati-

cally searches all available APs (Access

Points).

2. When switching on for the ﬁrst time, you

must conﬁrm the AP and perhaps enter

the key. After that, the radio will always

access this AP. If the AP can no longer

be found, it will be registered accordingly.

LAN CONFIGURATION

If you do not have a wireless network but do

have a cabled network, you can connect the

Internet radio with a network.

1. Switch the radio o.

2. Connect an Ethernet cable to the LAN

socket. Once switched on and choose

wired. The radio will automatically be

recognized as a cable client.

IM_PDR210-B/W_140618_V02_HR_1.indb 41 23/6/14 10:58 AM

ENGLISH

42

WLAN-REGION AND WLAN-NETWORK

• Select the WLAN-Region in which you

are located. The device then looks for

available wireless networks. If a wireless

network is not found, the device shows

the notiﬁcations <No WLAN network

found>. Please check in this case wheth-

er your router and WLAN are switched

on.

Note

Make sure that the DHCP-server of your

router (Access Point) is activated. Otherwise,

the WLAN connection must be conﬁgured

manually. The WLAN should send out the

SSID. If the SSID is not sent out, you must

conﬁgure the WLAN manually.

• Select the network from which you want

to operate Internet radio.

PUBLIC NETWORK CONNECTION

Select the appropriate WLAN-network by

clicking on the entry of the network’s name.

The connection procedure takes place

automatically.

Note

In the Systems settings > Setup wizard , you

can manually conﬁgure the network.

PRIVATE NETWORK CONNECTION

Select WPS connection type

If a network is protected by a WEP or WPA

encryption, the query for constructing a con-

nection over WPS (Wi-Fi Protected Setup)

appears. If the router of your wireless net-

work has a WPS function, select whether the

WPS connection should be established by

entering a PIN code over the WPS key on

the router.

WPS connection using PIN entry

A WPS-PIN appears in the Internet radio dis-

play. Enter this PIN and conﬁrm the Internet

radio with OK. The WPS connection will then

be established.

Connection using WPS key

Press the WPS key on the router and then

conﬁrm the display on Internet radio with

SELECT. The WPS connection is then

established.

CONNECTION USING THE DIRECT EN-

TROY OF THE NETWORK KEY

If you do not want to establish any connec-

tion using the WPS, select the entry, No

WPS and then enter the network key in the

following dialogue. Conﬁrm the entry with

SELECT.

IM_PDR210-B/W_140618_V02_HR_1.indb 42 23/6/14 10:58 AM

43

ENGLISH

COMPLETING THE WLAN CONNECTION

1. The connection begins. The device

should now establish a connection with

the WLAN. Once the connection has

been established, the notiﬁcation <Set-

up-Assistant is ﬁnished> appears.

Conﬁrm the display with SELECT.

2. If the WLAN cannot be accessed (e.g.

locked for new WLAN devices) the failure

notiﬁcation “Connection not successful”

appears.

3. In this case, check the setting of your

WLAN-router.

Note

The entered password (WEP/WPA key) will

be saved and will not need to be entered

again.

After a successful set-up and connection,

the following display appears:

MODE

Press MODE to select between:

– Internet radio

– Music Player

– FM radio

– AUX in

To choose the desired mode you also can

call up the main menu:

1. Press MENU in any mode setting

2. Select Main menu

IM_PDR210-B/W_140618_V02_HR_1.indb 43 23/6/14 10:58 AM

ENGLISH

44

INTERNET RADIO

Press MENU in any mode setting or directly

press MODE to call up Internet radio.

STATION LIST

MY FAVOURITES

To store a playing station as a favourite:

1. Press and hold “SELECT” until the dis-

play shows ‘Favourite added’.

2. The station appears in the default favour-

ites list Stations.

To select a favourite

1. Select “MENU” and choose “Station list”.

2. Choose “My Favourites” to get the

favourites list.

3. Select a station from the favourites list.

LOCAL STATIONS (REGION)

Here all stations from the selected region are

listed according to genre.

STATIONS (SELECTING STATION)

You can see all available stations by country

(Location), popularity (Popular stations) or

timeliness list (New stations).

1. Select Stations

2. Now you can select your station under

the speciﬁed options.

SENDER SELECTION VIA PODCAST

Here you can list all Podcasts according to

genre and country.

1. Select Podcast and press SELECT, in

order to conﬁrm the selection

2. Select a desired subfolder.

Note

You can register for free via the website

http://www.wiﬁradio-frontier.com. This is

where you can register your Internet radio

using the access code. You receive the

access code in the following menu point

“HELP”. Via this website, you can create

IM_PDR210-B/W_140618_V02_HR_1.indb 44 23/6/14 10:58 AM

45

ENGLISH

groupings for favourites lists, add new Inter-

net radio stations for your Internet radio and

synchronise your station lists with other in-

ternet radios.

MY ADDED STATIONS

If you have saved Podcasts via the website

http://www.wiﬁradio-frontier.com, you can

call them up here.

HELP

Select this entry to receive the access code

for your Internet radio with which you can

register yourself on the website http://www.

wiﬁradio-frontier.com.

MUSIC PLAYER

Your Internet radio supports the UPnP-Pro-

tocol “Universal Plug-and-Play” and DLNA

(Digital Living Network Alliance). You can

transfer audio ﬁles to your PC wirelessly to

your Internet radio if a UPnP software is in-

stalled. Using the UPnP / DLNA protocol, the

Internet radio can be used as Digital Media

Renderer (DMR). So you can play music ﬁles

from UPnP / DLNA compliant devices on the

Internet and radio, and, for example, adjust

the volume from the computer.

CONNECTING MEDIAPLAYER

Connection Between Internet radio and a

Media Server (NAS-Server, UPnP/DLNA

Compatible Server)

1. Open the main menu and select Music

Player.

2. Select from there the entry Media Li-

brary/Library, in order to ﬁnd available

media servers.

3. The radio starts the initialisation process.

4. After a few seconds, the media server

name is inserted provided it has been

found: “PC_Name: Media Server-Name”

5. If you want to connect the media server

with the radio, click on the entry of the

server.

Note

You might need to conﬁrm and allow the

connection on your PC.

PLAYING AUDIO FILES

1. In order to listen to audio ﬁles from the

network select the function Music Play-

er in the main menu or press MODE on

remote control.

2. Select Shared media to start the music

selection.

IM_PDR210-B/W_140618_V02_HR_1.indb 45 23/6/14 10:58 AM

ENGLISH

46

Setting FM radio stations

1. Press MODE to select FM radio stations.

2. The radio changes to the last selected

station.

Note

When you switch on the radio for the ﬁrst

time, it conducts an automatic search of FM

radio stations.

FREQUENCY SETTINGS

Set an FM radio station.

Manual frequency setting

Rotate SELECT knob to change the fre-

quency in 0.05 MHz steps.

Automatic frequency setting

Press SELECT and the radio stops search-

ing if an active station is found.

SAVING FM RADION STATIONS

You can save a maximum of 10 pre-set FM

radio stations.

1. Set the desired FM station.

2. Press and hold MEMORY and rotate

SELECT knob to pre-set a number 1

- 10.

3. Press MEMORY to conﬁrm the entry.

4. The pre-set number of the saved station

is shown.

FM RADIO STATION SELECTION

1. Press MEMORY to call up the pre-set

menu.

2. Select a pre-set number with SELECT

knob and conﬁrm the selection by press-

ing the SELECT knob.

SCAN SETTING

1. Press MENU and Scan Setting will be

displayed.

2. Press SELECT knob to conﬁrm the

selection.

IM_PDR210-B/W_140618_V02_HR_1.indb 46 23/6/14 10:58 AM

47

ENGLISH

AUX Mode

AUDIO SETTING

Selecting Mono or Stereo mode.

1. Press MENU.

2. Select the Audio Setting

USB Playback

1. Insert an USB Stick with MP3/WMA/

AAC music ﬁles.

2. Press MODE and select Music player.

3. Select USB playback.

4. Playback starts automatically and the

ﬁrst track will be played. If there is no

USB device connected, the message

NO USB device found will be displayed

on the screen.

Note

Connect the USB device directly to the

USB port of the unit. Using an extension

cable is not recommended and may cause

interference and failure of data transfer.

This product supports USB 1.1 and 2.0 up

to 32GB with ﬁle system FAT16 and FAT32.

1. Connect the audio cable (not included)

into the AUX IN jack (3.5 mm) at the rear

side of the device.

2. Press MODE to select AUX as a source.

3. Start playing from the device.

Attention

Check the safety and user instruction of the

external device before connection.

IM_PDR210-B/W_140618_V02_HR_1.indb 47 23/6/14 10:58 AM

ENGLISH

48

Time and Alarm settings

TIME SETTING

1. Press MENU in any mode setting and

select System settings.

2. Select Time/Date.

3. Press SELECT to conﬁrm the selection.

4. Select the desired submenu with the

SELECT knob:

• Set Time/Date:

Manual time and date setting

• Auto update:

Selection between update from FM,

Network and No update

• Set format:

Selection between 12/24 hour format

• Set time zone:

- Set daylight savings

SETTING ALARM

1. Press MENU in any mode setting and

select Main menu.

2. Select Alarms.

3. Select Alarm 1 or 2 in the main menu

or press ALARM button on the remote

control.

4. Select one of the two waking times in

order to save it:

Enable

Select how the alarm clock should be

switched on:

• Select o to deactivate the alarm.

• Select daily, once, weekend or week

days to activate the alarm.

Time

Set the time at which the alarm should be

set.

Mode

Select the mode for the alarm clock here:

• FM: Wake up with FM-Radio

• Internet Radio: Wake up with Internet

radio

• Buzzer: Wake up with alarm tone

Volume (0-32)

Here you can set the volume with which the

alarm clock will be switched on.

Save

Save the alarm setting.

Note: During alarm you can change the

snooze period by repeatedly pressing on the

SNOOZE button on the remote control.

SWITCHING OFF THE ALARM TONE

Once the alarm sounds, press

and the

alarm is switched o.

IM_PDR210-B/W_140618_V02_HR_1.indb 48 23/6/14 10:58 AM

49

ENGLISH

General Settings

SETTING THE SLEEP-TIMERS

Select Sleep in the main menu or press

SLEEP button repeatedly on the remote

control.

Press Sleep to select a period of time:

• [15 MINS]

• [30 MINS]

• [45 MINS]

• [60 MINS]

• [75 MINS]

• [90 MINS]

• [OFF]

If the sleep timer is not pre-selected, the de-

fault setting is OFF.

SYSTEM SETTINGS

To enter the System setting press MENU at

any mode.

Menu > System settings

1. Press MENU and select System settings.

2. The submenu will then be displayed.

EQUALISER

Here you can select pre-set sound formats

or create one of your own.

Select a sound format:

Normal, Flat, Jazz, Rock, Movie, Classic,

Pop, News, My EQ

The sound setting is accepted right away.

In My EQ proﬁle set up setting, you can

create your own setting for the sound.

Network Selection

Select this entry to display the list of net-

works with which the Internet radio can es-

tablish an automatic connection or select the

entry network assistant to search available

networks.

TIME/DATE

Follow the instructions in the section on set-

ting time.

IM_PDR210-B/W_140618_V02_HR_1.indb 49 23/6/14 10:58 AM

ENGLISH

50

Cleaning and care

LANGUAGE SELECTION

1. Press MENU and enter System settings

to select the submenu LANGUAGE.

2. Select a language.

FACTORY SETTING

Press MENU and enter System settings to

select the submenu FACTORY RESET. Press

SELECT knob to conﬁrm the selection.

UPDATING THE SOFTWARE

You can search software updates with the

product. Once you have accepted the con-

ditions for use, the download and installation

procedure for the new software updates be-

gins automatically.

Note

Make sure that the product is connected to

the Internet.

SETUP WIZARD

Press MENU and enter System settings to

select the submenu SETUP WIZARD. You

can set up all settings important for bringing

radio into operation

INFO

Here you can ﬁnd the version number of the

currently used software.

• Always pull the power plug from the pow-

er outlet before cleaning.

• Caution! Water must not enter the device.

• Clean the housing with a slightly damp

cloth.

• Do not use any sharp, abrasive or aggres-

sive cleaning agents.

• Do not use any chemicals (e. g. gas, alco-

hol) to clean the housing.

Disposal

Do not dispose of this appliance as

unsorted municipal waste. Return it

to a designated collection point for

the recycling of WEEE. By doing so, you will

help to conserve resources and protect the

environment. Contact your retailer or local

authorities for more information.

Please dispose of batteries in an

environmentally friendly manner Do

not put batteries into the household

waste. Please use the return and collection

systems in your community or contact the

dealer where you purchased the product.

IM_PDR210-B/W_140618_V02_HR_1.indb 50 23/6/14 10:58 AM

51

ENGLISH

Technical Data

Power supply

AC/DC Adaptor

Input

Output

Batteries (Remote Control)

Main unit

Input

Power consumption

USB port charging

Output

Tuner FM

Tuning Range

Tuning Grid

Speaker

Output power (RMS)

Sound System

Connectivity

USB

AUX

Dimension (W x H x D)

Weight

100-240 V~, 50/60 Hz, 0.65 A

12 V, 1.5 A

1 x CR2032 (3 V )

12 V , 1.5 A

18 W

5V/ 1000 mA

87.5-108 MHz

0.05 MHz

5 W

Mono

YES

approx. 115 x 190 x 128 mm

approx. 1.3 kg

IM_PDR210-B/W_140618_V02_HR_1.indb 51 23/6/14 10:58 AM

Page is loading ...

WWW.peaq-online.com

Imtron GmbH

Wankelstraße 5

D-85046 Ingolstadt

www.imtron.eu

IM_PDR210-B/W_140623_V02

IM_PDR210-B/W_140618_V02_HR_1.indb 101 23/6/14 10:59 AM

PEAQ PDR210 W Owner's manual

This manual is also suitable for

PEAQ PDR210 W Owner's manual

in other languages

Related papers

Other documents
