Basic Line
88
CABLE ON SPOOLS
- Wire gauge: 2 x 0.75 mm
2
- Wire construction: 24 x 0.2 mm
- Colour: transparent
- Dimensions: 4.7 x 2.2 mm
- Wire gauge: 2 x 0.75 mm
2
- Wire construction: 24 x 0.2 mm
- Colour: black
- Dimensions: 4.7 x 2.2 mm
- Wire gauge: 2 x 0.75 mm
2
- Wire construction: 24 x 0.2 mm
- Colour: white
- Dimensions: 4.7 x 2.2 mm
- Wire gauge: 2 x 1.5 mm
2
- Wire construction: 48 x 0.2 mm
- Colour: transparent
- Dimensions: 6.6 x 2.7 mm
- Wire gauge: 2 x 1.5 mm
2
- Wire construction: 48 x 0.2 mm
- Colour: transparent
- Dimensions: 6.6 x 2.7 mm
- Wire gauge: 2 x 1.5 mm
2
- Wire construction: 48 x 0.2 mm
- Colour: white
- Dimensions: 6.6 x 2.7 mm
BL 75T, spool A
EDP-No. 41800
ctn qty. 1 / 300m
BL 75S, SW, spool A
EDP-No. 41801
ctn qty. 1 / 300m
BL 75W, WS, spool A
EDP-No. 41802
ctn qty. 1 / 300m
BL 150T, spool A
EDP-No. 41803
ctn qty. 1 / 100m
BL 151T, spool C
EDP-No. 41804
ctn qty. 1 / 1000m
BL 150W, spool A
EDP-No. 41805
ctn qty. 1 / 100m
- Wire gauge: 2 x 2.5 mm
2
- Wire construction: 78 x 0.2 mm
- Colour: transparent
- Dimensions: 8.5 x 3.4 mm
BL 250T, spool A
EDP-No. 41806
ctn qty. 1 / 100m
- Wire gauge: 2 x 4.0 mm
2
- Wire construction: 126 x 0.2 mm
- Colour: transparent
- Dimensions: 10.6 x 4.3 mm
BL 400T, spool A
EDP-No. 41807
ctn qty. 1 / 50m
Pro Line
www.vivanco.com
Flex Line
89
Cable
on spools
- Wire gauge: 2 x 1.5 mm
2
- Wire construction: 189 x 0.1 mm
- Colour: transparent
- Dimensions: 7.0 x 2.9 mm
- Wire gauge: 2 x 1.5 mm
2
- Wire construction: 189 x 0.1 mm
- Colour: white
- Dimensions: 7.0 x 2.9 mm
- Wire gauge: 2 x 2.5 mm
2
- Wire construction: 322 x 0.1 mm
- Colour: transparent
- Dimensions: 8.5 x 3.4 mm
- Wire gauge: 2 x 2.5 mm
2
- Wire construction: 322 x 0.1 mm
- Colour: white
- Dimensions: 8.5 x 3.4 mm
FL 150T, spool A
EDP-No. 41811
ctn qty. 1 / 100m
FL 150W, spool A
EDP-No. 41812
ctn qty. 1 / 100m
FL 250T, spool A
EDP-No. 41813
ctn qty. 1 / 100m
FL 250W, spool A
EDP-No. 41814
ctn qty. 1 / 100m
- Wire gauge: 2 x 4.0 mm
2
- Wire construction: 511 x 0.1 mm
- Colour: transparent
- Dimensions: 10.6 x 4.3 mm
FL 400T, spool A
EDP-No. 41815
ctn qty. 1 / 50m
- Wire gauge: 2 x 2.5 mm
2
- Wire construction: 651 x 0.07 mm
- Colour: transparent
- Wire type: Oxygen free copper (OFC), silvered
- Dimensions: 8.5 x 3.4 mm
PL 250T, spool A
EDP-No. 41818
ctn qty. 1 / 100m
KX 710, spool A
EDP-No. 05881
ctn qty. 1 / ≥75dB / 100m
KX 710, spool B
EDP-No. 05882
ctn qty. 1 / ≥75dB / 400m
KX 910, spool A
EDP-No. 06801
ctn qty. 1 / ≥90dB / 100m
KX 910, spool B
EDP-No. 06802
ctn qty. 1 / ≥90dB / 400m
Coax connection ≥ 75dB
Coax connection ≥ 90dB
90
CABLE ON SPOOLS
Coax connection 75 ohm, double shielded, white
Tested in accordance with EN50083 / EN50117
- Inner cable: Ø 1.1 mm
- Shielding: double
- Dielectric: cell-PE, Ø 5.0 mm
- Jacket: PVC, Ø 6.8 mm
Attenuation:
300 MHz: 9.4 dB/100 m
500 MHz: 12.8 dB/100 m
800 MHz: 17.6 dB/100 m
960 MHz: 20.0 dB/100 m
1350 MHz: 23.2 dB/100 m
1750 MHz: 26.3 dB/100 m
2050 MHz: 29.5 dB/100 m
2500 MHz: 35.2 dB/100 m
Coax connection 75 ohm, double shielded, white
Tested in accordance with EN50083 / EN50117
- Inner cable: Ø 1.1 mm
- Shielding: double
- Dielectric: cell PE, Ø 5.0 mm
- Jacket: PVC, Ø 6.8 mm
Attenuation:
5 MHz: 1.5 dB/100 m
200 MHz: 8.2 dB/100 m
470 MHz: 12.7 dB/100 m
860 MHz: 18.1 dB/100 m
950 MHz: 20.1 dB/100 m
1750 MHz: 27.2 dB/100 m
2050 MHz: 29.7 dB/100 m
2500 MHz: 34.6 dB/100 m
Digital Sat/BK coaxial cable 75 ohm, white
Shielding level class A - according EN 50117
Supports Return pass and triple play
- Diameter: Ø 7 mm
- Inner cable: 1.024 mm copper
- Triple shielded
- Shielding level: 30 – 1000 MHz > 110 dB
- Shielding level: 1000 – 3000 MHz > 93 dB
Attenuation:
100 MHz: 4.5 dB/100 m
200 MHz: 7.4 dB/100 m
300 MHz: 9.6 dB/100 m
450 MHz: 12.4 dB/100 m
1000 MHz: 22.2 dB/100 m
1350 MHz: 25.0 dB/100 m
1750 MHz: 29.6 dB/100 m
2050 MHz: 33.3 dB/100 m
2400 MHz: 36.0 dB/100 m
KX 1110, spool A
EDP-No. 21450
ctn qty. 1 / 100m
KX 1110, spool B
EDP-No. 21451
ctn qty. 1 / 400m
KX 1110, spool C
EDP-No. 21452
ctn qty. 1 / 1000m
91
Cable
on spools
www.vivanco.com
Coax connection ≥ 100dB, Made in Germany
/
