02
INFORMATION FOR YOUR SAFETY!
THE FCC REGULATION WARNING (for USA)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequen-
cy energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
Please connect the designated DC adaptor to an AC outlet
of the correct voltage.
Do not connect it to an AC outlet of voltage other than that
for which your instrument is intended.
Unplug the DC power adaptor when not using the instru-
ment, or during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the instru-
ment. If this happens, remove the electric plug from the
outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
CAUTION
The normal function of the product may be disturbed
by Strong Electro Magnetic Interference. If so, simply
reset the product to resume normal operation by
following the owner's manual. In case the function
could not resume, please use the product in other
location.
Contents
Panel & Display Description
Front Panel..................................................................4
Rear Panel...................................................................5
Display.........................................................................5
Setup
Power Supply...............................................................6
Connections
Connecting an MP3/CD Player....................................7
Connecting a pair of Headphones...............................7
Connecting a Microphone...........................................7
Connecting a Sustain Pedal........................................7
Connecting a Computer...............................................7
Power Switch and Master Volume............................8
Playing the Demos.....................................................8
Playing the Sounds
Playing a Sound...........................................................9
Playing Two Sound Simultaneously-LAYER.................9
Playing Different Sounds with Both hands-SPLIT......9
Touch...........................................................................9
Sustain.......................................................................10
DSP Effect.................................................................10
Transpose..................................................................10
Octave.......................................................................10
Piano Mode...............................................................10
Auto Accompaniment
Selecting a Style........................................................11
Playing a Fill..............................................................11
Intro/Ending...............................................................11
Sync Start..................................................................12
Fade In/Out................................................................12
Accompaniment Volume............................................12
Tempo........................................................................12
Auto Bass Chord.......................................................13
Chord Basics.............................................................13
Quick Setting.............................................................14
Metronome
Turning on the Metronome........................................14
Selecting the Beat.....................................................14
Arpeggiator..............................................................15
Mixer.........................................................................15
Function Menu
Tune...........................................................................16
Octave.......................................................................16
Split Point..................................................................16
Beat Type...................................................................17
Touch.........................................................................17
Modulation................................................................17
DSP............................................................................17
Reverb Type..............................................................17
Reverb Level.............................................................17
Chorus Type..............................................................18
Chorus Level.............................................................18
Auto Power Off..........................................................18
Performance Memory...............................................19
Selecting a Bank........................................................19
Chord Reference......................................................19
Playing the Songs
Listening to the Songs...............................................20
Lesson Mode.............................................................20
Recording and Playback.........................................21
MIDI Function
What’s MIDI?.............................................................21
MIDI Connection........................................................21
Trouble Shooting......................................................22
Specifications..........................................................22
Appendices
Sound List.................................................................23
Style List....................................................................28
Song List....................................................................30
MIDI Implementation Chart........................................32
03
Panel & Display Description
Front Panel
1. [VOLUME] Knob
Adjust the master volume.
2. [ ] Button
Turn the power on or off.
3. [LESSON] Button
Enter the lesson mode.
4. [L/R] Button
Choose to practice the left hand
or right hand part.
[CHORD REF.] Button
Turn the chord reference function
on or off.
5. [FADE] Button
Turn the Fade In/Out function on
or off.
6. [TEMPO +/-] Buttons
Adjust the current tempo value.
7. [CHORD] Button
Enter the Chord Mode.
8. [INTRO/ENDING] Button
Play the Intro or Ending pattern.
9. [FILL A] Button
Play the fill-in pattern A.
10. [FILL B] Button
Play the fill-in pattern B.
11. [SYNC START] Button
Turn the Sync Start function on
or off.
12. [START/STOP] Button
Start or stop playing the style or
song.
13. [BANK] Button
Switch between memory banks.
[STORE] Button
Register the current panel settings.
14. [M1]~[M4] Buttons
Recall the registered panel settings.
15. [Q.S.] Button
Turn the Quick Setting
function on or off.
16. [RECORD] Button
Enter the Record Mode.
[PLAY] Button
Play back the recording.
17. [LAYER] Button
Turn the layer function on or off.
18. [SPLIT] Button
Turn the split function on or off.
19. [SUSTAIN] Button
Turn the sustain function on or off.
20. [SOUND] Button
Switch to Sound Mode.
Press [SOUND] and [STYLE] at the
same time to enter Demo Mode.
21. [STYLE] Button
Switch to Style Mode.
Press [SOUND] and [STYLE] at the
same time to enter Demo Mode.
22. [SONG] Button
Switch to Song Mode.
[ARP.] Button
Turn the Arpeggiator function on
or off.
23. [PIANO] Button
Turn the Piano Mode on or off.
24. [METRO] Button
Turn the metronome on or off.
25. [TRANSPOSE] Button
Adjust the Transpose value.
26. [MIXER] Button
Enter the Mixer menu.
27. [FUNCTION] Button
Enter the function menu.
28. [+]/[-] and Number Buttons
Set parameters value or select
the number.
29. LCD Display
Display all parameters and values
related to the current operation.
04
1
11
220
12
13 15
16 17 18 19
5
67
8 9 10
4
3
21 22 24 272623 25
29
14
28
Panel & Display Description
Rear Panel
30. USB Jack
Connect to a computer.
31. SUSTAIN Jack
Connect a sustain pedal.
32. PHONES Jack
Connect a pair of headphones.
33. AUX IN Jack
Connect an external audio source,
such as MP3 or CD player.
34. MIC Jack
Connect a microphone.
35. DC IN Jack
Connect the DC 12V power adapter.
05
Display
30 31 32 33 34 35
MIC INAUX INPHONESSUSTAIN 12V
1. RECORD/PLAY/MODULATION
2. NUMBER
3. SOUND/STYLE/DEMO/SONG
4. CHARACTER
5. TOUCH/SUSTAIN
6. RECORD
7. TREBLE CLEF
8. BASS CLEF
9. MEASURE
10. BEAT
11. TEMPO
12. CHORD
13. MEMORY/QUICK SETTING
14. FINGERED/FULL RANGE/FADE/A/B
15. NUMBER MUSICAL NOTATION
16. LESSON
17. LAYER/SPLIT/ARP./DSP
2
6
4
8
9
12
13
14
10
3
7
11
16 17
15
SUSTAIN
TOUCH
15
Setup
This section contains information about setting up your instrument
and preparing to play. Please go through this section carefully
before turning the power on.
Power Supply
You can power the instrument either by batteries or by power
adaptor. Follow the instructions described below.
Using Batteries
The instrument needs 6 pieces of AA size or equivalent alkaline
batteries for power supply.
1. Open the battery cabinet cover located on the bottom of the
instrument.
2. Insert the batteries, carefully following the polarity markings on the
cabinet.
3. Replace the cabinet cover. Make sure it locks firmly in place.
Notes:
1. Do not mix using any used and new batteries.
2. Always use the same types of batteries.
3. Remove the batteries when the instrument is not in use for a long
period of time.
Using Power Adaptor
1. Turn down the volume before connecting to power supply.
2. Connect the adaptor to the DC IN jack of the instrument.
3. Plug the adaptor into an AC outlet. This will automatically cut off
the battery power supply.
Notes:
1. In order to save energy, the instrument will automatically shut
down after 30 minutes if it is not used. (Please refer to Auto Power
Off).
2. For your safety, please unplug the instrument when it is not in use
or during a thunderstorm.
06
MIC INAUX INPHONESSUSTAIN 12V
Connecting an MP3/CD Player
The rear-panel AUX IN jack receives audio signals from an external
audio source such as an MP3 or a CD player.
Use an audio cable to connect the AUX IN jack of the instrument to
the OUTPUT jack of the MP3/CD player. The instrument’s speakers
will play the music transmitted from the external player, and you can
play along.
Connecting a pair of Headphones
A standard pair of stereo headphones can be connected to the
PHONES/OUTPUT jack for private practice or late-night playing.
The internal stereo speaker system is automatically shut off when a
pair of head phones is plugged into this jack.
Note:
Do not listen with the headphones at high volume for long periods
of time. Doing so may cause hearing loss.
Connecting a Microphone
You can plug a microphone to the MIC jack to sing along with your
keyboard performance or song playback.
1. Set the master volume to minimum level before connecting or
disconnecting a microphone.
2. Plug a microphone into the MIC jack.
3. Adjust the master volume to an appropriate level.
Connecting a Sustain Pedal
An optional footswitch can be plugged into the sustain jack and be
used to switch sustain on or off. Simply by pressing the pedal, you
will have a natural sustain as you play.
Connecting a Computer
Use a standard USB cable to connect the USB jack of the instru-
ment to the USB port of a computer. You can transmit MIDI
messages between the instrument and the computer.
Notes:
1. Do not set the USB device to be input and output simultaneously
when setting the software on the computer. Otherwise, the sound
will be overlapped when playing the keyboard.
2. We recommend using a USB2.0 interface to connect the
instrument to computer.
Connections
07
MIC INAUX INPHONESSUSTAIN 12V
MIC INAUX INPHONESSUSTAIN 12V
MIC INAUX INPHONESSUSTAIN 12V
MIC INAUX INPHONESSUSTAIN 12V
MIC INAUX INPHONESSUSTAIN 12V
DEMO
Power Switch
Before you switch your instrument on, please turn down the volume
of instrument and the connected audio equipment first.
1. Make sure the instrument is properly connected to power supply.
2. Press POWER SWITCH, the LCD screen is lit, and displays
“Loading!”, indicating the instrument is powered on.
Master Volume
Rotate the [VOLUME] knob clockwise to increase the master volume
or counter-clockwise to decrease it. You can use the knob to set the
desired volume level.
Note:
If the speakers do not produce sound, please check if the master
volume is set too low or if headphones are plugged into the
PHONES jack.
Power Switch and Master Volume
08
The instrument features a variety of demo songs.
1. Press the [STYLE] and [SOUND] buttons simultaneously to start
playing all demo songs in a loop. The LCD will display the current
demo number and name.
2. Select a demo song.
Use the number keys, the [+]/[-] buttons to select the desired
demo song.
3. Press the [STYLE] and [SOUND] buttons simultaneously again or
press the [START/STOP] button to stop playing and exit the demo
mode.
Note:
During demo playback, only the following buttons will work:
[START/STOP], [TEMPO -]/[TEMPO +], [+]/[-], the Number buttons,
[VOLUME] and [POWER].
Playing the Demos
123
456
789
0
LAYER
The instrument features a variety of exceptionally realistic sounds. Please refer
to Sound List.
Playing a Sound
1. Press the [SOUND] button.
Enter the SOUND mode. LCD shows “SOUND R1”, the sound number
and the sound name.
2. Select a sound.
Use the number keys, the [+]/[-] buttons to select the sound you want to
play.
3. Play the sound.
Play the keyboard and enjoy the beautiful sound.
Note:
When the LAYER and SPLIT function is on, you can press [SOUND] button
repeatedly to choose the sound source. The corresponding LCD indicator
will highlight between R1, R2, and L.
Playing Two SOUNDS Simultaneously-LAYER
1. Press the [LAYER] button to turn on the layer function. LCD shows
“SOUND R2”, the layered sound number and name.
2. Use the number keys, the [+]/[-] buttons to select the sound for SOUND
R2.
3. Play the keyboard, you will hear two different sounds layered together,
just like two different instruments being played at the same time.
4. Press the [LAYER] button again to turn off the layer function.
Playing Different Sounds with Both hands-SPLIT
The Split function splits the keyboard into two areas so as to create different
sounds for each of your hands. The left hand sound is the split sound “L” .
1. In idle mode, press the [SPLIT] button to turn the split function on.
The LCD displays the left hand sound name and number, and the
indicator “SOUND L” and “SPLIT”.
2. Use the number keys, the [+]/[-] buttons to select the sound for SOUND L.
3. Play the keyboard with both hands, and you will hear two different
sounds.
4. Press the [SPLIT] button again to turn off the split function.
Split Point
The key on the keyboard that separates sound L and sound R1/R2 is called
the “split point”. The default split point is at F#3 (19) , however you can assign
it to any other key. Refer to the Function Menu.
Touch
The keyboard is equipped with a touch response feature that lets you
dynamically and expressively controls the level of the sound with your playing
strength – just as on an acoustic instrument. Please refer to the function menu
to adjust the touch level.
09
123
456
789
0
SPLIT
Playing the Sounds
Sustain
When the Sustain feature is ON, all notes played on the keyboard will
have a longer sustain. Press the [SUSTAIN] button to turn sustain on or
off.
Note:
When using a sustain pedal, you can produce a much stronger and more
natural sustain effect than by using the [SUSTAIN] button.
DSP Effect
The DSP simulates sounds in real environment. With the DSP effects,
you can add ambiance and depth to your performance in a variety of
ways.
The function is turned on by default. You can refer to the function menu
to turn the DSP effect on or off.
Transpose
Transpose function allows the overall pitch of the instrument to be
transposed up or down by one octave in semitone steps.
1. the [TRANSPOSE] button to enter transpose menu. The LCD shows
the current transpose value.
2. Use [+]/ [-] buttons to adjust the transpose value.
3. Press the [+] and [-] buttons simultaneously to reset the transposition
to 0.
Octave
The octave function will shift the pitch of the specified sound layer up or
down in the step of an octave.
You can refer to the function menu to adjust the octave value.
Note:
After adjusting the octave, notes in the highest and lowest keyboard
range may not sound normally.
Piano mode
This function is to set the sound of the entire keyboard to piano instantly.
1. Press [PIANO] button to enter or exit piano mode.
2. In piano mode, you can play the accompaniment as in the other
modes, but it plays only the rhythm part.
Note:
In piano mode, the CHORD mode is automatically turned off.
Playing Sounds
10
TRANSPOSE
SUSTAIN
PIANO
SYNC
START
The auto accompaniment function puts a full backing band at your
fingertips. All you have to do is to play chords with your left hand, and
the accompaniment will automatically play along, instantly following
the chords you play. With auto accompaniment, even a solo performer
can enjoy playing with the backing of an entire band or orchestra.
The instrument features a variety of styles, please refer to the Style
List. Try selecting the different styles and enjoy the auto accompani-
ment.
Selecting a Style
1. Press the [STYLE] button.
Enter the STYLE mode. LCD shows “STYLE”, the style number and
the style name.
2. Use the number keys, the [+]/[-] buttons to select the style you want
to play.
3. Press the [START/STOP] button to start the rhythm tracks of the
auto accompaniment.
Sync Start
When style stops, press the [SYNC START] button to turn on the
function. The beats on LCD will flash along with the tempo.
1. In Sycn Start mode, if the CHORD mode is turned off, you can
press a key on the keyboard to start playing auto accompaniment
of the rhythm track.
2. In Sycn Start mode, if the CHORD mode is in use, you can press a
key on the chord range of the keyboard to start playing auto
accompaniment of all tracks.
Intro/Ending
The intro is an opening section of a song. When the intro pattern
finished, the system will automatically shift to the main section.
Ending is the ending section of a song. When the ending is finished,
accompaniment automatically stops.The length of the ending differs
depending on the selected style.
1. Press the [STYLE] button.
2. Select a style.
3. Turn the Chord Mode on.
4. Turn SYNC START on.
5. Press the [INTRO/ENDING], the “A” or “B” flashes on LCD, the style
is ready to play.
6. It will start the accompaniment as soon as you start playing in
Chord section. When the playback of the intro is finished, it
automatically switched to main A or B section.
7. Press the [INTRO/ENDING] again to play the ending section.
When the ending is finished, the auto accompaniment automatically
stops.
Note:
If you press [FILL A] or [FILL B] before the ending is finished, it will play
a fill-in then switch to the corresponding main section.
Auto Accompaniment
11
123
456
789
0
CHORD
START/
STOP
SYNC
START
INTRO/
ENDING FILL A FILL B
TEMPO
Playing a Fill
Auto fill in function automatically adds a fill to your performance.
When the fill-in is finished,accompaniment shifts to the Main section
(A,B).
Note:
If you keep pressing [FILL A]/[FILL B] buttons during style playback,
the fill-in pattern will repeat playing until the button is released.
Playback will then shift to the related MAIN section.
When style stops, press the [FILL A]/[FILL B] buttons to select a MAIN
section. “A or B” will highlight on LCD.
Fade In/Out
Fade In
Starting the style with fade in produces a smooth beginning, the
volume increases from low to high. Press the [FADE] button when
Style is stoppedLCD will show FADE. Press the [START/STOP]
button to start Style playing. LCD will showFADE.
The Accompaniment Volume will change from 0 to the set value in
about 8 seconds. The keyboard volume will change from 0 to default
value at the same time.
Fade Out
Stopping the style with fade out produces a smooth ending, the
volume decreases from high to low. Press the [FADE] button during
Style playing. LCD will show FADE.
The Accompaniment Volume will change from the set value to 0 in
about 8 seconds, and the style stops.
Accompaniment Volume
The function adjusts the accompaniment volume, so as to keep an
appropriate balance between the accompaniment volume and the
sound volume.
Press repeatedly the [MIXER] button to enter the mixer menu, and
when the LCD displays "Accomp", you can adjust the volume level
over the range of 0-32. LCD will show the current volume level.
Notes:
In the mixer menu, press both [-] and [+] buttons simultaneously to
mute the accompaniment part. LCD shows “OFF Accomp”. Press
both buttons again to unmute the accompaniment volume.
Tempo
Each style of the instrument has been programmed with a default
tempo; however, you can change it as needed.
1. Use the [TEMPO -]/[TEMPO +] buttons to change the tempo. The
value ranges from 5 to 280.
2. Hold down the [TEMPO -]/[TEMPO +] buttons to change the tempo
quickly.
3. Press the [TEMPO+] and [TEMPO-] buttons simultaneously to
restore the default tempo setting.
Auto Accompaniment
12
FILL A FILL B
FADE
MIXER
FADE
CHORD
Auto CHORD mode
1. Press the [CHORD] button, the LCD will display the “FINGERED”
indicator. The left hand section of the keyboard is the chord
section.
You can play different chords in the chord section.
Press [CHORD] button again to enter Full Range mode. The “FULL
RANGE” indicator will be lit. You can play chords over the entire
keyboard in multi-fingering.
2. Play chords in the chord section, and the LCD will display the
corresponding chord names.
3. Split Point Setting
Please refer to the function menu to set the split point. The split
point and the keys to its left all belong to the chord section.
Auto Accompaniment
13
Chord Basics
A chord, in music, is any harmonic set of three or more notes that is
heard as if sounding simultaneously. The most frequently encountered
chords are triads. A triad is a set of three notes that can be stacked in
thirds. When stacked in thirds, the triad's members, from lowest
pitched tone to highest, are called: the Root, the Third, and the Fifth.
Triad Type
There are following basic triad types:
Chord Inversion
We define this chord its root is not in the bass (i.e., is not the lowest
note) as an inversion chord. When the root is in the bass, we call the
chord: root-position chord. If we put the Third and Fifth in the root
position, then it forms “Inversion”, we call this chord “Inversion Chord”.
See the following major triad and its inverted chord.
Chord Name
The chord name contains two parts content: Chord root and Chord
type.
Single Finger
Single finger type not only can detect single finger but also can detect
multi finger. And the single finger makes it easily to play chords through
only one, two or three keys. Including major, minor, seventh, and minor
seventh chord. Refer to relevant picture on the right for details.
Major Triad
Minor Triad
Augmented
Triad
Diminished
Triad
A root with a major third added above and a perfect fifth
will consist as a “Major Triad”.
A root with a minor third added above and a perfect fifth
will consist as a “Minor Triad”.
A root with a major third added above and an
augmented fifth will consist as an “Augmented Triad”.
A root with a minor third added above and a diminished
fifth will consist as a “Diminished Triad”.
TEMPO
Q.S.
Auto Accompaniment
14
Metronome
Multi-finger
Multi-finger allows you to play chords in normal fingering. Try playing
the 32 chord types in C scale as listed on the right.
Note:
In full range mode, the entire keyboard will only recognize chords
played in normal fingering.
Quick Setting
When Quick Setting is switched on, you can instantly recall all
auto accompaniment related settings including sounds selection and
digital effects simply with a single touch of a button.
1. Press the [Q.S.] button to turns on the Quick Setting for
current style. LCD shows “Q.S.”.
2. Press one of the [M1]-[M4] buttons, various panel settings (such as
sound, effect, etc.) that match the selected style can be instantly
recalled.
3. CHORD mode is automatically turned on during Q.S. mode.
4. Press the [Q.S.] button again to quit Quick Setting mode,
the “Q.S.” indicator will disappear.
Note:
In Q.S. mode, the memory is not selectable.
Turning on the Metronome
Press the [METRO] button to turn on the metronome.
Press the [METRO] button again to turn off the metronome.
Press the [TEMPO+] / [TEMPO-] buttons to change the tempo of the
metronome.
Selecting the Beat
You can set the beat type in the function menu, please refer to the
function menu for details.
If you turn on the metronome during style playback, the metronome
sound will start from the next beat and its beat will match the current
style. When style stops, you can change the metronome beat as
desired.
The metronome is not usable in song mode.
METRO
15
The Mixer allows you to adjust separately the volume of different
tracks.
1. Press the [MIXER] button to enter the mixer menu, the LCD displays
the current mixer track.
2. Repeatedly press the [MIXER] button to select the track you want.
Then use [+]/[-] buttons to change the parameters.
The option and parameters are as follows:
Note:
It will exit the mixer menu if there is no operation in 3 seconds.
Pressing [+] and [-] buttons at the same time will mute the selected
track, the LCD will display “OFF”. Press the two buttons at the same
time again to unmute the track.
Mixer
Arpeggiator
The arpeggiator function will automatically generate arpeggios.
Simply play a chord with your left hand, and the instrument will play
a preset arpeggio pattern to produce a beautiful melody.
Turn the Arpeggiator on or off
Press and hold the [ARP.] button for 2 seconds to turn on the
function. The corresponding indicator will be lit. Press and hold the
[ARP.] button for 2 seconds again to turn off the function. The
corresponding indicator will light off.
Note:
Each sound is matched with a preset arpeggio pattern, so when you
change the sound, the default arpeggio pattern will change as well.
The Split Point of Arpeggiator
When you turn on the arpeggiator, the keyboard will be split into two
areas. Play chords in the left hand area, and melody in the right hand
area. The default split point is the same as in the split function: F#3
(19).
Options
Adjust the Accomp volume
Adjust the Rhythm track volume
Adjust the Bass track volume
Adjust the Chord 1 track volume
Adjust the Chord 2 track volume
Adjust the Chord 3 track volume
Adjust the Upper 1 track volume
Adjust the Upper 2 track volume
Adjust the Lower track volume
LCD Display
XXX Accomp
XXX Rhythm
XXX Bass
XXX Chord1
XXX Chord2
XXX Chord3
XXX Upper 1
XXX Upper 2
XXX Lower
Range
0-32
0-32
0-32
0-32
0-32
0-32
0-32
0-32
0-32
ARP.
MIXER
FUNCTION
Press the [FUNCTION] button to enter the function menu. The LCD
displays the current parameter item.
Press repeatedly the [FUNCTION] button to select an item, then use
the [+]/ [-] buttons to change the value of the selected item.
Parameter items and the value range in the function menu:
Note:
It will exit the function menu if there is no operation in 3 seconds.
Tune
The function adjusts the pitch of the entire keyboard in a 2-cent
increment.
1. Repeatedly press the [FUNCTION] button to select the tune menu.
The LCD displays “Tune”.Use the [+] / [-] buttons to change the
value over the range of -50 - +50.
2. Pressing [+] and [-] buttons at the same time will reset the tune value
to default “000”.
The setting applies to both accompaniment and the sound.
Octave
1. Repeatedly press the [FUNCTION] button to select the octave menu.
The LCD displays “Octave”. Use the [+] / [-] buttons to change the
value over the range of -2 - +2.
2. Pressing [+] and [-] buttons at the same time will reset the octave
value to default “000”.
Split Point
The Point on the keyboard that separates sound L and sound R1/R2 is
called the "split point". Left hand section controls the auto bass chord
accompaniment when the CHORD mode is on, or it plays the split
sounds when the CHORD mode is off.
1. Repeatedly press the [FUNCTION] button to select split point menu.
The LCD displays “Split Pt”. Use [+] / [-] buttons to change Split
Point.
The range of Split Point is: 1~61.
2. Press [+] / [-] buttons simultaneously will set the split point value to
its default setting: F#3 (19).
16
Parameter Item
Tune
Octave
Split Point
Beat Type
Touch
Modulation
DSP
Reverb Type
Reverb Level
Chorus Type
Chorus Level
Auto Power Off
LCD Display
XXX Tune
XXX Octave
XXX Split Pt
XXX Beat
XXX Touch
XXX Modul
XXX Dsp
XXX Rev Type
XXX Rev Lev
XXX Chr Type
XXX Chr Lev
XXX PowerOff
Range
-50 - +50
-2 - +2
1 - 61
0, 2 - 9
OFF, 1 - 3
On, OFF
On, OFF
1 - 10
0 - 32
1 - 8
0 - 32
OFF, 30, 60
Function Menu
Beat Type
1. Repeatedly press the [FUNCTION] button to select the beat menu.
The LCD displays “Beat”.
Use the [+ ]/ [-] buttons to change the beat type.
2. Pressing [+] and [-] buttons at the same time will reset the beat type
to default “004”.
Touch
1. Repeatedly press the [FUNCTION] button to select the touch menu.
The LCD displays “Touch”.
Use the [+ ]/ [-] buttons to change the touch level.
2. Pressing [+] and [-] buttons at the same time will reset the touch level
to default “002”.
Modulation
Repeatedly press the [FUNCTION] button to select the modulation menu.
The LCD displays “Modul”.
Use the [+] / [-] buttons to switch modulation on or off.
Note:
Modulation is not available for percussive sounds.
DSP
Repeatedly press the [FUNCTION] button to select the DSP menu. The
LCD displays “Dsp”.
Use the [+] / [-] buttons to switch DSP on or off.
Reverb Type
1. Repeatedly press the [FUNCTION] button to select the reverb type
menu. The LCD displays “Rev Type”.
Use the [+]/ [-] button to change the type value.
2. Pressing [+] and [-] buttons at the same time will reset the reverb type
to default “004”.
Reverb Level
1. Repeatedly press the [FUNCTION] button to select the reverb level
menu. The LCD displays “Rev Lev”.
Use the [+]/ [-] button to adjust the level over the range of 0-32.
2. Pressing [+] and [-] buttons at the same time will reset the reverb level
to default.
Function Menu
17
Chorus Type
1. Repeatedly press the [FUNCTION] button to select the chorus type
menu. The LCD displays “Chr Type”.
Use the [+]/ [-] button to change the type value.
2. Pressing [+] and [-] buttons at the same time will reset the chorus type
to default “003”.
Chorus Level
1. Repeatedly press the [FUNCTION] button to select the chorus level
menu. The LCD displays “Chr Lev”.
Use the [+]/ [-] button to adjust the level over the range of 0-32.
2. Pressing [+] and [-] buttons at the same time will reset the chorus
level to default.
Auto Power Off
1. Repeatedly press the [FUNCTION] button to select the power off
menu. The LCD displays “PowerOff”.
Use the [+]/ [-] button to change the time setting.
2. Pressing [+] and [-] buttons at the same time will reset the setting to
default “030” (30 min).
Function Menu
18
L / R
CHORD REF.
The Performance Memory feature allows you to save virtually all panel
settings to a Performance memory, and you can instantly recall them by
pressing a single button.
The instrument has 8 memory banks, and each bank has 4 memories
(M1-M4).
1. Hold down [STORE] button , then press one of the memory buttons
[M1] - [M4] to save the panel settings. The LCD will display “Mem
Stor” and the new settings will replace the previous memory data.
2. Press one of the memory buttons [M1] - [M4] to recall the panel
settings saved to that memory.
3. You can save following parameters to the memory:
Sound Parameter: sound, layer, DSP, mixer.
Accompaniment Parameter: style, tempo, and chord no/off,
accompaniment sections.
Function Parameter: touch, some parameters in the function menu.
Note:
Performance memory cannot be recalled when the Quick Setting
function is in use. The performance memory will reset to default settings
after power off.
Selecting a Bank
1. Press the [BANK] button. The LCD will display the bank number.
2. Repeatedly press the [BANK] button to select a bank over the range
of 1-8.
If you know the name of a chord but don't know how to play it, you can
use the Chord Reference function.
1. Press and hold the [CHORD REF.] button for 2 seconds to enter this
mode. The LCD displays the Chord Type and Chord Notes.
2. The keys above C4 (including C4) are used to assign the Chord Type,
and the keys above C6 (including C6) are used to assign the Chord
Root. When the Chord Type and Chord Root are confirmed, the LCD
will display the Chord and the staff notation.
3. When you play the correct chord on the chord range of the keyboard,
an applause sound will be heard.
4. Press and hold the [CHORD REF.] button for 2 seconds again to exit
this mode.
19
Chord Reference
M2M1 M3 M4BANK
BANK
Performance Memory
The instrument has a variety of songs (Please refer to the Song List).
Each song can be practiced in LESSON mode.
Listening to the Songs
1. Press the [SONG] button to enter the song mode. It will play all
songs circularly. Press the [SONG] button again, it will stop the song.
2. In song mode, use the number keys and [+]/[-] buttons to select a
song.
3. During song playback, you can press the [START/STOP] button to
stop the song, press it again to play the current song repeatedly.
4. Use the [TEMPO+]/[TEMPO-] buttons to change the tempo of the
current song.
5. When the song is stopped, press [STYLE], [SOUND], [LAYER],
[M1] - [M4] to exit the song mode.
Lesson Mode
The instrument presets 3 different ways to practice a song, as specified
in Lesson 1, Lesson 2 and Lesson3. The instrument will grade your
practice when you finish a lesson, helping you to keep track of your
progress.
1. When song playback is stopped, press the [LESSON] button to enter
the lesson mode or select a lesson to practice.
2. Press the [START/STOP] button to start the lesson. The LCD displays
the note that needs to be played.
3. Press the [START/STOP] button again to stop the lesson.
4. In lesson mode, press repeatedly the [L/R] button to select to
practice the left hand part, the right hand part, or both hands.
5. You can select to practice one of the three lessons. It will grade your
practice when you finish a lesson.
In lesson 1, you will learn to practice at the correct time value. It doesn't
matter even you play the wrong notes.
In lesson 2, you will learn to play the correct notes. The lesson will
continue only when you have played correctly the note displayed on
LCD.
In lesson 3, you will learn to play the correct notes at the correct time
value.
When you finish a lesson, the instrument will grade your practice by
telling you the level you get.
Level 1: OK.
Level 2: Good.
Level 3: Very Good.
Level 4: Excellent.
After grading, the song will play back again, and you can practice again.
Playing the Songs
20
L / R
CHORD REF.
LESSON
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
Page is loading ...
-
1
-
2
-
3
-
4
-
5
-
6
-
7
-
8
-
9
-
10
-
11
-
12
-
13
-
14
-
15
-
16
-
17
-
18
-
19
-
20
-
21
-
22
-
23
-
24
-
25
-
26
-
27
-
28
-
29
-
30
-
31
-
32
Ask a question and I''ll find the answer in the document
Finding information in a document is now easier with AI
Related papers
Other documents
-
Roland E-X10 Owner's manual
-
-
-
-
Roland E-X20A Owner's manual
-
-
Kurzweil KP300X Portable Keyboard User manual
-
Classic Cantabile SP-15 User manual
-
Startone MK-200 User manual
-
Startone MK-300 Owner's manual
