Dell Inspiron 15 3555 User manual

Inspiron 15

3000 Series

Service Manual

Regulatory Model: P47F

Regulatory Type: P47F005

Notes, cautions, and warnings

NOTE: A NOTE indicates important information that helps you make better use

of your computer.

CAUTION: A CAUTION indicates either potential damage to hardware or loss of

data and tells you how to avoid the problem.

WARNING: A WARNING indicates a potential for property damage, personal

injury, or death.

Copyright

international copyright and intellectual property laws. Dell

™

and the Dell logo are trademarks

of Dell Inc. in the United States and/or other jurisdictions. All other marks and names

mentioned herein may be trademarks of their respective companies.

Updated - 2016–01

Rev. A00

Contents

1 Before working inside your computer.............................9

Before you begin ......................................................... 9

Safety instructions...................................................... 10

Recommended tools.....................................................10

2 After working inside your computer............................. 12

3 Removing the battery...............................................13

Procedure.................................................................13

4 Replacing the battery............................................... 15

Procedure.................................................................15

5 Removing the optical drive........................................ 16

Prerequisites............................................................. 16

Procedure.................................................................16

6 Replacing the optical drive........................................ 19

Procedure.................................................................19

Post-requisites........................................................... 19

7 Removing the keyboard............................................ 20

Prerequisites............................................................. 20

Procedure.................................................................20

8 Replacing the keyboard............................................ 23

Procedure.................................................................23

Post-requisites........................................................... 23

9 Removing the base cover.......................................... 24

Prerequisites............................................................. 24

Procedure.................................................................24

3000 Series

3

10 Replacing the base cover......................................... 29

Procedure.................................................................29

Post-requisites........................................................... 29

11 Removing the hard drive......................................... 30

Prerequisites............................................................. 30

Procedure.................................................................30

12 Replacing the hard drive......................................... 33

Procedure.................................................................33

Post-requisites........................................................... 33

13 Removing the memory module.................................. 35

Prerequisites............................................................. 35

Procedure.................................................................35

14 Replacing the memory module.................................. 37

Procedure.................................................................37

Post-requisites........................................................... 38

15 Removing the wireless card......................................39

Prerequisites............................................................. 39

Procedure.................................................................39

16 Replacing the wireless card...................................... 41

Procedure.................................................................41

Post-requisites........................................................... 42

17 Removing the power-button board............................. 43

Prerequisites............................................................. 43

Procedure.................................................................43

18 Replacing the power-button board............................. 46

3000 Series

4

Procedure.................................................................46

Post-requisites........................................................... 46

19 Removing the speakers........................................... 48

Prerequisites............................................................. 48

Procedure.................................................................48

20 Replacing the speakers........................................... 50

Procedure.................................................................50

Post-requisites........................................................... 50

21 Removing the I/O board...........................................51

Prerequisites............................................................. 51

Procedure.................................................................51

22 Replacing the I/O board...........................................53

Procedure.................................................................53

Post-requisites........................................................... 53

23 Removing the coin-cell battery................................. 54

Prerequisites............................................................. 54

Procedure.................................................................54

24 Replacing the coin-cell battery..................................56

Procedure.................................................................56

Post-requisites........................................................... 56

25 Removing the heat-sink assembly.............................. 57

Prerequisites............................................................. 57

Procedure.................................................................57

26 Replacing the heat-sink assembly.............................. 59

Procedure.................................................................59

Post-requisites........................................................... 59

3000 Series

5

27 Removing the fan...................................................61

Prerequisites............................................................. 61

Procedure.................................................................61

28 Replacing the fan...................................................63

Procedure.................................................................63

Post-requisites........................................................... 63

29 Removing the system board......................................64

Prerequisites............................................................. 64

Procedure.................................................................65

30 Replacing the system board......................................69

Procedure.................................................................69

Post-requisites........................................................... 70

31 Removing the touch pad.......................................... 71

Prerequisites............................................................. 71

Procedure.................................................................71

32 Replacing the touch pad.......................................... 76

Procedure.................................................................76

Post-requisites........................................................... 76

33 Removing the power-adapter port..............................78

Prerequisites............................................................. 78

Procedure.................................................................78

34 Replacing the power-adapter port..............................81

Procedure.................................................................81

Post-requisites........................................................... 81

35 Removing the display assembly................................. 83

3000 Series

6

Prerequisites............................................................. 83

Procedure.................................................................84

36 Replacing the display assembly................................. 89

Procedure.................................................................89

Post-requisites........................................................... 89

37 Removing the display bezel...................................... 91

Prerequisites............................................................. 91

Procedure.................................................................92

38 Replacing the display bezel...................................... 93

Procedure.................................................................93

Post-requisites........................................................... 93

39 Removing the display panel...................................... 94

Prerequisites............................................................. 94

Procedure.................................................................95

40 Replacing the display panel...................................... 97

Procedure.................................................................97

Post-requisites........................................................... 97

41 Removing the camera............................................. 99

Prerequisites............................................................. 99

Procedure............................................................... 100

42 Replacing the camera............................................101

Procedure............................................................... 101

Post-requisites..........................................................101

43 Removing the display hinges................................... 103

Prerequisites............................................................103

Procedure............................................................... 104

3000 Series

7

44 Replacing the display hinges................................... 105

Procedure............................................................... 105

Post-requisites..........................................................105

45 Removing the palm rest......................................... 107

Prerequisites............................................................107

Procedure............................................................... 107

46 Replacing the palm rest......................................... 109

Procedure............................................................... 109

Post-requisites..........................................................109

47 Flashing the BIOS................................................. 110

48 Getting help and contacting Dell.............................. 111

Self-help resources.................................................... 111

Contacting Dell......................................................... 112

3000 Series

8

Before working inside your

computer

NOTE: The images in this document may differ from your computer depending

on the configuration you ordered.

Topics:

• Before you begin

• Safety instructions

• Recommended tools

Before you begin

1 Save and close all open files and exit all open applications.

2 Shut down your computer.

• Windows 10: Click or tap Start > Power > Shut down.

• Windows 8.1: On the Start screen, click or tap the power icon > Shut

down.

• Windows 7: Click or tap Start > Shut down.

NOTE: If you are using a different operating system, see the

documentation of your operating system for shut-down instructions.

3 Disconnect your computer and all attached devices from their electrical

outlets.

4 Disconnect all cables such as telephone cables, network cables and so on, from

your computer.

5 Disconnect all attached devices and peripherals, such as keyboard, mouse,

monitor, and so on, from your computer.

6 Remove any media card and optical disc from your computer, if applicable.

1

Before working inside your computer 9

Safety instructions

Use the following safety guidelines to protect your computer from potential damage

and ensure your personal safety.

WARNING: Before working inside your computer, read the safety information

that shipped with your computer. For more safety best practices, see the

Regulatory Compliance home page at www.dell.com/regulatory_compliance.

WARNING: Disconnect all power sources before opening the computer cover

or panels. After you finish working inside the computer, replace all covers,

panels, and screws before connecting to the power source.

CAUTION: To avoid damaging the computer, ensure that the work surface is

flat and clean.

CAUTION: To avoid damaging the components and cards, handle them by

their edges and avoid touching pins and contacts.

CAUTION: You should only perform troubleshooting and repairs as authorized

or directed by the Dell technical assistance team. Damage due to servicing

that is not authorized by Dell is not covered by your warranty. See the safety

instructions that shipped with the product or at www.dell.com/

regulatory_compliance.

CAUTION: Before touching anything inside your computer, ground yourself by

touching an unpainted metal surface, such as the metal at the back of the

computer. While you work, periodically touch an unpainted metal surface to

dissipate static electricity, which could harm internal components.

CAUTION: When you disconnect a cable, pull on its connector or on its pull

tab, not on the cable itself. Some cables have connectors with locking tabs or

thumb-screws that you must disengage before disconnecting the cable. When

disconnecting cables, keep them evenly aligned to avoid bending any

connector pins. When connecting cables, ensure that the ports and

connectors are correctly oriented and aligned.

CAUTION: Press and eject any installed card from the media-card reader.

Recommended tools

The procedures in this document may require the following tools:

Before working inside your computer 10

• Phillips screwdriver

• Plastic scribe

Before working inside your computer 11

After working inside your

computer

CAUTION: Leaving stray or loose screws inside your computer may severely

damage your computer.

1 Replace all screws and ensure that no stray screws remain inside your

computer.

2 Connect any external devices, peripherals, and cables you removed before

working on your computer.

3 Replace any media cards, discs, and any other parts that you removed before

working on your computer.

4 Connect your computer and all attached devices to their electrical outlets.

5 Turn on your computer.

2

After working inside your computer 12

Removing the battery

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your computer,

follow the instructions in After working inside your computer. For more

safety best practices, see the Regulatory Compliance home page at

www.dell.com/regulatory_compliance.

Topics:

• Procedure

Procedure

1 Close the display and turn the computer over.

2 Slide the battery-release latch to the unlocked position.

3 Lift the battery at an angle and remove the battery from the battery bay.

3

Removing the battery 13

1 battery 2 battery-release latch

4 Turn the computer over, open the display, and press the power button for five

seconds to ground the system board.

Removing the battery 14

Replacing the battery

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your computer,

follow the instructions in After working inside your computer. For more

safety best practices, see the Regulatory Compliance home page at

www.dell.com/regulatory_compliance.

Topics:

• Procedure

Procedure

1 Close the display and turn the computer over.

2 Place the battery in the battery bay and snap the battery into place.

NOTE: The battery-release latch returns to the locked position if the

battery is installed properly.

4

Replacing the battery 15

Removing the optical drive

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your computer,

follow the instructions in After working inside your computer. For more

safety best practices, see the Regulatory Compliance home page at

www.dell.com/regulatory_compliance.

Topics:

• Prerequisites

• Procedure

Prerequisites

Remove the battery.

Procedure

1 Remove the screw that secures the optical-drive assembly to the base cover.

2 Using a plastic scribe, push the optical-drive assembly out of the optical-drive

bay.

3 Pull the optical-drive assembly out of the optical-drive bay.

5

Removing the optical drive 16

1 optical-drive assembly 2 plastic scribe

3 screw 4 base cover

4 Carefully pry the optical-drive bezel off the optical drive.

5 Remove the screw that secures the optical-drive bracket to the optical drive.

NOTE: Note the orientation of the optical-drive bracket so that you can

replace it correctly.

Removing the optical drive 17

1 screw 2 optical drive

3 optical-drive bezel 4 optical-drive bracket

Removing the optical drive 18

Replacing the optical drive

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your computer,

follow the instructions in After working inside your computer. For more

safety best practices, see the Regulatory Compliance home page at

www.dell.com/regulatory_compliance.

Topics:

• Procedure

• Post-requisites

Procedure

1 Align the screw hole on the optical-drive bracket with the screw hole on the

optical drive.

NOTE: You must correctly align the optical-drive bracket to ensure that the

optical drive can be properly secured to the computer. For correct

orientation, see step 5 in “Removing the optical drive”.

2 Replace the screw that secures the optical-drive bracket to the optical drive.

3 Align the tabs on the optical-drive bezel with the slots on the optical drive and

snap the optical-drive bezel into place.

4 Slide the optical-drive assembly into the optical-drive bay.

5 Replace the screw that secures the optical-drive assembly to the base cover.

Post-requisites

Replace the battery.

6

Replacing the optical drive 19

Removing the keyboard

WARNING: Before working inside your computer, read the safety information

that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your computer,

follow the instructions in After working inside your computer. For more

safety best practices, see the Regulatory Compliance home page at

www.dell.com/regulatory_compliance.

Topics:

• Prerequisites

• Procedure

Prerequisites

Remove the battery.

Procedure

1 Turn the computer over and open the display.

2 Using a plastic scribe, gently release the tabs that secure the keyboard to the

palm-rest assembly.

3 Slide the keyboard up to release it from the slots on the palm-rest assembly.

4 Carefully turn the keyboard over and place it on the palm-rest assembly.

7

Removing the keyboard 20
