User manual
Dishwasher
ZDF 4010
Contents
Safety instructions _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2
Product description _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3
Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4
Programmes _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4
Options _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 5
Before first use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 6
Daily use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 8
Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ _ 10
Troubleshooting _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 11
Technical information _ _ _ _ _ _ _ _ _ _ _ _ 14
Environment concerns _ _ _ _ _ _ _ _ _ _ _ _ 14
Subject to change without notice.
Safety instructions
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and dam-
ages. Always keep the instructions with the ap-
pliance for future reference.
Children and vulnerable people safety
Warning! Risk of suffocation, injury or
permanent disability.
• Do not let persons, children included, with re-
duced physical sensory, reduced mental
functions or lack of experience and knowl-
edge use the appliance. They must have su-
pervision or instruction for the operation of
the appliance by a person who is responsible
for their safety. Do not let children play with
the appliance.
• Keep all packaging away from children.
• Keep all detergents away from children.
• Keep children and pets away from the appli-
ance door when it is open.
Installation
• Remove all the packaging.
• Do not install or use a damaged appliance.
• Do not install or use the appliance where the
temperature is less than 0 °C.
• Obey the installation instruction supplied with
the appliance.
Water connection
• Make sure not to cause damage to the water
hoses.
• The appliance is to be connected to the wa-
ter mains using the new supplied hose-sets.
Old hose sets must not be reused.
• Before you connect the appliance to new
pipes or pipes not used for a long time, let
the water flow until it is clean.
• The first time you use the appliance, make
sure that there is no leakage.
Electrical connection
Warning! Risk of fire and electrical shock.
• The appliance must be earthed.
• Make sure that the electrical information on
the rating plate agrees with the power supply.
If not, contact an electrician.
• Always use a correctly installed shockproof
socket.
• Do not use multi-plug adapters and extension
cables.
• Make sure not to cause damage to the mains
plug and to the mains cable. Contact the
Service or an electrician to change a dam-
aged mains cable.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure
that there is access to the mains plug after
the installation.
• Do not pull the mains cable to disconnect the
appliance. Always pull the mains plug.
Use
• This appliance is intended to be used in
household and similar applications such as:
– Staff kitchen areas in shops, offices and
other working environments
2
www.zanussi.com
– Farm houses
– By clients in hotels, motels and other resi-
dential type environments
– Bed and breakfast type environments.
Warning! Risk of injury.
• Do not change the specification of this appli-
ance.
• Put knives and cutlery with sharp points in the
cutlery basket with the points down or in a
horizontal position.
• Do not keep the appliance door open without
supervision to prevent to fall on it.
• Do not sit or stand on the open door.
• Dishwasher detergents are dangerous. Obey
the safety instructions on the detergent pack-
aging.
• Do not drink and play with the water in the
appliance.
• Do not remove the dishes from the appliance
until the programme is completed. There can
be detergent on the dishes.
Warning! Risk of electrical shock, fire or
burns.
• Do not put flammable products or items that
are wet with flammable products in, near or
on the appliance.
• Do not use water spray and steam to clean
the appliance.
• The appliance can release hot steam if you
open the door while a programme operates.
Disposal
Warning! Risk of injury or suffocation.
• Disconnect the appliance from the mains
supply.
• Cut off the mains cable and dispose of it.
• Remove the door catch to prevent children
and pets to get closed in the appliance.
Customer Care and Service
Contact the Service to repair the appliance. We
recommend only the use of original spare parts.
When you contact the Service, ensure that you
have the following information that is available
on the rating plate.
Model :
PNC :
Serial Number :
Product description
2
1
3
4
5
10
9
7
8
6
1
Worktop
2
Lower spray arm
3
Filters
4
Rating plate
5
Rinse aid dispenser
6
Detergent dispenser
7
Salt container
8
Water hardness dial
9
Upper spray arm
10
Upper basket
3
www.zanussi.com
Control panel
5
6
ABCDE
4
21
3
1
On/off button
2
Display
3
Indicators
4
Delay button
5
Programme buttons
6
Function buttons
Indicators Description
Wash indicator.
End indicator.
Multitab indicator.
Salt indicator. This indicator is off while the programme operates.
Rinse aid indicator. This indicator is off while the programme operates.
Programmes
Programme
1)
Degree of soil
Type of load
Programme
phases
Duration
(min)
Energy
(kWh)
Water
(l)
Heavy soil
Crockery, cut-
lery, pots and
pans
Prewash
Wash 70 °C
Rinses
Dry
80 - 90 1.6 - 1.8 22 - 24
2)
All
Crockery, cut-
lery, pots and
pans
Prewash
Wash 45 °C or 70 °C
Rinses
Dry
90 - 140 1.1 - 1.8 12 - 23
4
www.zanussi.com
Programme
1)
Degree of soil
Type of load
Programme
phases
Duration
(min)
Energy
(kWh)
Water
(l)
3)
Fresh soil
Crockery and
cutlery
Wash 65 °C
Rinse
30 0.9 9
4)
Normal soil
Crockery and
cutlery
Prewash
Wash 50 °C
Rinses
Dry
155 - 165 1.0 - 1.1 13 - 15
5)
All Prewash 12 0.1 4
1) The pressure and the temperature of the water, the variations of the mains supply, the options and the
quantity of dishes can change the programme duration and the consumption values.
2) The appliance senses the degree of soil and the quantity of items in the baskets. It automatically adjusts the
temperature and quantity of the water, the energy consumption and the programme duration.
3) With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
4) This is the standard programme for test institutes. With this programme you have the most efficient use of
water and energy consumption for crockery and cutlery with normal soil.
5) Use this programme to quickly rinse the dishes. This prevents the remaining food to bond on the dishes and
bad odours to come out from the appliance.
Do not use detergent with this programme.
Information for test institutes
For all the necessary information for test performance. send an email to:
Write down the product number (PNC) that is on the rating plate.
Options
Multitab option
Activate this option only when you use the com-
bi detergent tablets.
This option deactivates the flow of rinse aid and
salt. The related indicators are off.
The programme duration can increase.
Activating the multitab function
Activate or deactivate the multitab function
before the start of a programme. You can-
not activate or deactivate this function while a
programme operates.
1. Press the on/off button to activate the appli-
ance.
2. Make sure that the appliance is in setting
mode. Refer to ‘SETTING AND STARTING
A PROGRAMME'.
3. Press and hold function buttons (D) and (E)
at the same time until the multitab indicator
comes on.
The function stays on until you deactivate
it. Press and hold function buttons (D) and
(E) at the same time until the multitab indicator
goes off.
If you stop to use the combi detergent
tablets, before you start to use separately
detergent, rinse aid and dishwasher salt,
do these steps:
1. Deactivate the multitab function.
2. Set the water softener to the highest level.
3. Make sure that the salt container and the
rinse aid dispenser are full.
5
www.zanussi.com
4. Start the shortest programme with a rinsing
phase, without detergent and without
dishes.
5. Adjust the water softener to the water hard-
ness in your area.
6. Adjust the released quantity of rinse aid.
Before first use
1. Make sure that the set level of the water
softener agrees with the water hardness in
your area. If not, adjust the water softener.
Contact your local water authority to know
the water hardness in your area.
2. Fill the salt container.
3. Fill the rinse aid dispenser.
4. Open the water tap.
5. Processing residues can stay in the appli-
ance. Start a programme to remove them.
Do not use detergent and do not load the
baskets.
If you use the combi detergent tablets, ac-
tivate the multitab function. These tablets
contain detergent, rinse aid and other added
agents. Be sure that these tablets are applica-
ble to the water hardness in your area. Refer to
the instructions on the packaging of the prod-
ucts.
Adjusting the water softener
Hard water contains a high quantity of minerals
that can cause damage to the appliance and
bad washing results. The water softener neutral-
ises these minerals.
The dishwasher salt keeps the water softener
clean and in good conditions. Refer to the table
to adjust the water softener to the right level. It
makes sure that the water softener uses the
correct quantity of dishwasher salt and water.
You must adjust the water softener man-
ually and electronically.
Water hardness
Water softener
adjustment
German
degrees
(°dH)
French
degrees
(°fH)
mmol/l Clarke
degrees
Manual Elec-
tronic
51 - 70 91 - 125 9.1 - 12.5 64 - 88
2
1)
10
43 - 50 76 - 90 7.6 - 9.0 53 - 63
2
1)
9
37 - 42 65 - 75 6.5 - 7.5 46 - 52
2
1)
8
29 - 36 51 - 64 5.1 - 6.4 36 - 45
2
1)
7
23 - 28 40 - 50 4.0 - 5.0 28 - 35
2
1)
6
19 - 22 33 - 39 3.3 - 3.9 23 - 27
2
1)
5
1)
15 - 18 26 - 32 2.6 - 3.2 18 - 22 1 4
11 - 14 19 - 25 1.9 - 2.5 13 - 17 1 3
4 - 10 7 - 18 0.7 - 1.8 5 - 12 1 2
< 4 < 7 < 0.7 < 5
1
2)
1
2)
1) Factory position.
2) Do not use salt at this level.
6
www.zanussi.com
Manual adjustment
1 2
Turn the water hard-
ness dial to the posi-
tion 1 or 2.
Electronic adjustment
1. Press the on/off button to activate the appli-
ance. Make sure that the appliance is in set-
ting mode. Refer to ‘SETTING AND START-
ING A PROGRAMME’.
2. Press and hold function buttons (B) and (C)
at the same time until the indicators above
function buttons (A), (B) and (C) start to
flash.
3. Press function button (A).
• The indicators above function buttons (B)
and (C) go off.
• The indicator above function button (A)
continues to flash.
• The display shows the current setting of
the water softener, e.g.
= level 5.
4. Press function button (A) again and again to
change the setting.
5. Deactivate the appliance to confirm the set-
ting.
Filling the salt container
Caution! Only use dishwasher salt. Other
products can cause damage to the
appliance.
Water and salt can come out from the salt
container when you fill it. Risk of corrosion. To
prevent it, after you fill the salt container, start a
programme.
1 2
3
Put 1 litre of water in
the salt container (on-
ly for the first time).
4
5
6
Filling the rinse aid dispenser
Caution! Only use rinse aid for
dishwashers. Other products can cause
damage to the appliance.
The rinse aid, during the last rinsing phase,
helps to dry the dishes without streaks and
stains.
7
www.zanussi.com
1 2
max
M
A
X
1
2
3
4
+
3
4
M
A
X
1
2
3
4
+
To adjust the released quantity of rinse aid,
turn the selector between position 1 (lowest
quantity) and position 4 (highest quantity).
Daily use
1. Open the water tap.
2. Press the on/off button to activate the appli-
ance. Make sure that the appliance is in set-
ting mode. Refer to ’SETTING AND START-
ING A PROGRAMME’.
• If the salt indicator is on, fill the salt con-
tainer.
• If the rinse aid indicator is on, fill the rinse
aid dispenser.
3. Load the baskets.
4. Add the detergent.
5. Set and start the correct programme for the
type of load and soil.
Loading the baskets
Refer to the supplied leaflet with examples
of the load of the baskets.
• Only use the appliance to wash items that are
dishwasher-safe.
• Do not put in the appliance items made of
wood, horn, aluminium, pewter and copper.
• Do not put in the appliance items that can ab-
sorb water (sponges, household cloths).
• Remove remaining food from the items.
• Make soft the remaining burned food on the
items.
• Put hollow items (cups, glasses and pans)
with the opening down.
• Make sure that cutlery and dishes do not
bond together. Mix spoons with other cutlery.
• Make sure that glasses do not touch other
glasses.
• Put small items in the cutlery basket.
• Put light items in the upper basket. Make sure
that the items do not move.
• Make sure that the spray arms can move free-
ly before you start a programme.
Using the detergent
Caution! Use only detergents for
dishwashers.
Do not use more than the correct quantity
of detergent. Refer to the instructions on
the detergent packaging.
8
www.zanussi.com
1 2
A
3
Put the detergent or
the tablet in compart-
ment (A).
A
B
If the programme has
a prewash phase, put
a small quantity of de-
tergent in compart-
ment (B).
4
Detergent tablets do not fully dissolve with
short programmes and detergent residues
can stay on the dishes.
We recommend that you use detergent tablets
with long programmes.
Setting and starting a programme
Setting mode
The appliance must be in setting mode to ac-
cept some operations.
The appliance is in setting mode when, after the
activation:
• All the programme indicators come on.
If the control panel shows other conditions,
press and hold function buttons (B) and (C) at
the same time until the appliance is in setting
mode.
Starting a programme without delay start
1. Open the water tap.
2. To set a programme, keep the appliance
door ajar.
3. Press the on/off button to activate the appli-
ance.
4. Make sure that the appliance is in setting
mode.
5. Press the button of the programme you
want to set.
• The programme duration flashes in the
display.
• The related programme indicator comes
on.
• The wash indicator comes on.
6. Close the appliance door. The programme
starts.
• The display shows the programme dura-
tion that decreases with steps of 1 mi-
nute.
• The wash indicator stays on.
Starting a programme with delay start
1. Set the programme.
2. Press the delay button again and again until
the display shows the delay time you want
to set (from 1 to 19 hours).
• The delay time flashes in the display.
• The wash indicator goes off.
3. Close the appliance door. The countdown
starts.
• The display shows the countdown of the
delay start that decreases with steps of 1
hour.
• When the countdown is completed, the pro-
gramme starts.
– The wash indicator comes on.
– The display shows the programme dura-
tion.
9
www.zanussi.com
You can set a programme, options and the
delay start also with the appliance door
closed. In this condition, you only have 3 sec-
onds after each setting before the appliance
starts to operate.
Opening the door while the appliance
operates
If you open the door, the appliance stops. When
you close the door, the appliance continues
from the point of interruption.
Cancelling the delay start while the
countdown operates
Press and hold function buttons (B) and (C) at
the same time, until all the programme indica-
tors come on.
When you cancel a delay start, the appli-
ance goes back to setting mode. You have
to set the programme again.
Cancelling the programme
Press and hold function buttons (B) and (C) at
the same time, until all the programme indica-
tors come on.
Make sure that there is detergent in the de-
tergent dispenser before you start a new
programme.
At the end of the programme
When the programme is completed the display
shows 0 and the wash indicator goes off.
1. Press the on/off button to deactivate the ap-
pliance.
2. Close the water tap.
• If you do not deactivate the appliance,
after three minutes from the end of the
programme:
– All the indicators go off.
– The display shows one horizontal sta-
tus bar.
This helps to decrease the energy con-
sumption.
Press one of the buttons (not the on/off
button), the display and the indicators
come on again.
• Let the dishes become cold before you
remove them from the appliance. Hot
dishes can be easily damaged.
• First remove the items from the lower
basket, then from the upper basket.
• There can be water on the sides and on
the door of the appliance. Stainless steel
becomes cool more quickly than the
dishes.
Care and cleaning
Warning! Before maintenance, deactivate
the appliance and disconnect the mains
plug from the mains socket.
Dirty filters and clogged spray arms de-
crease the washing results.
Make a check regularly and, if necessary, clean
them.
Cleaning the filters
1
C
B
A
2
10
www.zanussi.com
3
To remove filters (B)
and (C), turn the han-
dle counterclockwise
and remove. Pull
apart filter (B) and
(C). Wash the filters
with water.
A
4
Remove filter (A).
Wash the filter with
water.
D
A
5
Put filter (A) to its ini-
tial position. Make
sure that it assembles
correctly under the
two guides (D).
6
Assemble filters (B)
and (C). Put them into
position in filter (A).
Turn the handle
clockwise until it
locks.
An incorrect position of the filters can
cause bad washing results and damage to
the appliance.
Cleaning the spray arms
Do not remove the spray arms.
If the holes in the spray arms are clogged, re-
move remaining parts of soil with a thin pointed
object.
External cleaning
Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use abra-
sive products, abrasive cleaning pads or sol-
vents.
Troubleshooting
The appliance does not start or it stops during
operation.
Before you contact the Service, refer to the in-
formation that follows for a solution to the prob-
lem.
With some problems, the display shows
an alarm code:
•
- The appliance does not fill with water.
•
- The appliance does not drain the wa-
ter.
•
- The anti-flood device is on.
Warning! Deactivate the appliance before
you do the checks.
Problem Possible cause Possible solution
The programme does not
start.
The mains plug is not connected in
the mains socket.
Connect the mains plug.
11
www.zanussi.com
Problem Possible cause Possible solution
The appliance door is open. Close the appliance door.
The fuse in the fuse box is damaged. Replace the fuse.
The delay start is set. Cancel the delay start or wait for the
end of the countdown.
The appliance does not fill
with water.
The water tap is closed. Open the water tap.
The water pressure is too low. Contact your local water authority.
The water tap is clogged or there is
limescale on it.
Clean the water tap.
The filter in the water inlet hose is
clogged.
Clean the filter.
The water inlet hose has a kink or a
bend.
Make sure that the position of the
hose is correct.
The anti-flood device is on. There are
water leakages in the appliance.
Close the water tap and contact the
Service.
The appliance does not
drain the water.
The sink spigot is clogged. Clean the sink spigot.
The water drain hose has a kink or a
bend.
Make sure that the position of the
hose is correct.
After the checks are completed, activate the ap-
pliance. The programme continues from the
point of interruption.
If the problem occurs again, contact the Serv-
ice.
If the display shows other alarm codes, contact
the Service.
The washing results and drying results are not satisfactory
Problem Possible cause Possible solution
The dishes are not clean. The filters are clogged. Clean the filters.
The filters are not correctly assem-
bled and installed.
Make sure that the filters are correctly
assembled and installed.
The spray arms are clogged. Remove remaining soil with a thin poin-
ted object.
The programme was not applicable
for the type of load and soil.
Make sure that the programme is appli-
cable for the type of load and soil.
Incorrect position of the items in the
baskets. Water could not wash all
items.
Make sure that the position of the
items in the baskets is correct and that
the water can easily wash all items.
The spray arms could not turn freely. Make sure that the position of the
items in the baskets is correct and
does not cause the blockage of the
spray arms.
12
www.zanussi.com
Problem Possible cause Possible solution
The quantity of detergent was not
sufficient.
Make sure that you add the correct
quantity of detergent in the dispenser
before you start a programme.
There was no detergent in the deter-
gent dispenser.
Make sure that you add detergent in
the dispenser before you start a pro-
gramme.
Limescale particles on the
dishes.
The salt container is empty. Make sure that there is dishwasher salt
in the salt container.
The set level of the water softener is
incorrect.
Make sure that the set level of the wa-
ter softener agrees with the water
hardness in your area.
The cap of the salt container is loose. Tighten the cap.
Whitish streaks and stains
or bluish layers on glasses
and dishes.
The released quantity of rinse aid is
too much.
Decrease the released quantity of rinse
aid
.
The quantity of detergent was too
much.
Make sure that you add the correct
quantity of detergent in the dispenser
before you start a programme.
Dry water drop stains on
glasses and dishes.
The released quantity of rinse aid was
not sufficient .
Increase the released quantity of rinse
aid.
The quality of the detergent can be
the cause.
Try a different brand of detergent.
The dishes are wet. The programme had no drying phase. Set a programme with the drying
phase.
The dishes are wet and
matt.
The rinse aid dispenser is empty. Make sure that there is rinse aid in the
rinse aid dispenser.
The quality of the rinse aid can be the
cause.
Try a different brand of rinse aid.
The quality of the combi detergent
tablets can be the cause.
• Try a different brand of combi deter-
gent tablets.
• Activate the rinse aid dispenser and
use the rinse aid together with the
combi detergent tablets.
Activating the rinse aid dispenser with the
multitab function activated
1. Press the on/off button to activate the appli-
ance. Make sure that the appliance is in set-
ting mode. Refer to ‘SETTING AND START-
ING A PROGRAMME’.
2. Press and hold function buttons (B) and (C)
at the same time until the indicators above
function buttons (A), (B) and (C) start to
flash.
3. Press function button (B) .
• The indicators above function buttons (A)
and (C) go off.
• The indicator above function button (B)
continues to flash.
• The display shows the current setting of
the rinse aid dispenser.
Off
On
13
www.zanussi.com
4. Press function button (B) to change the set-
ting.
5. Deactivate the appliance to confirm the set-
ting.
6. Adjust the released quantity of rinse aid.
7. Fill the rinse aid dispenser.
Technical information
Dimensions Width / Height / Depth (mm) 600 / 850 / 610
Electrical connection Refer to the rating plate.
Voltage 220-240 V
Frequency 50 Hz
Water supply pressure Min. / max. (bar / MPa) (0.5 / 0.05 ) / (8 / 0.8 )
Water supply
1)
Cold water or hot water
2)
max. 60 °C
Capacity Place settings 12
Power consumption Left-on mode 0.99 W
Off-mode 0.10 W
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
2) If the hot water comes from alternative sources of energy, (e.g. solar panels, aeolian energy), use the hot
water supply to decrease energy consumption.
Environment concerns
The symbol on the product or on its
packaging indicates that this product may not
be treated as household waste. Instead it
should be taken to the appropriate collection
point for the recycling of electrical and
electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent
potential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. For more detailed
information about recycling of this product,
please contact your local council, your
household waste disposal service or the shop
where you purchased the product.
• Discard correctly the packaging material. Re-
cycle the materials with the symbol
.
14
www.zanussi.com
15
www.zanussi.com
www.zanussi.com/shop
156959641-B-102013
-
1
-
2
-
3
-
4
-
5
-
6
-
7
-
8
-
9
-
10
-
11
-
12
-
13
-
14
-
15
-
16
Zanussi ZDF4010X dishwasher offers a range of programs to suit your dishwashing needs, from heavily soiled pots and pans to lightly soiled dishes. Choose the right program for the job, and the dishwasher will adjust water temperature, energy consumption, and program duration accordingly. With its multitab function, you can use combi detergent tablets, which combine detergent, rinse aid, and other agents for a complete clean. The water softener ensures optimal performance by removing minerals from the water, preventing damage to the appliance and ensuring sparkling results.
Ask a question and I''ll find the answer in the document
Finding information in a document is now easier with AI
