UG:306 Page 1
PI3740-00-EVAL1, -EVAL2
Cool-Power
®
ZVS Switching Regulators
Buck-Boost Evaluation Board User Guide
Introduction
The PI3740-00 evaluation board comes in two versions, EVAL1 and EVAL2. EVAL1 should be used to
evaluate the PI3740 in constant voltage or standard constant current applications where V
OUT
is above
8V. EVAL2 is designed for specialized constant current applications using high-side current sense where
V
OUT
is below 8V. These boards have been designed to showcase various constant voltage and constant
current applications and can be configured with a few selectable jumpers. This guide will walk the user
through the various options.
The PI3740-00-LGIZ is a high efficiency, wide input range DC-DC ZVS Buck-Boost regulator with
integrated controller, power switches, and support components all within a high density
0.4” x 0.55” System-in-Package (SiP). The evaluation board measures 2.5”x2.25” and contains all
the components necessary for a variety of applications. Not all components will be needed for
all applications.
Part Ordering Information
The customer evaluation boards can be ordered following the link to Vicors step down regulators Cool
Power products listing.
USER GUIDE | UG:306
Introduction 1
Part Ordering Information 1
Box Contents 2
Features 3
General Information 3
Power Up Procedure 3
Constant Voltage Operation
(EVAL1) 4
Constant Current Operation
(EVAL1, EVAL2) 4
Constant Current Float
Voltage Adjustment 4
Adjusting the Charging
Current 5
Constant Current
Configuration #1:
(PI3740-00-EVAL1 Board) 5
Constant Current
Configuration #2:
(PI3740-00-EVAL1 Board) 6
Constant Current
Configuration #3:
(PI3740-00-EVAL1 Board) 7
Constant Current
Configuration #4:
(PI3740-00-EVAL2 Board) 8
Current Sense Element in
Each Board 8
Only One Current Sense
Element 8
Stability 8
Test Points 9
Schematics 10
Bill of Materials 12
Additional or Changed
Components for
PI3740-00-EVAL2 Board 14
Contents Page
UG:306 Page 2
IMPORTANT NOTICE:
Be sure to read the precautions below entirely BEFORE using the evaluation board. Do not operate the
evaluation board unless you have the appropriate safety precautions in place on your bench to ensure a
successful experience.
The list below is not comprehensive and is not a substitute for common sense and good practice.
When testing electronic products always use approved safety glasses. Follow good laboratory practice
and procedures.
During operation, insure the power devices and surrounding structures can be operated safely.
Care should be taken to protect the user from accidental contact when under power.
Provide a strain relief for wires and place the system on the bench in such a way as to prevent
accidental displacement from bench top.
Review thermal consideration and guideline associated with operating the evaluation board. Most
notably use a bench top fan and use rubber feet to elevate the PCB as they allow air flow
to the bottom.
Remove power and use caution when connecting and disconnecting test probes and interface lines
to avoid inadvertent short circuits and contact with hot surfaces.
Verify power connections to avoid reversing applied voltage polarities.
Avoid creating ground loops between the SGND and PGND pins when making measurements.
The product evaluation board is designed for general laboratory evaluation. It is not recommended
for installation in end user equipment.
Refer to the specific regulator module data sheet for electrical rating of the device, thermal and
mechanical product details. It is important to remain within the device rated range when testing.
The evaluation board is designed for user convenience to evaluate the performance of Vicors mounted
ZVS Buck-Boost product. Sockets are provided to permit quick probing. The evaluation board provides
lugs and top layer banana jack footprint for input and output connections, signal connectors allowing
wire, signal test points for easy connection to standard test equipment, and Kelvin Johnson-Jack for
accurate voltage measurements of power nodes.
Box Contents
The evaluation board ships with the following contents:
1 x PI3740-00-EVAL1 or PI3740-00-EVAL2 customer evaluation board
8 x jumpers
UG:306 Page 3
Features
1. Input and output lugs for source and load connections.
2. Location to place through-hole input aluminum-electrolytic capacitor. (CIN3)
3. Input source filter (L1, L200, RIN)
4. Oscilloscope probe jack for accurate, high frequency output (JV
OUT
) and input (JV
IN
) voltage
measurements.
5. Signal pins test points and wire connectors.
6. Kelvin voltage test points and sockets for all pins of PI3740.
7. Jumper selectable High Side / Low Side current sensing
8. Jumper selectable float voltage.
General Information
V
IN
Range: 8 – 60V
DC
V
OUT
Range: 10 – 50V
DC
(for constant voltage operation)
Output Power: 50 – 140W*
*See PI3740-00 data sheet for maximum power rating at your particular input and output voltages.
Power Up Procedure
1. Ensure the jumpers are installed as shown in the following pictures depending on which
configuration is chosen.
2. Connect the load as shown in the following pictures making sure of the polarity. (Positive to V
OUT
and negative to GND or BAT-)
3. Connect the input source making sure of the polarity. ( Positive to +V
IN
and negative to GND)
4. Turn-on input source ensuring it is within the range indicated in the general information section.
UG:306 Page 4
Constant Voltage Operation (EVAL1)
For constant voltage operation install JLGH, JPG, JISP, JISN as shown in Figure 1. The regulated output
voltage can be adjusted by changing REA1 per the following equation.
V
FLOAT
= (1.5887*REA1) + 1.7 where REA1 is in kΩ. With the present values, the output
voltage is about 24V.
Note: During constant voltage operation, short VSP to VDR to ensure the PI3740 internal amplifier does not affect
performance.
Constant Current Operation (EVAL1, EVAL2)
Constant Current mode is required for battery and super capacitor charging applications. Both EVAL1
and EVAL2 can be configured for constant current operation. EVAL1 should be the default board for
all constant current applications with the exception of high side current sense applications where V
OUT
can drop below 8V. Both evaluation boards can be configured to operate in a typical CC/CV charging
scheme where the regulator output starts out in CC mode and then transitions to CV mode as soon as
the battery voltage reached a predetermined float voltage.
Constant Current Float Voltage Adjustment
The float voltage or the voltage where the converter transitions to constant voltage mode, can be
adjusted by changing REA1 per the following equation.
Vfloat = (1.5887*REA1) + 1.7 where REA1 is in kΩ. The board is shipped with REA1 = 14kΩ which
sets the float voltage to 24V. The board is also shipped for easy configuration for V
OUT
values
of 48V and 12V.
To configure for one of these preset values simply remove REA1 and place a jumper on J302 for 48V
OUT
or J303 for 12V
OUT
.
Figure 1
Jumper Placement for Constant
Voltage Operation (EVAL1)
Figure 2
Jumper Locations for Preset
J302 48V
OUT
(shown)
or J303 12V
OUT
UG:306 Page 5
Constant Current Configuration #1: (PI3740-00-EVAL1 Board)
Low Side Current Sense Using PI3740 Internal Amplifier
This configuration senses the current through R106 and uses the internal general purpose amplifier of
the PI3740 to regulate the current. The jumpers need to be installed as shown. This configuration can
be used for super-cap charging as well as battery charging. The benefit of this configuration is that you
can use a standard value current sense resistor and adjust the current by changing a single 0603 resistor.
It does require 6 resistors and a reference to implement the circuit. These components are contained
within the evaluation board.
Install: JSHUNT, JVSN, JVSP, JLGH, JGP. Also install JISP & JISN between the 2 pins closest to JGP. This
will short IS+ and IS- to ground.
Adjusting the Charging Current
The charging current can be adjusted by changing R104 per the following equation.
Icharge= (0.62-(62µA*R104))/R106. In this example it would be: (0.62-(62µA*5.11k)/0.1 or 3.03A
LOAD
V
IN
Figure 3
Jumper Placement for
Constant Current Operation
Configuration #1 (EVAL1)
UG:306 Page 6
Constant Current Configuration #2: (PI3740-00-EVAL1 Board)
High Side Current Sense Using R
SENSE
For customers who prefer high-side current sense, this configuration senses the current through R
SENSE
and uses the internal Imon amplifier and the LGH pin of the PI3740. The LGH pin is the inverting
input to an amplifier which has a 0.1V reference. Including R
SENSE
, only 4 components are required
for the current control loop. V
OUT
minimum is 8V due to the common mode range of the IMON
amplifier. This configuration cannot be used for super cap charging.
Install jumpers as shown.
Install: JISP, JISN connecting RSENSE to IS+ and IS-, J200 connecting IMON to LGH, JTRK.
Charging Current: The LGH amplifier has a reference of 100mv nominally. The Imon amplifier has a
gain of 20. So the voltage across R
SENSE
will be 5mv when the circuit is active. Therefore, the current will
be approximately 5mv/R
SENSE
.
Figure 4
Jumper Placement for
Constant Current Operation
Configuration #2 (EVAL1)
UG:306 Page 7
Constant Current Configuration #3: (PI3740-00-EVAL1 Board)
Low Side Current Sense and LGH
Current is sensed through R106 and, through a compensation network, fed into the LGH pin. This
is a low-side current sense configuration which requires only 4 components including the current
sense resistor.
Install jumpers as shown.
Install: J200 connecting R106 to R205/R206, JTRK, JISP and JISN shorting IS+ and IS- to ground.
Charging Current: The charging current will be approximately 100mv/R106. If a standard resistor value
cannot be found that gives you the required current, use configuration #1.
Figure 5
Jumper Placement for
Constant Current Operation
Configuration #3 (EVAL1)
UG:306 Page 8
Constant Current Configuration #4: (PI3740-00-EVAL2 Board)
High Side Current Sense Using INA193 and LGH
For applications where V
OUT
is below 8V and high side current sense is preferred, this
configuration must be used. This configuration senses current through R
SENSE
and the output of the
INA193 is fed into the LGH pin through a compensation network. The minimum recommended R
SENSE
is
20mΩ. The maximum output voltage in this configuration remains 50V
DC
.
Install jumpers as shown.
Install: J301, JTRK, JISP and JISN to connect IS+ and IS- to ground.
Charging Current: The INA193 has a gain of 20. The output of the INA193 is divided down by R301
and R302. The LGH voltage is 100mv. Therefore the charge current is approximately
(100mv*8/20)/R
SENSE
, or 40mv/R
SENSE
.
Paralleling Boards
Current Sense Element in Each Board
If more current is required than can be supplied by one board, two boards may be used in parallel.
Jumper the following pins together between boards; SGND, TRK, EAO, EN. Use short, low impedance
jumpers especially on the SGND and EAO pins.
Only One Current Sense Element
If only one board has a current-sense resistor, the LGH pins must also be connected together. Also,
the connection to IMON, on the board which does not have the current-sense resistor, must be
opened. (Remove J200).
Stability
The both evaluation boards are designed to be stable in a wide variety of applications. If instability is
seen in your application, contact Vicor’s application support for assistance.
Figure 6
Jumper Placement for
Constant Current Operation
Configuration #4 (EVAL2)
UG:306 Page 9
Table 1
Test Point Descriptions
Test Points
Reference Designator/
Functional Name
Description
VIN_F Input voltage test point close to VIN of the PI3740.
+VOUT SENSE1
–VOUT SENSE 1
Output voltage test points.
VDR
A 5.1V auxiliary supply with max loading of 2mA. If used this pin must have a se-
ries resistance such as R103 = 1kΩ with a decoupling cap of 0.1µF such as C124.
PGD
Power good indicator. During a regulator fault this pin is pulled internally to signal
ground.
EN
Input to the regulator. If left floating or driven high (VEN_MAX = 5.5V) regulator
will be enabled.
SGND Internal logic ground.
TRK
Soft-start and track input. An external capacitor may be connected between TRK
pin and SGND to increase the rise time of the internal reference during soft-start.
IMON Output of the internal current sense amplifier.
EAO
Error Amp output. External connection for additional compensation and current
sharing.
EXT_REF Error Amp Inverting Input separated with REA3 = 10kΩ.
VSP Non-inverting input to an independent amplifier.
VSN Inverting input to an independent amplifier.
VDIFF Output of the internal independent amplifier.
LGH Input for constant current amplifier.
SYNCO Synchronization Output.
SYNCI Synchronization Input.
UG:306 Page 10
ADDR0
ADDR1
EAIN
SYNCO
SYNCI
EAO
J2_1
PGD
VDR
-VO SENSE
VDR
SYNCO
SYNCI
PGD
ENABLE
COMP
TRK
SCL
SDA
VS1
VS2
EAO
TRK
SGND1
DNP
PG SENSE
VIN_F
LGH
A7
EN
A5
SYNCI
B1
VDIFF
A11
VS1
K4
EAIN
A12
VSP
A10
VSN
A9
COMP
A8
SYNCO
C1
SCL
A3
ADDR0
A2
ADDR1
A1
SDA
A4
TRK
A6
SGND
B14
EAO
A13
VDR
E1
VS1
K5
VOUT
J14
VOUT
K13
VIN
J1
PGD
D1
VIN
H1
PGND
K7
VIN
K1
VS2
K10
VIN
K2
VIN
G1
VOUT
H14
VOUT
G14
PGND
K8
VOUT
K14
VS2
K11
IMON
A14
IS+
E14
IS-
D14
PI37XX
CTRK
DNP
CCOMP
4.7nF
CEAO
DNP
10.0K
RPGD
ADDRO/FT2
ADDR1/FT1
CVDR
0.1uF
10.0K
RSYNCI
C7
4.7UF
1
J2
1
J3
1
J1
1
J4
PGND
VOUT
RSENSE
.0015
IMON
DNP
R1
DNP
R3
DNP
R2
DNP
R4
ADDR1ADDR0
VDR
IMON
JVIN
JVOUT
VSP
VDIFF
VSN
VSP
C6
.1uF
ISN
DNP
RIMON
.15
RIN
ISP
Tie
VSN
VDIFF
200K
RDIFF1
1 MEG
RDIFF2
14.0kREA1
1.07k
REA4
49.9
RGP
JGP
DNP
CEAIN1
DNP
EXT_VREF
10.0K
REA3
DNP
REA2
DAC
PCBNumber
PCB
PCBNumber
DNP
RZ2
0
RZ1
VSP
IMON
Jumper J5 to connect IMON to VP forATE Testing.
DNP
CIN3
J6
SGNDENABLE
VSUPPLY
A1
1
GND
2
A2
3
Y2
4
VCC
5
Y1
6
U1
NC7WZ14
23
D1A
14
D1B
1.00k
R5
VDR
4
12
3
TOPVIEW
DUAL LED ORIENTATION
PGD
PCBNumber
12
MECH PIN
3
M
E
C
H
PI
N
LMAG
500nH
F1 F2
Fiducials
** Output Voltage programmed to 24V typical. End user to change divider or apply an external
voltage to EXT_VREF to change output voltage.**
PCM0xxx
-VO SENSE 1
+ VO SENSE 1
SGND
1
EN
2
SDA
3
SCL
4
H1
I2CHeader
J5
SGND
0
RSCL
0
RSDA
Serial # Label
*
PCB0xxxrA
D501
BAT54XV2CT
C201
1.0nf
47K
R204
100k
R205
0
R206
C202
100pf
R208
.1
LGH
C10
4.7UF
C12
4.7UF
C9
4.7UF
C11
4.7UF
C13
4.7UF
C8
4.7UF
C14
4.7UF
C203
4.7UF
C204
4.7UF
C205
4.7UF
C206
4.7UF
C2
4.7UF
C3
4.7UF
C1
4.7UF
C4
4.7UF
C5
4.7UF
65nH
FP0404R1
L200
CIN1
4.7UF
CIN2
4.7UF
JTRK
DNP
JLGH
DNP
J200
0.51
RDAMP
VINVIN_FILT
IMON
VOUT1
LGH
SRP7030-1R0M
1 2
L1
1.0uH
1 2
L201
47uH
JISP
JISN
SHUNT2
F3 F4
3
1
2
6
5
4
V OUT
V-
+IN
V+
RG
-IN
INA193AIDBVR
U1800
0
R303
0
R304
C302
DNP
C301
0.1uF
1k
R302
6.98k
R301
193OUT
193OUT
VDR
29.4KR305
6.49kR306
J302
J303
J301
LGH
ENABLE
Figure 7
PI3740 Evaluation Board
Schematic Page 1
Schematics
UG:306 Page 11
** Output Voltage programmed to 24V typical. End user to change divider or apply an external
voltage to EXT_VREF to change output voltage.**
10.0K
R101
4.02K
R102
10.0K
R103
10.0K
R100
5.11K
R104
SOT23_5
LMV431ACM5
C
A
REF
U1901
R106
.1
1
BAT-
1.0k
R105
Battery-
VDR
VOUT VIN
ADDR0ADDR1
SYNCO
VDR
DAC
VIN_FILT
ISN
SDA
SCL
ENABLE
EAO
VSP
VDIFF
PGD
VSN
SYNCI
1
2
3
4
5
6
7
8
P1 P2
P3 P4
SAMTECLPHS-04-24
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
CN1
SAMTEC LPHS HORZ Edge Conn
SHUNT
JVSP
DNP
JVSN
DNP
JSHUNT
DNP
VSP
VSN
C100
DNP
DNP
R107
CIN4
4.7UF
CIN5
4.7UF
CIN6
4.7UF
CIN7
4.7UF
CIN8
4.7UF
CIN9
4.7UF
CIN10
4.7UF
VIN
CIN11
4.7UF
VIN_FILT
COUT1
4.7UF
COUT2
4.7UF
COUT3
4.7UF
COUT4
4.7UF
COUT5
4.7UF
COUT6
4.7UF
COUT7
4.7UF
COUT8
4.7UF
VOUT1
SHUNT
Tie
SHUNT2
FOOT 1
A
FOOT 2
A
FOOT 3
A
FOOT 4
A
Figure 8
PI3740 Evaluation Board
Schematic Page 2
Schematics (Cont.)
UG:306 Page 12
Bill of Materials
Table 1
Bill of Materials
Populated Components
Reference
Designator
Description QTY Manufacturer
Manufacturer
Part Number
C1, C2, C3,
C4, C5, C7,
C8, C9, C10,
C11, C12, C13,
C14, C203,
C204, C205,
C206, CIN1,
CIN2, CIN4,
CIN5, CIN6,
CIN7, CIN8,
CIN9, CIN10,
CIN11, COUT1,
COUT2,
COUT3,
COUT4,
COUT5,
COUT6,
COUT7, COUT8
Capacitor, X5R, Ceramic, 4.7µF,
80V, 1206
35 MURATA GRM32ER71K475KE14L
CCOMP Capacitor, X7R, 4700pF, 50V, 0603 1 MURATA GRM188R71H472KA01D
C201 Capacitor, X7R, 1nf, 50V, 0603 1 MURATA GRM188R71H102KA01D
C202 Capacitor, X7R, 100pf, 50V, 0603 1 MURATA GRM188R71H101KA01D
D1 Diode, LED, Red/Green, 1mm x 1mm 1 ROHM SML-P24MUWT86
D501
Diode, Schottky, 30V, 200ma,
BAT54XV2CT
1 FAIRCHILD BAT54XV2
J5, J200, JISN,
JISP
Connector Header 3 Position 0.1" Pitch 4 3M 961103-6404-AR
L200 Inductor, 65nH, 20A, FP0404 1 EATON FP0404R1-R065-R
L201 Inductor, 48µH, 3.4A 1 PANASONIC ETQP5M470YFK
L1 Inductor, 1µH, 11A, SRP7030-1R0M 1 BOURNS SRP7030-1R0M
R5, R105 Resistor, 1.00k,1%,0.1W, 0603 2 ROHM MCR03EZPFX1001
RSYNCI, RPGD,
REA3, R100,
R101, R103
Resistor, 10.0k, 1%, 0.1W, 0603 6 ROHM MCR03EZPFX1002
R205 Resistor, 100k, 1%, 0.1W, 0603 1 ROHM MCR03EZPFX1003
R305 Resistor, 29.4k, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL2942R
R306 Resistor, 6.49k, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL6491
REA1 Resistor, 14.0k, 1%, 0.1W, 0603 1 MCR03EZHFL1402
RSENSE Resistor, .0015, 1%, 1W 1 PANASONIC ERJ-M1WTJ1M5U
R106, R208 Resistor, 0.10, 1%, 2W 2 BOURNS CRM2512-FX-R100ELF
RSCL, RSDA,
RZ1, R206
Resistor, 0Ω, 1%, 0.1W, 0603 4 ROHM MCR03EZPJ000
U1
Dual Schmitt Trigger Inverter,
NC7WZ14,SC70-6
1 FAIRCHILD NC7WZ14EP6X
U1901 Adjustable shunt regulator, 1.24V 1 TI LMV431ACM5
UG:306 Page 13
Bill of Materials (Cont.)
Table 1 (Cont.)
Bill of Materials
Populated Components
Reference
Designator
Description QTY Manufacturer
Manufacturer
Part Number
RIN Resistor, 0.15, 1%, 0.25W, 1206 1 ROHM MCR18EZHFLR150
H1 4 Position, I
2
C Header 1 MOLEX 22-23-2041
PI3740 Wide Input Range BB 10X14 SiP 1 VICOR PI3740-00
JGP, J6, J301,
J302, J303,
JTRK, JVSN,
JVSP, JSHUNT,
JLGH
Connector Header 2 Position 0.1" Pitch 10 3M 961102-6404-AR
R204 Resistor, 47K, 5%, 0.1W, 0603 1 ROHM MCR03EZPFX4702
CVDR
Capacitor, X7R Ceramic, 0.1µF, 50V,
0603
1 TDK
CGA3E3X7S2A104K-
080AB
LMAG Inductor, 0.42µH, 42A, HCV1206 1 EATON HCV1206-R42-R
RIMON, REA2,
RZ2, R1, R2, R3,
R4, C6, C100,
C301, C302,
CEAIN1, CEAO,
CIN3, CTRK,
EAO, ENABLE,
EXT_VREF,
JVIN, LGH,
PGD, IMON,
R107, R301
R302,R303,
R304, SGND,
TRK, U1800,
SYNCI, SYNCO,
VDIFF, VDR,
VIN_F, VOUT,
VSN, VSP,
+ VO SENSE 1,
- VO SENSE 1
Do Not Populate 38
REA4 Resistor, 1.07k, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL1071
RDIFF1 Resistor, 200k, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL2003
RDIFF2 Resistor, 1 MEG, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL1004
RGP Resistor, 49.9, 1%, 0.1W, 0603 1 ROHM MCR03ERTF49R9
R102 Resistor, 4.02k, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL4021
JVOUT, JVIN Connector, Johnson Jack 2 TEKTRONIX 131503100
R104 Resistor, 5.11k, 1%, 0.1W, 0603 1 ROHM MCR03EZHFL5113
RDAMP Resistor, 0.51, 1%, 0.25W, 1206 1 ROHM MCR18ZEHFLR510
UG:306 Page 14
Bill of Materials (Cont.)
Additional or Changed Components for PI3740-00-EVAL2 Board
Reference
Designator
Description QTY Manufacturer
Manufacturer
Part Number
C301
Capacitor, X7R Ceramic, 0.1µF, 50V,
0603
1 TDK
CGA3E3X7S2A104K-
080AB
RSENSE (Value
Changed)
Resistor, 0.020, 1%, 1W 1 PANASONIC ERJ-M1WSF20MU
R301 Resistor, 6.98k, 1%, 0.1W, 0603 1 ROHM MCR03EZPFX6981
R302 Resistor,1.00k,1%, 0.1W, 0603 1 ROHM MCR03EZPFX1001
R303,R304 Resistor, 0Ω, 1%, 0.1W, 0603 2 ROHM MCR03EZPJ000
U1800 Current Shunt Monitor, INA193A 1 TI INA193AIDBVR
Table 2
Bill of Materials
for Additional or Changed
Components
Limitation of Warranties
Information in this document is believed to be accurate and reliable. HOWEVER, THIS INFORMATION
IS PROVIDED “AS IS” AND WITHOUT ANY WARRANTIES, EXPRESSED OR IMPLIED, AS TO THE
ACCURACY OR COMPLETENESS OF SUCH INFORMATION. VICOR SHALL HAVE NO LIABILITY FOR THE
CONSEQUENCES OF USE OF SUCH INFORMATION. IN NO EVENT SHALL VICOR BE LIABLE FOR ANY
INDIRECT, INCIDENTAL, PUNITIVE, SPECIAL OR CONSEQUENTIAL DAMAGES (INCLUDING, WITHOUT
LIMITATION, LOST PROFITS OR SAVINGS, BUSINESS INTERRUPTION, COSTS RELATED TO THE REMOVAL
OR REPLACEMENT OF ANY PRODUCTS OR REWORK CHARGES).
Vicor reserves the right to make changes to information published in this document, at any time
and without notice. You should verify that this document and information is current. This document
supersedes and replaces all prior versions of this publication.
All guidance and content herein are for illustrative purposes only. Vicor makes no representation or
warranty that the products and/or services described herein will be suitable for the specified use without
further testing or modification. You are responsible for the design and operation of your applications
and products using Vicor products, and Vicor accepts no liability for any assistance with applications or
customer product design. It is your sole responsibility to determine whether the Vicor product is suitable
and fit for your applications and products, and to implement adequate design, testing and operating
safeguards for your planned application(s) and use(s).
VICOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED OR WARRANTED FOR USE IN LIFE SUPPORT,
LIFE-CRITICAL OR SAFETY-CRITICAL SYSTEMS OR EQUIPMENT. VICOR PRODUCTS ARE NOT CERTIFIED
TO MEET ISO 13485 FOR USE IN MEDICAL EQUIPMENT NOR ISO/TS16949 FOR USE IN AUTOMOTIVE
APPLICATIONS OR OTHER SIMILAR MEDICAL AND AUTOMOTIVE STANDARDS. VICOR DISCLAIMS
ANY AND ALL LIABILITY FOR INCLUSION AND/OR USE OF VICOR PRODUCTS IN SUCH EQUIPMENT OR
APPLICATIONS AND THEREFORE SUCH INCLUSION AND/OR USE IS AT YOUR OWN RISK.
Terms of Sale
The purchase and sale of Vicor products is subject to the Vicor Corporation Terms and Conditions of Sale
which are available at: (http://www.vicorpower.com/termsconditionswarranty)
Export Control
This document as well as the item(s) described herein may be subject to export control regulations.
Export may require a prior authorization from U.S. export authorities.
11/17
Contact Us: http://www.vicorpower.com/contact-us
Vicor Corporation
25 Frontage Road
Andover, MA, USA 01810
Tel: 800-735-6200
Fax: 978-475-6715
www.vicorpower.com
email
Customer Service: custserv@vicorpower.com
Technical Support: apps@vicorpower.com
©2017 Vicor Corporation. All rights reserved. The Vicor name is a registered trademark of Vicor Corporation.
All other trademarks, product names, logos and brands are property of their respective owners.
Rev 1.4 Page 15
-
1
-
2
-
3
-
4
-
5
-
6
-
7
-
8
-
9
-
10
-
11
-
12
-
13
-
14
-
15
VICOR PI3740-00-EVAL2 User manual
- Type
- User manual
- This manual is also suitable for
Ask a question and I''ll find the answer in the document
Finding information in a document is now easier with AI
Related papers
Other documents
-
NOX NOXLIVE2 Datasheet
-
Rohm BD7F100HFN-EVK-004 Operating instructions
-
Keys Fitness KF-LPHS User manual
-
-
-
-
-
Thermaltake A2331 User manual
-
Community Playthings R302 User guide
-
